Fiat 500x User guide

The data contained in this publication is intended merely as a guide. FCA Italy S.p.A. reserves the right to modify
the models and versions described in this booklet at any time for technical and commercial reasons.
If you have any further questions please consult your FIAT dealer.
Printed in recycled paper without chlorine. OWNER HANDBOOK
FIAT500X
ENGLISH
Cop 500X LUM GB.qxp_500 UM ITA 02/08/16 12:16 Pagina 1

We really know your car because we invented, designed and built it: we really know every single detail.
At Fiat Service authorised workshops you can find technicians directly trained by us,
offering quality and professionalism for all service operations.
Fiat workshops are always close to you for the regular servicing operations, season checks
and practical recommendations by our experts.
With Original Parts distributed by MOPAR
®
, you maintain the reliability, comfort
and performance features that you bought your new car for over time.
Always ask for Genuine Parts for the components used on our cars; we recommend them because
they come from our steady commitment in research and development of highly innovative technologies.
For all these reasons: rely on Genuine Parts, because they are the only ones designed
by FCA for your car.
SAFETY:
BRAKING SYSTEM
ENVIRONMENT: PARTICULATE FILTERS,
CLIMATE CONTROL MAINTENANCE
COMFORT: SUSPENSION
AND WINDSCREEN WIPERS
PERFORMANCE: SPARK PLUGS,
INJECTORS AND BATTERIES
LINEACCESSORI
ROOF RACK BARS, WHEEL RIMS
WHY CHOOSING
GENUINE PARTS
This Owner Handbook is intended to show the vehicle's operating conditions.
For the enthusiast user who wants to have insights, curiosities and detailed information about the characteristics and functions
of the vehicle, Fiat gives the opportunity to consult a dedicated section which is available in electronic format.
ONLINE VEHICLE OWNER HANDBOOK
The following symbol is reported within the text of the Owner Handbook, next to the subjects for which details are provided.
Go to the www.mopar.eu/owner website and access your personal area.
The “Maintenance and care” page includes all the information about your vehicle and the link to access eLUM, where you will find
all the details of the Owner Handbook.
Alternatively, to access this information, go to the Internet website at http://aftersales.fiat.com/elum/.
The eLUM website is free and will allow you, among many other things, to easily consult the on-board documents
of all the other vehicles of the Group.
Have a nice reading and happy motoring!
Cop 500X LUM GB.qxp_500 UM ITA 02/08/16 12:16 Pagina 2

Dear Customer,
We would like to congratulate and thank you for choosing a Fiat.
We have written this handbook to help you get familiar with all the features of your car.
Here you will find information, advice and important warnings regarding use of your vehicle and how to achieve the best
performance from the technical features of your Fiat 500X.
You are advised to read it right through before taking to the road for the first time, to become familiar with the controls and
above all with those concerning brakes, steering and gearbox; at the same time, you can understand the car behaviour on
different road surfaces.
This document contains specifications, special procedures and essential information for caring for and maintaining your Fiat
500X over time, driving it safely and running it correctly.
After reading it, you are advised to keep the handbook inside the car, for an easy reference and for making sure it remains on
board the car should it be sold.
In the attached Warranty Booklet you will also find a description of the Services that Fiat offers to its customers, the Warranty
Certificate and the detail of the terms and conditions for maintaining its validity.
We are sure that these will help you to get in touch with and appreciate your new car and the service provided by the people at
Fiat.
Enjoy reading. Happy motoring!
This Owner Handbook describes all Fiat 500X versions. Options, equipment dedicated to specific markets or
versions are not explicitly indicated in the text: as a consequence, you should only consider the information which
is related to the trim level, engine and version that you have purchased. Any content introduced throughout the
production of the model, outside the specific request of options at the time of purchase, will be identified with the
wording (where provided).
The data contained in this publication should be understood as intended to guide you in the correct use of the car.
FCA Italy S.p.A. aims at a constant improvement of the vehicles produced. For this reason it reserves the right to
make changes to the model described for technical and/or commercial reasons.
For further information, contact a Fiat Dealership.

