Overview
The SafeAirTM 250-CO carbon monoxide (CO) detector is an accu-
rate and reliable means of alerting building occupants of potentially
dangerous levels of CO in the protected area. The internal electro-
chemical sensor communicates with a sophisticated on-board
microprocessor that accurately tracks CO levels over time.
This commercial-grade detection technology results in quick
response, reliable sensing, fast reset time, and superior false alarm
immunity. Its small size allows the 250-CO to blend inconspicu-
ously with any decor, and its smooth contoured design is compat-
ible with both residential and commercial environments.
Unaffected by normal indoor temperature variations, the 250-CO
actually self-adjusts for environmental changes and operates reli-
ably under a wide variety of conditions. It also monitors its own
performance and automatically compensates for sensitivity drift
throughout the course of its service life.
The 250-CO features the SafeTest™ functional test feature, which
facilitates testing with real CO gas. SafeTest meets the functional
test requirement in NFPA 720, 2009/2012 editions.
Like all CO detectors, the 250-CO has a limited service life. When
it approaches this point, the 250-CO’s six-year end-of-life timer
automatically triggers a warning, locally, at the control panel, and
optionally, at a central monitoring station, indicating that the device
must be serviced.
An integrated temporal 4 sounder provides local signaling capabil-
ity for the 250-CO, and it easily interfaces with any listed intrusion or
fire alarm system by means of its 150mA output relay. Its low current
draw results in little additional demand on the system power supply.
The 250-CO fully complies with the latest UL 2075 requirements
which allows for installation in a wide range of both residential and
commercial settings.
Standard Features
• SafeTest™ enables a full functional test with spray of real CO
gas
• Electro-chemical sensing technology
• Transmits sensor end-of-life to the control panel and central
station if the system is monitored
• Fully listed to the latest UL 2075 CO standard for residential or
commercial occupancies
• Built-in trouble/power supervision relay
• Six-year sensor
• Self-diagnostics keep the device operating optimally through-
out its service life
• 12 or 24VDC operation and 150mA relay contact configurable
for normally open or normally closed operation
• Large SEMS terminals ease wiring installation 14 to 22 AWG
• One-touch TEST/HUSH button simplifies local operation
• Integrated 85 dBa temporal 4-sounder for local notification
• On-board LED provides local alarm and trouble indication
• Inconspicuous footprint and attractively contoured design
• Adapter plate makes replacing ESL 240-COe CO detector
simple
12/24VDC
Carbon Monoxide
Detector with SafeTestTM
250-CO

Page 2 of 4 DATA SHEET FX85001-0618
Not to be used for installation purposes. Issue 4
Application
The SafeAir 250-CO Carbon Monoxide Detector is intended for
ordinary indoor-dwelling unit applications in both residential and
commercial occupancies, including single/multiple family residential
occupancies, hotel rooms, dorm rooms, and other areas approved
by the authority having jurisdiction (AHJ). The 250-CO detec-
tor can connect to either UL 985 (Household Fire Warning) or UL
864 (Commercial Fire) control panels. It is not intended for use in
industrial applications such as gasoline refineries or parking ga-
rages, which require different listings. The 250-CO detector has an
optional adapter mounting plate for the ESL 240COe CO detector.
To purchase the plate order P/N 250-COPLT-5PKG.
Selecting a suitable location is critical to the operation of CO
detectors. Install the 250-CO in accordance with NFPA 720 Stan-
dard for the Installation of Carbon Monoxide (CO) Detection and
Warning Equipment. Place wall-mounted detectors at least 5 ft.
(1.5 m) up from the floor. For ceiling mounted applications, place
the detector at least 1 ft. (0.3 m) from any wall.
Recommended CO detector locations:
9Within 10 ft. (3 m) of all sleeping areas, including areas such
as hotel rooms and dorm rooms.
9In a suitable environment: areas with a temperature range of
32 to 104°F (0 to 40°C) and with a relative humidity range of 0
to 90% noncondensing.
9In residential dwellings, locate detectors in every bedroom,
within 10 ft. (3 m) of sleeping areas, and on each level. At a
minimum, place one detector outside the sleeping areas.
Recommended locations for CO detectors
Always check with your local building codes,
legislation, and Authority Having Jurisdiction
for specific CO location requirements in your area
Recommended CO detector locations in commercial occupancies:
9On every habitable level of the building based on an engineer-
ing evaluation considering potential sources and migration of
carbon monoxide
9In any area required by local building codes, legislation, or
Authorities Having Jurisdiction
9On a firm, permanent surface
Do not install the CO detector:
8Within 10 ft. (3 m) of a fuel-burning appliance
8Near air conditioners, heating registers, and any other ventilation
source that may interfere with CO gas entering the detector
8Where furniture or draperies may obstruct the airflow
8In a recessed area
Operation
SafeTest functional test: This test facilitates the use of CO test
spray to verify the correct operation of the detector. Functional
testing is mandatory per NFPA 720 as of January 2012. The
SafeTest mode is activated by pressing and holding the test/hush
button for 5-10 seconds. While in SafeTest mode, directing UL
classified CO testing spray at the sensor port will result in the acti-
vation of the alarm relay, and the sounder and red LED to activate
in a temporal-four pattern. Pressing and holding the test/hush will
exit SafeTest mode. Note: See 250-CO installation instructions for
information on approved CO test spray.
Distinct 85 dB temporal four-sounder alarm: The 85 dB
temporal-four sounder provides a distinctive alarm notification that
is easy to differentiate from smoke alarm notification devices. The
alarm beeps four times, rests five seconds and then repeats the
pattern.
Test/hush button: Use the test/hush button to test the alarm and
silence an activated alarm. Pushing the test/hush button silences
the integral sounder for five minutes. The red alarm light stays on
and if CO is still present after five minutes, the detector once again
sounds in the temporal-four pattern. The hush feature does not
operate at CO levels above 350 ppm (parts per million).
End of sensor life indicator: The detector uses both a flash-
ing green LED and intermittent sounder chirps to indicate that the
detector needs replacing. To silence the detector, push the test/
hush button. The detector also begins signaling a trouble when the
CO sensor is approaching end-of-life. When connected to a Listed
control panel, the trouble relay can report a trouble condition locally
at the panel and optionally at the central station, if the system is
monitored.
Common trouble relay: The trouble relay opens to indicate a
trouble condition upon lost power, CO sensor cell trouble, or cell
end-of-life.
Installation
The 250-CO Carbon Monoxide Detector is a four-wire device
designed to use a Class 2 output from a control panel or auxiliary
power supply Listed to UL 985 or 864 standards.
All wiring must conform to the NFPA 70 National Electric Code, UL
2075, NFPA 720, and applicable codes. Use 14 to 22 AWG wire.
WARNINGS: Connect the CO detector only to a zone dedicat-
ed exclusively for CO detection and that is monitored 24 hours
a day. Do not connect to an initiating circuit with fire or security
devices. Failure to properly install, test, and maintain a CO
detector may cause it to fail, potentially resulting in loss of life.
The 250-CO/240-COe adapter plate
Use the 250-COPLT-5PKG
adaptor plate when replacing
a 240-COe with a 250-CO
to cover the footprint of the
240-COe. For example, use
the plate to cover any paint
discoloration left behind from
the 240-COe.

