Fiat 500 Abarth Owner's manual

Page 53
FIAT
®
500
500
CHRYSLER GROUP FLEET
The newest addition to the Chrysler Group LLC
compact fleet family delivers a distinctively European
flair with decidedly American values. The flared
aerodynamic design and stylish available painted-
pocket 15- or 16-inch wheels show Continental
design cues, but the world-class 1.4-liter engine with
MultiAir technology helps reduce emissions, sips
gas, and delivers up to 31 city and 40 hwy mpg.
(8)
It also interfaces with advanced technology to
communicate ideal fuel consumption to the driver —
perfect for American distances. With technology that
starts with standard ParkSense and the multi-feature
Electronic Stability Control,
(3) the list of safety and
security features is both impressive and important. In
the final analysis, this compact urban vehicle gives
your fleet the complete package: economical and
robust performance, state-of-the-art electronics and
communications, and outstanding ride quality.
PRODUCT HIGHLIGHTS
 1.4L 16V MultiAir® I4 engine — Standard
 5-speed manual transmission — Standard
 6-speed automatic transmission — Available (non-turbo models only)
 Convertible soft top — Cabrio and Abarth® Cabrio only
 50/50 split-folding rear seatback with adjustable head
restraints(1) — Standard
 Blue&MeTM Hands-Free Communications with USB, Bluetooth®(7)
and iPod® interface — Standard
 TomTom® Navigation with Blue&Me Hands-Free Connect — Available
 SiriusXM Satellite Radio(6) — Available
 Power door locks/mirrors/windows — Standard
 Center console-mounted 12-volt power accessory outlet — Standard
 Power sunroof with one-touch open — Available
 Premium leather-wrapped steering wheel — Available
 Electronic Vehicle Information Center — Includes outside
temperature, trip data, average fuel, distance to empty, low fuel,
and service and range data — Standard
 Beats AudioTM Premium Sound System — Available
 Steering wheel-mounted audio controls — Standard
 eco:DriveTM — Lets the user track how efficiently he/she is
driving — Available (non-turbo models only)
SAFETY & SECURITY
 Front-seat Active head restraints(1) — Standard
 Dual advanced driver and front-passenger air
bags(2) — Standard
 Side-curtain air bags for outboard
occupants(2) — Standard
 Driver’s knee-blocker air bag(2) — Standard
 Front-seat-mounted side air bags(2) — Standard
 Electronic Stability Control(3) (ESC) includes
Traction Control and Brake Assist — Standard
 Antilock brake system (ABS) — Standard
 Security alarm — Available
 Anti-theft engine immobilizer system — Standard
 Tire Pressure Monitoring System — Standard
 ParkSense® Rear Park Assist System(5) — Standard
 Hill Start Assist — Standard

