Fine elements SDA42 User manual

Double Hot Plate
Model SDA42

IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed. These instructions should be saved for future
reference:
• Read and familiarise yourself with all operating instructions before
using this Double Hot Plate.
• Before plugging your unit into the mains, visually check that the unit is
intact and has not suffered any transit damage.
• Check that the voltage indicated on the data plate corresponds with
that of the local network before connecting the appliance to the mains
power supply.
• Close supervision is required when using this appliance near children.
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children unless they are older than 8 and supervised.
• Keep the appliance and its cord out of reach of children less than 8
years.
• Do not touch hot surfaces. The outer surfaces are liable to get hot
during use. Always use the handles and knobs.
• Do not immerse the appliance or its cord in water or any other liquids.
• Do not leave the appliance unattended during use.
• Do not leave the appliance unattended whilst connected to the mains
supply.
• Always use this appliance on a solid, level, non-flammable surface.
• Do not use this appliance outdoors.
• Do not use this Double Hot Plate with a programmer, timer, separate
remote-control system or any other device that switches the appliance
on automatically.
• It is imperative to unplug the power cord after the appliance has been
used, before it is cleaned and whilst being repaired.
• Repairs to electrical appliances should only be performed by a
qualified electrician. Improper repairs may place user at serious risk.
• Do not operate this appliance with a damaged plug or cord, after a
malfunction or after being dropped or damaged in any way.
• Regular, periodic checks should be carried out on the mains cable to

ensure no damage is evident. Should there be any signs of damage
the appliance should not be used.
• If the power cable is damaged, it should only be replaced by the
manufacturer or a suitable qualified after-sales-service in order to
avoid a hazard
• Do not allow the mains cable to hang over sharp edges or come in
contact with hot surfaces.
• Do not run the mains cable under carpets, rugs, etc.
• Allow the unit to cool before storage.
• Before cleaning, disconnect the appliance from the mains supply and
allow to cool.
• This appliance is intended for household use only and should not be
used for industrial purposes.
• Do not use any accessories or attachments with this appliance other
than those supplied or recommended by supplier.
• Do not use this appliance for anything other than its intended use.
• Do not push objects into any openings as damage to the appliance
and/or electric shock may occur.
• Ensure appliance is situated in an open area, do not allow it to come
in contact with Cupboards, Curtains, wall coverings, clothing or other
flammable materials.
• Unplug after each use. Grasp the plug, not the cord.
NB During the first few minutes of initial use, you may notice a
slight odour and a little smoke. This is normal and will quickly
disappear, It is the coating applied to the heating elements to
prevent any corrosion during transit.

Description of parts
Before the first time you use your Double Hot Plate
Please read these operating instructions thoroughly and keep them in
a safe place for future reference.
Remove all packing materials and discard responsibly.
Before using your Double Hot Plate for the first time, turn the Hot
plate to the highest setting (5) for 3 to 5 minutes to condition the
protective coating.
NB This should be the only time the Double Hot Plate is operated
without a cooking utensil on it.
A pan 15 - 17cm in diameter is recommended for best results. Smaller
pans are not recommended. Ensure larger pans do not protrude
beyond the edge of the Hot Plates or the controls.
Operating Instructions
• Place the Double Hot Plate on a solid, level non-flammable surface.
• Ensure that Thermostat Controls are in the off position.
• Insert the mains plug into the mains socket.
• Rotate the Thermostat Control clockwise from 0 (low heat) through to
5 (high heat) and leave at the desired setting. The Neon Indicator will
light to show the hot plate is being heated up.
• Once the hot plate is at the correct temperature the Neon Indicator
will go out, the Neon Indicator will go on and off during use to show
the temperature of the hot plate is being maintained.
• Return the Thermostat control to the position and remove the
mains plug from the socket after use.
Double Hot Plates
Thermostat
Controls
Neon Indicators

Care and Use of your Double Hot Plate
• Always disconnect the Double Hot Plate from the mains power supply
and allow to cool before cleaning.
• Clean the outside of the Double Hot Plate with a soft damp cloth.
Never clean the Double Hot Plate with harsh or abrasive cleaners.
• Do not submerge any part of Double Hot Plate or its cord in water or
any other liquids.
Technical Data
Voltage : 220-240V AC 50Hz
Rated power : 2500 W
Fitting a new plug
If for any reason you need to fit a new plug, the flexible mains lead
must be connected as shown below. The wires in the mains lead
fitted to this appliance are coloured in accordance with the following
code:
Brown wire = Live (L)
Blue wire = Neutral (N)
Green and Yellow = Earth (E)
If colours of the wires in the mains lead of this appliance do not
correspond with the coloured marking identifying the terminals in
your plug, proceed as follows:
Connect
Brown to
Live (L)
Connect
Blue to
Neutral
(N)
Ensure the outer sheath of the
mains lead is securely held by the
cable clamp
Connect
Green &
Yellow to
Earth (E)

The wire which is coloured Blue must be connected to the terminal
which is marked with the letter N or coloured Black. The wire which
is coloured Brown must be connected to the terminal which is
marked with the letter L or coloured Red. The wire which is
coloured Green and Yellow must be connected to the terminal
which is marked with the letter E or coloured Green.
Before refitting the plug cover check that there are no cut or stray
strands of wire inside the plug. Use a 13 Amp BS 1362 fuse, only
BSI or ASTA approved fuses should be used. If you are in any way
unsure which plug or fuse to use, always refer to a qualified
electrician.
Note: After replacing or changing a fuse on moulded plug which
has a fuse cover, the cover must be refitted to the plug, the
appliance must not be used without a fuse cover.
Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist. Check with
your Local Authority or retailer for recycling advice.
Fine Elements® is a registered trade mark of Europasonic (UK) Ltd
!
!
!
Europasonic (UK) Ltd
Manchester M3 1JS
www.europasonic.com
