FirstBuild Opal Nugget Ice Installation instructions

Opal
nugget ice
Learn more about Opal
www.nuggetice.com
Safety information 2
What’s included in the box 4
Getting started 5
Care and cleaning 5
Understanding the display 8
Making ice with Opal 9
Draining Opal 9
Firstbuild app for Opal 10
Water filter 10
Normal sounds 11
Radio frequency interference 11
Product specifications 12
Warranty 13
Write Model and Serial numbers here
Model #
Serial #
Model and Serial numbers are located on the
back of your product.
1
TM
Ver. 2/13/2017
FirstBuild.com
Use and Care
TM

READ, FOLLOW, AND SAVE THESE INSTRUCTIONS 2
IMPORTANT SAFETY INFORMATION READ ALL INSTRUCTIONS BEFORE USING
SAFETY INFORMATION
To reduce the risk of fire, explosion, electric shock, exposure to UV radiation, or injury
when using your Opal, follow these basic safety precautions:
To reduce the risk of injury when using your Opal, follow these basic safety precautions:
Do not remove any safety, warning, or product information labels from your ice maker.
Li ing Hazard: It is recommended to have two people move and install the ice maker in order
to prevent injury.
SAFETY INFORMATION
Do not, under any circumstances, alter or remove the third (ground) prong from the power
cord. For personal safety, this product must be properly grounded.
Do not exceed power outlet ratings. It is recommended that the ice maker is connected to its
own circuit. Use only a 115 V, 60 Hz standard electrical supply that is properly grounded in
accordance with the National Electric Code and local codes and ordinances.
Due to potential safety hazards under certain conditions, we strongly advise against the use
of an extension cord. However, if you must use an extension cord, it is absolutely necessary
that it is a UL-listed, 3-wire ground type appliance extension cord having a grounding type
plug and that the electrical rating of the cord be 15 Amperes (minimum) and 120 Volts.
This product must be properly installed and located in accordance with the installation
instructions before it is used. Product is for indoor household use only. Do not use outdoors.
Do not store or use flammable vapors or liquids near this product.
Do not allow children to climb, stand, or hang on the ice maker. They could seriously injure
themselves.
Do not look directly at UV lamp when it is operating. The light emitted by the lamp will cause
serious eye damage and burn unprotected skin.
In order to avoid exposure to UV radiation, disconnect power to the ice maker before
removing the external covers.
Do not use with water that is micro-biologically unsafe or of unknown quality.
Place power cord in such a way it cannot be pulled on by children or cause a tripping hazard.
Place power cord in such a way that it is not in contact with hot surfaces.
Do not operate if any component, including the cord or plug, is damaged. Contact FirstBuild
for repair or replacement. See page 13 for more information.
Unplug the product before cleaning by hand and when not in use.
Do not immerse any part of the product in water.
Do not plug or unplug product with wet hands.
Do not attempt to disassemble, repair, modify, or replace any part of your product. See page
13 for Warranty information.
Use this product only for its intended purpose as described in this user manual.
Do not use any accessories not recommended by the manufacturer.

