Festool CT 15 E HEPA User manual

en Original Instructions - Mobile dust extractors 6
fr Notice d’utilisation d’origine - Aspirateurs mobile 15
es Manual de instrucciones original - Sistemas móviles de aspiración 26
Read all instructions before using
Lire toutes les instructions avant de démarrer les travaux.
Lea y comprende todas las instrucciones antes de usar.
CT 15 E HEPA
Festool GmbH
Wertstraße 20
73240 Wendlingen
Germany
www.festoolusa.com
10237931 / A / 2019-10-08

1-1
1-2
1-3
1-4
1-5
1-6
1-7
1-8
1-9
1-10
1-11
1-12
1

Contents
1 Symbols.......................................................6
2 About this manual....................................... 6
3 Safety warnings...........................................7
4 Parts of the machine.................................10
5 Technical data........................................... 10
6 Intended use..............................................10
7 Operation...................................................10
8 Settings......................................................12
9 Working..................................................... 12
10 Service and maintenance..........................14
11 Environment..............................................14
1 Symbols
Symbol Significance
Warning of general danger
Risk of electric shock
Read operating instructions and
safety notices!
Wear a dust mask.
Tip or advice
Handling instruction
W watt
Symbol Significance
h hour
min minutes
s seconds
kg kilograms
Pa pascal
dB decibel
V volts
A amperes
Hz hertz
~ a.c. alternating current
d.c. direct current
n0no load speed
Class II construction
rpm
min-1 revolutions per minute
’’ inch
lbs. pound
diameter
Do not climb on the unit
2 About this manual
Save these instructions
It is important for you to read and understand
this manual. The information it contains relates
to protecting your safety and preventing prob
lems. The symbols below are used to help you
recognize this information.
DANGER Description of imminent hazard and failure to avoid hazard will result in death.
WARNING Description of hazard and possible resulting injures or death.
CAUTION Description of hazard and possible resulting injuries.
NOTICE Statement including nature of hazard and possible result.
HINT Indicates information, notes, or tips for improving your success using the tool.
English
6

3 Safety warnings
When using an electrical appliance, basis precautions should always be
followed, including the following:
READ ALL INSTRUCTIONS
BEFORE USING THIS DUST EXTRACTOR:
WARNING- To reduce the risk of fire, electric shock, or injury:
– Do not leave the dust extractor when plugged in. Unplug from outlet
when not in use and before servicing.
– Use indoors only.
– Do not allow to be used as a toy. Close attention is necessary when used
by or near children.
–Use only as describes in this manual. Use only manufacturer's recom-
mended attachments.
–Do not use with damaged cord or plug. If the dust extractor is not work-
ing as it should, has been dropped, damaged, left outdoors, or dropped
into water, return it to a service center.
– Do not pull or carry by cord, use cord as a handle, close a door on cord,
or pull cord around sharp edges or corners. Do not run dust extractor
over cord. Keep cord away from heated surfaces.
– Do not unplug by pulling on cord. To unplug, grasp the plug, not the
cord.
– Do not handle plug or dust extractor with wet hands.
– Do not put any object into openings. Do not use with any opening
blocked; keep free of dust, lint, hair, and anything that may reduce air
flow.
–Keep hair, loose clothing, fingers, and all parts of body away from open-
ings and moving parts.
– Turn off all controls before unplugging.
– Use extra care when cleaning on stairs.
–Do not use to pick up flammable or combustible liquids, such as gaso-
line, or use in areas where they may be present.
– Connect to a properly grounded outlet only. See Grounding instructions.
– Do not pick up anything that is burning or smoking, such as cigarettes,
matches, or hot ashes, hot chips or particles, sparks.
– Do not use without dust bag and/or filters in place.
SAVE THESE INSTRUCTIONS
English
7
IMPORTANT SAFETY INSTRUCTIONS

