Fiat Connect Nav+ User manual

The car is fitted with the infotelematic CONNECT system designed in accordance with the specific features of
the passenger compartment and with a personalised design that blends with the styling of the dashboard.
The system is installed in a user-friendly position for the driver and the graphics on the front panel make it
easy to quickly locate the controls which facilitates the use of them.
To increase safety against theft the set is fitted with a protection system that allows the use of it only on the
car on which it was fitted originally.
The pages that follow contain the instructions for use which we advise you to read carefully and always keep
within reach (e.g. in the glove compartment).
So enjoy your reading and have a good journey.
IMPORTANT For the navigation system only use the original CD provided with the car or in any case other
CDs of the same brand.

3
CONNECT Nav+
ADVICE, CONTROLS AND GENERAL INFORMATION ... 5
ADVICE ............................................................................................................ 5
CONTROLS .................................................................................................... 10
Front panel controls ...................................................................................... 10
Steering wheel controls ................................................................................ 14
GENERAL INFORMATION ........................................................................ 15
System power on ............................................................................................ 16
System power off ............................................................................................ 17
Main mode ........................................................................................................ 18
Protection against theft ................................................................................. 19
AUDIO ............................................................................................................ 21
SCREEN OPTIONS AND FUNCTIONS ................................................ 21
RADIO MODE ................................................................................................ 22
Traffic information .......................................................................................... 24
Seeking alternative frequencies ................................................................... 26
“Frequency” function ..................................................................................... 26
Autostore function ......................................................................................... 27
Band Scan function ......................................................................................... 28
Preset Scan function ...................................................................................... 28
Radio setup function ...................................................................................... 29
LOC/DX function ........................................................................................... 29
Mono/Stereo function ................................................................................... 29
PTY-Prog. Type function .............................................................................. 30
RDS function .................................................................................................... 31
Regional function ............................................................................................ 31
Audio setup function ..................................................................................... 32
Bass .................................................................................................................... 33
Treble ................................................................................................................ 33
Balance/Fader function .................................................................................. 33
Loudness ........................................................................................................... 33
Equalizer ............................................................................................................ 34
Auto Vol. Cont. function .............................................................................. 35
CD MODE ....................................................................................................... 37
Shuffle function ................................................................................................ 38
Scan function .................................................................................................... 39
Compression function ................................................................................... 39
CD setup function .......................................................................................... 39
Audio setup function ..................................................................................... 42
CD-CHANGER MODE ................................................................................ 42
Shuffle function ................................................................................................ 44
Prog function ................................................................................................... 45
Scan function .................................................................................................... 45
Compression function ................................................................................... 45
CDC setup function ....................................................................................... 45
Audio setup function ..................................................................................... 47
MP3 MODE ...................................................................................................... 47
Main screen options and functions.............................................................. 49
Audio setup function ..................................................................................... 50
Direct selection function .............................................................................. 50
Define Playlist function .................................................................................. 50
Playlist function ............................................................................................... 50
Compression function ................................................................................... 51
Scan function .................................................................................................... 51
Shuffle function ................................................................................................ 51
Playing the Playlist ........................................................................................... 52
Playing MP3 CD .............................................................................................. 53
Define Playlist function .................................................................................. 54
CELLULAR TELEPHONE WITH VOICE COMMANDS ... 60
GENERAL INFORMATION ........................................................................ 60
PRELIMINARY OPERATIONS ................................................................... 61
Entering and exiting the telephone mode ................................................ 61
Inserting the telephone card ........................................................................ 63
Entering the PIN code ................................................................................... 64
INCOMING CALLS ...................................................................................... 65
OUTGOING CALLS ..................................................................................... 65
DIALLING A SERVICE NUMBER .............................................................. 66
Frequent Numbers function ........................................................................ 67
Ph/Book function ............................................................................................ 68
Message function.............................................................................................. 75
LAST CALL function ...................................................................................... 79