Page 54
BFLT14-011
(1)Always sit properly with the head restraint properly adjusted. Never place anything in front of the head
restraint. (2)Always sit properly in the seat with the seat belt fastened. Children 12 and under should always be
in a backseat correctly using an infant or child restraint system or with the seat belt positioned correctly for the
child’s age and weight. All occupants should always wear their lap and shoulder belts properly. (3)Always drive
carefully, consistent with conditions. Always wear your seat belt and obey traffic laws. (5)Always look before
proceeding. An electronic drive aid is not a substitute for conscientious driving. Always be aware of your
surroundings. (6)SiriusXM services require subscriptions, sold separately after the 12-month trial included with
the new vehicle purchase. If you decide to continue your service at the end of your trial subscription, the plan
you choose will automatically renew and bill at then-current rates until you call SiriusXM at 1-866-635-2349 to
cancel. See SiriusXM Customer Agreement for complete terms at www.siriusxm.com. All fees and programming
subject to change. Our satellite service is available only to those at least 18 and older in the 48 contiguous USA
and D.C. Our Sirius satellite service is also available in PR (with coverage limitations). Our Internet radio service
is available throughout our satellite service area and in AK and HI. © 2013 Sirius XM Radio Inc. Sirius, XM and
all related marks and logos are trademarks of Sirius XM Radio Inc. (7)Phone must support Bluetooth Phone Book
Access Profile (PBAP). (8)EPA estimates. Actual mileage may vary. Chrysler is a registered trademark of Chrysler
Group LLC. Chrysler Group LLC reserves the right to make changes at any time, without notice or obligation. All
product specifications are based on authorized information as of 5/10/13. Photographs are for
representational purposes only. FIAT 500 is a registered trademark and Eco:Drive is a trademark of Chrysler
Group LLC. The Bluetooth word, mark and logo are registered trademarks and are owned by Bluetooth SIG, Inc.
FIAT, Abarth and the scorpion design are registered trademarks used under license by Chrysler Group LLC. FIAT
and MultiAir are registered trademarks and Blue&Me is a trademark of Fiat S.p.A. TomTom is a registered
trademark of TomTom International BV. Bose is a registered trademark of Bose Corporation. iPod is a registered
trademark of Apple Inc.
FIAT
®
500
500
CHRYSLER GROUP FLEET
STANDARD ON ALL 2014 FIAT® 500 MODELS
 Active Head Restraints(1) — Front
 Air Bags
(2) — Driver knee blocker
— Dual advanced driver and front-passenger
— Front-seat-mounted
— Supplemental side-curtain air bag for driver, front-passenger and
rear-seat outboard occupants
 Air Filtration System
 AM/FM/CD MP3 Radio
 Antenna — Roof-mounted for Hatchback models, windshield-mounted for
Cabrio models
 Auxiliary Audio Input Jack
 Battery — Maintenance-free
 Brakes — Four-wheel disc ABS
 Carpet — Floor
 Child Seat Anchor System (LATCH)
 Console — Floor with cup holders
 Daytime Running Lamps — Default is “ON”; programmable through EVIC
 Defroster — Rear window
 Door Handles — Chrome
 Door Locks — Power
 Driver’s Easy-Entry Seat with Memory
 Driver’s-side Spotter Mirror
 Electronic Stability Control(3) (ESC) — Includes Traction Control and
Brake Assist
 Floor Mats — Front
 Fuel Tank — 10.5-gallon
 Glass — Tinted
 Headlamps — Bi-halogen projector
 Hill Start Assist
 Passenger Assist Handle — All models except Pop
 Power Outlet — 12-volt, center console-mounted
 Rear Cargo Shelf Panel
 Remote Entry
 Seat Belts — Front three-point with shoulder adjustment
— Rear, outboard and center three-point
 Seatback Pockets — Driver and Front-Passenger
 Seats — Manual driver’s seat
— Rear — 50/50 split-folding seatbacks
 Speed Control — Steering wheel-mounted controls
 Steering — Power, electric
 Steering Column — Tilt, manual
 Tachometer
 Tire Pressure Monitoring System
 Tire Repair Kit
 Windows — Power, driver and front-passenger one-touch down
 Windshield Wipers — Front, variable-intermittent
— Rear, washer/wiper (all models except Cabrio)
POWERTRAINS
2-door Hatchback 2-door Cabrio
Engines Transmissions
Pop Sport 500t Lounge Abarth® Pop Lounge Abarth
1.4L 16V MultiAir® I4
101 horsepower
98 lb-ft of torque
5-speed
Manual S S S S S
1.4L 16V MultiAir I4
101 horsepower
98 lb-ft of torque
6-speed
Automatic O O O O O
1.4L 16V MultiAir I4
Turbo 160 hp
170 lb-ft of torque
5-speed
Manual S S
1.4L 16V MultiAir I4
Turbo 135 hp
150 lb-ft of torque
5-speed
Manual S
DIMENSIONS*/SPECIFICATIONS
Exterior 2-door Hatchback 2-door Cabrio
Wheelbase 90.6 90.6
Track Front 55.4 55.4
Rear 55.0 55.0
Length 139.6 139.6
Height 59.8 59.8
Width 64.1 64.1
Tires (base model; set of 4) Standard P185/55R15 P185/55R15
Spare — Compact Available Available
Tire Service Kit Standard Standard
Cargo Capacity Normal cu. ft. seats up 9.5 5.4
Normal cu. ft. seats down 30.1 23.4
Seating Capacity Front/Rear 2/2 2/2
Fuel Capacity Gallons 10.5 10.5
EPA Fuel Economy (city/highway) Standard engine and transmission 31 city/40 highway 31 city/40 highway
Interior
Head Room Front 38.9 38.6
Rear 35.6 36.8
Shoulder Room Front 49.4 49.4
Rear 46.4 46.4
Hip Room Front 47.9 47.9
Rear 42.6 42.0
Leg Room Front 40.4 40.4
Rear 31.7 31.7
EPA Interior Volume Index (cu. ft.) 85.1 81.0
*Dimensions in inches unless otherwise noted.

Page 55
FIAT
®
500
500
CHRYSLER GROUP FLEET
2-door Hatchback 500 Cabrio 500
STANDARD FEATURES AND OPTIONS Pop Sport 500t Lounge Pop Lounge Abarth Abarth
Mechanical Features
Alternator — 120-amp • • • • • • • •
Battery — 500-amp, maintenance-free • • • • • • • •
Brakes — Antilock 4-wheel disc with Electronic Brake Distribution • • • •
— Antilock 4-wheel disc with Electronic Brake Distribution with Rosso (Red) front and rear calipers •
— Antilock 4-wheel performance disc with Electronic Brake Distribution with Rosso (Red) front and rear calipers • • •
Engine Block Heater O O O O O O • •
Engine Cover — Abarth logo • •
— Painted, with FIAT badging • • • • •
— Painted, with MultiAir® Turbo badging •
Exhaust Systems — Abarth-designed, dual outlet • •
— Bright stainless steel exhaust tips • • • • •
Fuel Filler System — Non-locking cap • • • • • • • •
Fuel Tank — 10.5-gallon • • • • • • • •
Speed Control — Located on steering wheel • • • • • • • •
Steering — Power electric • • • • • •
— Sport mode with unique calibration • • • • • • • •
Suspension — Performance-tuned • •
— Sport • •
— Sport-tuned shock absorbers, springs and performance-designed control arms •
— Touring • • • •
Exterior Features
Badging — 500 Cabrio, on B-pillars • •
— Abarth, on body-side • •
— Abarth, on front fascia and liftgate • •
— FIAT, on front fascia and liftgate • • • • • •
Belt Moldings — Black • • • • • •
— Chrome • •
Body Kits — Rocker cladding • • • •
Bodyside Molding — Body-color with integrated 500 badge • •

