Fireplace 700 D User manual

TYPICAL JETMASTER FREE STANDING INSTALLATION INSTRUCTIONS
WOOD / GAS
WOOD INSTALLATION TO COMPLY WITH AS/NZS2918:2001
7/2013
1.FS.1A
IMPORTANT: Read all instructions carefully before starting installation. Failure to follow these instructions
may result in a fire hazard and will void the warranty

Table 1
Fig. 1
A
A1
A2
Jetmaster
B
C
20
E
F
H
I
JK
L*
100
N
25
M
F
F
25
O
40
min 1300 mm
12
125 125
min min
D
E
G
Solid Fuel
700 D
A1100
A1 800
A2 700
B440
C890
D830
E75**
F225
G650
H700
I300
J125
K90
L* 480*
M250
N275
O325
Drawing not to scale
FREE STANDING DIMENSIONS
** A minimum 75mm thickness refers only
to Hebel Block.
Minimum 100mm thickness required if
poured concrete on heat sensitive oor.
If installed on a concrete oor, suggest to
differentiate the oor protector area to rest
of oor surface.
Fig 1,2,3,4 and Table 1,2,3 relate to installations with tested ue
systems, as per AS/NZS 2918:2001 - Appendix F, with a ceiling
angle between 0° - 30° inclusive.
Note: For installations with a ceiling angle greater than 30°, refer
to Fig. 5 & 6 and AS/NZS 2918:2001 4.6.3(b)
*Ceiling Plate may vary in size depending
on ceiling angle. Please specify ceiling pitch
prior to ordering the ceiling plate
1.FS.1B

PARALLEL POSITIONING
H
A
D
E
100
G
C
H
B
C
F
Solid Fuel
Description 700 D
AMin. distance from ue centre to side wall 650
BMin. distance from ue centre to back wall 302.5
CMin. distance from rebox opening to oor protector lateral side 200
DMin. Floor Protector width 1100
EMin. side clearance to combustible wall 300
FMin. Floor Protector depth 300
GMin. overall oor protector depth 940
HMin. side clearance to combustible material not protruding from
the front of the free standing cabinet 50
Table 2
Drawing not to scale
Fig. 2
1.FS.1C

50
¯
A
B
C
D
E
50
F
G
B
C
E
A
CORNER POSITIONING (45˚)
Solid Fuel
Description 700 D
AMin. distance from ue centre to side wall 582
BMin. distance from rebox opening to oor protector lateral side 302.5
CMin. oor protector dimension 1422
DMin. oor protector front width 1100
EMin. Floor Protector projection from wall 644
FMin. Floor Protector depth 300
GMin. overall oor protector depth 1460
Table 3
Fig. 3
Drawing not to scale
1. If a separate oor protector is being used position now. Place the rebox on the oor protector
to suit the minimum installation clearances. (See Fig 2 or 3).
2. Slide the cabinet over the rebox, ensuring the tabs are aligned and the cabinet is secure.
3. The cabinet is equipped with 2 x angle brackets located at the rear to seismically restrain the
rebox and the oor protector to the oor.
4. Fit 2 x 6mm xings suitable for the oor material. DO NOT over tighten.
FIREBOX INSTALLATION - WOOD
1.FS.1D

