APPLICABILITY & EFFECTIVITY
Effective for all systems manufactured after November 2011
Driver Manual
(Supplement to the FieldServer Instruction Manual)
FS-8700-01 Modbus RTU
&
FS-8700-08 Modbus ASCII
There are several similarities between these two drivers and we have
incorporated them into the same manual to ensure that our information
stays current. Although both drivers are referenced in this manual, they are
different drivers and need to be ordered separately."
Driver Version:
4.03
Document Revision:
21

FS-8700-01 Modbus RTU/ASCIIFS-8700-01_Modbus_RTU Driver Manual Table of Contents
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
TABLE OF CONTENTS
1Modbus RTU/ Modbus ASCII Description .......................................................................................................3
2Driver Scope of Supply ................................................................................................................................... 3
2.1 Supplied by FieldServer Technologies for this driver ...................................................................................3
2.2 Provided by Supplier of 3rd Party Equipment...............................................................................................3
3Hardware Connections................................................................................................................................... 4
4Data Array Parameters...................................................................................................................................5
5Configuring the FieldServer as a Modbus RTU or Modbus ASCII Client...........................................................6
5.1 Client Side Connection Parameters..............................................................................................................6
5.2 Client Side Node Parameters .......................................................................................................................7
5.3 Client Side Map Descriptor Parameters .......................................................................................................7
5.3.1 FieldServer Related Map Descriptor Parameters .....................................................................................7
5.3.2 Driver Related Map Descriptor Parameters.............................................................................................8
5.3.3 Timing Parameters...................................................................................................................................8
5.3.4 Map Descriptor Examples. .......................................................................................................................9
6Configuring the FieldServer as a Modbus RTU or Modbus ASCII Server ........................................................ 10
6.1 Server Side Connection Parameters...........................................................................................................10
6.2 Server Side Node Parameters ....................................................................................................................11
6.3 Server Side Map Descriptor Parameters ....................................................................................................12
6.3.1 FieldServer Specific Map Descriptor Parameters ...................................................................................12
6.3.2 Driver Specific Map Descriptor Parameters ...........................................................................................12
6.3.3 Map Descriptor Examples ......................................................................................................................13
6.3.4 Slave_Id..................................................................................................................................................13
Appendix A. Useful Features –Modbus RTU........................................................................................................ 14
Appendix A.1. Managing Floating points with Modbus...........................................................................................14
Appendix A.1.1. Transferring non-integer values with one register.................................................................14
Appendix A.1.2. Transferring 32 bit values with two registers.........................................................................15
Appendix A.2. Node_Offline_Response...................................................................................................................16
Appendix B. Useful Features................................................................................................................................ 17
Appendix B.1. Map Descriptor Functions ................................................................................................................17
Appendix C. Troubleshooting............................................................................................................................... 18
Appendix C.1. Server Configuration of System Station Address..............................................................................18
Appendix D. Vendor Information......................................................................................................................... 19
Appendix D.1. Connection to York Modbus Microgateway ....................................................................................19
Appendix D.2. Modbus ASCII - Examples of FieldServer setup for typical clients ...................................................19
Appendix D.2.1. FieldServer with GE Cimplicity as client..................................................................................19
Appendix D.2.2. FieldServer with Intellution FIX as a client .............................................................................19
Appendix E. Reference......................................................................................................................................... 21
Appendix E.1. Data Types ........................................................................................................................................21
Appendix E.2. Single Writes.....................................................................................................................................21
Appendix E.2.1. Example: FC 6 = Write Single Register ...................................................................................22
Appendix E.3. Read/write Operation.......................................................................................................................22