Page 3 of 4 DATA SHEET FX85001-0618
Not to be used for installation purposes. Issue 4
Alarm
IDC (NO) End-of-line
device (pro-
vided by the
life safety
system)
PWR -
PWR +
End-of-line
device (pro-
vided by the
life safety
system)
Alarm
IDC (NO)
Supervisory
IDC (NC)
PWR -
PWR +
Alarm
IDC (NO)
Supervisory
IDC (NC)
End-of-line device
(provided by the life safety system)
End-of-line
device (pro-
vided by the
life safety
system)
PWR -
PWR +
NO C NC - + NO C NO C NC - + NO C
Configuration: Multiple devices, separate alarm, trouble zone
Configuration: Multiple devices, single zone
Configuration: Single device, single zone
Wiring

Page 4 of 4 DATA SHEET FX85001-0618
Not to be used for installation purposes. Issue 4
05-31-1205-31-12
North America
T 885-286-8889
Asia
T 852-2907-8108
F 852-2142-5063
Australia
T 61-3-9239-1200
F 61-3-9239-1299
Europe
T 32-2-725-11-20
F 32-2-721-40-47
Latin America
T 561-998-6100
F 561-994-6572
Specifications subject to change without notice.
© 2012 Interlogix.
All rights reserved.
interlogix.com
Specifications
Input voltage 12 or 24 VDC supplied by control panel or resettable auxiliary power
supply
Current consumption
Normal
Alarm
20 mA
40 mA (75 mA in test)
Alarm relay
Type
UL rating
150mA at 33 VDC
Form C
Zone
Common trouble relay
Type
UL rating
150mA at 33 VDC
Normally opened held closed with power applied
Common
CO alarm level 70 PPM = 60-240 min.
150 PPM = 10-50 min.
400 PPM = 4-15 min.
Sounder 85 dB with temporal 4 pattern
Compatible control panel Listed to UL 985 or 864 standard
Compatible electrical box North American 2½ in. (64 mm) deep 1-gang
Wire size 14 to 22 AWG (0.25 to 2.0 mm²)
Dimensions (W x L x D)
Detector
Adapter plate
3.1 x 4.6 x 1.3 in. (7.8 x 11.7 x 3.2 cm)
4.5 x 6.5 x 0.2 in. (11.4 x 16.5 x 0.5 cm)
Weight
Detector
Adapter plate
4.7 oz. (133 g)
1.6 oz (46 g)
Color White
Operating environment
Temperature
Relative humidity
32 to 104°F (0 to 40°C)
0 to 90%, noncondensing
UL rating Listed to ANSI/UL 2075 Standard
Ordering Information
Model Description
250-CO SafeAir Carbon monoxide detector, alarm & trouble relays, sounder,
end-of life signal, 12/24VDC
250-COPLT-5PKG Adaptor plate for use when replacing the 240-COe CO detector with
a 250-CO
CO Gas Test Spray Functional CO gas test spray Solo C-6 available from SDI
(www.sdifire.com) through security distribution.