ESSENTIAL INFORMATION!
REFUELLING
Petrol engines: only refuel with unleaded petrol with octane rating (RON) not less than 95 in compliance with the European
specification EN228. Do not use petrol containing methanol or ethanol E85. Using these mixtures may cause misfiring and
driving issues, as well as damage fundamental components of the supply system. For further details on the use of the correct
fuel see the "Refuelling the car" paragraph in the "Starting and driving" chapter.
Diesel engines: refuel only with Diesel fuel motor vehicles conforming to the European specification EN590. The use of
other products or mixtures may damage the engine beyond repair and consequently invalidate the warranty, due to the
damage caused. For further details on the use of the correct fuel see the "Refuelling the vehicle" paragraph in the "Starting
and driving" chapter.
STARTING THE ENGINE
Versions with manual transmission (petrol engines): make sure that the parking brake is engaged; set the gear lever to
neutral, fully depress the clutch pedal without pressing the accelerator, then turn the ignition key to AVV or press the ignition
device button; release the key or button as soon as the engine has started.
Versions with manual gearbox (diesel engines): make sure that the handbrake is engaged; set the gear lever to neutral,
fully depress the clutch pedal without pressing the accelerator, then turn the ignition key to MAR and wait for the warning
light to switch off. Turn the ignition key to AVV or press the ignition device button; release the key or the button as soon as
the engine has started.
Versions with automatic transmission: make sure that the handbrake is engaged and that the gear lever is in P (Parking)
or N (Neutral), depress the brake pedal, without pressing the accelerator pedal, then turn the ignition key to AVV or press the
ignition device button; release the key or the button as soon as the engine has started.
PARKING ON FLAMMABLE MATERIAL
The catalytic converter develops high temperatures during operation. Do not park the car on grass, dry leaves, pine needles
or other flammable material: fire hazard.
RESPECTING THE ENVIRONMENT
The vehicle is fitted with a system that carries out a continuous diagnosis of the emission-related components in order to
help protect the environment.

ELECTRICAL ACCESSORIES
If, after buying the vehicle, you decide to add electrical accessories (with the risk of gradually draining the battery), contact a
Fiat Dealership. They can calculate the overall electrical requirement and check that the vehicle's electric system can support
the required load.
SCHEDULED SERVICING
Correct maintenance of the car is essential for ensuring that it maintains its performance and its safety features, its
environmental friendliness and low running costs for a long time to come.
"CYBERSECURITY" DEVICES
The car is equipped with security devices developed according to the technological standards currently applied in the
automotive industry to protect the onboard electronic systems from hacking attempts. The purpose of these security devices is
to minimise the risk of cyber-attacks or the installation of viruses or malware which could compromise the performance of the
car and/or allow stealing of personal data of the buyers and/or users and/or unauthorised dissemination of said information.
The car's purchaser must not remove, modify or tamper with these anti-hacking security devices. The Manufacturer will
therefore not be liable for negative consequences and/or damage to the vehicle and/or to the buyer and/or to third parties
deriving from the removal, modification or alteration of the security devices performed by the car's purchaser and/or user.

SYMBOLS
Some car components have coloured labels whose symbols indicate precautions to be observed when using this component.
A plate summarising these symbols can also be found under the bonnet.
1J0A2300C

CHANGES/ALTERATIONS TO THE CAR
IMPORTANT Any change or alteration of the car might seriously affect its safety and road holding, thus causing accidents, in
which the occupants could even be fatally injured.
IMPORTANT The use of these devices inside the passenger compartment (without an external aerial) may cause the electrical
systems to malfunction. This could compromise the safety of the vehicle in addition to constituting a potential hazard for
passengers' health.
IMPORTANT If mobile phones/laptops/smartphones/tablets are inside the car and/or close to the electronic key, reduced
performance of the Keyless Entry/Keyless Go system may occur.

