Fisher & Paykel CleanSmart WL8060P User manual

Installation instructions
Install the washer on a solid and level floor surface ensuring it has at least 20 mm clearance on each side. The washer
must not be installed on any textured floor coverings (eg carpets, rugs).
Product and minimum clearance dimensions
https://producthelp.fisherpaykel.com/au/Wash/Top_Loaders/CleanSmart/WL8060P1/User_Guide_WL8060P1/03_Installation_…
Updated: Fri, 14 Feb 2020 17:08:14 GMT
Powered by
1

Product Dimensions
Property (mm) WL8060P
A. Overall height of product* (to highest point on console) 1045 – 1075
B. Overall width of product 600
C. Overall depth of product 600
D. Height of product to top of lid* (closed) 950 – 980
E. Height of lid open* (measured from bottom of product) 1350 – 1385
Standpipe height min. 850 – 1200
Minimum Clearances
Property (mm) WL8060P
F. Minimum cavity width 640
G. Minimum depth clearance (including inlet hoses, drain hose and bowed
front) 660
H. Minimum clearance to adjacent product# (dryer) 20
https://producthelp.fisherpaykel.com/au/Wash/Top_Loaders/CleanSmart/WL8060P1/User_Guide_WL8060P1/03_Installation_…
Updated: Fri, 14 Feb 2020 17:08:14 GMT
Powered by
2

Maximum Capacity
Property (kg) WL8060P
Maximum Capacity 8.0
* Includes adjustable mounted feet and the range of movement.
# Applies either side.
Unpacking
To ensure the best performance from your new washer please follow the instructions below.
Removing the packaging
1. Remove the outer packaging.
2. Tilt the washer backwards and walk it off the base
packer one foot at a time (ensure the lid is still
taped down).
3. Remove the base packer from under the washer
by tilting the washer backwards and pulling the
packer out the front.
4. Remove the tape, lift the lid and remove the bowl
packer from the bowl.
5. Remove the hoses and accessories.
6. Keep the base packer and bowl packer in case
they are required for future transit.
Tilt washer backwards to remove packer
https://producthelp.fisherpaykel.com/au/Wash/Top_Loaders/CleanSmart/WL8060P1/User_Guide_WL8060P1/03_Installation_…
Updated: Fri, 14 Feb 2020 17:08:14 GMT
Powered by
3

Please ensure that the base packer has been removed BEFORE OPERATING your
washer.
Location
Install the washer on a solid and level floor surface ensuring it has at least 20 mm
clearance on each side. The washer must not be installed on any textured floor coverings
(eg carpets, rugs).
In your clothes washer you will find:
• 1 hose guide.
• 2 inlet hoses.
Drain hose
1. Carefully pull the drain hose out from the back of
the washer by pulling the exposed part of the hose
downward and outward.
2. To guide the drain hose over the tub or standpipe
the hose guide MUST be fitted to the drain hose.
To prevent siphoning the
drain hose should not
extend more than 20 mm
from the end of the guide.
The height of the standpipe
or tub should be between
850 – 1200 mm. The
drainhose can be trimmed
to length.
Fitting the drain hose guide
https://producthelp.fisherpaykel.com/au/Wash/Top_Loaders/CleanSmart/WL8060P1/User_Guide_WL8060P1/03_Installation_…
Updated: Fri, 14 Feb 2020 17:08:14 GMT
Powered by
4

3. Place the drain hose in the tub or standpipe. Do
not fit the hose to a drain spigot. Drainage must not
be airtight in order to prevent siphoning.
Electrical connection
• This appliance must be supplied with a 220 – 240 V, 50 Hz, sinusoidal, 10 A electrical supply.
• Check the power cord for damage, making sure it is not squashed or twisted.
• A damaged power cord must be replaced by a Fisher & Paykel Authorised Repairer, in order to avoid a hazard.
The appliance must not be operated until it is repaired, as there is a risk of electric shock.
Draining
• Regularly check that your standpipe or tub is free from lint or other obstructions, which may affect how your
washer works or may cause flooding.
• In multi-storey apartments or any upper floor, the washer should be installed on a floor equipped with a drain.
• Draining must comply with local by-laws.
Water supply
Your cold water should not exceed 35°C and your hot water should not exceed 65°C.
Temperatures above these may cause the washer to fault or cause damage to the washer.
• If you have an uncontrolled water heating source (eg a wet back or solar heating system) you should fit a
tempering valve. This will ensure the hot water temperature remains within safe limits. Contact your registered
plumber to select and install the tempering valve.
• Inlet water static pressure: Max. 1 MPa (150 psi) Min. 34 KPa (5 psi)
• Inlet water flow rate at tap: Min. 6 litres/min.
• This appliance must be installed in accordance with the installation instructions before use.
• Provide accessibility of the plug or incorporate a switch in the fixed wiring in accordance with the
wiring rules to allow disconnection of the appliance from the supply after installation.
• Do not operate this washer if it has been damaged during transport. Contact your Fisher &
Paykel dealer or Fisher & Paykel Authorised Repairer.
https://producthelp.fisherpaykel.com/au/Wash/Top_Loaders/CleanSmart/WL8060P1/User_Guide_WL8060P1/03_Installation_…
Updated: Fri, 14 Feb 2020 17:08:14 GMT
Powered by
5

