FireMagic Echelon Diamond "A" Series User manual

REV 1 - 1610040810 L-C2-407
Fig. 3-2
CORRECT
PLACE GRILL SO PREVAILING WIND
BLOWS TOWARD FRONT OF GRILL
Stand Alone Outdoor
Gas Grill
Quick Start Guide
INSTALLER: Leave these instructions with consumer. CONSUMER: Retain for future reference.
CAUTION: For your safety read the installation instructions and owner’s manual provided with the grill.
This grill must be installed in accordance with local codes and ordinances, or, in the absence of local codes, with either the latest National Fuel Gas Code (ANSI
Z223.1/NFPA 54), and Natural Gas and Propane Storage and Handling Installation Code (CSA-B149.1).
This appliance and its individual shutoff valves must be disconnected from the gas-supply piping system when testing the system at pressures in excess of ½ psig.
This appliance must be isolated from the gas-supply piping system by closing its dedicated manual shutoff valve during any pressure testing of the gas-supply
system at pressures up to and including ½ psig.
WHEN INSTALLING AND OPERATING THIS APPLIANCE WITH PROPANE (L.P.) GAS, ALL INSTRUCTIONS AND WARNINGS INYOUR OWNER’S MANUAL
MUST BE OBSERVED. FAILURE TO DO SO MAY RESULT IN A FIRE OR EXPLOSION CAUSING SERIOUS INJURY OR DEATH.
This grill is designed for outdoor use only. DO NOT use this grill inside a building, garage, or enclosed area (see paragreaph below). DO NOT use this
grill in or on a recreational vehicle or boat.
A minimum 5 foot clearance is required between the countertop and the overhead construction. When installed under combustible overhead construction, the area
above the cooking surface of the grill must be covered with an exhaust hood. The exhaust hood provides the protection for the combustible overhead construction.
DO NOT use this appliance under unprotected combustible overhead construction.When installed under overhead non-combustible construction, an exhaust
hood is highly recommended. When using an exhaust hood: the area above the cooking surface of the grill must be covered with a hood larger than the cooking
area of the grill, and with a minimum of 1200 CFM (cubic feet per minute) for proper outdoor application.
2-Unpacking
Carefully unpack the grill, removing all packing material and protective film. Verify that all
parts have arrived undamaged by consulting the parts list in the owner’s manual. Remove
foam packed hardware from oven area. (See Fig. 2-1.)
Consult the parts list in the owner’s manual. If any parts are missing or damaged,
immediately contact the Fire Magic dealer before beginning installation.
Important: The 2 shipping screws must be removed prior to removing the unit from
the wooden pallet. The screw located on the bottom left side of the unit is
accessed by opening the door. The screw located on the bottom right side of
the unit is accessed by removing the lower drawer.
To remove the drawer; pull it completely out. Release the drawer from the
drawer slides by pressing the black lever down on the right side, and up on
the left side.
Fig. 2-1
1-Safety
Lift out foam packed hardware
Remove plastic
zip-ties
3-Installation
Location
Locate the grill on a flat level surface. Refer to the INSTALLATION
REQUIREMENTS section of your grill owner’s manual for complete details.
CAUTION: Wind blowing into or across the rear oven lid vent (Fig.
3-1) can cause poor performance and/or dangerous
overheating. Orient the grill so that the prevailing wind
blows toward the front of the grill (Fig. 3-2).
CAUTION: To prevent dangerous overheating, the rear of the unit must have
a minimum clearance of 4” from any non-combustible wall.
YOU MUST PROTECT REAR OVEN
VENT FROM PREVAILING WIND
Rear oven lid vent
INCORRECT
Fig. 3-1
ReRearar oovevenn lilidd veventnt
Ventilation diagram
Fig. 3-5
To connect the regulator/
hose assembly to the
propane-gas cylinder valve
fitting: Press the hand nut
on the regulator over the
Acme thread fitting on the
cylinder valve. Turn the hand
nut clockwise to engage the
threads and tighten until
snug.
UL
Fig. 3-4 Type I Acme thread quick coupler
Vent
QCC
Type 1
valve
Brass Acme
thread fitting
Liquid level
indicator
(optional)
Hand nut with
Acme thread
Regulator
Hose
Hand wheel
Pressure
relief
valve
Connect Gas supply
These quick start instructions assume a
propane cylinder configured unit. See main
instructions for natural gas or household
propane configured units.
Place approved propane 20 lb cylinder in
tank tray and lock holder in position (Fig. 3-3).
Connect quick coupler hose and regulator
supplied with unit to propane cylinder (Fig.
3-4).
Turn all burner control knobs to the OFF
position. Open the main cylinder valve. Then
carefully check all gas connections for leaks
with a brush and half-soap/half-water solution
before lighting. NEVER USE A MATCH OR
OPEN FLAME TO TEST FOR LEAKS.