USE OF THE OWNER HANDBOOK
OPERATING INSTRUCTIONS
Each time direction instructions (left/right or forwards/backwards) about the vehicle are given, these must be understood as
regarding an occupant in the driver's seat.
Special cases not complying with this rule will be specified as appropriate in the text.
The figures in the Owner Handbook are provided by way of example only: this might imply that some details of the image do not
correspond to the actual arrangement of your car.
In addition, the Handbook has been conceived considering vehicles with steering wheel on the left side; it is therefore possible
that on vehicles with steering wheel on the right side, the position or construction of some controls is not exactly mirror-like with
respect to the figure.
To identify the chapter with the information needed you can consult the index at the end of this Owner Handbook.
Chapters can be rapidly identified with dedicated graphic tabs, at the side of each odd page. A few pages further there is a
key for getting to know the chapter order and the relevant symbols in the tabs. There is in any case a textual indication of the
current chapter at the side of each even page.
IMPORTANT NOTES AND PRECAUTIONS
While reading this Owner Handbook you will find a series of WARNINGS to prevent procedures that could damage your
vehicle.
There are also PRECAUTIONS that must be carefully followed to prevent incorrect use of the components of the car, which
could cause accidents or injuries.
Therefore all WARNINGS and PRECAUTIONS must always be carefully followed.
IMPORTANT NOTES and PRECAUTIONS are recalled in the text with the following symbols:
personal safety;
vehicle safety;
environmental protection.
NOTE These symbols, when necessary, are indicated besides the title or at the end of the line and are followed by a number.
That number recalls the corresponding warning at the end of the relevant section.

GETTING TO KNOW YOUR CAR
KNOWING THE INSTRUMENT PANEL
SAFETY
STARTING AND DRIVING
IN AN EMERGENCY
SERVICING AND MAINTENANCE
TECHNICAL SPECIFICATIONS
MULTIMEDIA
CONTENTS

9
GETTING TO KNOW YOUR CAR
In-depth knowledge of your new
vehicle starts here .
The handbook that you are reading
simply and directly explains how it is
made and how it works.
That’s why we advise you to read
it seated comfortably on board, so
that you can see immediately what is
described here for yourself.
DASHBOARD .............................. 10
THE KEYS................................... 11
IGNITION DEVICE ........................ 12
FIAT CODE.................................. 13
ALARM SYSTEM.......................... 14
DOORS ...................................... 15
SEATS........................................ 18
HEAD RESTRAINTS ..................... 20
STEERING WHEEL....................... 21
REAR-VIEW MIRRORS ................. 22
EXTERIOR LIGHTS....................... 24
INTERIOR LIGHTS........................ 27
WINDSCREEN WIPER/REAR
WINDOW WIPER ......................... 28
CLIMATE CONTROL SYSTEM ....... 32
ELECTRIC WINDOWS .................. 37
ELECTRIC SUNROOF................... 38
BONNET..................................... 40
BOOT......................................... 41

GETTING TO KNOW YOUR CAR
10
DASHBOARD
2F1B0755
1. Adjustable side air diffusers 2. Left stalk: direction indicators, main beam headlights, flashing, Lane change function 3.
Instrument panel 4. Controls on the steering wheel: Cruise Control, Speed Limiter 5. Right stalk: windscreen wiper/washer,
rear window wiper/washer, rain sensor sensitivity level setting 6. Uconnect™ 7. Start&Stop, hazard lights, passenger airbag
LED status 8. Refrigerated upper storage compartment (for versions/markets, where provided) 9. Passenger front airbag 10.
Adjustable central air diffusers 11. Lower compartment box 12. Climate controls 13. Buttons on central console: seat heater,
Park Assist system, USB port (plus one second USB port, for versions/markets, where provided) 14. Knee bag 15. Ignition
device (key or button) 16. Driver front airbag 17. Steering wheel controls: display menu, trip computer, multimedia, telephone,
voice recognition 18. Control panel: light switch, headlight adjuster