4
Incoming calls function ................................................................................... 79
Outgoing calls function ................................................................................. 80
Memo function ................................................................................................ 81
WAP function .................................................................................................. 82
Settings function .............................................................................................. 87
Options function ............................................................................................. 88
NAVIGATOR .............................................................................................. 92
GENERAL INFORMATION ........................................................................ 92
SCREEN OPTIONS AND FUNCTIONS ................................................ 93
GRAPHIC INSTRUCTIONS ....................................................................... 94
VOICE INSTRUCTIONS ............................................................................. 94
NAVIGATION CD-ROM PLAYER ........................................................... 95
MAIN SCREEN ............................................................................................... 96
OTHER MENUS ............................................................................................. 99
SELECT ADDRESS ......................................................................................... 99
Address ............................................................................................................. 100
Points of interest ............................................................................................ 103
Last destinations ............................................................................................. 105
Bookmarks......................................................................................................... 105
RDS-TMC ......................................................................................................... 106
Dest 1 – Dest 2 .............................................................................................. 108
VISUALIZATION ........................................................................................... 109
DELETE DESTINATION .............................................................................. 109
VOICE BOOKMARKS .................................................................................. 111
MAP PREFERENCES .................................................................................... 113
ROUTE OPTIONS ......................................................................................... 115
ON-BOARD COMPUTER (TRIP) .................................................... 116
GENERAL INFORMATION ........................................................................ 116
GENERAL TRIP and TRIP B function ........................................................ 116
ETA (Estimated Time of Arrival) ................................................................ 117
Distance to destination ................................................................................. 117
Speed limit ........................................................................................................ 117
Km/miles to empty ......................................................................................... 117
Instant consumption ...................................................................................... 118
Trip time ........................................................................................................... 118
Distance traveled ............................................................................................ 118
Average speed ................................................................................................. 118
Average consumption .................................................................................... 118
Trip: speed ....................................................................................................... 118
Trip: MY CAR ................................................................................................. 119
Trip: info ........................................................................................................... 121
Trip: reset ......................................................................................................... 123
VOICE RECOGNITION ........................................................................ 124
GENERAL INFORMATION ........................................................................ 124
VOICE COMMANDS ................................................................................... 125
Keywords ......................................................................................................... 125
Examples (voice commands) ....................................................................... 132
INFORMATION AND ASSISTANCE SERVICES (SOS) ..... 141
Medical advice function ................................................................................. 141
Roadside assist. function ............................................................................... 142
Personal number function ............................................................................ 142
Emergency 112 function ............................................................................... 142
Phone settings function ................................................................................. 143
Calls for medical advice or roadside assistance ...................................... 144
bCONNECT Infomobility services ............................................................ 145
MY CAR ......................................................................................................... 148
LANGUAGE .................................................................................................... 149
DATE & TIME ................................................................................................. 150
VEHICLE ........................................................................................................... 152
SYSTEM (programming) ................................................................................ 156
Instrument panel ............................................................................................. 156
Video .................................................................................................................. 157
Power OFF ....................................................................................................... 157
FAULTS ......................................................................................................... 159
Internal faults ................................................................................................... 159
Overtemperature faults ................................................................................ 159

5
CONNECT NAV+
ADVICE
ROAD SAFETY
You are recommended to learn how
to use the different functions of the
CONNECT Nav+ and in particular of
the radio (e.g. storing stations) before
starting to drive.
RECEPTION CONDITIONS
Reception conditions change con-
stantly when driving. Reception can be
disturbed by the presence of moun-
tains buildings bridges particularly
when far away from the broadcaster
received.
IMPORTANT When receiving
traffic information the volume might
be higher than normal.
CARE AND MAINTENANCE
The structure of the CONNECT
Nav+ ensures long years of operation
with no need for particular mainte-
nance. In the event of a fault contact
Fiat Deale ship.
Some care must however be taken
to ensure the complete efficiency of
the CONNECT Nav+:
– the monitor is sensitive to scratch-
ing liquid detergents and UV rays;
– liquids that penetrate inside may
damage the device irreparably.
Clean the front panel and display on-
ly using a soft dry antistatic cloth.
Cleaning and polishing products may
damage the surface.
AA
AADD DDVV VVII IICC CCEE EE,, ,, CC CCOO OONN NNTT TTRR RROO OOLL LLSS SS
AA
AANN NNDD DD GG GGEE EENN NNEE EERR RRAA AALL LL II IINN NNFF FFOO OORR RRMM MMAA AATT TTII IIOO OONN NN
Too high a volume when dri-
ving can put the driver’s life
at risk and that of other people.
Therefore the volume should always
be adjusted in such a way that it is
always possible to hear the noises of
the surrounding environment (e.g.
horns, ambulance, police sirens, etc.).
ARNING