FS-8700-01 Modbus RTU/ASCIIFS-8700-01_Modbus_RTU Driver Manual Page 3 of 22
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
1MODBUS RTU/ MODBUS ASCII DESCRIPTION
The Modbus RTU and Modbus ASCII drivers allow the FieldServer to transfer data to and from devices using
Modbus RTU or Modbus ASCII protocol respectively. Data can be transferred over either RS-232 or RS-485. The
driver was developed for Modbus Application Protocol Specification V1.1a" from Modbus-IDA. The specification
can be found at www.modbus.org. The FieldServer can emulate either a Server or Client.
The information that follows describes how to expand upon the factory defaults provided in the configuration files
included with the FieldServer.
There are various register mapping models being followed by various vendors
To cover all these models FieldServer uses the following three Models
Modicon_5digit –Use this format where addresses are defined in 0xxxx, 1xxxx, 3xxxx or 4xxxx format. A
maximum of 9999 registers can be mapped of each type. This is FieldServer driver’s default format.
ADU –Application Data Unit address. Use this format where addresses of each type are defined in the
range 1-65536
PDU –Protocol Data unit address. Use this format where addresses of each type are defined in the range
0-65535.
The key difference between ADU and PDU is for example if Address_Type is ADU and address is 1, the driver will
poll for register 0. If Address_Type is PDU, the driver will poll for address 1.
Note 1: If vendor document shows addresses in extended Modicon (i.e. 6 digit) format like 4xxxxx then consider
these addresses as xxxxx (omit the first digit) and use either ADU or PDU
Note 2: The purpose of providing 3 different ways of addressing the Modbus registers is to allow the user to
choose the addressing system most compatible with the address list being used. At the protocol level, the same
protocol specification is used for all three with the exception of the limited address range for Modicon_5digit.
2DRIVER SCOPE OF SUPPLY
2.1 Supplied by FieldServer Technologies for this driver
FieldServer Technologies PART #
Description
FS-8915-10
UTP cable (7 foot) for RS-232 use 1
2.2 Provided by Supplier of 3rd Party Equipment
PART #
Description
Modbus RTU or Modbus ASCII device
1This cable is necessary for connection to the driver. It is shipped with the FieldServer and not separately with the driver.

FS-8700-01 Modbus RTU/ASCIIFS-8700-01_Modbus_RTU Driver Manual Page 4 of 22
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
3HARDWARE CONNECTIONS
It is possible to connect a Modbus RTU or Modbus ASCII device to any of the existing serial ports on the
FieldServer2. These ports simply need to be configured for the appropriate driver in the configuration file.
Configure the Modbus RTU or Modbus ASCII device according to manufacturer’s instructions.
RJ45 to
EIA232
Connector
Connect
to 2-wire
RS-485
network
OR
RJ45 Connector
Typical DB9/DB25
kit assemblies are
shown here. Refer
to the third party
device literature
for exact
configuration
required.
DB25M
FUNCTION FROM TO COLOUR
Rx RJ45-01 DB9F-03 WHITE
GND RJ45-04 DB9F-05 GREEN
Tx RJ45-08 DB9F-02 BLUE
FUNCTION FROM TO COLOUR
RX RJ45-01 DB25M-03 WHITE
CTS RJ45-02 DB25M-05 BROWN
DSR RJ45-03 YELLOW
GND RJ45-04 DB25M-07 GREEN
GND RJ45-05 RED
TX RJ45-08 DB25M-02 BLUE
RTS RJ45-07 DB25M-04 ORANGE
DTR RJ45-06 BLACK
8917-01 WIRE LIST
FUNCTION FROM TO COLOUR
RX RJ45-01 DB25F-02 WHITE
CTS RJ45-02 DB25F-04 BROWN
DSR RJ45-03 YELLOW
GND RJ45-04 DB25F-07 GREEN
GND RJ45-05 RED
TX RJ45-08 DB25F-03 BLUE
RTS RJ45-07 DB25F-05 ORANGE
DTR RJ45-06 BLACK
8917-04 WIRE LIST
DB25F
DB9M FUNCTION FROM TO COLOUR
RX RJ45-01 DB9M-02 GREY
CTS RJ45-02 DB9M08 BROWN
DSR RJ45-03 DB9M-06 YELLOW
GND RJ45-04 DB9M-05 GREEN
GND RJ45-05 RED
TX RJ45-08 DB9M-03 BLUE
RTS RJ45-07 DB9M-07 ORANGE
DTR RJ45-06 DB9M-04 BLACK
8917-03 WIRE LIST
BASE NAME:
FILE NAME:
FIELDSERVER
MODBUS RTU or MODBUS ASCII
CONNECTION DIAGRAM
DATE: 2/5/07
BY: MC
(408)-262-2299
DB9F 8917-02 WIRE LIST
2Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for details of the ports available
on specific hardware.

FS-8700-01 Modbus RTU/ASCIIFS-8700-01_Modbus_RTU Driver Manual Page 5 of 22
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
4DATA ARRAY PARAMETERS
Data Arrays are “protocol neutral” data buffers for storage of data to be passed between protocols. It is necessary
to declare the data format of each of the Data Arrays to facilitate correct storage of the relevant data.
Section Title
Data_Arrays
Column Title
Function
Legal Values
Data_Array_Name
Provide name for Data Array
Up to 15 alphanumeric characters
Data_Array_Format
Provide data format. Each Data Array can only take
on one format.
FLOAT, BIT, UInt16, SInt16,
Packed_Bit, Byte, Packed_Byte,
Swapped_Byte
Data_Array_Length
Number of Data Objects. Must be larger than the
data storage area required by the Map Descriptors
for the data being placed in this array.
1-10, 000
Example
// Data Arrays
Data_Arrays
Data_Array_Name
, Data_Array_Format
, Data_Array_Length
DA_AI_01
, UInt16
, 200
DA_AO_01
, UInt16
, 200
DA_DI_01
, Bit
, 200
DA_DO_01
, Bit
, 200