11
THE KEYS
KEY WITH REMOTE
CONTROL
1)
1)
1)
Metal insert (A) fig. 3 of the key
operates:
the ignition device;
the driver's door lock.
3F1B0007C
Press button (B) to open/close the
metal insert.
2)
ELECTRONIC KEY
(versions with Keyless Go system)
On versions equipped with "Keyless
Go" system, the vehicle features an
electronic key (A) fig. 4, of which two
copies are provided.
4F1B0008C
Door and boot locking
Briefly press the or "FIAT" button:
locking of doors and luggage
compartment with roof light off and
single flash of direction indicators
(where provided).
Rapidly press the button twice
to open the luggage compartment
remotely (where provided).
The direction indicators will flash twice
to indicate that the boot has been
opened.
Lights switching on (key with
remote control only)
Press the button to remotely
control the switching on of the side and
main beam headlights, for a maximum
of 90 seconds.
Pressing button again, the lights
switched on previously will go off (if
the parking light function was already
active, it will remain so). If, when 90
seconds have passed, the button
is pressed, the main beam headlights
and the side/tail lights will stay on for a
further 30 seconds.
REQUEST FOR
ADDITIONAL KEYS
Should a new key with remote control
or a new electronic key be necessary,
go to a Fiat Dealership, taking an ID
document and the car ownership
documents.
WARNING
1) Do not swallow the battery. Danger of
chemical burns. The keys contain a small
battery. If the battery is swallowed, it can
cause severe internal burns in just 2 hours
and cause death. Keep new and used
batteries out of the reach of children. If
the battery compartment does not close
securely, discontinue use of the product
and keep it out of reach of children. If you
believe that batteries may have been
swallowed or inserted inside the body,
seek medical attention immediately. The
emergency key (where provided) must be
immediately inserted into the electronic key
to prevent easy access to the battery.
2) Button (B) should only be pressed when
the key is away from the body, in particular
from the eyes and from objects that can
be spoilt (e.g. clothes). Do not leave the
key unattended to avoid the button being
accidentally pressed while it is being
handled, e.g. by a child.

GETTING TO KNOW YOUR CAR
12
IMPORTANT
1) The electronic components inside
the key may be damaged if the key is
subjected to strong shocks. In order
to ensure complete efficiency of the
electronic devices inside the key, it should
never be exposed to direct sunlight.
IMPORTANT
1) Used batteries may be harmful to the
environment if not disposed of correctly.
They must be disposed of as specified by
law in the special containers or taken to a
Fiat Dealership, which will take care of their
disposal.
IGNITION DEVICE
Versions with key without remote
control
The key can be turned to three different
positions: fig. 5
STOP: engine off, key can be
removed, steering column locked (with
key removed). Some electrical devices
(e.g. central door locking system,
alarm, etc.) are still available;
MAR: driving position. All electrical
devices are available;
AVV: engine starting.
3) 4)
5F1B0642
Versions with electronic key
("Keyless Go" system)
To activate the starter switch fig. 6
the electronic key must be inside the
passenger compartment.
The ignition device activates also if the
electronic key is inside the boot or on
the rear shelf.
6F1B0014C
The ignition device has the following
possible states:
STOP: engine off, steering locked.
Some electrical devices (e.g. central
door locking system, alarm, etc.) are
still available;
MAR: driving position. All electrical
devices are available. This state can be
entered by pressing the ignition device
button once, without pressing the
brake pedal (versions with automatic
transmission) or the clutch pedal
(versions with manual gearbox);
AVV: engine starting.
NOTE The ignition device does NOT
activate if the electronic key is inside
the boot and this is open.
NOTE With the ignition device at
MAR, if 30 minutes pass with the
vehicle stationary (versions with manual
gearbox) or with the gear lever at
P (Park) (versions with automatic
transmission) and the engine stopped,
the ignition device will automatically
move to the STOP position.
NOTE With the engine running, it is
possible to go away from the car taking
the electronic key with you. The engine
will still be running. The vehicle will
indicate the absence of the key on
board when the door is closed.
NOTE If the device does switch off the
engine, refer to the “Display” paragraph
in the “Knowing the instrument panel”
chapter, where available, and contact
the Fiat Dealership as soon as possible.

