Your model
Wash program controls
Operating instructions - Starting a wash
Note: each drawer in
double models has its
own controls and can
run independently of
the other drawer.
ECO selector
and indicator
Press if you’d
like the program
to use less energy.
The indicator will
glow red when an
Eco program has
been selected.
Discard scraps
Scrape large food particles off
(e.g. bones, fruit stones) and
remove any foreign objects
(e.g. toothpicks, strings, paper).
Start wash or set Delay start
Close the drawer and press .
Select wash
Power the dishwasher on
then select wash program .
Add detergent and check rinse
aid
Fill the detergent dispenser (a) with
powdered detergent and close the
dispenser door.
Important!
Do not place liquid detergent or tablets in
the detergent dispenser.
If the indicator on its plug (c) glows
bright red, refill the rinse aid
dispenser (b) with liquid rinse aid.
Make sure you then refit the rinse
aid plug back into its original
position.
If using a tablet, place it in the
cutlery basket (d) or at the bottom
of the drawer.
14
5
6
2
3
Load dishes carefully
To help with wash performance,
arrange dishes so they are
evenly spaced and not nesting.
Check spray arm(s)
Ensure there are no items
blocking the spray arm(s) from
rotating.
DD60DDFX7
DD60DDFM7
DD24DDF(T)X7
DD60SDF(T)X7
DD60SDF(T)M7
DD24SDF(T)X7
DD90SDFTX2
DD90SDFTM2
DD36SDFTX2
Main controls
Power on/off
Press to turn the dishwasher on
or off.
Opening the drawer will automatically
turn the dishwasher on for 30 seconds.
Cancel wash/Cancel Delay start
Press to cancel a wash that has
already started or to cancel the Delay
start setting.
If there is any water in the drawer,
it will automatically drain before the
dishwasher turns off.
Start/Pause
Press to start, pause, or resume a
wash.
After pausing a wash, wait for 3 beeps
before opening the drawer. Forcing it
open in mid-cycle may cause damage
or injury.
Set Delay start
1 Press and hold until the light
above it changes from blue to
purple, then release. You are now
in Delay start mode.
2 Press briefly again, repeating
as many times as the number of
hours you want to delay the start
of a wash by. The dishwasher will
emit a beep for every hour of delay
time (1 to 12 hours).
You have now set Delay start. The
wash will start once the delay time
is over, provided the drawer is closed.
Keylock
Keylock disables all the buttons
– helpful when cleaning the
dishwasher.
To activate, press and hold until
you hear one beep (3 seconds). The
light above the button will glow
steadily.
To cancel, press and hold until the
light above it goes out.
Childlock
Childlock locks the drawer and
disables all the buttons, preventing
unauthorized use by children.
To activate, press and hold until
you hear two beeps (5 seconds). The
light above the button will glow
steadily.
To cancel, press and hold until the
light above it goes out.
a
b
d
c
Keep this document handy for easy reference.
For detailed information on the features of your dishwasher, see your ‘User guide’.
Before using your dishwasher, make sure you read the full ‘User guide’, with special attention to the ‘Safety and warnings’ section.
For contact information or if you require service, assistance or replacement parts, see the end of this document or your ‘Service & warranty’ booklet.
Wash
program
selector
Press to
scroll
through the
wash
programs.
STANDARD PROGRAMS - designed to clean and dry your dishes
ECO PROGRAMS - designed to clean your dishes energy-efficiently
HEAVY
Heavily soiled
pots, pans and
dishes.
HEAVY ECO
Heavily soiled
everyday
dishes.
FAST
Lightly soiled
dishes.
FAST ECO
Lightly soiled,
non-greasy
dishes.
RINSE
Prevents
odors
and soils
drying on
dishes.
DELICATE
Lightly soiled
and heat
sensitive
crockery.
DELICATE
ECO
Lightly soiled,
non-greasy
and heat
sensitive
crockery.
NORMAL
Dishes that are
quite heavily
soiled or food
soils that have
been left to dry
overnight
NORMAL
ECO
Normal soiled
dishes for
optimum
water and
energy usage.
The Energy
Guide is based
on this cycle.
Wash program indicators
These show which program is selected.
NZ AU US CA
QUICK START GUIDE
DishDrawerTM dishwasher (Designer)
continued over

After the wash
Dos and don’ts of loading
Preference options
For more info
The dishwasher will beep six times to indicate the end of the wash program.
You may notice the following noises at the end of the wash. These are all part of normal operation:
In double models, both drawers may be draining simultaneously.
The drying fan may continue to run after a wash program has finished for a set time or until the drawer is opened. The fan
assists with drying and uses negligible amounts of energy.
For best drying results, we recommend unloading the dishes once they have cooled.
You can change the setting of these options to suit your preferences or circumstances. We recommend selecting the most suitable
settings before you start using your dishwasher.
A neatly arranged load with evenly
spaced dishes helps wash performance.
Sharp or pointed items must be placed
horizontally or with sharp edges/points
facing down to avoid risk of injury.
Overcrowding reduces wash
performance.
Protruding items will stop the
internal lid of the drawer from
sealing properly, which could result
in a service call.
Ensure there is enough space between
plates. Mix spoons, knives and forks
within the cutlery basket to prevent
them from nesting.
If plates and cutlery are nesting,
they are less likely to be cleaned
well.
Ensure that water reaches all items on
the adjustable racks. Dishware is blocking water from
reaching items on the adjustable
racks.
For detailed information on the
features of your dishwasher
For warranty information
If you…
have any questions or comments
need a Fisher & Paykel authorized
technician to service your product
need replacement parts or accessories
want to register your product
see your ‘User guide’
see your ‘Service and warranty’ booklet
see your ‘Service and warranty’ booklet or contact us
NZ toll-free, 24/7 0800 372 273 www.fisherpaykel.co.nz
AU toll-free, 24/7 1300 650 590 www.fisherpaykel.com.au
USA toll-free, 24/7 1 888 936 7872 www.fisherpaykel.com
CA toll-free, 24/7 1 888 936 7872 www.fisherpaykel.ca