En cas, vous ne devez modifier ni retirer la troisième broche (terre) du cordon
électrique. Pour votre sécurité, ce produit doit être correctement mis à la terre.
N'excédez pas les valeurs nominales de la prise électrique. Nous recommandons que la machine
à glaçons soit branchée à son propre circuit. Utilisez uniquement une alimentation électrique
standard de 115 V, 60 Hz, correctement mise à la terre conformément au code national de
l'électricité et aux codes et règlements locaux en vigueur.
En raison de risques potentiels pour la sécurité dans certaines conditions, nous vous mettons
fortement en garde contre l'utilisation d'un cordon prolongateur. Si toutefois vous devez utiliser
un cordon prolongateur, celui-ci doit présenter les caractéristiques suivantes : type pour
électroménagers à trois broches avec mise à la terre, fiche avec mise à la terre, homologation UL,
valeurs nominales de 15 ampères (minimum) et 120 volts.
Ce produit doit être installé correctement et placé conformément aux instructions d'installation
avant son utilisation. Ce produit est destiné à un usage domestique à l'intérieur seulement. Ne
l'utilisez pas à l'extérieur.
Ne rangez ni n'utilisez des vapeurs ou des liquides inflammables à proximité de ce produit.
Ne permettez pas aux enfants de grimper sur la machine à glaçons, ni de s'y tenir ou s'y agripper.
Ils pourraient se blesser gravement.
Ne regardez pas la lampe UV directement lorsqu'elle est allumée. La lumière émise par la lampe
peut causer des lésions sévères aux yeux ou brûler la peau non protégée.
Afin de prévenir l'exposition aux radiations UV, débranchez l'alimentation électrique à la machine
à glaçons avant de retirer les couvercles extérieurs.
N'utilisez pas d'eau impropre à la consommation ou de qualité douteuse sur le plan
microbiologique.
Placez le cordon électrique de façon qu'il ne soit pas tiré par les enfants et qu'il ne pose pas un
risque de trébuchement.
Placez le cordon électrique de façon qu'il ne touche pas aux surfaces chaudes.
Ne faites pas fonctionner l'appareil si un de ses composants, cordon et fiche inclus, est
endommagé. Communiquez avec FirstBuild pour une réparation ou un remplacement. Voir la
page 13 pour de plus amples renseignements.
Débranchez le produit avant de le nettoyer à la main ou lorsqu'il n'est pas utilisé.
N'immergez aucune pièce de ce produit dans l'eau.
Ne branchez ni ne débranchez le produit avec les mains mouillées.
Ne tentez pas de démonter, réparer, modifier ou remplacer une pièce quelconque de ce produit.
Voir la page 13 pour des renseignements sur la garantie.
Utilisez ce produit uniquement aux fins auxquelles il est destiné qui sont décrites dans ce manuel
d'utilisation.
N'utilisez aucun accessoire qui n'est pas recommandé par le fabricant.
Lisez , suivre, et conserver ces instructions . 3
CONSIGNES DE SÉCURITÉ IMPORTANTES - LISEZ TOUTES LES INSTRUCTIONS AVANT L'UTILISATION
CONSIGNES DE SÉCURITÉ
Pour réduire le risque d'incendie, d'explosion, de choc électrique, d’exposition
aux rayons UV ou de blessure lors de l’utilisation de votre Opal, observez les
consignes de sécurité élémentaires suivantes.
Pour réduire le risque de blessure lors de l’utilisation de votre Opal, observez les
consignes de sécurité élémentaires suivantes:
Ne retirez aucune étiquette apposée sur la machine à glaçons qui présente des renseignements
sur la sécurité, les avertissements ou le produit.
Risque associé à une charge lourde : Nous recommandons que deux personnes déplacent et
installent la machine à glaçons afin de prévenir les blessures.
CONSIGNES DE SÉCURITÉ

What’s included in the box
4
Box Contents
Opal ice maker Ice scoop
Quick start guide
Drip tray
Ice bin

Getting started
5
Installation and setup Care and cleaning
Installation requirements
Product is designed to be installed indoors. Do not use your ice maker outdoors.
Product must be installed upright on a flat, level surface that is able to support the
total weight when full of water.
Ensure a minimum of three inches (3”) clearance around the side and back walls of the
ice maker for proper air circulation.
Install the product in a well-ventilated area with an ambient temperature between
55°F and 90°F.
Do not place the product near heat sources such as ovens or cooktops.
Do not place the product in direct sunlight.
Prepare Opal for use
1. Carefully remove packing material. Do not use sharp tools that can damage the box
contents.
2. Ensure all components are present. If any item is missing, please contact
support@firstbuild.com.
3. Place the ice maker upright on a flat, level surface and plug it in.
4. Install drip tray by sliding it under the front edge of Opal. The tray slots should align
with the front feet of Opal.
5. Rinse the ice maker with clean water for five minutes before first use. Start with
step 4 of cleaning instructions on page 6. It is not necessary to use bleach for the first
rinse.
Li ing Hazard: It is recommended to have two people move and install the
ice maker in order to prevent injury.
Care and cleaning
To keep your nugget ice tasting fresh and your Opal looking great, we recommend
cleaning your opal at least once per week
.
To clean the exterior of the ice maker, unplug the product, then use a so cloth dampened
with soapy water to gently clean the exterior surfaces. Dry with a so cloth.
The exterior stainless steel surfaces can be cleaned with commercially available stainless
steel cleaner. Use only a liquid cleaner free of grit and rub in the direction of the brush lines
with a damp, so sponge. Do not use appliance wax, polish, solvents, or chemicals on the
stainless steel. Do not use soap to clean the reservoir. Use a so cloth moistened with
water.
Some types of under-cabinet lamps can be hot enough
to cause damage to your Opal top’s appearance.
!ATTENTION
!CAUTION

Care and cleaning (continued)
6
Care and cleaning
For First Time Use only, Start at Step 4 :
1. Unplug Opal and remove drip tray
2. Remove filter (if present), and replace with
the reservoir’s screened intake cap.
3. Drain Opal (see page 9 for detailed
instructions).
4. Plug in Opal and slide the rear switch to the
“Clean” position.
5. The display ring will light up yellow and
pulse.
NOTE: Do not use soap to clean the water
reservoir. Do not clean Opal immediately
a er use, wait at least 1 hour.
6. Create a solution of five (5) cups water and
one (1) tsp household bleach.
7. Pour solution into water reservoir.
8. Touch the display button to start the
cleaning process, the light will start to spin
and you will hear water circulating. A er
three minutes the water will stop and the
light will begin to pulse again.
Chemical Exposure Hazard, when cleaning with Bleach, use bleach in a well
ventilated area and avoid mixing bleach with other household cleaners.
To clean Opal’s internal components, complete the following steps:
Unplug the product before cleaning by hand, and when not in use.