13
For more information on the engine
start-up, see the description in the
"Starting the engine" paragraph, in the
"Starting and driving" chapter.
5) 6)
STEERING LOCK
Activation
Versions with key without remote
control : with the device at STOP,
remove the key and turn the steering
wheel until it locks.
IMPORTANT If the ignition key has
been moved from the MAR to the
STOP position, the steering lock
cannot engage until the key is removed
from the ignition device.
Versions with electronic key : the
steering lock engages when the driver
door is opened, with the ignition device
button at STOP and speed 3 km/h.
Turning off
Versions with key without remote
control : slightly moving the steering
wheel, turn the key to the MAR
position.
Versions with electronic key : the
steering lock disengages when the
ignition device is pressed and the
electronic key is recognised.
7) 8)
WARNING
3) If the ignition device has been tampered
with (e.g. attempted theft), have it checked
over by a Fiat Dealership before driving
again.
4) Always take the key with you when
you leave your car to prevent someone
from accidentally operating the controls.
Remember to engage the electric parking
brake. Never leave children unattended in
the car.
5) It is absolutely forbidden to carry out
any after-market operation involving
steering system or steering column
modifications (e.g.: installation of
anti-theft device) that could badly affect
performance and safety, invalidate
the warranty and also result in non-
compliance of the car with type-approval
requirements.
6) Never extract the mechanical key while
the car is moving. The steering wheel will
automatically lock as soon as it is turned.
This holds true for cars being towed as
well.
7) Before exiting the car, ALWAYS engage
the parking brake, steer the wheels,
engage the first gear if uphill and the
reverse if downhill. On versions with
automatic transmission, bring the gear
lever to P (Park) and press the ignition
device to bring it to STOP. If the vehicle is
parked on a steep slope, chock the wheels
with wedges or stones. When leaving the
car, always lock all the doors by pressing
the dedicated button on the handle (see
"Keyless Entry" in the paragraph "Doors").
8) For versions equipped with the Full
Keyless System, do not leave the
electronic key inside or near the car or in a
place accessible to children. Do not leave
the vehicle with the ignition device in MAR
position. A child could activate the electric
window winders, other controls or even
start the vehicle.
FIAT CODE
The Fiat Code system prevents
unauthorised use of the car, disabling
engine starting.
The system does not need to be
enabled/activated: operation is
automatic, regardless of the fact that
the vehicle's doors are locked or
unlocked.
When the ignition device is set to MAR,
the Fiat Code system identifies the
code transmitted by the key. If the
code is recognised as valid, the Fiat
Code system enables engine starting.
When the ignition device is brought
back to STOP, the Fiat Code system
deactivates the control unit controlling
the engine, thus preventing its starting.
For the correct engine starting
procedures, see the instructions in
the "Starting the engine" paragraph,
"Starting and driving" chapter.

GETTING TO KNOW YOUR CAR
14
IRREGULAR OPERATION
If, during starting, the key code is not
correctly recognised, the icon is
displayed on the instrument panel (see
the instructions in the "Warning lights
and messages" paragraph, "Knowing
the instrument panel" chapter). This
condition leads to the engine switching
off after 2 seconds. In this case, bring
the ignition device to STOP and then
to MAR; if it is still blocked, try with
the other keys provided. If it is still not
possible to start the engine, contact a
Fiat Dealership.
If the icon is displayed while driving,
this means that the system is running
a self-diagnosis (e.g. due to a voltage
drop). If the display persists, contact a
Fiat Dealership.
ALARM SYSTEM
Activation of the alarm triggers the
acoustic warning and the direction
indicators.
IMPORTANT The alarm is adapted
by the Manufacturer to meet the
requirements of the various countries
where the car is marketed.
SWITCHING ON THE
ALARM
(where provided)
With the doors, bonnet and tailgate
closed and the ignition device turned
to STOP, point the key with remote
control or electronic key towards the
vehicle and press and release the
"FIAT" button.
For versions with electronic key, the
alarm can also be armed by pressing
the "door lock" button, located on
the door external handle. For more
information, refer to the Keyless Entry
paragraph a few pages further on.
The system emits a visual and acoustic
warning (where provided) and enables
door locking.
With the alarm on, warning light A fig. 7
flashes on the instrument panel.
7F1B0643
The activation of the alarm is preceded
by a self-diagnosis stage: if a fault is
detected, the system emits a further
acoustic warning.
Locking the doors without engaging
the alarm is also always possible by
locking the doors by putting the metal
insert of the key inside the driver side
door lock.
IMPORTANT If the doors are unlocked
by putting the metal insert into the
driver side door lock, the alarm, if
previously enabled, is not disabled. It
will be possible to disable the alarm by
turning the starter switch to MAR, or
by pressing button on the remote
control.
TURNING THE ALARM
OFF
IMPORTANT Activating the central
opening using the metal insert of the
key will not turn the alarm off.