FLUE SYSTEM INSTALLATION - WOOD
Note These instruction apply to 225mm dia ue pipe systems as tested to
AS/NZS 2918:2001
1. Either locate the appliance in position or by measuring at the ceiling mark the ue pipe centre
position. Check that the outer casing is unobstructed through the attic space or roof area.
2. Spike the centre with a nail. Transfer this position to the next surface above. Plumb bob/laser.
3. Cut out the ceiling penetration hole – square or rectangle – short axis equals outer casing
diameter plus 50mm, long axis as required. See Table 4 . Perform the same at the roof
penetration.
4.
Frame out the hole with minimum 75 x 50 timber or as required for roong material. Minimum
requirement at roof penetration see NZ Building Code E2 Acceptable Solution (from 01/07/05).
5. Install the outer casing so that :-
(i) lower end is ush with the underside of the ceiling material and
(ii) with the addition of metal “L” brackets, afx to the outer casing at 90 degrees secure the
outer casing centrally to the ceiling and roof nogs. Alternatively substitute the “L” brackets for
25mm thick non heat sensitive packers. Secure the outer casing through the packers with hori-
zontal xings to the nogs. Refer to the General Instruction for termination height. The option of
outer casing slips to be taken into account.
6. Flash the outer casing to the roof material with the appropriate approved ashing.
7. If using an outer/inner casing combination, now install the inner casing ensuring it extends a
minimum 200mm above the high side of the roof penetration. If not using a combination see
‘11’ below.
8. Refer to Firebox Installation, points 1 & 2.
9. Prepare the ceiling plate and place upside down over the ue spigot.
10.Install the ue pipes by preferred method – either up or down the outer casing. Afx each
length per the notes in General Instructions (above). Extend the ue pipe above the outer
casing to suit the casing cover/cowl assembly.
11. If the inner casing has not been installed, install now. Refer to 7 above for minimum height.
12.Install the cowl assembly, i.e. Top spacer, casing cover and cowl.
13.Position and secure the ceiling plate with the screws and spacers.
14.Wipe the ue pipe to remove nger marks.
15. Refer to Firebox Installation, points 3 & 4.
GENERAL INSTRUCTIONS FOR FLUE SYSTEM
▪ Flue pipe installed crimp/narrow end down
▪ Outer casings installed crimped/narrow end up. (Critical when exposed above the roof)
▪ Inner casings - direction not critical
▪ Flue pipes - seal all joints including rebox spigot.
- x with a minimum of 3 stainless steel rivets
▪ Flue pipe spacers - afx to ue pipe
▪ Flue system termination point - Refer to AS/NZS 2918:2001 4.9.1, see Fig. 9.
▪ Façade or Chase systems - same rule applies as above.
▪ Roof penetration and ashing method refer to NZ Building Code E2.(From 01/07/05)
1.FS.1E

Inner casing 200 mm
above roof line
ADD Cowl
Casing cover
Spider bracket
Roof Line
Outer flue pipe casing
Inner Flue pipe casing
Internal swage
Flue pipe
Timber nogs
Ceramic Spacers and screws
Ceiling plate
Jetmaster Freestanding
Floor protector
Jetmaster
25
12.5
12
Floor Protector
Jetmaster Freestanding
Flue Pipe
Ceiling Plate
Ceramic spacers and screws
Internal Swage
Inner Casing
Outer Casing
Inner Casing 200mm
above roof line
Roof Line
Approved Flashing
Spider Bracket
Casing Cover
ADD Cowl
FLUE PENETRATION - WOOD
Drawing not to scale
Fig. 4
Tested ue systems, as per AS/NZS 2918:2001
oversized casing cover
is necessary
Non combustible material
Hebel block or 12mm
Promina board or similar
under the ashing
minimum 25mm gap
between ue pipe casing &
combustible material
1.FS.1F

A
A
100
12
150
Fig. 5
FLUE PENETRATION - WOOD
Un-tested ue systems, as per AS/NZS 2918:2001, 4.6.3(b)
A
A
100
12
100
Fig. 6 ADD Cowl
Casing Cover
Spider Bracket
Approved Flashing
Greater than 30°
AS/NZS2918:2001
Un-tested ue with sloped ceiling
penetration greater than 30° from
horizontal
4.5.1.2(b) = 50mm clearance to
combustible material
A = 62.5mm for 225mm Ø ue pipe
4.6.3(b)
Fig 4.6 = downward distance of
casing and 3 x ø ue distance of
the ceiling plate
ADD Cowl
Casing Cover
Spider Bracket
Approved Flashing
Greater than 30°
3 x Ø ue pipe
AS/NZS2918:2001
Un-tested ue with sloped ceiling
penetration greater than 30° from
horizontal
4.5.1.2(b) = 50mm clearance to
combustible material
A = 62.5mm for 225mm Ø ue pipe
4.6.3(b)
Fig 4.6 = 3 x ø ue from active ue
to heat sensitive surface
3 x Ø ue pipe
ue pipe
Ø
ue pipe
Ø
1.FS.1G

