First Light T-MAX User manual

T-MAX
™
USER MANUAL

FIRST-LIGHT USA, LLC
205 S. Main Street
Seymour, IL 61875
Phone: [phone]
Fax: [phone]
Email: info@rstlight-usa.com
www.rstlight-usa.com
TABLE OF CONTENTS
Specications ............................................................................................................... 3
Battery Installation........................................................................................................ 4
Components ................................................................................................................. 5
Basic Functions ............................................................................................................ 6
Lockout/Ready Mode.............................................................................................. 6
Momentary Mode.................................................................................................... 7
Constant-On Mode ................................................................................................. 7
Cycle Control .......................................................................................................... 8
Ready Strobe Mode ............................................................................................... 8
Low Battery Indication .................................................................................................. 9
Finger Loop ................................................................................................................ 10
Steel Belt Clip..............................................................................................................11
Lifetime Limited Warranty........................................................................................... 12

2
Thank you for purchasing the First-Light USA T-MAX™ Tactical Light.
Please carefully review this manual prior to use.
IMPORTANT – PLEASE READ FIRST
The intense white light emitted by the primary white LED may cause temporary
blinding, regardless of the brightness level used. Use caution during operation.
Do not point light directly into eyes at any distance. Not for use by children.
LITHIUM BATTERY WARNING
Lithium batteries can be dangerous if used improperly. Never disassemble,
short circuit, recharge, or expose to water, re, or high temperatures. Never use
batteries of different ages, capacities, or brands together. Store separately and
properly dispose of batteries after use. Keep away from children.

3
SPECIFICATIONS
Lumen Output
700 Lumens (at the maximum brightness setting)
Batteries
● (2) CR123 3-Volt Lithium Batteries, ANSI: 5018LC, IEC: CR17345
● Run Time
Max: 2 hours
High: 4 hours
Medium: 16 hours
Low: 60 hours
NOTE: High quality, rechargeable CR123 batteries may be used to power the T-MAX™
Tactical Light. The user should identify the voltage capacity of any rechargeable
batteries prior to installing them into the T-MAX Tactical Light.
IMPORTANT: Never install any rechargeable CR123 batteries that exceed a
combined voltage of 8 volts as this will damage the internal circuitry and
void the warranty.
Environmental Specications
● Normal Operating Temperatures: (-20°F) to 120°F
● Waterproof

4
REPLACEMENT PARTS
To order replacement parts, please call 877.454.4450 or visit www.rstlight-usa.com.
BATTERY INSTALLATION
STEP 1. Remove battery cap. Insert two batteries “+” terminals rst
(as shown above).
STEP 2. Reinstall battery cap. Hand-tighten until snug.
STEP 3. Ensure batteries are properly installed by pressing any button on the control
panel. The red LED “lock” should illuminate indicating the light is in Lockout
Mode. If it does not, repeat Steps 1 and 2, ensuring both “+” terminals are
facing up.

5
COMPONENTS
CRENULATED BEZEL
BATTERIES
LAMP HOUSING
STEEL BELT CLIP
FINGER LOOP BATTERY
HOUSING/SLEEVE
CRENULATED
BATTERY CAP
CONTROL PANEL

6
Control Panel Diagram
CONSTANT-ON
CONTROL
LOCK / UNLOCK
INDICATOR
CYCLE CONTROL
MOMENTARY
CONTROL
BASIC FUNCTIONS
LOCKOUT/READY MODE
Lockout Mode prevents accidental illumination.
To unlock the light and enter Ready Mode,press
the Constant-On and Cycle Control
buttons simultaneously and release. The green
“unlock” indicator will illuminate signaling that
visible light modes are active.
To reenter Lockout Mode at any time during use,
press and hold the Constant-On and Cycle
Control buttons simultaneously for 1 second.
The red “lockout” indicator will illuminate.
CONSTANT-ON
CONTROL
CYCLE
CONTROL
LOCK / UNLOCK
INDICATOR

7
CONSTANT-ON
CONTROL
NOTE: While the primary white LED is
activated in Momentary Mode, Constant-On
Mode can be activated by simultaneously
pressing the Constant-On Control and
Momentary Control buttons then
releasing both buttons.
CONSTANT-ON MODE
The Constant-on Control button activates the
primary white LED and secondary color LEDs in
Constant-On Mode.
• To turn on the primary white LED from the
off position, press and hold the Constant-
On Control button until the white LED
illuminates then release.
• To turn on the secondary color LEDs from the
off position, press and release the Constant-On
Control button.
• To turn the light off, press and release the
Constant-On Control button.
MOMENTARY
CONTROL
MOMENTARY MODE
The Momentary Control button activates the
primary white LED at maximum brightness when
pressed. When released, the white LED turns off.
NOTE: To momentarily activate the secondary colored LEDs from
the off position, press and hold the Cycle Control button.
When released, the secondary LEDs turn off. The secondary
LEDs will illuminate at the last used Constant-On brightness level.

