Fiat Doblo User manual

1Nero 603 83 540 Connect DOBLO GB
The vehicle is fitted with the infotelematic CONNECT system designed in accordance with the specific fea-
tures of the passenger compartment and with a personalised design that blends with the styling of the dashboard.
The system is installed in a user-friendly position for the driver and the graphics on the front panel make it
easy to quickly locate the controls which facilitates the use of them.
The pages that follow contain the instructions for use, which we advise you to read carefully and always keep
within reach (e.g. in the glove compartment).
So, enjoy your reading and have a good journey.
IMPORTANT For the navigation system only use the original CD provided with the vehicle or in any case
other CDs of the same brand.
001-023 Doblo Connect GB 15-06-2007 10:32 Pagina 1

2Nero 603 83 540 Connect DOBLO GB
001-023 Doblo Connect GB 15-06-2007 10:32 Pagina 2

ADVICE, CONTROLS AND GENERAL
INFORMATION .......................................................... 7
ADVICE .............................................................................. 7
Road safety ........................................................................ 7
Reception conditions ....................................................... 7
Care and maintenance ..................................................... 7
System software updating ............................................... 8
BUTTONS AND SELECTORS .......................... 10-11-12
GENERAL INFORMATION .......................................... 13
Important notes for use
and road safety .................................................................. 13
System power on ............................................................. 13
System power off ............................................................. 14
PROTECTION AGAINST THEFT ............................... 15
MAIN MODE .................................................................... 16
Standard information ....................................................... 16
SETUP FUNCTION ......................................................... 17
Video ................................................................................... 18
Power off ............................................................................ 19
Serial - modem (data interface) ..................................... 19
Fleet management ............................................................ 20
AUDIO ............................................................................. 24
SCREEN OPTIONS AND FUNCTIONS ................... 24
RADIO MODE ................................................................. 25
Manual tuning .................................................................... 26
Automatic tuning .............................................................. 27
Manual station storage .................................................... 27
Listening to stored stations ............................................ 27
AUDIO SETUP function (audio adjustments) ............ 28
TA function (traffic information) ................................... 28
AF function (seeking alternative frequencies) ............ 30
RDS function ..................................................................... 30
CONNECT Nav
3Nero 603 83 540 Connect DOBLO GB
CONNECT Nav
3
001-023 Doblo Connect GB 15-06-2007 10:32 Pagina 3

4Nero 603 83 540 Connect DOBLO GB
CONNECT Nav
4
PTY-PROG. TYPE function
(choosing a type of programme) ................................... 31
AUTOSTORE function
(automatic station storage) ............................................ 32
BAND SCAN function .................................................... 33
PRESET SCAN function .................................................. 33
STATION LIST function ................................................. 33
RADIO SETUP function .................................................. 33
LOC-DX function
(tuner sensitivity adjustment) ........................................ 34
MONO/STEREO function .............................................. 34
REGIONAL function ........................................................ 34
NEWS function ................................................................. 35
CD MODE ......................................................................... 35
CD SHUFFLE function (random playing) .................... 36
CD TA function (traffic information) ........................... 36
CD REPEAT function ...................................................... 37
CD PROG function ......................................................... 37
CD SCAN function .......................................................... 37
CD COMPRESSION function ....................................... 37
CD SETUP menu .............................................................. 38
AUDIO SETUP function (audio adjustments) ............ 41
AUDIO SETTINGS .......................................................... 42
Info ....................................................................................... 42
Bass ...................................................................................... 42
Treble .................................................................................. 43
Loudness ............................................................................ 43
Equalizer ............................................................................. 43
Manual equalizer ............................................................... 44
Auto. vol. cont. ................................................................. 45
Balance/fader ..................................................................... 45
Autoclip detect ................................................................. 46
Max. vol. at. on .................................................................. 46
MP3 MODE ....................................................................... 47
Main screen options and functions ............................... 48
AUDIO SETUP function (audio adjustments) ............ 49
DEFINE PLAYLIST function ........................................... 49
PLAYLIST function ........................................................... 49
VIEW PLAYLIST function ............................................... 50
COMPRESSION function ............................................... 50
TA function ........................................................................ 50
SCAN function .................................................................. 50
SHUFFLE function ............................................................ 50
REPEAT function .............................................................. 51
001-023 Doblo Connect GB 15-06-2007 10:32 Pagina 4