6
CONNECT NAV+
IMPORTANT NOTES
– In the event of a fault the CON-
NECT Nav+ should be checked and
repaired only at Fiat Deale ship.
– In case of particularly low temper-
atures the display might take a certain
time to reach the optimum brightness.
– In the case of prolonged parking
with high outside temperature the au-
tomatic thermal protection of the sys-
tem may come into action suspend-
ing operation until the passenger com-
partment temperature falls to accept-
able levels.
COMPACT DISC
If a Compact Disc is used on the
sound system remember that the
presence of dirt or marks on Compact
Discs may cause skipping when playing
and poor sound quality. The same hap-
pens if Compact Discs are bent by ac-
cident.
IMPORTANT Never use 8 cm au-
dio or MP3 CDs even with the spe-
cial adapter since this format damages
the system.
To obtain optimum playing condi-
tions we give the following advice:
– Only use Audio Compact Discs
with the brand:
– Carefully clean all Compact Discs
of any fingerprints and dust using a soft
cloth. Support Compact Discs on the
edges and clean from the centre out-
wards.
Be careful not to knock the
display with pointed or
hard objects and avoid
touching with the hands. Do not
press on the display when cleaning.

7
CONNECT NAV+
No
– Never use chemical products for
cleaning (e.g. spray cans antistatics or
thinners) as they might damage the
surface of Compact Discs.
– After listening to them put Com-
pact Discs back in their boxes to avoid
marking or scoring which could cause
skipping when playing.
– Do not expose Compact Discs to
direct sunlight high temperatures or
damp for prolonged lengths of time to
prevent them from bending.
– Do not stick labels or write on the
recorded surface of Compact Discs.
To remove a Compact Disc from its
container press on the centre and
raise the disc holding carefully from
the edges.
Always hold a Compact Disc by the
edge. Never touch the surface.
To remove fingerprints and dust use
a soft cloth starting from the centre of
the Compact Disc towards the cir-
cumference.
Proper way to hold
the compact disc
Removing the disc
New discs may be rough around the
edges. When using these discs the
player might not work or the sound
might skip. To remove roughness
from the edge of a disc use a ball-point
pen etc.
Ball-point pen
Roughness
IMPORTANT Do not use the pro-
tective sheets for CDs in commerce
or discs with stabilisers etc. as they
might get stuck in the internal mech-
anism and damage the disc.

8
CONNECT NAV+
Do not use solvents such as stain re-
movers antistatic sprays or thinners
in commerce for cleaning Compact
Discs.
Do not use highly scratched cracked
or distorted Compact Discs. This
could damage the player or prevent
it from working properly.
No
No
Notes about Compact Discs
Do not stick labels on the surfaces of
a Compact Disc or write on the sur-
face with pens or pencils.
No
IMPORTANT Should copy-pro-
tected CDs be used then few sec-
onds may be required before the sys-
tem starts to play them. Moreover
due to the proliferation of always new
and different protection methods it is
not guaranteed that the CD player can
play whatever protected disc. Copy
protection is often indicated on the
CD cover in small letters or hard to
read characters. Usually it is indicat-
ed by writings like: “COPY CON-
TROL” “COPY PROTECTED”
“THIS CD CANNOT BE PLAYED
ON A PC/MAC” or it is identified by
symbols like:
Protected discs (and their cover)
very often are not marked with the au-
dio CD identification symbol:

9
CONNECT NAV+
Do not expose Compact Discs to di-
rect sunlight or any other source of
heat.
GENERAL INFORMATION
The CONNECT Nav+ controls and
provides information for the following
systems and functions:
– GPS (Global Positioning System)
based navigation;
– Sound system with RDS (Radio Da-
ta System) radio MP3 CD and CD
Changer;
– GSM (Global System for Mobile
Communication) based telephone
with WAP and SOS-call (emergency
call) functions;
– Voice recognition (VR module)
with voice synthesis and voice memo.
The CONNECT Nav+ system main-
ly consists of the following:
– a keypad consisting of 28 push-but-
tons and 2 knobs;
– controls on steering wheel (8 push-
buttons + 1 encoder)
– electronics boxed in a properly
housing located inside the dashboard.
The interface is the multifunction in-
formation display for all the integrat-
ed components.
Multifunction info mation
display
The system uses a graphic 6 5” 16/9
LCD 256-colour TFT display with a
resolution of 400 x 240 pixels.
The display brightness can be
changed depending on the environ-
ment conditions and the driver’s re-
quirements storing two settings day
and night which are automatically set
to correspond with the turning on/off
of the external lights if this has been
set in MY CAR menu.
No
