Bosch Door/window contact II Operator's manual

Door/window contact II
quick instructions
Product description
The door/window contact II detects open doors
and windows for improved security and energy
efficiency.
Description of the symbols
Warning!
Note about hazards
Note:
Additional
important information
Note about the installation video
Safety instructions
▶ Do not charge used batteries, and do not
attempt to reactivate them using heat or
other means. Do not short-circuit batteries.
Do not expose batteries to strong sunlight. Do
not throw batteries into fire!
There is a risk of explosion!There is a risk of explosion!
8-750-002-164

▶ Make sure the polarity is correct when
inserting the batteries! Only use batteries
of the same type. Drained batteries must
be removed from the device immediately.
Remove batteries from the device if it is not in
use for a long period of time.
Increased risk of leakage!Increased risk of leakage!
▶ The device is not a toy! Do not allow children to
play with it. Never leave the packaging material
lying around unattended. Plastic film and small
parts may pose a danger to children.
▶ Store small cells and batteries which could
be swallowed out of the reach of children.
Swallowing can result in burns, perforation of
the soft tissue and death. Severe burns can
occur within 2 hours after swallowing. In the
event that a cell or battery is swallowed, seek
medical assistance immediately.
▶ When remotely or automatically controlling a
device, it is not always possible to guarantee
that commands are actually executed or that
the correct device status is displayed in the
app and on other Smart Home display devices
because of external circumstances. This may
lead to material damage and/or personal
injury. Therefore, you must ensure to the
greatest extent possible that no person is
endangered at the time of remote operation
or automated control. Please take special
care when setting up or adjusting the remote
control or when using the automated control
and check the desired functionality at regular
intervals.

▶ Do not open up the device. It does not contain
any parts to be maintained by the user. If a
fault occurs, have the device checked by a
specialist.
▶ We accept no liability for material damage
or personal injury which is caused by
improper use or failure to observe the safety
instructions. In these cases, any guarantee
claim becomes void! We accept no liability for
consequential damage.
▶ This device may be used by children from 8
years of age and by persons with reduced
physical, sensory or mental capacities, or a
lack of experience and knowledge provided
these persons are supervised or have been
instructed in the safe use of the device, and
understand the corresponding risks.
▶ For safety and approval reasons (CE/UKCA),
the device may not be modified and/or no
changes may be made to the device without
authorisation.
▶ Any use other than that which is described
in the user manual is considered improper
and leads to the exclusion of guarantee and
liability.
▶ Do not use the device if it has damage visible
from the outside, for example, to the housing,
control elements or connection sockets, or if it
has a malfunction. If in doubt, please contact
our service team.

▶ Please note that the emergency phone number
in the app is not automatically called if the
device detects a hazard. You must always
make an emergency call if required!
▶ Please note that the device can only warn you
via your mobile device if this is switched on
and connected to the internet.
▶ Only use the device together with original
components and recommended products
from Bosch partners.
▶ With regard to the magnet supplied, maintain
a minimum distance of 10 cm to 15 cm from
a pacemaker. The magnets generate a field
which can interfere with the functioning of
pacemakers.

Product overview
4
1
5
7
6
3
2
Notes
▶ The range within buildings can differ
significantly from the range in open spaces.
In addition to the transmitting power and
the receiving properties of the receiver,
environmental factors such as humidity, as
well as the local structural situation, play an
important role.
▶ The device is only suitable for use in residential
environments.
▶ The device is only intended for private use.

Item Description
1Sensor unit
2Status LED
3Operating button
4Battery compartment
5Mounting plate
6Unlocking
7Magnet
You can also use the explanatory videos
and additional information on our
website as an additional aid for mounting,
especially the magnet mounting options,
installing, starting up or restoring the
factory settings on your Bosch Smart
Home door/window contact:
www.bosch-smarthome.com/rom/
door-window-contact-2

Start-up
Ensure that you have a Bosch Smart Home
controller and the Bosch Smart Home app and
have successfully configured both. Now start
the Bosch Smart Home app and select “Add new
device”. Follow the instructions in the app.
Manually triggering individual
automations
Pressing the operating button (3) for a short and
long period of time can be configured individually
in the app as triggers for automations.
Break function: Temporarily ignore sensor
status
Pressing the operating button (3) twice activates
the break function. After this is activated, the
status of the door/window contact is temporarily
ignored by the system for a one-time opening/
closing process or for a specific amount of time.
This function can be deactivated permanently in
the device settings in the app.