5Nero 603 83 540 Connect DOBLO GB
CONNECT Nav
5
Playing the PLAYLIST ...................................................... 51
Playing MP3 CD ................................................................ 51
Define PLAYLIST .............................................................. 52
PLAYLIST ........................................................................... 53
View PLAYLIST ................................................................. 53
CELLULAR TELEPHONE (TEL) ........................ 54
GENERAL INFORMATION .......................................... 54
PRELIMINARY OPERATIONS ...................................... 55
Entering and exiting the telephone mode ................... 55
Inserting the telephone card .......................................... 57
Entering the PIN code ..................................................... 58
Incoming calls .................................................................... 58
Outgoing calls .................................................................... 59
Dialling a service number ............................................... 59
Frequent numbers function ............................................ 60
Last calls received function ............................................ 62
Last numbers called function ......................................... 62
Directory function ........................................................... 63
Select ................................................................................... 63
Add ...................................................................................... 66
Play voice directory ......................................................... 69
Delete voice directory .................................................... 69
WAP function ................................................................... 69
VOICE MEMO function .................................................. 75
MESSAGES SMS - (Short Message Service) ................ 77
Dial ...................................................................................... 77
Select ................................................................................... 79
Center number ................................................................. 80
Phone option function ..................................................... 81
Phone settings function ................................................... 83
NAVIGATOR (NAV) ................................................. 85
GENERAL INFORMATION .......................................... 85
NAVIGATION CD ROM PLAYER .............................. 87
MAIN NAVIGATION SCREEN .................................... 88
SELECT POINT ................................................................ 89
Address ............................................................................... 90
Points of interest .............................................................. 93
Last destinations ............................................................... 95
Directory ............................................................................ 96
RDS-TMC .......................................................................... 97
001-023 Doblo Connect GB 15-06-2007 10:32 Pagina 5

6Nero 603 83 540 Connect DOBLO GB
CONNECT Nav
6
Home 1 – Home 2 ........................................................... 99
Info GPS .............................................................................. 100
Detour ................................................................................ 101
Set route ............................................................................ 102
Destination and route ..................................................... 103
Voice directory ................................................................. 103
ON-BOARD COMPUTER (TRIP) ....................... 104
GENERAL INFORMATION .......................................... 104
Time to destination .......................................................... 104
Distance to destination ................................................... 105
Speed limit ......................................................................... 105
Distance traveled .............................................................. 105
Average speed ................................................................... 105
Trip time ............................................................................ 105
TRIP SUBMENU ............................................................... 106
General Trip ...................................................................... 106
Trip: Setup ......................................................................... 106
Trip: Speed ......................................................................... 107
VOICE RECOGNITION .......................................... 110
GENERAL INFORMATION .......................................... 110
VOICE COMMANDS ..................................................... 111
Keywords – summary ..................................................... 111
VOICE COMMAND EXAMPLES ................................. 117
INFORMATION AND ASISTANCE
SERVICES ....................................................................... 126
Infomobility function ........................................................ 126
Medical advice function ................................................... 130
Roadside assist. function ................................................. 130
Personal number function .............................................. 131
Emergency 112 function ................................................. 131
Settings function ............................................................... 131
Calls for medical advice and
roadside assistance ........................................................... 133
FAULTS ........................................................................... 134
Internal faults ..................................................................... 134
Overtemperature faults .................................................. 134
001-023 Doblo Connect GB 15-06-2007 10:32 Pagina 6

