FINTIE KAW000X User manual

Kids wireless keyboard with touchpad
User Manual

Pairing Steps
Note: See Product overview section below for more details.
Step 1. Switch Power switch On to turn your keyboard on.
Step 2. Press the “Fn + C” keys together to enter pairing mode.
Step 3. Verify your device’s Bluetooth® settings are on.
Select Settings > Bluetooth > On.
Step 4. Select “Pair new device”.
Step 5. Select “Fintie Keyboard” from your device’s list of available devices to
complete pairing.
Step 6. The Bluetooth pairing indicator will turn off after your device has paired
successfully.
Sleep Mode
The keyboard will enter sleep mode after being idle for 30 minutes. Press any key
to wake the keyboard. Wait up to 2 seconds for the keyboard to reconnect with the
tablet before starting to type.
Charging Your Keyboard
1. Plug the USB-C end of the charging cable into the keyboard and the other
USB end into your preferred USB charger. (USB charger is not included.)
2. When charging, the power indicator will turn red. Generally, it takes
approximately 2 hours for a full charge. (Output: DC 5 V/500 mA.)
Package Contents
1 x Keyboard
1 x Protective Case
1 x USB-C Charging Cable
1 x User Manual
Specifications
Bluetooth Version
BLE 5.0
Operating Range
Up to 10 metres
Working Voltage
3.0-4.2 V
Working Current
1 mA
Charging Current
200 mA
Sleeping Current
0.01 mA
Re-connect Time
Apx. 2 seconds
Stand-by Time
365 days
Charge Time
≤ 2 hours
Uninterrupted Work Time
Up to 500 hours
Lithium Battery Capacity
300 mAh
Frequency Band
2400 to 2483.5 MHz
Maximum Radio-frequency power
0 dBm

Product Overview
①Power indicator: Turns green for 3 seconds.
Caps Lock indicator: Green light is on.
②Bluetooth indicator: Flashes blue when pressing “Fn + C”.
③Charging indicator: Red while charging. Green when fully charged.
Low battery indicator: Flashes red when charging is required.
④Power Switch: Slide “on” to power on and “OFF” to power off the keyboard.
⑤Charging port: Only used for charging.
Keys and Function
Home
(Press and Hold for
Alexa)
Search for
Back
Open file folder
Brightness -
Brightness +
Previous track
Play/Pause
Next track
Volume -
Volume +
Lock screen
Open Silk
E-mail
Fn+
Touchpad
on/off

Touchpad Function
Gesture
Finger action
Function
1-finger tap
Left-Click
1-finger slide
Move cursor
1-finger double-click and
hold
Drag and Drop
2-fingers tap
Right-Click
2-fingers vertical/horizontal
movement
Scroll / Pan
3-fingers slide up
See all open windows
3-fingers slide down
Show the desktop
3-fingers slide to the left
Switch between open
windows
3-fingers slide to the right
Switch between open
windows
Troubleshooting
If your device does not respond to the keyboard, try the following.
1. On your Fire HD tablet, navigate to “Settings > Connected Devices >
Previously connected devices” and delete any entries for unused Bluetooth
devices including “Fintie Keyboard”.
2. Restart your device.
3. Turn your keyboard off and back on.
4. Forget and re-pair your keyboard.
5. If your keyboard does not establish or maintain a Bluetooth connection, reset
the Bluetooth module by charging your keyboard.
6. If your keyboard does not operate correctly after charging it, please contact
your authorized retailer.
Safety Tips
• Do not place heavy objects on the keyboard.
• Do not disassemble the product.

• Keep the product away from oils, chemicals and organic liquids.
• Use only a damp, soft cloth, like microfibre, to wipe the keyboard.
• Dispose of the battery according to local laws.
• Keep the product away from sharp objects.
***** For UK customers only *****
Recycling Your Old Electricals Is Easy!
Recycle your electrical and electronic devices for free at your local recycling
centre. To find your nearest centre, visit www.recycle-more.co.uk and type in your
postcode.
Why Recycle?
Unwanted electrical equipment is the UK’s fastest growing type of waste.
Many electrical items can be repaired or recycled, saving natural resources and the
environment. If you do not recycle, electrical equipment will end up in landfill
where hazardous substances will leak out and cause soil and water
contamination–harming wildlife and also human health.
We’re proud to support your local authority in providing local recycling facilities
for electrical equipment.
To remind you that old electrical equipment can be recycled, it is now marked
with the crossed-out wheeled bin symbol. Please do not throw any electrical
equipment (including those marked with this symbol) in your bin.
What is WEEE?
The Waste Electrical or Electronic Equipment (WEEE) Directive requires
countries to maximise separate collection and environmentally friendly processing
of these items.
How Are We Helping?
In the UK, distributors including retailers must provide a system which allows all
customers buying new electrical equipment the opportunity to recycle their old
items free of charge. As a responsible retailer, we have met the requirements
placed on us by financially supporting the national network of WEEE recycling
centres established by local authorities. This is achieved through membership of
the national Distributor Take-back Scheme (DTS).
To find more information on WEEE recycling and to locate your nearest recycling
centre, please visit www.recycle-more.co.uk.

IC Caution
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Contact Us
Website: www.fintie.com
E-mail: [email protected]
North America
Tel: [phone]
(Monday-Friday: 9:00 AM – 5:00 PM EST)
Europe
Tel: [phone]
(Monday-Friday: 9:00 AM – 5:00 PM CET)
Manufacturer
Shenzhen The South Magic Co., Ltd
No.27 Da Fa Road, Ban Tian Street, Long Gang District
Shen Zhen, China 518100
Amazon, Fire and all related marks are trademarks of Amazon.com, Inc. or its
affiliates.

This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
The device has been evaluated to meet general RF exposure requirement. The
device can be used in portable condition without restriction.
IC Caution
This device contains licence-exempt transmitter(s)/receiver(s) that comply
with Innovation, Science and Economic Development Canada’s licence-exempt
RSS(s). Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may
cause undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est
conforme aux CNR d’Innovation, Sciences et Développement économique
Canada applicables aux appareils radio exempts de licence. L’exploitation est
autorisée aux deux conditions suivantes :
(1) L' appareil ne doit pas produire de brouillage;
(2) L' appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d' en compromettre le fonctionnement.
FCC Warning
