Filtrine B103 Technical specifications

Wrench
Cartridge Regulator Valve Assembly
Exploded View
Brass Retaining Ring
Button Trim Ring
Cartridge Regulator
Neoprene
Seal
Spanner
Valve Assembly
Body
See B103 FLUSH BUTTON INSTALL [EB] for valve assembly
part numbers
Hands-Free B103 Bottle Filling Station
Maintenance Instructions
DRAWING
PART NO. DESCRIPTION ORDER PART NO.
1 CARTRIDGE REGULATOR ASSEMBLY 45.0006
2
BATTERY BOX 6.1712
AA LITHIUM BATTERIES - 4 PACK 51.0592
3 CONTROL MODULE 6.1716
4 SOLENOID VALVE 6.1708
5
SENSOR (FOR B103 WITH BOTTLE
COUNTER) 6.1714
RED LENSE 6.1717
6SENSOR (FOR B103 WITHOUT BOTTLE
COUNTER) 6.1713
7 BOTTLE COUNTER, 3-30VDC 6.1730
ASSEMBLY SENSOR ASSEMBLY (FOR B103 WITH
BOTTLE COUNTER) - PART NO. 2, 3, 4 & 5) 6.1709
ASSEMBLY SENSOR ASSEMBLY (FOR B103 WITHOUT
BOTTLE COUNTER) - PART NO. 2, 4 & 6 6.1710
Sensor Activated B103
Maintenance Instructions
To remove the cover plate, unscrew the Jackman
screws from both sides and slide the cover plate out.
Cartridge Regulator Replacement and Flow
Adjustment:
Turn off water to the fixture and depress button on
cartridge regulator to drain water left in the line.
Using the spanner wrench or needle nose pliers,
unscrew the brass regulator retaining ring.
Gently wiggle cartridge back and forth to remove it
from the brass valve assembly body.
Check to ensure that the old neoprene seal was also
removed. Install new neoprene seal on the new
cartridge regulator and install new assembly into the
valve body, ensuring inlet and outlet holes on the
cartridge are lined up and the cartridge is seated
properly in the valve body.
Reinstall the regulator retaining ring and tighten using
the spanner wrench or needle nose pliers.
Turn on water to fixture and test for flow and leaks by
pushing plunger with flat screwdriver.
Adjust the flow by turning the white screw head on the
cartridge regulator. Turn it clockwise to decrease flow
and counterclockwise to increase flow.
Sensor Adjustment:
To adjust the distance of the sensor intensity, turn
yellow phillips head screw on control module circuit
board clockwise to lengthen distance and counter
clockwise to shorten it.
Bottle Counter Reset:
To reset the bottle counter, press and hold the black
reset button (see diagram above for location) for a few
seconds while passing hand across the sensor.
Filtrine Mfg. Co. ∙ 15 Kit St. Keene, NH 03431 USA
800-930-3367 ∙ 603-352-5500 ∙ FAX [phone]
www.filtrine.com ∙ dr[email protected] 01/15/2020
"HANDS-FREE" BOTTLE FILLING
STATION ASSEMBLY [EB] - PAGE 1
1
Reset Button
(Water Inlet)
Bottle Counter
7
4
" Stop Valve
3
5
Body
B103
2
Cover Plate 1
4
6

Filtrine Mfg. Co. ∙ 15 Kit St. Keene, NH 03431 USA
800-930-3367 ∙ 603-352-5500 ∙ FAX [phone]
www.filtrine.com ∙ dr[email protected] 12/06/2019
"HANDS-FREE" BOTTLE FILLING
STATION ASSEMBLY [EB] - PAGE 2
CONTROL MODULE LEGEND
1 SOLENOID PIN RECEPTOR
2CONTROL CABLE (SENSOR EYE) PIN
RECEPTOR
3 AC INPUT PIN RECEPTOR
4 DC INPUT PIN RECEPTOR
5ELECTRO-MECHANICAL PUSH
BUTTON PIN RECEPTOR
6BATTERY PACK INPUT RECEPTOR
(DC)
7DIP SWITCHES
8RESET BUTTON
9SENSOR DISTANCE ADJUSTMENT
SCREW
10 RED LED LIGHT
11 CABLES TO BOTTLE COUNTER
CONTROL MODULE
BATTERY PACK
(4 AA BATTERIES)
MOTION SENSOR
SOLENOID VALVE
Includes [4] AA lithium
batteries with approximately
400,000 activation cycles.
Features automatic shutoff [30
second] - helps prevent
vandalism and water waste.
5
67
8
4 3 9 2 1
"Hands-Free" Control Module Diagram
"Hands-Free" Control Module Instructions
To adjust sensor length, turn the sensor adjustment screw (9)1.
Turn clockwise to lengthen the sensor distance2.
Turn counterclockwise to shorten the sensor distance3.
10
BOTTLE COUNTER
BOTTLE COUNTER
RESET BUTTON
11
"Hands-Free" Sensor Activation Components