Proper grill airflow must be maintained as
shown in Fig. 3-5.
Fig. 3-3
Quick
coupler
Propane
cylinder (tank)
Sideburner
shelf (if
equipped)
Tool holder Paper towel
holder
Backburner
cover (if
equipped)
Tank tray latch
ECHELON
diamond “A” series
Installation must be performed by a qualified professional service technician.

REV 1 - 1610040810 L-C2-407
4-Grill Setup
Fig. 4-1
Cooking grid
Flavor grid
(not with IR)
Backburner
cover
Warming
rack
Cotter
pin
Rotisserie
rod storage
ring
6-Propane Safety
Gas Cylinders
IMPORTANT: READ AND FOLLOW ALL WARNINGS PROVIDED WITH THE PROPANE-GAS CYLINDER.
READ ALL SAFETY INSTRUCTIONS AND WARNINGS REGARDING THE USE OF PROPANE GAS FOUND IN
YOUR OWNER’S MANUAL.
Sideburner
lid
Parts Placement Checklist
Place the following items according to their position and orientation in
Fig. 4-1:
Flavor grids, cooking grids, heat zone dividers, backburner cover,
warming rack, and meat probe.
Leave pre-installed E-burners in place to maintain proper alignment.
Backburner Cover
Hook the backburner cover over the top of the backburner to protect
the backburner from grease, dust and dirt when it is not in use. Remove
before use.
Warming Rack
The warming rack comes pre-installed. Remove zip ties before use.
Consult the owner’s manual to remove or replace.
Charcoal / Smoker Drawer (if equipped)
The basket is for use directly above a main burner. Consult the owner’s
manual for complete installation and operation.
Shelf/Sideburner (if equipped)
Align the four (4) holes in the shelf with the four (4) holes in the side of
the cart while aligning and engaging the burner venturi with the orifice
(Fig. 4-2). Insert the four (4) screws (provided) into the holes and tighten.
Connect the spark wire to igniter electrode (Fig. 4-2). Open sideburner
lid, set cap on burner, and set grid into shelf.
Screws
Igniter
electrode
Air shutter
Orifice
Spark
wire Fig. 4-2
Venturi
Note: For infrared burner equipped
grills; see detailed instructions
included in your owner’s manual.
Fig. 5-2
Left main burner
control knob
Right
main burner
control knob
Center right main burner
control knob
Center left main
burner
control knob
Right backburner
control knob
(if equipped)
Left
backburner
control knob
(if equipped)
Pull-out drip
tray
Drip tray
liners
Drip tray (with
lighting instructions)
5-Test
Note: This unit must be connected to 120VAC power for electronic lighting.
1. Open lid(s) or remove cover(s) from burner(s) to be lit.
2. Turn all gas control knob(s) to their OFF position(s).
3. Turn on the gas at its source.
Note: DO NOT turn on more than one valve at a time for either electronic or manual lighting.
4. Depress the desired control knob for 5 seconds, then, while pressing turn it counterclockwise to the
HI LIGHT position. Once the burner lights, release the knob.
CAUTION: If a burner does not light within five (5) seconds of turning on the control knob, depress
the knob and turn it to the OFF position. WAIT FIVE (5) MINUTES before repeating
step 4. If you smell gas, follow the instructions on the cover of the grill owner’s manual.
If the burners still do not light after several attempts, refer to the grill owner’s manual
for manual lighting.
5. Repeat step 4 for each additional burner to be lit.
Door
Drawers
Sideburner
control knob
WHEN OPERATING THIS
APPLIANCE WITH PROPANE, ALL
INSTRUCTIONS AND WARNINGS
MUST BE OBSERVED. FAILURE TO
DO SO MAY RESULT IN A FIRE OR
EXPLOSION CAUSING SERIOUS
INJURY OR DEATH.
For your convenience and safety;
when the control knob is in the
ON position, the gas flow indicator
will change from blue to red. (Red
indicates gas flow.) See Fig. 5-1.
Fig. 5-1 - Burner valve control knob
OFF
HI
LIGHT
LOW
TO TURN OFF
T O TURN ON
Read setting
here
HIGH to
LIGHT
Read setting here
(OFF position shown)
To Turn OFF
To Turn ON
Use
HI (high)
to light
Press
knob in
to turn
Gas Flow
Indicator
Light
switch
E-burner *
(comes pre-
installed)
*The burner ports
and carry-over slots
must be kept clean to
ensure proper ignition
and operation.
The light switch is push button operated,
and is located on the right side of the
control panel (see Fig. 5-2). It controls the
power to all lights.
Replacement parts can
be ordered from your
local Fire Magic dealer.
Charcoal/smoker
basket