8
READY STROBE MODE
With light in Ready Mode, but not on, activate
strobe by pressing the Cycle Control button.
The strobe will activate as long as the Cycle
Control button is pressed.
With the light in Constant-On Mode, activate the
strobe by pressing and holding the Momentary
Control button with the base of the thumb.
Then press the Cycle Control button with the
front portion of the same thumb.
The Ready Strobe function can be activated
ONLY as a momentary function and cannot be
locked on.
NOTE: Upon exiting Ready Strobe Mode,
the light will default to the last used function.
CYCLE
CONTROL
MOMENTARY
CONTROL
CYCLE
CONTROL
CYCLE CONTROL
The Cycle Control button is used to adjust the
brightness level of the primary white LED while in
Constant-On Mode. Press and release the Cycle
Control button when the primary LED is illuminated
to select one of three brightness levels. The light will
default to the last used Constant-On brightness setting.

9
LOW BATTERY
When the battery nears the end of its useful life
the red Lock/Unlock indicator will begin to ash.
Once the useful life of the batteries has been
reached the T-MAX™ will begin to limit its output
in order to extend run time.
LOCK / UNLOCK
INDICATOR

10
FINGER LOOP
Your T-MAX™ comes equipped with a Finger Loop
installed in a neutral/straight-forward position. In
order to enhance the ergonomic control of the
T-MAX, it is recommended that the Finger Loop
be slightly offset to better align the thumb with the
control panel.
The Finger Loop can be moved by pushing it to
the desired position.
FINGER LOOP
LOOSEN HERE
INSTALLING FINGER LOOP
A smaller Finger Loop is also provided. In order
to install the smaller Finger Loop, loosen the
threaded connection between the lamp housing
and battery housing until the large Finger Loop is
loosened to a point at which it can be removed.
Insert the collar of the smaller Finger Loop so that
it is seated within the machined groove located at
the top of the battery housing.
IMPORTANT: Ensure that the Finger Loop
remains securely seated during use.
Hand-tighten the connection between
the battery housing and lamp housing as
rmly as possible.

11
T-MAX™STEEL CLIP
The T-MAX Steel Clip can be adjusted to any desired
position by loosening the connection between the
battery housing and the lamp housing to the point
where the Steel Clip can be moved.
Move the Steel Clip to the desired position and re-
tighten the connection.
MOLLE/PALS Webbing Attachment
The T-MAX MOLLE Steel Clip is specially
designed to attaching securely to MOLLE/
PALS webbing. See Figure A to view suggested
mounting option.
Figure A: MOLLE Steel Clip
attached to MOLLE/PALS
webbing
LOOSEN HERE

12
FIRST-LIGHT USA, LLC LIFETIME LIMITED WARRANTY
The PERIOD OF WARRANTY shall be for the lifetime of the lighting device from date of purchase. First-Light USA will repair or replace,
free of charge, at First-Light USA’s option, any part due to defects in materials or workmanship. Certain countries and jurisdictions
restrict limited lifetime warranties. If you reside in one of these countries or jurisdictions, First-Light USA extends to you a 10 year limited
warranty, which maintains the following terms and conditions.
First-Light USA, at First-Light USA’s option, may refund the purchase price to the original owner if unable to make the product perform the
work for which it was designed by repair or replacement of a product of at least equal value. The limited warranty contained herein is the
purchaser’s exclusive remedy.
THIS WARRANTY EXCLUDES damage or defects caused by neglect, abuse, misuse, alteration, disassembly, improper maintenance or
accidents. Batteries, or damaged caused by defective or neglected batteries are excluded from this warranty. Accessory items are also
excluded from this warranty. Electronics (other than light emitting diodes (LEDs), are limited to a 3 year warranty with proof of purchase.
To obtain warranty service, call 877.454.4450 or send e-mail to info@rstlight-usa.com.
First-Light USA will then issue a Return Merchandise Authorization (RMA) and instructions on warranty return. The original owner must
include the RMA upon returning the product in order to obtain warranty service from First-Light USA.
We will pay to ship the repaired or replaced product to the original owner’s address if located within United States. If the original owner’s
address is located outside of the United States, we will ship the product freight collect.
If we determine the remedy is not covered under this warranty, we will notify you and inform you of service options available on a fee
basis.
FIRST-LIGHT USA, LLC MAKES NO OTHER WARRANTY OF ANY KIND, EXPRESSED OR IMPLIED. ALL IMPLIED WARRANTIES,
TO INCLUDE BUT NOT LIMITED TO WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE WHICH
EXCEED THE OBLIGATIONS AND TIME LIMITS STATED IN THIS WARRANTY ARE HEREBY DISCLAIMED BY FIRST-LIGHT USA,
LLC AND EXCLUDED FROM THIS LIMITED WARRANTY. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED
WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
ALSO EXCLUDED FROM THIS WARRANTY ARE ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES INCLUDING LOSS OF USE.
SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES; EXCLUSIONS
MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE
TO STATE.
FIRST-LIGHT USA, LLC
WARRANTY AND SERVICE DEPARTMENT
205 S. Main Street, Seymour, IL 61875
Phone: [phone]
Fax: [phone]
Email: info@rstlight-usa.com

WHEN YOUR LIGHT DEPENDS ON IT.
www.rstlight-usa.com
®
REV_15-03