FS-8700-01 Modbus RTU/ASCIIFS-8700-01_Modbus_RTU Driver Manual Page 6 of 22
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
5CONFIGURING THE FIELDSERVER AS A MODBUS RTU OR MODBUS ASCII CLIENT.
For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration Manual. The
information that follows describes how to expand upon the factory defaults provided in the configuration files
included with the FieldServer (See “.csv” sample files provided with the FieldServer).
This section documents and describes the parameters necessary for configuring the FieldServer to communicate
with a Modbus RTU or Modbus ASCII Server.
5.1 Client Side Connection Parameters
Section Title
Connections
Column Title
Function
Legal Values
Port
Specify which port the device is connected to the FieldServer
P1-P8, R1-R23
Baud*
Specify baud rate
110 –115200, standard baud
rates only. 9600
Parity*
Specify parity
Even, Odd, None
Data_Bits*
Specify data bits
7, 8
Stop_Bits*
Specify stop bits
1,2
Protocol
Specify protocol used
Modbus RTU
Modbus _RTU
Modbus ASCII
MB_ASCII
Poll_Delay*
Time between internal polls
0-32000s, 0.05s
Example
// Client Side Connections
Connections
Port
, Baud
, Parity
, Data_Bits
, Stop_Bits
, Protocol
, Handshaking
, Poll_Delay
P1
, 9600
, None
, 8
, 1
, Modbus _RTU4
, None
, 0.100s
3Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for details of the ports available
on specific hardware.
4Change protocol to MB_ASCII to use Modbus ASCII protocol

FS-8700-01 Modbus RTU/ASCIIFS-8700-01_Modbus_RTU Driver Manual Page 7 of 22
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
5.2 Client Side Node Parameters
Section Title
Nodes
Column Title
Function
Legal Values
Node_Name
Provide name for Node
Up to 32 alphanumeric characters
Node_ID
Modbus station address of physical Server Node
1-255
Protocol
Specify protocol used
Modbus RTU
Modbus_RTU
Modbus ASCII
MB_ASCII
Port
Specify which port the device is connected to the
FieldServer
P1-P8, R1-R23
Node_Type*5
Set to Block_Mode if Remote Server Node (RSN) only
supports Write Multiple –FC16 & FC15
Block_Mode, FC05 (Single_Coil);
FC06 (Single_Register)
Address_Type6
Specify Register Mapping Model
ADU,PDU, -, Modicon_5digit
Example:
// Client Side Nodes
// For devices where 65536 addresses are available in each memory area.
Nodes
Node_Name
, Node_ID
, Protocol
, Port
,Address_Type
Modbus device 1
, 1
, Modbus _RTU7
, P1
,ADU
Modbus device 2
, 2
, Modbus_RTU
, P1
,PDU
// For devices where only 9999 registers are available in each memory area.
Nodes
Node_Name
, Node_ID
, Protocol
, Port
Modbus device 3
, 3
, Modbus_RTU
, P1
5.3 Client Side Map Descriptor Parameters
5.3.1 FieldServer Related Map Descriptor Parameters
Column Title
Function
Legal Values
Map_Descriptor_Name
Name of this Map Descriptor
Up to 32 alphanumeric characters
Data_Array_Name
Name of Data Array where data is to
be stored in the FieldServer
One of the Data Array names from Section 4
Data_Array_Offset
Starting location in Data Array
0 to (Data_Array_Length -1) as specified in
Section 4
Function
Function of Client Map Descriptor.
Wrbc, Wrbx, Rdbc, Arco, Arcs. Refer to
Appendix B.1 for more information.
5Refer to Appendix E.3 for more information.
6Optional for Modicon 5 digit devices
7Change protocol to MB_ASCII to use Modbus ASCII protocol