7
Care and cleaning
Cleaning the bin and tray:
To clean the ice bin, remove the ice bin from the ice maker and clean with a so cloth
dampened with soapy water. Rinse thoroughly. Dry with a so cloth. Do not use solvents or
chemicals.
The drip tray should be wiped dry. Water le in this area may leave deposits. To clean the
drip tray, remove the tray from Opal and use a so cloth dampened with mild soapy water to
gently clean the surface. Dry with a so cloth. Do not use solvents or chemicals.
9. When the light pulses, drain Opal.
10. Unhook the top of the drain hoses
at the back of the unit. Then lay
them down to drain into a sink or
bucket that is below the level of
the ice maker. Remove the plugs
and allow the water to completely
drain.
11. Once water stops flowing,
re-insert the drain plugs.
12. Add five (5) cups of fresh water to
the water reservoir, and touch the
button. The light ring is divided
into four sections to indicate each
stage. Successive quarters of the
ring will become brighter with
each rinse cycle.
13. Rinse three (3) times with fresh
water. Repeat steps 7 through 12
three (3) more times, adding fresh
water to the reservoir each time.
(You may continue to repeat the
rinse cycle, for as many times as
you like.)
14. When complete, slide the rear
switch back to “Ice” mode.

Understanding the display
8
Operation
Opal uses an innovative light ring to let you know what it is doing.
Falling white: Opal is currently
making ice.
Solid white: Ice bin is full.
Opal is no longer continuing
to make ice.
Swishing blue: Opal needs
more water.
Pulsing yellow: Opal is in
cleaning mode awaiting drain
and refill confirmation.
Rotating yellow: Opal is
rinsing (cleaning mode).
Button
Touch once to turn Opal ON or OFF.
Touch and hold for 3 seconds to dim the interior lighting if desired.
Display ring
Displays status of the Opal ice maker. See below for details.
Mode switch (located on back)
Switch in “Ice” position places Opal in ice making mode.
Switch in “Cleaning” position places Opal in cleaning mode.
Button Display
ring
Slowly falling white: Opal is
defrosting. Please don’t
unplug or turn o , this takes
30 minutes.

Making ice with Opal
9
Operation
Once Opal has been cleaned, move the ice maker to its desired location and
complete the following steps:
1. Remove ice bin.
2. Fill reservoir with potable (safe to
drink) water up to the “Max Fill” line.
Water hardness must be less than 12
grains per gallon. Do not fill reservoir
with any liquid except water. Using
any liquid except potable water is
misuse and will void your warranty.
3. Plug the ice maker into a grounded
outlet.
4. Touch the display button to start the
ice maker. The display will flash green
to indicate the ice maker is ON, then
transition to the falling white display.
5. Opal will begin to produce ice in 15-30
minutes. It will continue to make ice
until the bin is full, or it runs out of
water. To continue making ice, just
add more water.
Draining Opal
We recommend draining your Opal when:
1. You put it away, or anytime it’s being relocated.
2. You turn it o for more than a few days. (i.e. vacation)
3. Your’e not using much ice. Continuous recirculation of meltwater may aect taste.
For best results, drain your Opal.

FirstBuild app for Opal
Operation
Use the FirstBuild app to enhance your nugget ice experience!
Installing the FirstBuild app will allow you to do the following:
Schedule start and stop times
See if Opal needs more water
The FirstBuild mobile app can be found and downloaded from the Apple App Store for
your Apple device. Or, Google Play Store for your Android device.
For help with the FirstBuild app, including how to pair your device, check out our support
page at support.firstbuild.com
Note: Works with Android, iPhone 4s or newer, iPad 3 or newer, iPad Mini, and iPod
Touch 5th generation and newer.
10
Water filter
The Opal Water Filter,
available at nuggetice.com, is
the only water filter
compatible with Opal. Please
follow the installation
instructions included with
your filter.
Note: Remove your water filter (if
installed) and reinstall the
screened intake cap prior to
cleaning your Opal.
Screened intake cap Water filter snaps into place.