15
DISARMING THE ALARM
To completely deactivate the alarm
(e.g. during a long period of car
inactivity), close the doors by turning
the metal insert of the key with remote
control in the door lock.
IMPORTANT If the batteries of the key
with the remote control run out or the
system fails, the alarm can be switched
off by placing the starter switch in the
MAR position.
DOORS
LOCKING/UNLOCKING
DOORS FROM THE
INSIDE
Central locking/unlocking
If all doors are closed properly, they
will automatically be locked once
the vehicle has exceeded 20 km/h
("Autoclose" function). This function
can also be disabled using the menu
on the instrument panel.
To lock the doors, press the button
located on the front door trim fig. 8. To
unlock the doors, press the button.
8F1B0024C
Manual locking/unlocking
Doors can also be locked/unlocked by
turning device (A) fig. 9 integral to the
front door inner handles.
9F1B0017C
Operating the rear door device only
locks the door concerned.
Position 1: door unlocked
Position 2 : door locked.
Where the function is present,
operating the interior handle of one of
the two front doors will unlock all the
doors and the luggage compartment
tailgate according to the mode set
using the menu on the display or on the
Uconnect™ system and will open only
the concerned door.
LOCKING/UNLOCKING
DOORS FROM THE
OUTSIDE
Locking from the outside
With the doors closed, press the
"FIAT" button on the key or fit and
then turn its metal insert in the driver's
door lock.
2)
Where the automatic mirror folding and
opening function is present, the exterior
rear-view mirrors will be automatically
folded when the central door locking
system is operated from the outside.
Door unlocking from the outside
Press the button on the key or turn
its metal insert in the driver's door lock.
Where the automatic mirror opening
function is present, the exterior
rear-view mirrors will be automatically
returned to driving position when the
central door locking system is operated
from the outside.

GETTING TO KNOW YOUR CAR
16
The Keyless Entry system can identify
the electronic key near the doors and
tailgate.
The system lets you lock/unlock the
doors (or the tailgate) without having to
press any button on the electronic key.
If the system identifies that the
electronic key detected outside the
vehicle is valid, the owner of the key
can simply grasp one of the front
handles to deactivate the alarm and
unlock the door and tailgate opening
mechanism.
Where the function is provided,
grasping the handle of the driver's
door unlocks the driver's side door
or all doors depending on the mode
set using the display menu or the
Uconnect™ system.
Door locking
To lock the doors, proceed as follows:
make sure that you have the
electronic key with you and are near
the driver or passenger door handle;
press the "door locking" button (A)
fig. 10 on the handle: this will lock all
doors and the luggage compartment
tailgate. Locking the doors will also
activate the alarm (where provided).
10 F1B0063C
IMPORTANT After pressing the "door
locking" button, you need to wait
2 seconds before the doors can
be unlocked again using the door
handle. It is therefore possible to
check whether the vehicle is locked
correctly by pulling the door handle
within 2 seconds. The doors will not be
unlocked again.
IMPORTANT Do not simultaneously
lock and unlock by pulling the handle
(see fig. 11).
11 F1B0251C
Driver side door emergency
opening
If the electronic key does not work
(e.g. because its battery is flat), the
emergency metal insert inside the key
can anyway be used to operate the
lock, unlocking the driver side door.
To extract the metal insert, proceed as
follows:
use the device (A) fig. 12 and remove
the metal insert (B) pulling it outwards;
12 F1B0020C
insert the metal insert in the driver
side door lock and turn it to unlock the
door.
Locking/unlocking the tailgate
Approaching the tailgate with a valid
electronic key, press the opening
button (A) fig. 13 underneath the
tailgate handle to unlock the tailgate.
NOTE If there is an alarm system, the
latter will be temporarily disabled only
for the luggage compartment area.
KEYLESS ENTRY
(where provided)
3)