Inlet hoses
Failure to adhere to the
following instructions may
result in a flood and
damage to property:
• New hose sets provided
with the washer shall be
used to connect the
washer to the water
supply.
• Old hose sets should not
be used.
• We recommend replacing
the inlet hoses every 5
years.
• Hoses should be checked
from time to time and
replaced if any wear, cuts,
bulges, kinks or leaks are
found.
1. Connect the straight ends of the inlet hoses to the
taps (there are washers fitted in both ends).
Connect the red connector hose to Hot, and the
white connector hose to Cold.
2. Connect the elbow ends of the inlet hoses to the
corresponding washer inlet valves. Inlet valves are
marked on the back of the washer. Ensure the Hot
valve is connected to the hot tap and the Cold
valve is connected to the cold tap.
H = Hot C = Cold
This clothes washer should be plumbed into both a hot
and cold water supply otherwise some cycles may not
function correctly.
Inlet hose ends
https://producthelp.fisherpaykel.com/au/Wash/Top_Loaders/CleanSmart/WL8060P1/User_Guide_WL8060P1/03_Installation_…
Updated: Fri, 14 Feb 2020 17:08:14 GMT
Powered by
6

Your washer does not have
an internal heater to heat
water.
Levelling instructions
It is IMPORTANT to level the washer to ensure good spin performance.
A spirit level is provided with your washer. Use this to level your washer, always placing it on a clean, flat surface.
The washer is level when the bubble sits in the centre, within the two lines.
Your washer is equipped with self-locking feet at the front to ensure they do not move once you have levelled
your washer. To adjust the feet, tilt the washer back and twist to move them up or down.
After levelling, the corners of the washer should be clear of the floor and the washer must
not rock in any direction.
1. Move the washer to its final position using the top
corners to manoeuvre the product into place (do
not push on the centre front of the washer). We
recommend a minimum clearance of 20 mm each
side and 40 mm at the rear of the washer.
2. Open the lid, place the spirit level at the
centre front of the top deck forward of the lid lock
slot. Level the washer from side to side by winding
up or down the front feet (Fig.1).
3. With the lid closed, tilt the washer forward away
from the wall approximately 100 mm (Fig.2), the
self-adjusting feet will release. Gently lower the
washer back down.
4. Open the lid, place the spirit level at either the right
hand or left hand side of the top deck. Level the
washer from front to back using the front feet only
(Fig.3), winding both feet in or out equally. Tilt the
washer forward again and lower back down (Fig.2).
5. Re-check the washer is level. Move the spirit level
around to all positions once more, checking the
Fig.1 Levelling side to side
https://producthelp.fisherpaykel.com/au/Wash/Top_Loaders/CleanSmart/WL8060P1/User_Guide_WL8060P1/03_Installation_…
Updated: Fri, 14 Feb 2020 17:08:14 GMT
Powered by
7

washer is level in all areas. Repeat step 4 if
necessary. Check the washer does not rock from
side to side, front to back, or corner to corner.
• Keep your spirit level for
the next time you move or
reposition your washer.
• If moving or transporting
your washer in the future,
ensure you tape the lid
down beforehand.
Fig.2 Tilt washer forward
Fig.3 Levelling from front to back
Completing your installation
• Turn on the water and check all hose connections for leaks. Make sure there are no kinks in the hoses. Check
the hose connections for leaks again after 24 hours.
• Uncoil power cord, remove and discard the plastic pin cover, and plug into wall socket.
• Connect the appliance to an earthed outlet protected by a fuse of suitable capacity.
Do not touch or operate the washer with wet hands or with bare feet.
https://producthelp.fisherpaykel.com/au/Wash/Top_Loaders/CleanSmart/WL8060P1/User_Guide_WL8060P1/03_Installation_…
Updated: Fri, 14 Feb 2020 17:08:14 GMT
Powered by
8

Installation test cycle
Your washer must be correctly installed before use. Check the installation and operation of the washer using the
following procedure:
1. Touch ‘Power’
to activate your washer.
2. Touch both the
and ‘Options’ buttons at the same time, and hold for three seconds.
3. Touch
to start the installation test cycle. The display will show
.
4. The washer will beep to signal the end of the installation test cycle. Any faults will be displayed on the screen
(refer to the back of this user guide to help identify faults). If you need further assistance, please contact a
Fisher & Paykel Authorised Repairer or our Customer Care Centre. Refer to ‘Customer Care’ section for
contact details.
If there are no faults found, the washer will automatically turn off at the end of the
installation test cycle.
Accessories and Spare Parts
Available from your Fisher & Paykel dealer or a Fisher & Paykel Authorised Repairer.
Hose Inlet
Long (2 m) Part No. 422680P
Hose Inlet
Large Bore Part No. 426123P
Drain Hose Part No. 425627P
https://producthelp.fisherpaykel.com/au/Wash/Top_Loaders/CleanSmart/WL8060P1/User_Guide_WL8060P1/03_Installation_…
Updated: Fri, 14 Feb 2020 17:08:14 GMT
Powered by
9

Accessories and Spare Parts
Extension
Power
Cord
If the power cord of your clothes washer is damaged it must be replaced by a Fisher & Paykel
Authorised Repairer in order to avoid a hazard, as it is not a standard power cord.