FS-8700-01 Modbus RTU/ASCIIFS-8700-01_Modbus_RTU Driver Manual Page 8 of 22
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
5.3.2 Driver Related Map Descriptor Parameters
Column Title
Function
Legal Values
Node_Name
Name of Node to fetch
data from
One of the Node names specified in “Client Node
Descriptor” above
Data_Type8
Specify memory area
Address_Type = ADU
Coil, Discrete_Input, Input_Register, Holding_Register,
Single_Coil, Single_Register, Slave_Id
Address_Type = PDU
FC01, FC02, FC03, FC04,
FC05, FC06, FC15, FC16
Address_Type = Modicon_5digit
- (Dash), Single_Register, Single_Coil
Address
Starting address of
read block
Address_Type = ADU
1-65536
Address_Type = PDU
0-65535
Address_Type = Modicon_5digit
40001, 30001, etc
Length
Length of Map
Descriptor.
1-125 (For Analog polls),
1-800 (For Binary polls).
Data_Array_Low_Scale*
Scaling zero in Data
Array
Any signed 32 bit integer in the range:
-2,147,483,648 to 2,147,483,647. 0
Data_Array_High_Scale*
Scaling max in Data
Array
Any signed 32 bit integer in the range:
-2,147,483,648 to 2,147,483,647. 100
Node_Low_Scale*
Scaling zero in
Connected Node
Any signed 32 bit integer in the range:
-2,147,483,648 to 2,147,483,647. 0
Node_High_Scale*
Scaling max in
Connected Node
Any signed 32 bit integer in the range:
-2,147,483,648 to 2,147,483,647. 100
5.3.3 Timing Parameters
Column Title
Function
Legal Values
Scan_Interval*
Rate at which data is polled
0-32000, 1
8Optional only for Modicon_5digit addressing, and only if Single writes do not need to be forced

FS-8700-01 Modbus RTU/ASCIIFS-8700-01_Modbus_RTU Driver Manual Page 9 of 22
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
5.3.4 Map Descriptor Examples.
// Client Side Map Descriptors
// Note: All three examples below are addressing the same Modbus registers.
// For Nodes where Address_Type is ADU
Map_Descriptors
Map_Descriptor_Name
, Data_Array_Name
, Data_Array_Offset
, Function
, Node_Name
, Data_Type
, Address
, Length
,Scan_Interval
CMD_AI_01
, DA_AI_01
, 0
, Rdbc
, MODBUS DEVICE1
, Input_Register
, 1
, 20
,1.000s
CMD_AO_01
, DA_AO_01
, 0
, Rdbc
, MODBUS DEVICE1
, Holding_Register
, 1
, 20
,1.000s
CMD_DI_01
, DA_DI_01
, 0
, Rdbc
, MODBUS DEVICE1
, Discrete_Input
, 1
, 20
,1.000s
CMD_DO_01
, DA_DO_01
, 0
, Rdbc
, MODBUS DEVICE1
, Coil
, 1
, 20
,1.000s
// For Nodes where Address_Type is PDU
Map_Descriptors
Map_Descriptor_Name
, Data_Array_Name
, Data_Array_Offset
, Function
, Node_Name,
, Data_Type
, Address
, Length
,Scan_Interval
CMD_AI_02
, DA_AI_02
, 0
, Rdbc
, MODBUS DEVICE2
, FC04
, 0
, 20
,1.000s
CMD_AO_02
, DA_AO_02
, 0
, Rdbc
, MODBUS DEVICE2
, FC03
, 0
, 20
,1.000s
CMD_DI_02
, DA_DI_02
, 0
, Rdbc
, MODBUS DEVICE2
, FC02
, 0
, 20
,1.000s
CMD_DO_02
, DA_DO_02
, 0
, Rdbc
, MODBUS DEVICE2
, FC01
, 0
, 20
,1.000s
// For Nodes where Address_Type is Modicon_5digit.
Map_Descriptors
Map_Descriptor_Name
, Data_Array_Name
, Data_Array_Offset
, Function
, Node_Name,
, Address
, Length
, Scan_Interval
CMD_AI_03
, DA_AI_03
, 0
, Rdbc
, MODBUS DEVICE3
, 30001
, 20
, 1.000s
CMD_AO_03
, DA_AO_03
, 0
, Rdbc
, MODBUS DEVICE3
, 40001
, 20
, 1.000s
CMD_DI_03
, DA_DI_03
, 0
, Rdbc
, MODBUS DEVICE3
, 10001
, 20
, 1.000s
CMD_DO_03
, DA_DO_03
, 0
, Rdbc
, MODBUS DEVICE3
, 00001
, 20
, 1.000s

