FLAIM
Trainer™
Quick Setup Guide
Copyright © 2020

2
Welcome to the FLAIM
community. Thank you
for your purchase of the
FLAIM Trainer virtual reality
training system.
Quick Setup Guide
This manual should get you on your way in no time. It is designed for
trainers with minimal understanding of virtual reality. The FLAIM Trainer
system is not designed to replace hot fire training, but instead allows
experiential learning through a number of practical scenarios developed
to improve dynamic thinking, risk assessment, radio messaging, muscle
memory, hose handling technique and nozzle control. Our system is
designed so you can train people at all levels in your organisation, from
novice through to experienced firefighters. Giving you the ability to train and
develop their skillsets in safe environment with immersive, repeatable and
realistic fire scenarios.
The FLAIM Trainer can also be used to train the public in the dangers of
fire and allow them to appreciate the work that you do.
The FLAIM Systems Team
Train more, learn more, prepare better.

3
1. Put battery holders on top of the tripods
2. Screw tripod swivel mounts and base stations onto the tripods
3. Insert batteries into the battery holders
4. Connect power cables after you have placed tripod in right place
5. Raise tripods to approximately 2m/7ft height
6. Setup tripods 6m/13ft apart, diagonally
1. Connect Miracast HDMI receiver to TV or projector with HDMI cable
2. Connect HDMI receiver to power via USB cable to TV/projector
3. If TV has no USB, use USB power supply
4. Select correct output on your TV or projector
1. Setup hose reel at back of the training area
2. Secure hose reel to fixed point or heavy object
3. Connect hose reel to powerpoint/electrical outlet
Part 1.
Part 3.
Part 2.
Check: Tracker LED lights are on
Check: Hose reel LED light on, hose retracts when button pushed
Check: FLAIM Miracast default screen is visible

4
1. Lay down BA set with connected VR Headset in front of hose reel
2. With hose reel behind you, point the VR Headset to straight ahead
3. Insert battery into battery compartment
4. Turn BA on and wait for up to 4 minutes
Part 4.
1. Take nozzle and connect it to the hose
2. Take tracker “puck” and connect it (magnet) to front of nozzle
3. Click and release puck centre button. Wait a few seconds for LED
Part 5.
Check: On/off button LED light on BA should be on
Check: HDMI receiver has connected to the FLAIM BA computer
Check: Bottom of the screen shows the FLAIM control window
Check: LED light on VR Headset is green (and not red)
Check: Puck LED light is on
Check: Hose reel retracts when water turned on

5
1. Start a scenario
2. Turn on Heat Suit on iPad
1. Take mouse and turn it on
2. Pickup iPad
3. Double click iPad button and stop (swipe away) running programs
4. Start Flaim Trainer program on iPad
5. Run “Room Setup” on iPad - when done, turn off and store mouse
6. Click “Restart FLAIM System” on iPad
Part 7.
Quick Startup Check
Part 6.
Check: VR Headset shows scenario and detects motion
Check: All functions of nozzle
Check: Heat Suit
Hose reel: on
SCBA backpack: on (red light)
Trackers: on; pointing towards each other; LED on
Nozzle: puck connected; LED on
HDMI Receiver: on; connected to TV/projector; set to right source
Student screen: FLAIM Trainer status “Ready”
iPad: instructor programme restarted

6
Breakdown Checklist
1. Unscrew swivel mounts, base stations and battery holders
Pack everything into case, in right place
Fold tripods and store
2. Take battery out of BA backpack and store
Store BA set and place heat suit on top of BA
Take care the cables are secured
3. Disconnect “puck” from hose reel and store
Disconnect nozzle from hose reel and store
Disconnect hose reel from power and untie rope
Tie rope back onto hose reel and store
4. Disconnect HDMI receiver and power cable from TV and store
5. Store iPad in support kit case
Check mouse is in support kit case
Look around to see if you have forgotten anything
6. Charge BA batteries
Charge tracker / base station batteries
Charge puck
Charge iPad

7
1. Reconnect TFT nozzle using iPad Advanced Settings. Try again
2. Remove puck and remove batteries from nozzle
3. Put batteries back in nozzle and connect puck. Try again
4. Replace batteries and try again
5. Try Step 1 once more.
Quick Errors
1. Push the “Show Instructor Screen” on the iPad
2. If that fails. Connect BA direct to screen with HDMI cable or re-pair
using ‘Connect Display’ in Advanced Settings on iPad.
1. Check hose reel is on. Try again
2. Check WiFi settings. If iPad is connected to FLAIM WiFi enter WiFi
Password: FLAIM123. Try again
3. Check iPad WiFi setting for FLAIM IP address is 192.168.0.21 and
subnet mask 255.255.255.0. Try again
1. Go to STEAM VR, right click on tracking puck and select manage
VIVE Trackers
2. Make sure that Mode is set to “disabled”
otherwise:
FLAIM screen does not show on TV (it stays on MIracast screen)
iPad does not show FLAIM Instructor screen
Nozzle does not respond
Nozzle is pointing upwards instead of forwards in VR