Page 56
FIAT
®
500
500
CHRYSLER GROUP FLEET
2-door Hatchback 500 Cabrio 500
Pop Sport 500t Lounge Pop Lounge Abarth Abarth
Door Handles — Chrome • • • • • • • •
Front and Rear Fascias — Abarth-designed front fascia: brake cooling ducts, intercooler “nostrils,” and
functional cooling behind Abarth badge • •
— Abarth-designed rear fascia: two-piece with body-color upper, honeycomb grille accents, and lower diffuser • •
— Body-color • • • • • • • •
— Body-color with chrome accents • •
— Front two-piece performance-designed with body-color surround, brake cooling ducts, intercooler
“nostrils” and honeycomb grilles •
— Rear two-piece performance-designed with body-color upper, and lower diffuser •
Glass — Tinted • • • • • • • •
Headlamps — Bi-halogen projector • • • • • • • •
— Daytime running lamps • • • • • • • •
— Fog lamps • • • • • •
Mirror Caps — Bianco (White) mirror cap with Bianco Abarth bodyside stripe (requires Grigio, Rosso or
Nero exterior paint) O O
— Grigio (Gray) mirror cap with Grigio Abarth bodyside stripe (requires Nero, Rosso or Bianco
exterior paint) O O
— Rosso (Red) mirror cap with Rosso Abarth bodyside stripe (requires Grigio, Bianco or Nero
exterior paint) O O
— Nero (Black) mirror cap with Nero Abarth bodyside stripe (requires Grigio, Rosso or Bianco
exterior paint) O O
Mirrors, Exterior — Manual folding, power, heated, body-color • • • • • •
— Manual folding, power, heated, chrome • •
Spoiler — Body-color • • • •
Tires — P185/55R15 All-Season • • • •
— P195/45R16 All-Season • •
— P195/45R16XL Pirelli® Cinturato All-Season Performance • •
— P205/40R17 Pirelli P-Zero Nero Three-Season Performance O O
— Compact spare O O O O O O
— Tire repair kit • • • • • • • •
Top — Power folding 3-position premium soft top • • •
Exterior Features, continued

Page 57
FIAT
®
500
500
CHRYSLER GROUP FLEET
2-door Hatchback 500 Cabrio 500
Pop Sport 500t Lounge Pop Lounge Abarth Abarth
Wheels — 15-inch steel with wheel covers • •
— 15-inch aluminum (Style 1) O O
— 15-inch aluminum (Style 2) •
— 15-inch aluminum (Style 3) Cabrio •
— 15-inch aluminum with premium finish O O
— 16-inch aluminum (with Mineral Gray painted pockets) •
— 16-inch aluminum (with Black painted pockets) •
— 16-inch Abarth-designed cast-aluminum with Dark Mineral Gray painted pockets ••
— 17-inch Abarth-designed forged aluminum, finished in Bianco O O
— 17-inch Abarth-designed forged aluminum, finished in Hyper Black O O
Windows — Power with driver and front-passenger one-touch down • • • • • • ••
Wipers — Two-speed variable intermittent • • • • • • ••
— Rear window washer/wiper • • • • •
Interior Features
Air Conditioning — Automatic temperature control (included in Comfort and Convenience Package) P P • • P P
— Manual single-zone • • • • ••
Air Filtration — Micron air filter • • • • • • • •
Antennas — Roof-mounted for Hatchback models; in windshield for Cabrio models • • • • • • • •
Assist Handle — Passenger-side • • • • • •
Cup Holders — Front: one large and two small • • • • • • • •
— Rear: two floor-mounted • • • • • • • •
Defroster — Rear window • • • • • • • •
Door Locks — Power • • • • • • • •
Electronic Vehicle Information Center (EVIC) — Includes trip odometer, outside temperature, average fuel
usage, distance to empty, low fuel and service data • • • • • • • •
Fixed Glass Roof •
Floor Mats — Front, with FIAT 500 logo • • • • • •
— Premium, embroidered with Abarth logo • •
Front Door Pockets • • • • • • • •
Interior Accents — Chrome door handles • • • • • • • •
— Instrument panel, exterior-color matched • • • • • • • •
Exterior Features, continued