FS-8700-01 Modbus RTU/ASCIIFS-8700-01_Modbus_RTU Driver Manual Page 10 of 22
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
6CONFIGURING THE FIELDSERVER AS A MODBUS RTU OR MODBUS ASCII SERVER
For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration Manual. The
information that follows describes how to expand upon the factory defaults provided in the configuration files
included with the FieldServer (See “.csv” sample files provided with the FieldServer).
This section documents and describes the parameters necessary for configuring the FieldServer to communicate
with a Modbus RTU or Modbus ASCII Client.
The configuration file tells the FieldServer about its interfaces, and the routing of data required. In order to enable
the FieldServer for Modbus RTU or Modbus ASCII communications, the driver independent FieldServer buffers
need to be declared in the “Data Arrays” section, the FieldServer virtual Node(s) needs to be declared in the
“Server Side Nodes” section, and the data to be provided to the clients needs to be mapped in the “Server Side
Map Descriptors” section. Details on how to do this can be found below.
Note that in the tables, * indicates an optional parameter, with the bold legal value being the default.
6.1 Server Side Connection Parameters
Section Title
Connections
Column Title
Function
Legal Values
Port
Specify which port the device is connected
to the FieldServer
P1-P8, R1-R29
Baud*
Specify baud rate
110 –115200, standard baud rates only, 9600
Parity*
Specify parity
Even, Odd, None
Data_Bits*
Specify data bits
7, 8
Stop_Bits*
Specify stop bits
1, 2
Protocol
Specify protocol used
Modbus RTU
Modbus_RTU
Modbus ASCII
MB_ASCII
Example
Change protocol to MB_ASCII to use Modbus ASCII protocol
// Server Side Connections
Connections
Port
, Baud
, Parity
, Data_Bits
, Stop_Bits
, Protocol
P1
, 9600
, None
, 8
, 1
, Modbus_RTU
9Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for details of the ports available
on specific hardware.

FS-8700-01 Modbus RTU/ASCIIFS-8700-01_Modbus_RTU Driver Manual Page 11 of 22
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
6.2 Server Side Node Parameters
Section Title
Nodes
Column Title
Function
Legal Values
Node_Name
Provide name for Node
Up to 32 alphanumeric
characters
Node_ID
Node ID of physical Server Node
1 –255
Protocol
Specify protocol used
Modbus RTU
Address_Type10
Specify Register Mapping Model
ADU,PDU, -,
Modicon_5digit
Node_Offline_Response*
Set the FieldServer response to the Modbus RTU
Client when the Server Node supplying the data has
gone offline
No_Response,
Old_Data,
Zero_Data,
FFFF_Data,
Refer to Appendix A.2 for
further information.
Node_Description*
Specify Node description text
Any string up to 99
characters long, -
Example
Change protocol to MB_ASCII to use Modbus ASCII protocol
// Server Side Nodes
// For devices where 65536 addresses are available in each memory area.
Nodes
Node_Name
, Node_ID
, Protocol
, Address_Type
MB_Srv_11
, 11
, Modbus_RTU
, ADU
MB_Srv_12
, 12
, Modbus_RTU
, PDU
// For devices where only 9999 registers are available in each memory area.
Nodes
MB_Srv_13
, 13
, Modbus_RTU
, Modicon_5digit
MB_Srv_14
, 14
, Modbus_RTU
, -
10 Optional for Modicon 5 digit devices

FS-8700-01 Modbus RTU/ASCIIFS-8700-01_Modbus_RTU Driver Manual Page 12 of 22
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
6.3 Server Side Map Descriptor Parameters
6.3.1 FieldServer Specific Map Descriptor Parameters
Column Title
Function
Legal Values
Map_Descriptor_Name
Name of this Map Descriptor
Up to 32 alphanumeric characters
Data_Array_Name
Name of Data Array where data is to be
stored in the FieldServer
One of the Data Array names from
Section 4
Data_Array_Offset
Starting location in Data Array
0 to (Data_Array_Length -1) as specified
in Section 4
Function
Function of Server Map Descriptor
Passive
6.3.2 Driver Specific Map Descriptor Parameters
Column Title
Function
Legal Values
Node_Name
The name of the Node
being represented.
One of the Node names specified in Section 6.2
Data_Type11
Specify memory area
Address_Type = ADU
Coil, Discrete_Input, Input_Register, Holding_Register,
Single_Coil, Single_Register, Slave_ID
Address_Type = PDU
FC01, FC02, FC03, FC04,
FC05, FC06, FC15, FC16
Address_Type = Modicon_5digit
- (Dash), Single_Register, Single_Coil
Length*
Length of Map Descriptor
1-10000, 1
Address
Starting address of read
block
Address_Type = ADU
1-65536
Address_Type = PDU
0-65535
Address_Type = Modicon_5digit
40001, 30001, etc
Data_Array_Low_Scale*
Scaling zero in Data Array
Any signed 32 bit integer in the range:
-2,147,483,648 to 2,147,483,647. 0
Data_Array_High_Scale*
Scaling max in Data Array
Any signed 32 bit integer in the range:
-2,147,483,648 to 2,147,483,647. 100
Node_Low_Scale*
Scaling zero in Connected
Node
Any signed 32 bit integer in the range:
-2,147,483,648 to 2,147,483,647. 0
Node_High_Scale*
Scaling max in Connected
Node
Any signed 32 bit integer in the range:
-2,147,483,648 to 2,147,483,647. 100
11 Optional only for Modicon_5digit addressing, and only if Single writes do not need to be forced

