Fit4Home HH-LSYT User manual

1
Please Keep For Future Reference
IMPORTANT - Please Read Instructions Fully Before Assembly Or Use
These instructions contain important information which will help you get the best
from your equipment and ensure safe and correct assembly, use and maintenance.
If you need help or have damaged or missing parts,
call the Customer Helpline: 0330 124 0718 (Opening hours: Mon-Fri 9:00am-5:00pm)
or Email: [e-mail]
USER MANUAL
HH-LSYT CAMPING TENT

2
IMPORTANT SAFETY INFORMATION
IMPORTANT SAFETY INFORMATION
BE SURE TO READ THE ENTIRE MANUAL BEFORE YOU ASSEMBLE OR OPERATE
YOUR ITEM. IN PARTICULAR, NOTE THE FOLLOWING SAFETY PRECAUTIONS:
1. Allow at least 6m spacing between tents and caravans or other vehicles.
2. Never use fuel-burning devices (e.g.,disposable barbecues, camping stoves, camping heaters,
lanterns, and charcoal grills)inside a tent.
3. Never use candles in or near a tent - torches are much safer
4. Flammable liquids and Liqueed Petroleum Gas cylinders should be kept outside the tent
5. Oil burning appliances are not recommended
6. Cooking appliances should never be used in small tents
7. Never light a candle or have any other kind of ame burning apparatus in or near to a tent
8. Cook outside and away from the tent
9. Don’t smoke inside the tent and keep any ammable material away from the cooking area
10. Have an escape plan
CAUTION: Read all instructions carefully before operating this product. Retain
this Owner’s Manual for future reference.
PARTS LIST
No. Description Qty
01 Holdall Bag 1
02 Large Pole Bag 1
03 Small Parts Bag 1
04 Tent with xed groundsheet 1
05 Orange Pole PART A) 1
06 Black Pole with Red Band
(PART B)
4
07 Grey Pole (PART C) 2
08 Black Pole with Green Band
(PART D)
2
09 Black Pole (PART E) 2
10 Black Pole with Hook
(PART F)
2
11 Black Pole with Hook
(PART G)
2
12 Plain Black Pole with Silver
Ends (PART H)
2
13 Tent Pegs (PART I) 12
14 Guyline Ropes (PART J) 8
15 Guyline Rope Guides
(PART K)
8
16 Top Sheet (PART L) 1
17 Room Divider 1

3
PARTS LIST
PART A
PART B
PART C
PART D
PART E
PART F, G ,H
PART I
PART J
PART K
PART L
Tent Storage Bag
Tent with Groundsheet
DIAGRAM

4
STEP 1-2
1. Lay out the tent groundsheet at on the
ground, where you would like to pitch the
tent
2. Assemble each folded grey pole (PART C)
into 2 long grey poles
STEP 3-5
3. Feed each one of the assembled grey poles
diagonally through the orange tunnels, from
one corner to the other.
4. Assemble the folded orange pole (PART A)
to create 1 long pole.
5. Feed the orange pole through the
horizontal orange tunnel.
STEP 6-8
6. Feed the end of each grey pole, into one of
the slots of the 3-sided black connectors,
which are already attached to the tent.
7. Feed each end of the orange pole into
one of the slots, of the 2-sided black
connectors, which are attached to each
side of the tent.
8. Assemble each of the folded black & red
poles (PART B) into 4 long poles.
STEP 9-10
9. Slot one end, of each black & red pole, to
one side of the 3-sided black connector, on
each corner of the tent.
10.Slot the tent pole pin (That comes attached
to the tent with the pole ring) into the other
end of each of the black & red pole to
secure this in place.
ASSEMBLY INSTRUCTIONS

5
ASSEMBLY INSTRUCTIONS
STEP 11-12
11.Fix each black & red pole in place via the
black clip attached to the tent
12.Assemble each of the folded black & green
poles (PART D) into 2 long poles.
STEP 13-15
13.Slot one end, of each black & green pole,
to the other side of the 2-sided black
connector, on each side of the tent.
14.Slot the tent pole pin (That comes attached
to the tent with the pole ring) into the other
end of each of the black & green pole, to
secure this in place.
15.Fix each black & green pole in place via the
black clip attached to the tent
STEP 16-18
16.Assemble each of the folded black poles
(PART E) into 2 long poles.
17.Slot each end, of each black pole, to
the remaining side of the 3-sided black
connectors, on the front and the back of
the tent.
18.Fix each black pole in place via the black
clip attached to the tent.
STEP 19-20
19.Raise the tent, this will take some co-
ordination.
20.Tie the attached string, in the middle of the
tent to x the poles in place.

6
ASSEMBLY INSTRUCTIONS
STEP 21
21. Attach the guylines (PART J) to the orange
windbreakers and peg into the soft ground
with the guylines rope guides (PART K)
and tent pegs (PART I) to secure the tent in
place.
STEP 22
22. Clip the tent cover (PART L) into place via
the green clips and Velcro strips which
are attached to the tent. Adjust them as
required.
STEP 23 - 26
23. For the canopy, assemble the short black
poles (PARTS F, G, H) to create 2 long black
poles
24. Feed the silver end of each assembled
black pole, through the awning guide and
attach 2 guylines.
25. Secure by pegging the guylines into the
ground.
26. Your tent is now set up and ready.