3000
or less
3000
More than 3000
600 min.
3000
Any nearby structure
increase from 1000mm
minimum until clear within
3000mm of flue top
increase as necessary
until nothing within
3000mm of flue top
Table 4
Fig. 9
FLUE SYSTEM MINIMUM TRIM OUT
X
Y
X
Y
Flue Pipe
Min. 25mm Clearance
Min. 25mm Clearance
Flue Pipe Casing
Fig. 8
Wood MODEL FLUE SYSTEM MINIMUM TRIM OUT DIMENSION
X (min) Y (min)
700 D 225/275/325 375 375
MINIMUM HEIGHT OF FLUE SYSTEM EXIT - WOOD
1.FS.1H
As per AS/NZS 2918:2001 4.9.1 Fig 4.9

AIR REPLACEMENT - WOOD
MINIMUM VENT SIZE (x2)
Square Design (L x H) Rectangle Design (L x H)
100 x 100 200 x 50
The Fireplace Ltd species that allowances must be made for air replacement vents to be located near the
replace, to aid combustion and reduce the possibility of back venting. Refer to Table 5 for air vent sizing
and suggested location see Fig 9.
Fig. 9 - Location points A,B,C are suggested combinations. A minimum of one pair of air vents is
recommended or one large vent, as per location point C.
Allowance to be made for minimum 2 inlet ducts from outside to internal vent location.
A
C
A
BB
Table 5
Fig. 10
1.FS.1I

AS/NZS2918:2001 General Notes
WARNINGS:
WARNING: THE APPLIANCE AND FLUE SYSTEM SHALL BE INSTALLED IN ACCORDANCE WITH
AS/NZS2918 AND THE APPROPRIATE REQUIREMENTS OF THE RELEVANT BUILDING CODE OR
CODES.
CAUTION: MIXING OF APPLIANCE OR FLUE SYSTEM COMPONENTS FROM DIFFERENT SOURCES
OR MODIFYING THE DIMENSIONAL SPECIFICATION OF COMPONENTS MAY RESULT IN HAZARD-
OUS CONDITIONS. WHERE SUCH ACTION IS CONSIDERED, THE MANUFACTURER SHOULD BE
CONSULTED IN THE FIRST INSTANCE.
CAUTIONS: CRACKED AND BROKEN COMPONENTS, e.g. GLASS PANELS OR CERAMIC TILES, MAY
RENDER THE INSTALLATION UNSAFE.
WARNING: DO NOT USE FLAMMABLE LIQUIDS OR AEROSOLS TO START OR REKINDLE THE
FIRE.
WARNING: DO NOT USE FLAMMABLE LIQUIDS OR AEROSOLS IN THE VICINITY OF THIS
APPLIANCE WHEN ITS OPERATING.
WARNING: DO NOT STORE FUEL WITHIN HEATER INSTALLATION CLEARANCES.
WARNING: WHEN OPERATING THIS APPLIANCE AS AN OPEN FIRE USE A FIRE SCREEN.
CAUTION: THIS APPLIANCE SHOULD BE MAINTAINED AND OPERATED AT ALL TIMES IN ACCORD-
ANCE WITH THESE INSTRUCTIONS.
CAUTION: THE USE OF SOME TYPES OF PRESERVATIVE-TREATED WOOD AS A FUEL CAN BE
HAZARDOUS.
1.FS.1L