FS-8700-01 Modbus RTU/ASCIIFS-8700-01_Modbus_RTU Driver Manual Page 13 of 22
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
6.3.3 Map Descriptor Examples
// Server Side Map Descriptors where Node Address_Type is ADU
// Note: All three examples below are addressing the same Modbus registers.
// For Nodes where Address_Type is ADU
Map_Descriptors
Map_Descriptor_Name
, Data_Array_Name
, Data_Array_Offset
, Function
, Node_Name
, Data_Type
, Address
, Length
, Data_Array_Low_Scale
, Data_Array_High_Scale
, Node_Low_Scale
, Node_High_Scale
SMD_AI_01
, DA_AI_01
, 0
, Passive
, MB_Srv_11
, Input_Register
, 1
, 200
, 0
, 100
, 0
, 10000
SMD_AO_01
, DA_AO_01
, 0
, Passive
, MB_srv_11
, Holding_Register
, 1
, 200
, 0
, 100
, 0
, 10000
// Server Side Map Descriptors where Node Address_Type is PDU
Map_Descriptors
Map_Descriptor_Name
, Data_Array_Name
, Data_Array_Offset
, Function
, Node_Name
, Data_Type
, Address
, Length
, Data_Array_Low_Scale
, Data_Array_High_Scale
, Node_Low_Scale
, Node_High_Scale
SMD_AI_02
, DA_AI_02
, 0
, Passive
, MB_Srv_12
, FC04
, 0
, 200
, 0
, 100
, 0
, 10000
SMD_AO_02
, DA_AO_02
, 0
, Passive
, MB_srv_12
, FC03
, 0
, 200
, 0
, 100
, 0
, 10000
// For Nodes where Address_Type is Modicon_5digit.
Map_Descriptors
Map_Descriptor_Name
, Data_Array_Name
, Data_Array_Offset
, Function
, Node_Name
, Address
, Length
, Data_Array_Low_Scale
, Data_Array_High_Scale
, Node_Low_Scale
, Node_High_Scale
SMD_AI_01
, DA_AI_01
, 0
, Passive
, MBP_Srv_13
, 30001
, 200
, 0
, 100
, 0
, 10000
SMD_AO_01
, DA_AO_01
, 0
, Passive
, MBP_Srv_13
, 40001
, 200
, 0
, 100
, 0
, 10000
6.3.4 Slave_Id
The following Map Descriptor is used to respond to the Report Slave_Id request. The FieldServer's Slave_Id is 11 and the run status depends upon the data
validity at the specified offset in the specified Data Array - if the data is valid, the status will be 255 (running) otherwise the status will be 0 (off).
Map_Descriptors
Map_Descriptor_Name
, Data_Array_Name
, Data_Array_Offset
, Function
, Node_Name
, Address
, Length
, Data_Type
SMD_DO1
, DA_DO_01
, 0
, Passive
, RTU_Srv_21
, 00001
, 1
, Slave_ID
Length is not
used, revert to
default of 1

FS-8700-01 Modbus RTU/ASCIIFS-8700-01_Modbus_RTU Driver Manual Page 14 of 22
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
Appendix A. Useful Features –Modbus RTU
Appendix A.1. Managing Floating points with Modbus
Modbus as a standard does not support floating point formats. Many vendors have written higher level communications software to use two 16 bit registers
to represent floating point or 32 bit integers. This requires conversion software on both ends of the communication channel. The FieldServer supports this
function and also provides other options to resolve this issue.
Appendix A.1.1. Transferring non-integer values with one register
It is possible to represent values higher than 32767 using one register in one of two ways:
Declare data arrays as type Uint16 (Unsigned integer). This will give you a range from 0 to 65535.
Use the scaling function on the FieldServer, which will allow you to set up any range, with 16 bit resolution.
The following example shows how scaling can be achieved on the Server side of the configuration. Note that scaling can also be done on the Client side to
scale down a value that was scaled up by a Modbus vendor. Further information regarding scaling can be found in the FieldServer Configuration manual.
Example :
Map_Descriptors
Map_Descriptor_Name
, Data_Array_Name
, Data_Array_Offset
, Function
, Node_Name
, Address
, Length
, Data_Array_Low_Scale
, Data_Array_High_Scale
, Node_Low_Scale
, Node_High_Scale
SMD_AI1
, DA_AI_01
, 0
, Passive
, MBP_Srv_11
, 30001
, 200
, 0
, 100
, 0
, 10000
SMD_AO1
, DA_AO_01
, 0
, Passive
, MBP_Srv_11
, 40001
, 200
, 0
, 100
, 0
, 10000
This example multiplies the values in the data array by 100 (10000 on Node_High_Scale is 100X larger than 100 on Data_Array_High_Scale). This is most
commonly used when the user wants to introduce values after the decimal point. For example, a value of 75.6 will be sent as 7560, which can then be rescaled
by the Modbus master.