The status LED (2) shows the status of the door/
window contact using flashing codes.
Status LED Device status Recommended action
Flashes orange Tuning mode
(is active) or device
is communicating with
the controller
Please wait
Flashes green Tuning mode
(successful) or
transfer successful /
process confirmed
Flashes red Tuning mode
(not successful) or
process failed
If this is the first tuning attempt, please try
again. Otherwise reset the device to the factory
settings and contact the service department if
necessary.
Flashes orange
after the button is
pressed twice
Break function is active Open and close door/window 1x to end the
status or wait until the device ends the status
itself.
Continuously
flashes red
(every 15 s)
Fault detected
(e. g. battery status,
wireless connection)
Follow the instructions in the app (message
centre).

Resetting to factory settings
You can reset the device to its factory settings as
follows:
Remove the battery. While reinserting it, keep the
operating button (3) pressed until the status LED
(2) flashes orange. Release it briefly and press/
hold it again until the LED lights green. If the LEDs
light up red during the reset process, remove the
battery again and repeat the process. The device
then restarts. Please note that it can take a few
seconds until the door/window contact is ready
for operation again.
When resetting to factory settings, the
settings and information are only lost from
the device and not from the Bosch Smart
Home controller.
To re-configure the device, first delete it
in the device management section of the
Bosch Smart Home app and then add it
again in the usual configuring process.
Maintenance and cleaning
Removing or changing the batteryRemoving or changing the battery
To remove or replace the battery, activate the
unlocking (6) at the mounting plate (5) and then
remove the sensor unit (1). Remove the battery.
Take care to ensure the correct polarity when
replacing them.
The device does not require maintenance. Leave
any repairs to a specialist. Clean the device with a
soft, clean, dry and lint-free cloth. When cleaning,
do not use any cleaning agents containing
solvents.

Environmental protection and
disposal
Electrical or electronic devices which are
no longer usable must be collected
separately and disposed of via an
environmentally friendly recycling facility
(European Directive on Waste Electrical and
Electronic Equipment). Use your country’s
specific return and collection systems when
disposing of waste electrical or electronic
devices.
Used batteries do not go in the house-
hold waste! Dispose of them at your local
battery collection point!
Simplified declaration of conformity
Robert Bosch Smart Home GmbH hereby
declare that the radio equipment type
Bosch Smart Home BSEN-C2 corresponds with
the directive 2014/53/EU. The complete text of
the EU declaration of conformity is available via
the following web address:
https://eu-doc.bosch.com
Robert Bosch Smart Home GmbH hereby
declares that the radio system type
BSEN-C2 complies with Regulation 2017.
The full text of the declaration of conformity is
available at the following internet address:
https://gb-doc.bosch.com

Technical data
Device type designation BSEN-C2
Protection class IP45
Ambient temperature – 20°C … + 60°C
Max. humidity 85 %
(non-condensing)
Dimensions (W × H × D)
Sensor unit 22 × 75 × 23 mm
Magnet 10 × 20 × 3 mm
Weight
Sensor unit 22 g (without battery)
Magnet 5 g
Radio frequency band 2.4 – 2.4835 GHz
Radio protocol ZigBee 3.0
Max. transmitting
power
10 mW
Radio range in the open < 100 m
Software class A
Receiver category 2
Battery 1 × CR123A
Battery lifespan
(typical)
< 5 years
Technical modifications reserved

Spare parts
Order no. Description
8-750-0 02-148 Magnet, white
8-750-002-149 Magnet, anthracite
8-750-002-151 Magnet unit + 2 × spacer, white
8-750-002-150 Magnet unit + 2 × spacer, anthracite
Open source software
This Bosch Smart Home product uses open-
source software. License information for the
components used can be found on the cover
sheet for the attached documents.
Service information
Robert Bosch Smart Home GmbH
Schockenriedstraße 17
70565 Stuttgart-Vaihingen
Germany
ser[email protected]
@ www.bosch-smarthome.com/service
8-750-002-164 V001 01/2022