17
After closing the luggage compartment,
the alarm system will be reactivated
again.
WARNING With the car locked, if the
tailgate only is unlocked, if a key is
detected inside when it is locked, the
tailgate will unlock again and the lights
flash twice.
13 F1B0757
The tailgate can be locked by pressing
the button on the electronic key or
on the inner door panel.
NOTE Luggage compartment opening
is disabled while the car is moving.
While travelling, if the tailgate is closed
correctly, it will be locked automatically
when the car speed is faster than
20 km/h together with the doors
("Autoclose" function). This function
can also be disabled using the menu
on the instrument panel.
DEAD LOCK DEVICE
(where provided)
9)
This safety device inhibits the operation
of the interior door handles and the
door locking/unlocking button.
Activating the device
The device is activated on all doors by
pressing the "FIAT" button on the
key with remote control or for vehicles
with Keyless Entry, by pressing the
unlock button on the exterior door
handle of the car.
Deactivating the device
The device disengages automatically:
when the doors are unlocked
(pressing button on the key with
remote control);
when the ignition device is set to
MAR;
when one of the front handles is
gripped on vehicles equipped with
Keyless Entry.
CHILD SAFETY DEVICE
10) 11)
This system prevents the rear doors
from being opened from the inside.
This device fig. 14 can be engaged only
with the doors open:
14 F1B0023C
position : device engaged (door
locked);
position : device not engaged
(door may be opened from the inside).
The device remains engaged even if the
doors are electrically unlocked.
The device remains engaged even if the
doors are electrically unlocked.
IMPORTANT The rear doors cannot be
opened from the inside when the child
safety device is engaged.
WARNING
9) Once the Dead Lock device is engaged,
it is impossible to open the doors from
inside the car. Therefore, before getting
out of the car check that there is no-one
left on board.
10) NEVER leave children unattended
inside the car, let alone leave the car with
the doors unlocked in a place that children
can access easily. Children may seriously,

GETTING TO KNOW YOUR CAR
18
or even fatally, injure themselves. Also
ensure that children do not inadvertently
operate the electric parking brake, the
brake pedal or the automatic transmission
lever.
11) Always use this device when carrying
children. After engaging the device on
both rear doors, check that it is actually
engaged by trying to open a door with the
internal handle.
IMPORTANT
2) Make sure to take the key with you
once a door or the tailgate is locked, to
prevent locking the same key inside the
car. If the key is locked inside, it can only
be retrieved by using the second key
provided.
3) The operation of the recognition system
depends on various factors, such as,
for example, any electromagnetic wave
interference from external sources (e.g.
mobile phones), the charge of the battery
in the electronic key and the presence of
metal objects near the key or the car. In
these cases it is still possible to unlock
the doors by using the metal insert in the
electronic key (see description on the
following pages).
SEATS
FRONT SEATS WITH
MANUAL ADJUSTMENT
12)
4)
Longitudinal adjustment
Lift lever (A) fig. 15 and push the seat
forwards or backwards.
13)
15 F1B0019C
IMPORTANT Make the adjustment
while sitting on the seat involved (driver
side or passenger side).
Height adjustment
(where provided)
Move lever (B) upwards or downwards
to achieve the required height.
IMPORTANT Make the adjustment
while sitting on the seat involved (driver
side or passenger side).
Backrest angle adjustment
Use lever (C ) to adjust the backrest
angle, accompanying it with the
movement of the torso (operate the
lever until the desired position is
reached, then release it).
Electric lumbar adjustment
When the starter switch is at MAR,
press button (A) fig. 16 to adjust the
lumbar area support for maximum
comfort while driving.
16 F1B0016C
ELECTRICALLY
ADJUSTABLE FRONT
SEATS
(where provided)
5)
The buttons for electrical seat
adjustment are on the outer side of the
seat, near the floor.
These buttons can be used to adjust
the height, the lengthwise position in