FS-8700-01 Modbus RTU/ASCIIFS-8700-01_Modbus_RTU Driver Manual Page 15 of 22
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
Appendix A.1.2. Transferring 32 bit values with two registers
If a Modbus Server sends two consecutive registers to the FieldServer representing either a floating point value or
a 32 bit integer value, the FieldServer can combine and decode these registers back into their original format. To
do this, the user must read the registers into an integer data array, and then use the Moves function to move the
data to a floating point or 32 bit integer data array. The “function” field in the move must be populated with the
correct move function required. Details of the available function fields are listed in the FieldServer configuration
manual along with a more detailed explanation of moves. Note that functions also exist to split a floating point
value into two integers using the reverse operation.
A diagrammatic representation of this process is depicted below:
The example below shows how a floating point value is retrieved from two Modbus registers that were placed in
an integer data array.
Example
Data_Arrays
Data_Array_Name
, Data_Format
, Data_Array_Length
DA1
, Int16
, 20
DA2
, Float
, 10
Moves
Function
, Source_Data_Array
, Source_Offset
, Target_Data_Array
, Target_Offset
2.i16-1.float-sw
, DA1
, 0
, DA2
, 6
This Move will cause two integers at offsets 0 and 1 in the integer Data Array DA1 to be copied to offset 6 in the
Float Data Array DA2. In the process of copying the values, the integers will be combined and treated as an IEEE 32
bit floating point number.
Modbus Device
Two 16 bit
integers polled:
e.g: 40001,
length 2
Together, they
combine to
form a 32 bit
IEEE Floating
point number.
Source Data
Array
-------------------------
Offset 0: 40001
-------------------------
Offset 1: 40002
-------------------------
Float Data Array
-------------------------
Offset 40: Float
value
-------------------------
Modbus Poll
Special
Move
Unreadable
content
Sensible data

FS-8700-01 Modbus RTU/ASCIIFS-8700-01_Modbus_RTU Driver Manual Page 16 of 22
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
Appendix A.2. Node_Offline_Response
This function is specific to the Modbus RTU driver.
In systems where data is being collected from multiple Server Nodes and made available on a FieldServer
configured as a Modbus RTU Server, when a Server Node goes offline the default behavior of the FieldServer
would be to stop responding to polls for this data. This might not be what the user wants. Various options exist
making it possible to signal that the data quality has gone bad without creating error conditions in systems
sensitive to the default option.
The following options can be configured under the Node parameter, Node_Offline_Response, to set the response
of the FieldServer to the Modbus RTU Client when the Server Node supplying the data is offline:
No_Response - this is the default option. The FieldServer simply does not respond when the
corresponding Server Node is offline.
Old_Data - The FieldServer will respond, but with the last known value of the data. This maintains the
communication link in an active state, but may hide the fact that the Server Node is offline.
Zero_Data - The FieldServer will respond, but with the data values set to zero. If the user normally expects
non-zero values, this option will signal the offline condition without disrupting communications.
FFFF_Data - The FieldServer will respond, but with the data values set to FFFF (hex). If the user normally
expects other values, this option will signal the offline condition without disrupting communications.
When configured as a Server this parameter can force a desired exception response as follows:
Node_Offline_Message or Exception_4 - FieldServer's response will be Exception 4
Gateway_Path_Unavailable or Exception_A - FieldServer's response will be Exception A
Gateway_Device_Failed or Exception_B - FieldServer's response will be Exception B
Example:
Nodes
Node_Name
, Node_ID
, Protocol
, Node_Offline_Response
, Port
DEV11
, 11
, Modbus_RTU
, No_Response
, -
DEV12
, 12
, Modbus_RTU
, Old_Data
, -
DEV15
, 15
, Modbus_RTU
, Zero_Data
, -
DEV16
, 16
, Modbus_RTU
, FFFF_Data
, -
DEV17
, 17
, Modbus_RTU
, Exception_4.
, -
DEV18
, 18
, Modbus_RTU
, Gateway_Path_Unavailable
, -

