Fisher & Paykel WH1060P1 User manual

Customising Wash Cycle
Delay Start
The ‘Delay Start’ option enables you to delay the start of the wash cycle from between 5 minutes and 12 hours. Times
you can select are 5 min, 15 min, 30 min, 1 hour, then hourly up to 12 hours. This can be useful to time your washing to
finish when you arrive home from work, or to start once you have finished in the shower. Some stain removers also
require you to spray them on then leave for several minutes, before washing. Your washer will wait for the selected time
then start the cycle without any other inputs from you.
To Programme a ‘Delay Start’ time:
1. Touch the ‘More’
button to increase the delay time. The delay time will increase from 5 minutes up to 12 hours.
– If you hold the ‘More’
button down, the time displayed on the screen will increase after every half second (more convenient than
touching the button repetitively)
2. Touch the ‘Less’
button to decrease the time or turn ‘Delay Start’ off.
Once started, the time will count down on the display screen in 1 minute increments. The ‘Delay Start’ light will flash and
the
light will stop flashing and be on constantly.
https://producthelp.fisherpaykel.com/nz/Wash/Front_Loaders/WashSmart/WH1060P1/User_Guide_WH1060P1/11_Customisi…
Updated: Tue, 16 Nov 2021 12:17:21 GMT
Powered by
1

To Cancel ‘Delay Start’ Time:
If you want to remove ‘Delay Start’ after the countdown has begun,
1. Touch
to pause the countdown.
2. Touch ‘Less’
button to reduce the time to zero.
3. Touch
again to start the cycle immediately.
Wash Temp
Your washer offers five wash temperatures:
Cold 30°C 40°C 60°C 90°C
• Touch the ‘Wash Temp’ button to increase or decrease the wash temperature.
– The washer will fill with both hot and cold water (if possible) to achieve the selected wash
temperature.
– If required, ie for cold supply or cold connection only, the washer will heat the water to the
selected temperature.
– Some temperatures are not available on some cycles as a safeguard for your
clothes (eg 60°C or 90°C on the ‘Delicate’ cycle).
When 90°C temperature is selected, the door glass will become hot. Take
care when touching the door. Keep children away from the washer.
https://producthelp.fisherpaykel.com/nz/Wash/Front_Loaders/WashSmart/WH1060P1/User_Guide_WH1060P1/11_Customisi…
Updated: Tue, 16 Nov 2021 12:17:21 GMT
Powered by
2

Spin Speeds for WH1060P1 and WH1260P1 Models
• Touch the ‘Spin Speed’ button repeatedly to select spin speeds for:
– WH1060P1 model: 500 rpm, 800 rpm, 1000 rpm or 1200 rpm.
– WH1260P1 model: 500 rpm, 800 rpm, 1100 rpm or 1400 rpm.
• There is an additional ‘No Spin’ option for both models:
– Select ‘No Spin’ to end the cycle after the rinse to remove items you
wish to drip dry. The washer will complete the spins within the wash and
rinse portions of cycle; only the final spin will not be completed.
– After removing the items for drip dry and you wish to spin dry the
remaining items, press ‘POWER’ and select the ‘Spin’ cycle. If necessary,
modify the spin speed to best care for your load (ie spin delicate items at
500 rpm for best garment care). WH1060P1 WH1260P1
If an out of balance load occurs, your washer will compensate by using a lower spin speed.
Soil Level
The ‘Soil Level’ option lets you adjust the wash to suit the amount of soil in your load.
• Touch the ‘Soil Level’ button repeatedly to select among 3 options: ‘Heavy’ (for dirty clothes);
‘Light’ (for items that are only lightly soiled), and ‘Normal’ (for normal soil level).
– The wash time will be adjusted accordingly to give the load the right amount of agitation to
remove the soil.
https://producthelp.fisherpaykel.com/nz/Wash/Front_Loaders/WashSmart/WH1060P1/User_Guide_WH1060P1/11_Customisi…
Updated: Tue, 16 Nov 2021 12:17:21 GMT
Powered by
3

Wash Boost
• Touch the ‘Wash Boost’ button repeatedly to select among ‘Pre Wash’ for extra dirty loads,
and ‘Rinse+’ for adding an extra rinse to your clothes.
Pre Wash
Your washer will start with a short wash in cool water to remove excess soil. After this the machine
will drain and then fill at the selected temperature for the main wash.
‘Pre Wash’ cannot be selected anymore once a wash cycle starts. ‘Pre Wash’ must be selected
before the cycle starts.
Use liquid or powdered detergent in the PRE WASH liquid/powder compartments when using ‘Pre Wash’ option. When
you select ‘Pre Wash’, the compartment is flushed at the start of the cycle.
Rinse+
Your washer gives your clothes an extra rinse if you have a particularly dirty load, or you have sensitive skin. Your load
will undergo an extra rinse to get rid of any residual detergent or soil in the items.
‘Rinse+’ will not be available if the ‘Eco’ option has been selected.
Options
https://producthelp.fisherpaykel.com/nz/Wash/Front_Loaders/WashSmart/WH1060P1/User_Guide_WH1060P1/11_Customisi…
Updated: Tue, 16 Nov 2021 12:17:21 GMT
Powered by
4

• Touch the ‘Options’ button repeatedly to select between ‘Wrinkle Free’ and ‘Eco’.
Wrinkle Free
We recommend you remove the clothes from the washer immediately after the completion of the
cycle to minimise wrinkling and creasing of items and to prevent dye run. However, if you will not
be present at the end of the wash you can select ‘Wrinkle Free’.
When ‘Wrinkle Free’ is selected, the washer will tumble the clothes once every 15 minutes for up to 12 hours after the
cycle has finished. The ‘Wrinkle Free’ light and
button will flash, and the washer will beep at regular intervals to remind you to remove your load. To remove the load
during this phase, touch the
button.
Eco
Use the ‘Eco’ option to save water and energy. Selecting ‘Eco’ will reduce the wash temperature slightly and alter the
wash and rinse programming.
‘Eco’ cannot be selected after a wash cycle has been started, ie if you touch
and try to select ‘Eco’ it will be unavailable. ‘Eco’ must be selected before the cycle starts. This
option will not be available if ‘Rinse+’ has been selected.
• If you wish to, you can select both ‘Wash Boost’ options of ‘Pre Wash’ and ‘Rinse+’ to perform
on the same cycle. Likewise, you can select ‘Eco’ and ‘Wrinkle Free’ to perform on the same
cycle. Touch the appropriate button until both options are selected. Repeat to deselect an option.
• For clothes care and performance reasons not all options are available on all cycles.
https://producthelp.fisherpaykel.com/nz/Wash/Front_Loaders/WashSmart/WH1060P1/User_Guide_WH1060P1/11_Customisi…
Updated: Tue, 16 Nov 2021 12:17:21 GMT
Powered by
5

Reset Defaults
You can reset your washer to the default settings it left the factory with:
1. Turn the dial to select ‘Spin’.
2. Touch and hold the ‘Delay Start’ ‘More’
, the ‘Delay Start’ ‘Less’
and ‘Options’ buttons together for 3 seconds
will appear on the screen and the machine will beep.
3. Your washer will now be reset to the default settings.