Polarization Instructions
To reduce the risk of electric shock, this vacuum cleaner has a polarized
plug (one blade is wider than the other). This plug will fit in a polarized out-
let only one way. If the plug does not fit fully in the outlet, reverse the plug.
If it still does not fit, contact a qualified electrician to install the proper out-
let. Do not change the plug in any way.
GROUNDING INSTRUCTIONS
This appliance must be grounded. If it should malfunction or breakdown,
grounding provides a path of least resistance for electric current to reduce
the risk of electric shock. This vacuum cleaner is equipped with a cord hav-
ing an equipment-grounding conductor and grounding plug. The plug must
be inserted into a appropriate outlet that is properly installed and ground-
ed in accordance with all local codes and ordinances.
WARNING
- Improper connection of the equipment grounding conductor can result in
a risk of electric shock. Check with a qualified electrician or service person
if you are in doubt as to whether the outlet is properly grounded. Do not
modify the plug provided with the dust extractor - if it will not fit the outlet,
have a proper outlet installed by a qualified electrician.
GROUNDED
OUTLET BOX
GROUNDED
PIN
GROUNDED
OUTLET
GROUNDING METHODS - SKETCH A
This appliance is for use on a nominal 120-V circuit and has a grounding
attachment plug that looks like the plug illustrated in sketch A in Figure
beside. Make sure that the appliance is connected to an outlet having the
same configuration as the plug. No adaptor should be used with this appli-
ance.
Further safety instructions
– This appliance must not be used by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge. Children need to be supervised to ensure they do not
play with the appliance.
– The mobile dust extractor must not be carried by the suction hose
mount [1-3].
English
8

CAUTION
This machine is for indoor use only.This ma-
chine shall be stored indoors only.
Health hazard by dust
WARNING!
various dust created by power sanding, sawing, grinding, drilling and other
construction activities contains chemicals known (to the State of California)
to cause cancer, birth defects or other reproductive harm. Some examples
of these chemicals are:
– lead from lead-based paints,
– crystalline silica from bricks and cement and other masonry products,
and
– arsenic and chromium from chemically treated lumber.
The risk from these exposures varies, depending on how often you do this
type of work. To reduce your exposure to these chemicals: work in a well
ventilated area, and work with approved safety equipment, such as dust
masks that are specially designed to filter out microscopic particles. Wash
hands after handling.
WARNING
TO REDUCE THE RISK OF INJURY, USER
MUST READ INSTRUCTION MANUAL.
English
9

4 Parts of the machine
[1-1] Electrical outlet module
[1-2] Cable and accessory holder
[1-3] Suction hose mount
[1-4] Handle
[1-5] Lock
[1-6] Filter drawer
[1-7] Locking clip
[1-8] Exhaust opening
[1-9] Dirt trap
[1-10] On/off switch
[1-11] MAN button
[1-12] Suction power adjustment
The specified illustrations appear at the begin
ning of the Operating Instructions.
5 Technical data
Mobile dust extractors
Power consumption 2.9 - 10 A (350 –1200 W)
Max. electrical outlet module connected load. 2 A (240 W)
Max. suction capacity (air), extractor/turbine 130 m³/h (4591 cu.ft./h) / 222 m³/h (7840
cu.ft./h)
Max. vacuum, turbine 24000 Pa
Filter surface area 3898 cm² (604.2 sq.in.)
Suction hose 27 mm x 3.5 m (1-1/16 x 11.5")
Mains power cable length 5.5 m (18 ft.)
Sound pressure level as per EN 60335-2-69/uncertain
ty K
70 dB(A)
Hand-arm vibration value as per EN 60335-6-69/
uncertainty K
< 2.5 m/s² / 1.5 m/s²
Degree of protection IP X4
Container capacity 15 l (4 gal.)
Dimensions LxWxH 470x320x435 mm (18.5 x 12.6 x 17.1 in.)
Weight 11.2 kg (24.7 lbs)
6 Intended use
Mobile dust extractor suitable for
– Extracting non-hazardous dust, dirt, sand
and chips,
– Extracting water,
– Increased loads during commercial use,
according to IEC/EN 60335-2-69.
This extractor has been tested in accordance
with EPA RRP. The HEPA Filter is tested and
certified in accordance with IEST RP-CC-001, to
filter and exhaust air particles to 0.3 microns
with at least 99.97 % efficiency with no bypass
leakage.
The mobile dust extractor is only suitable for
indoor use.
The user is liable for improper or non-in
tended use.
7 Operation
WARNING
Unauthorised voltage or frequency!
Risk of accidents
► Observe the specifications on the ma
chine’s name plate.
► Observe country-specific regulations.
7.1 Initial commissioning
► Insert the filter bag [2].
► Connect the suction hose[3].
English