Normal sounds
11
Operation
Your new ice maker may make sounds that are not familiar. Most of these sounds
are normal. Hard surfaces like the floor, walls, and countertops can amplify these
sounds. The following describes the sounds that may be new to you and what may
be creating them.
WHIR - When Opal is first turned on, you may notice the condenser fan spinning.
BUZZ - When the water pump first turns on, it may be dry and slightly noisy. Once
it is filled with water, the noise reduces significantly.
RATTLE - Rattling noises may be produced from the flow of the refrigerant. These
noises should reduce significantly once the refrigerant system has stabilized.
GURGLE - When the refrigerant system shuts o , there may be a brief gurgle as
the refrigerant stops flowing.
HUM - The compressor is a motor. It produces a low toned humming sound while it
is running.
CLICK - As nugget ice is produced, it drops into the ice drawer. The first nuggets
produced are the loudest, as they impact the bottom of the ice bin. As the bin fills,
this noise reduces significantly.
SQUEAK – When Opal is in need of defrosting, it may start to squeak as ice starts
to build up around the mechanisms. The defost cycle is automatic, and may take
30-45 minutes. During this time, the front button won’t respond.
Radio frequency interference
This product has been tested and found to comply with the limits set forth in Title 47
CFR Part 15 - Radio Frequency Devices. Operation is subject to the following conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation. This
product generates, uses, and can radiate radio frequency energy, and if not used in
accordance with the instructions, may cause harmful interference to radio
communications. If this product does cause harmful interference to radio or television
reception, which can be determined by unplugging Opal, the user is encouraged to try to
correct the interference by one or more of the following measures:
Reorient or relocate the TV or radio antennas.
Increase the distance between the product and TV or radio.
Plug Opal into a separate outlet from a radio or TV.
The transmitter must not be co-located or operating in conjunction with other antennas or transmitters.

Product specifications
12
Specifications
Note: Technical data and performance information provided for reference only.
Specifications are subject to change. Check the rating label on your ice maker for the most
accurate information.
*The actual quantity of ice produced will vary with environmental conditions.
Description of product Portable nugget ice maker
Model OPAL01
Voltage/Frequency 120V AC / 60 Hz
Current 2.5 A
Color Stainless/Black
Ice storage capacity 3.0 lbs
Ice making rate 24 lbs per day*
Dimensions (width x depth x height) 10.5 in x 14 in x 17 in
Installation clearance (sides and back) 3 in
Operating environment 55°F - 90°F
Weight (when empty) 44 lbs
Note: Products containing refrigerants
This product contains a refrigerant, which under Federal Law must be removed prior to product
disposal. If you are disposing this, or any refrigeration product, check with your local waste company
for guidance.
In order to avoid exposure to UV radiation, disconnect power to the
ice maker before removing the external covers.
Do not attempt to repair or replace UV lamp

Opal nugget ice maker Limited Warranty
13
Warranty
Limited Warranty:
One (1) year from the date of receipt of the product.
What is covered:
Product failure during the Limited Warranty Period, due to a defect in materials or workmanship.
What is not covered:
Product failure due to abuse, misuse, improper use, or commercial use.
Damage to the product caused by accident, fire, floods, or acts of God.
Incidental or consequential damages caused by possible defects with this product.*
So ware bugs that can be corrected with an update via the “FirstBuild” App.
Labor and other charges to install and/or remove the product.
What FirstBuild will do:
If your product qualifies for this Limited Warranty, FirstBuild will either: (1) replace your product with a new
or remanufactured product, or (2) refund the purchase price of the product, at FirstBuild’s sole discretion.
Limitations:
The Limited Warranty is extended to the original purchaser for products purchased for home use within the
US and Canada.
* Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty
gives you specific legal rights, and you may also have other rights which vary from state to state. To determine
what your legal rights are, consult your local or state consumer a airs o ce or your state’s Attorney General.
How to file a warranty claim
All warranty claims must be initiated through an e-mail to warranty@firstbuild.com. When initiating a
claim, please provide your First and Last name, US or Canada shipping address, phone number, and
proof of purchase. FirstBuild will respond to your inquiry and give you further instructions on how to
handle your claim. No return shipments will be accepted until they are authorized by a representative of
FirstBuild. All return shipments should be sent to FirstBuild c/o Warranty Claims Dept., 333 East Brandeis
Avenue, Louisville, KY, 40208
EXCLUSION OF IMPLIED WARRANTIES: Your sole and exclusive remedies are product exchange or refund
as provided in this Limited Warranty. Any implied warranties, including the implied warranties of
merchantability or fitness for a particular purpose, are limited to six (6) months or the shortest period
allowed by law.
