FINTIE EB0007X User manual

Wireless Keyboard
User Manual

Pairing Steps
Step 1. Switch On/Off to On to turn your keyboard on.
Step 2. Press the “Fn + C” keys together to enter pairing mode.
Step 3. Verify your device’s Bluetooth® settings are on.
Select Settings > Bluetooth > On.
Step 4. Select “Pair new device”.
Step 5. Select “Fintie Keyboard” from your device’s list of available devices to
complete pairing.
Step 6. The Bluetooth pairing indicator will turn off after your device has paired
successfully.
Sleep Mode
The keyboard will enter sleep mode after being idle for 30 minutes. Press any key
to wake the keyboard up. Wait up to 2 seconds for the keyboard to reconnect
with the wireless devices before starting to type.
Charging Your Keyboard
1. Plug the Type-C end of the charging cable into the keyboard and the other
USB end into your preferred USB charger. (USB charger is not included.)
2. When charging, the power indicator will turn red. Generally, it takes
approximately 4 hours for a full charge. (Output: DC 5 V/500 mA.)
Package Contents
1 x Keyboard
1 x USB-C Charging Cable
1 x User Manual
Specifications
Bluetooth Version
BLE 5.0
Operating Range
Up to 10 metres
Working Voltage
3.0-4.2 V
Working Current
1 mA
Charging Current
200 mA
Sleeping Current
0.01 mA
Re-connect Time
Apx. 2 seconds
Stand-by Time
365 days
Charge Time
≤ 4 hours
Uninterrupted Work Time
400 hours
Lithium Battery Capacity
500 mAh
Frequency Band
2402 to 2480 MHz
Maximum Radio-frequency power
0 dBm

Product Overview
① Power indicator: Turns blue for 3 seconds.
Bluetooth indicator: Flashes blue when pressing “Fn + C”.
Caps Lock indicator: Blue light is on.
② Charging indicator: Red while charging.
Green when fully charged.
Low battery indicator: Flashes red when charging is required.
③ Charging port: Only used for charging.
Keys and Function
Home
(Press and Hold for
Alexa)
Search for
Back
Open file folder
Brightness -
Brightness +
Previous track
Play/Pause
Next track
Volume -
Volume +
Lock screen
Open Silk
E-mail
Fn +
Split screen
Troubleshooting
If your device does not respond to the keyboard, try the following.
1.
On your wireless devices, navigate to “Settings > Connected Devices >
Previously connected devices” and delete any entries for unused
Bluetooth devices including “Fintie Keyboard”.
2. Restart your device.
3. Turn your keyboard off and back on.
4. Forget and re-pair your keyboard.
5. If your keyboard does not establish or maintain a Bluetooth connection, reset
the Bluetooth module by charging your keyboard.
6. If your keyboard does not operate correctly after charging it, please contact
your authorised retailer.
Safety Tips

• Do not place heavy objects on the keyboard.
• Do not dissemble the product.
• Keep the product away from oils, chemicals and organic liquids.
• Use only a damp, soft cloth, like microfibre, to wipe the keyboard.
• Dispose of the battery according to local laws.
• Keep the product away from sharp objects.
***** For UK customers only *****
Recycling Your Old Electricals Is Easy!
Recycle your electrical and electronic devices for free at your local recycling
centre. To find your nearest centre, visit www.recycle-more.co.uk and type in
your postcode.
Why Recycle?
Unwanted electrical equipment is the UK’s fastest growing type of waste.
Many electrical items can be repaired or recycled, saving natural resources and
the environment. If you do not recycle, electrical equipment will end up in landfill
where hazardous substances will leak out and cause soil and water
contamination–harming wildlife and also human health.
We’re proud to support your local authority in providing local recycling facilities
for electrical equipment.
To remind you that old electrical equipment can be recycled, it is now marked
with the crossed-out wheeled bin symbol. Please do not throw any electrical
equipment (including those marked with this symbol) in your bin.
What is WEEE?
The Waste Electrical or Electronic Equipment (WEEE) Directive requires countries
to maximise separate collection and environmentally friendly processing of these
items.
How Are We Helping?
In the UK, distributors including retailers must provide a system which allows all
customers buying new electrical equipment the opportunity to recycle their old
items free of charge. As a responsible retailer, we have met the requirements
placed on us by financially supporting the national network of WEEE recycling
centres established by local authorities. This is achieved through membership of
the national Distributor Take-back Scheme (DTS).
To find more information on WEEE recycling and to locate your nearest recycling
centre, please visit www.recycle-more.co.uk.

FCC Warning
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by
manufacturer could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
The device has been evaluated to meet general RF exposure requirement. The
device can be used in portable condition without restriction.
IC Caution
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may
cause undesired operation of the device.
