SPECIFICATIONS
Igniter Class: Class 3 special
Approval: Factory Mutual
Output Energy: 12 joules per spark
Output Voltage: 2000 vdc
Input Voltage: 110/220 VAC, +/- 10%, 50/60 Hz
Input Power: 110 vac (2-A fuse); 220 vac (1-A fuse)
Spark Rate: 3 sparks per second
Spark Rod Length: 195 in. (495.3 cm) maximum
Spark Rod Diameter: 0.625 in. (1.6 cm)
Spark Tip Type: Surface gap (aircraft)
Spark Tip Length: 8 and 27 inches (20.3 and 68.6 cm)
Spark Tip Resistance: 200 to 600 ohms (center electrode to outer case)
Spark Tip Material: Stainless steel with a silicon carbide insulator
Maximum Recommended Tip Temperature: 537.8° C (1000° F)
Power Pack Temperature Ratings: -18° C to 57° C (0° F to 135° F)
Power Pack Enclosure: NEMA-4 approved cabinet (NEMA-4X optional)
Power Pack Dimensions: 10 in. high x 8 in. wide x 4.25 in. deep
(25.4 cm x 20.3 cm x 10.8 cm)
Power Pack Mount Holes: 10.75 in. x 6.0 in. (27.3 cm x 15.2 cm)
Field Conduit Hole Diameter: 0.88 in. (2.2 cm)
Power Cable: 12 gage, 3000 v, in 0.5-in. (1.3-cm) flexible conduit
Power Cable Lengths: 6, 9, 12, 15, 20, 25, 50 ft. (1.8, 2.7, 3.7, 4.6, 6.1, 7.6, 15.2m),
15 foot standard
Duty Cycle: 100% at temperature rating
OVERVIEW
1. Mount the power pack in a suitable location as far as possible from the burner front extreme
temperatures. Ensure that cable connectors are facing downward.
2. Carefully insert the HESI spark rod tip into the guide tube until the spark rod extends into the
primary ignition zone. With Fireye SureFire 20 gas igniters, position spark tip flush with front of
baffle plate.
3. If retraction assembly is supplied, manually or automatically exercise the retract assembly to
verify correct operation.
4. Once tip penetration is set, attach and tighten the locking device to the spark rod.
5. Connect cable assembly from the power unit to the spark rod. Tighten threaded connection.
6. Connect power input leads to H (hot), N (neutral), and G (ground) to terminal block 2 inside the
power pack.
7. Energize the power pack to test the spark tip. Observe proper operation.
