Field Tuff FTF-456MD User manual

Mesh Deck
OWNER’S MANUAL
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other
basic safety precautions may result in serious personal injury.
-MODEL # FTF-456MD -
02262020

Page 2
Thank you very much for choosing this product! For future reference, please complete the
owner’s record below:
Model: FTF-456MD Purchase Date: _______________
Save the receipt, warranty, and these instructions. It is important that you read the entire manual
to become familiar with this product before you begin using it.
This product is designed for certain applications only. The manufacturer cannot be responsible
for issues arising from modification. We strongly recommend this product not be modified and/or
used for any application other than that for which it was designed. If you have any questions
relative to a particular application, DO NOT use the product until you have first contacted us to
determine if it can, or should, be performed on the product.
For technical questions, please call 1-218-943-6296.
TECHNICAL SPECIFICATIONS
Dimensions
54 ½” x 72 ½”
Material
Steel
IMPORTANT SAFETY INFORMATION
WARNING: Read and understand all instructions. Failure to follow all instructions listed
below may result in serious injury.
CAUTION: Do not allow persons to operate or assemble this mesh deck until they
have read this manual and have developed a thorough understanding of how it works.
WARNING: The warnings, cautions, and instructions discussed in this instruction
manual cannot cover all possible conditions or situations that could occur. It must be
understood by the operator that common sense and caution are factors that cannot be built into this
product, but must be supplied by the operator.
SAVE THESE INSTRUCTIONS

Page 3
WORK AREA
•Keep work area clean, free of clutter, and well lit. Cluttered and dark work areas can cause
accidents.
•Keep children and bystanders away while operating the mesh deck. Distractions can cause
you to lose control, so visitors should remain at a safe distance from the work area.
•Be alert of your surroundings. Using a mesh deck in confined work areas may put you
dangerously close to sharp tools and rotating parts.
PERSONAL SAFETY
•Stay alert, watch what you are doing, and use common sense when using a mesh deck. Do not
use while you are tired or under the influence of drugs, alcohol, or medication. A moment of
inattention while operating a mesh deck may result in serious personal injury.
•Dress properly. Do not wear loose clothing, dangling objects, or jewelry. Keep your hair, clothing,
and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving
parts.
•Use safety apparel and equipment. Use safety goggles or safety glasses with side shields that
comply with current national standards or, when needed, a face shield. Use a dust mask if
working in dusty work conditions. This applies to all persons in the work area.Also use non-skid,
safety shoes, hardhat, heavy-duty work gloves, dust collections systems, and hearing protecting
when appropriate.
•Do not have passengers on the tow vehicle when pulling the mesh deck.
•Do not turn too short when pulling the mesh deck. Turning too short can result in the mesh
deck catching a tire and possibly injuring the operator.
MESH DECK USE AND CARE
•Do not modify the mesh deck in any way. Unauthorized modification may impair the function
and/or safety and could affect the life of the equipment. There are specific applications for which
the mesh deck was designed.
•Always check for damaged or worn-out parts before using the mesh deck. Broken parts will
affect mesh deck operation. Replace or repair damaged or worn parts immediately.
•Store idle mesh deck. When the mesh deck is not in use, store it in a secure place out of the
reach of children. Inspect it for good working condition prior to storage and before re-use.

Page 4
ASSEMBLY
Step 1
Connect mesh section (B) Male to female mesh section (A) with 2 sets of
M10x55mm bolts in area (D) and 2 sets of M10x65mm in area (E) (bed cross bar
connection). Do Not tighten hardware at this point.
Step 2
Repeat same process with remaining sections. Do not tighten hardware at
this point.

Page 5
Step 3
Assemble the 2 halves with 8 sets of M10x20mm bolts/nuts in area
(F). Do not tighten hardware at this point.
Step 4
Attach the 4pcs frame connector parts (C) with 4 sets M8x65mm bolts/nuts to
the bed beam (G); then pre-assemble one M8 x 65 (H) bolt/nut to each frame
connector for connecting the bed to the cart frame. Do not tighten the
hardware at this point.

Page 6
Step 5
To connect the assembled mesh deck to your utility cart frame (FTF-2200UW
or ATV-2200HSH), attach the 4pcs frame connector parts (C) using the 4 sets
of pre-assemble M8 x 65 (H) bolt/nut to the brackets located on the cart frame
as shown in below illustration. Tighten all hardware when complete.
MAINTENANCE
•Tighten all nuts before/after each use.

Page 7
PARTS LIST:
For technical questions, please call 1-218-943-6296.
WARRANTY
One-year limited parts warranty.
TG
PO BOX 203
Miltona, MN 56354
Made in China
Part #
Description
Qty.
A
Male bed Mesh
2
B
Female Bed Mesh
2
C
Frame Connector
4
D
M10 x 55mm bolts/nuts (for bed beam connection)
4
E
M10 x 65mm bolts/nuts (for bed cross bar connection)
4
F
M10 x 20mm bolts/nuts (for bed halves connection)
8
G
M8 x 65mm bolts/nuts (for frame connectors connection)
4
H
M8 x 65mm bolts/nuts (pre-assembled on frame connectors)
4