FS-8700-01 Modbus RTU/ASCIIFS-8700-01_Modbus_RTU Driver Manual Page 17 of 22
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
Appendix B. Useful Features
Appendix B.1. Map Descriptor Functions
Function
Description
Rdbc
This is an active Map Descriptor which polls the device once every scan interval. The function will also
execute writes from the Data Array to a remote device when a change is detected, but only when
used in conjunction with writeable addresses.
Arco
The Arco function is the same as Rdbc except that the length of the Map Descriptor is taken as the
number of zones to poll. The start zone number is specified under the Zone Map Descriptor field.
More than one Arco Map Descriptor may be used to poll two series of zone numbers, eg. from 5-10
and from 300-340. Arco Map Descriptors with Length 1 perform the same function as Rdbc Map
Descriptors with the same length.
Arcs
This function will perform the same operation as an Rdbc (Arc) function, but will sequence through
the range of addresses starting at "Address" and wrapping at "Address + Length". A length of 1 will be
used for every one of the Addresses that gets polled.
Wrbx
The Wrbx function will write data from the Data Array to the remote device. The write is triggered by
a change in the associated Data Array. If the associated Data Array is updated a write will occur, even
if the value/s within the Data Array have not changed. The “Scan_Interval” parameter is not required
for this function as writes are event driven and not continuous
Wrbc
This is similar to the Wrbx function, except that the writes occur at a regular interval rather than on
an event driven basis. The frequency of the writes is determined by the “Scan_Interval” parameter.

FS-8700-01 Modbus RTU/ASCIIFS-8700-01_Modbus_RTU Driver Manual Page 18 of 22
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
Appendix C. Troubleshooting
Appendix C.1. Server Configuration of System Station Address
When using the FieldServer as a Modbus Server, the FieldServer System Station address must be configured to be
different from any of the configured Modbus Server Node_ID’s. Configuring these to be the same invokes
proprietary system information to be transmitted, and should therefore be avoided.

FS-8700-01 Modbus RTU/ASCIIFS-8700-01_Modbus_RTU Driver Manual Page 19 of 22
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
Appendix D. Vendor Information
Appendix D.1. Connection to York Modbus Microgateway
If connecting the FieldServer to a York Modbus Microgateway, the Node_ID of the Microgateway is defined by the
address DIP switches. If switch 4 is set to ‘On’ and the other switches are set to ‘off’ then Node_ID of the
Microgateway is ‘247’, the parity is ‘Even’, and the stop bits are 1. Other Node_ID combinations can be found in
the York Modbus Microgateway Installation Manual.
Appendix D.2. Modbus ASCII - Examples of FieldServer setup for typical clients
Appendix D.2.1. FieldServer with GE Cimplicity as client
Run the Cimplicity “Workbench” and create a “New Project” with a unique “Project Name” option of
“Basic Control” and protocol “Modbus ASCII”.
Check the project properties and continue with the “Project Wizard Setup” that appears.
Add Modbus port giving it a description.
Create and configure the devices, select “new item”.
Name the device, select the port, give it a description (e.g. FieldServer), and choose “SYSTEM” resource.
Create and configure the points.
Select “new item”, name the point and choose the appropriate device.
Under the “General” tab, point properties require a description. Note that the elements must have a
value greater than 8.
Under the “Device” tab, properties need the appropriate address (e.g. 40001 and also require the leading
0’s), change the update criteria to “On Scan”.
When the project is configured, run by pressing the “play” button.
Expect the Cimplicity driver to connect and poll the FieldServer for a range of valid addresses, and then
proceed to poll for just the configured Points.
From the start menu choose the “Point Control Panel”, select edit and add the project you want to view.
Note, to log on the User name “ADMINISTRATOR” must be supplied
Use “Modbus ASCII Diagnostics” to connect to host and then read the register.
Appendix D.2.2. FieldServer with Intellution FIX as a client
Install Intellution FIX, choosing the MB1 Modbus ASCII I/O driver
Run from Start menu and choose “Intellution Fix”.
Choose “System Configuration Utility”.
Modify SCADA, add the MB1 Modbus ASCII I/O driver
Configure the Modbus ASCII Driver.

FS-8700-01 Modbus RTU/ASCIIFS-8700-01_Modbus_RTU Driver Manual Page 20 of 22
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
Device is D11, select 5-digit address, add the FieldServer virtual Node ID to station address
Set up poll record
SAVE the configuration.
Open “Startup”
Open “Mission Control” from the “Apps” menu and confirm Fix is polling.
To display the data create a link in Fix draw, add link, data link.
Give it a tagname, allow data entry, numeric entry and set enable option.
If tag is not in database, select “Add”, choose “AR”. Then set output enable, device MB1, I/O address d11.
Save the settings
Use “Quickview” from the “View” menu to confirm the reading of data without ??? appearing
Change the value and wait a few seconds to ensure the change really occurred.