7Nero 603 83 540 Connect DOBLO GB
CONNECT Nav
7
ADVICE
ROAD SAFETY
You are recommended to learn how
to use the different functions of the
system and in particular of the radio
(e.g. storing stations) before starting
to drive.
IMPORTANT When receiving
traffic information the volume might
be higher than normal.
CARE AND MAINTENANCE
The structure of the system ensures
long years of operation with no need
for particular maintenance. In the
event of a fault, contact Fiat Deal-
ership.
Some care must however be taken
to ensure the complete efficiency of
the system:
– the monitor is sensitive to scratch-
ing, liquid detergents and UV rays;
– liquids that penetrate inside may
damage the device irreparably.
Clean the front panel and display on-
ly using a soft, dry antistatic cloth.
Cleaning and polishing products may
damage the surface.
RECEPTION CONDITIONS
Reception conditions change con-
stantly when driving. Reception can be
disturbed by the presence of moun-
tains, buildings, bridges particularly
when far away from the broadcaster
received.
Be careful not to knock
the display with pointed or
hard objects and avoid
touching with the hands. Do not
press on the display when cleaning.
A
AD DV VI IC CE E, ,C CO ON NT TR RO OL LS SA AN ND D
G
GE EN NE ERR RA AL LI IN NF FO OR RM MA AT TI IO ON N
Too high a volume when
driving can put the driver’s
life at risk and that of other people.
Therefore the volume should al-
ways be adjusted in such a way that
it is always possible to hear the
noises of the surrounding environ-
ment (e.g. horns, ambulance, police
sirens, etc.).
WARNING
001-023 Doblo Connect GB 15-06-2007 10:32 Pagina 7

8Nero 603 83 540 Connect DOBLO GB
CONNECT Nav
8
– Never use chemical products for
cleaning (e.g. spray cans, antistatics or
thinners) as they might damage the
surface of Compact Discs.
– After listening to them put Com-
pact Discs back in their boxes to avoid
marking or scoring which could cause
skipping when playing.
– Do not expose Compact Discs to
direct sunlight, high temperatures or
damp for prolonged lengths of time to
prevent them from bending.
– Do not stick labels or write on the
recorded surface of Compact Discs.
To remove a Compact Disc from its
container, press on the centre and
raise the disc holding carefully from
the edges.
Proper way to hold
the compact disc
Removing the disc
IMPORTANT NOTES
– In the event of a fault the CON-
NECT system should be checked and
repaired only at Fiat Dealership.
– In case of particularly low temper-
atures the display might take a certain
time to reach the optimum brightness.
– In the case of prolonged parking
with high outside temperature, the au-
tomatic thermal protection of the sys-
tem may come into action suspend-
ing operation until the passenger com-
partment temperature falls to accept-
able levels.
SYSTEM SOFTWARE
UPDATING
When new versions are available for
the software of the navigation module,
the system can be updated to benefit
of the improvements made for con-
trolling certain functions.
Software updating is to be seen to by
specialised staff of the Fiat Dealer-
ship.
COMPACT DISC
If a Compact Disc is used on the
sound system, remember that the
presence of dirt or marks on Compact
Discs may cause skipping when play-
ing and poor sound quality. The same
happens if Compact Discs are bent by
accident.
IMPORTANT Never use 8 mm au-
dio or MP3 CDs, even with the spe-
cific adapter, since this format will
damage the system.
To obtain optimum playing condi-
tions we give the following advice:
– Only use Audio Compact Discs
with the brand:
– Carefully clean all Compact Discs
of any fingerprints and dust using a soft
cloth. Support Compact Discs on the
edges and clean from the centre out-
wards. Always hold a Compact Disc by the
edge. Never touch the surface.
001-023 Doblo Connect GB 15-06-2007 10:32 Pagina 8

9Nero 603 83 540 Connect DOBLO GB
CONNECT Nav
9
New discs may be rough around the
edges. When using these discs the
player might not work or the sound
might skip. To remove roughness
from the edge of a disc use a ball-point
pen, etc.
No
Ball-point pen
Roughness
Do not use solvents such as stain re-
movers, antistatic sprays or thinners
in commerce for cleaning Compact
Discs.
IMPORTANT Do not use the pro-
tective sheets for CDs in commerce
or discs with stabilisers, etc. as they
might get stuck in the internal mech-
anism and damage the disc.
Notes about Compact Discs
Do not stick labels on the surfaces of
a Compact Disc or write on the sur-
face with pens or pencils.
No
No
Do not expose Compact Discs to di-
rect sunlight or any other source of
heat.
Do not use highly scratched, cracked
or distorted Compact Discs. This
could damage the player or prevent
it from working properly.
No
No
To remove fingerprints and dust, use
a soft cloth starting from the centre of
the Compact Disc towards the cir-
cumference.
001-023 Doblo Connect GB 15-06-2007 10:32 Pagina 9
