Sunny Health & Fitness SF-BH6802 User manual

POWER RACK
SF-BH6802
USER MANUAL
IMPORTANT! Please retain owner’s manual for maintenance and adjustment instructions.
Your satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE
CONTACTED US:
[email protected] or 1- 877 - 90SUNNY (877-907-8669).

1
IMPORTANT SAFETY INFORMATION
We thank you for choosing our product. To ensure your safety and health, please use this
equipment correctly. It is important to read this entire manual before assembling and using the
equipment. Safe and effective use can only be achieved if the equipment is assembled,
maintained and used properly. It is your responsibility to ensure that all users of the equipment
are informed of all warnings and precautions.
1. Before starting any exercise program, you should consult your physician to determine if you
have any medical or physical conditions that could put your health and safety at risk, or
prevent you from using the equipment properly. Your physician’s advice is essential if you are
taking medication that affects your heart rate, blood pressure or cholesterol level.
2. Be aware of your body’s signals. Incorrect or excessive exercise can damage your health.
Stop exercising if you experience any of the following symptoms: pain, tightness in your chest,
irregular heartbeat, shortness of breath, lightheadedness, dizziness or nauseous feeling. If
you do experience any of these conditions, you should consult your physician before
continuing with your exercise program.
3. Keep children and pets away from the equipment. The equipment is designed for adult use
only.
4. Use the equipment on a solid, flat level surface with a protective cover for your floor or carpet.
To ensure safety, the equipment should have at least 4 feet(1.2 M) of free space all around it.
5. Ensure that all nuts and bolts are securely tightened before using the equipment. The safety of
the equipment can only be maintained if it is regularly examined for damage and/or wear and
tear.
6. Always use the equipment as indicated. If you find any defective components while
assembling or checking the equipment, or if you hear any unusual noises coming from the
equipment during exercise, discontinue use of the equipment immediately and do not use until
the problem has been rectified.
7. Wear suitable clothing while using the equipment. Avoid wearing loose clothing that may
become entangled in the equipment.
8. Do not place fingers or objects into the moving parts of the equipment.
9. The maximum weight capacity of this unit is 880 pounds (400 KG).
10.The equipment is not suitable for therapeutic use.
11.To avoid bodily injury and/ or damage tothe product or property, proper lifting and moving are
required.
12.Your product is intended for use in cool and dry conditions. You should avoid storage in
extreme cold, hot or damp areas as this may lead to corrosion and other related problems.
13.This equipment is designed for indoor and home use only; it is not intended for commercial
use.

2
EXPLODED DIAGRAM

3
HARDWARE PACKAGE
SPANNER 2PC

4
PARTS LIST
Ordering Replacement Parts (U.S. and Canadian Customers only)
Please provide the following information in order for us to accurately identify
the part(s) needed:
√ The model number (found on cover of manual)
√ The product name (found on cover of manual)
√ The part number found on the “EXPLODED DIAGRAM” and “PARTS LIST”
(found near the front of the manual)

5
STEP 1:
Attach
Right Stabilizer (No. 2) to
Center Stabilizer (No. 3) using 2
Bolts (No. 19), 4 Washers (No.
23), and 2 Nuts (No. 22). Tighten
and secure with Spanner.
Repeat these steps to attach the
Left Stabilizer (No. 1).
STEP 2:
Attach Support Tube (No. 8) to
Right Stabilizer (No. 2) using 2
Bolts (No. 17), 2Washers (No.
23), and 2Nuts (No. 22). Tighten
and secure with Spanner,
Repeat these steps to attach Sup-
port Tube (No. 8) to the
Left Sta-
bilizer (No. 1).
ASSEMBLY INSTRUCTIONS

6
STEP 3:
Attach Upright Posts (No. 4) to
Right Stabilizer (No. 2) using 2
Bolts (No. 17), 2Washers (No.
23), and 2 Nuts (No. 22). Tighten
and secure with Spanner.
Repeat to attach Upright Post
(No. 4) to Left Stabilizer (No. 1).
Attach Pull Up Bar (No. 5) and
Pull Up Bar Plates (No. 7) to Up-
right Posts (No. 4) using 4 Bolts
(No. 18), 8Washers (No. 23), and
4Nuts (No. 22). Tighten and
secure with Spanner.
STEP 4:
Attach 2Locking Plates (No. 6)
to the
Right Stabilizer (No. 2)
using 4 Bolts (No. 18), 8 Wash-
ers, and 4 Nuts (No. 22). Do not
tighten all the way until all 4 are in
place. Tighten and secure with
Spanner.
Repeat the steps to attach 2Lock-
ing Plates (No. 6) to the Left Sta-
bilizer (No. 1).

7
STEP 5:
Attach Band Peg (No. 9) to the
Right Stabilizer (No. 2) using 2
Bolts (No. 19), 4Washers (No.
23), and 4Nuts (No. 22). Tighten
and secure with Spanner.
Repeat to attach Band Peg (No.
9) to the Left Stabilizer (No. 1).
STEP 6:
Attach Pivot Bracket (No. 10) to
Center Stabilizer (No. 3) using 2
Bushings (No. 29), 1 Washer
(No. 25), and 1Nut (No. 24).
Tighten and secure with Spanner.
Cover with Nut Cap (No. 30)
Attach Landmine (No. 11) to
Pivot Bracket (No. 10) using 1
Bolt (No. 20), 2Washers (No.
27), and 1Nut (No. 26). Tighten
and secure with Spanner.

8
STEP 7:
Attach Plate Holders (No. 12) to
Support Tubes (No. 8) using 2
Buffer Washers (No. 28), 2
Washers (No. 23) and 2Bolts
(No. 21). Tighten and secure with
Spanner.
Hold the Right Bar Holder (No.
16) horizontally with the bracket
on the right. Insert Right Bar
Holder (No. 16) into Upright Post
(No. 4) at desired height. Turn the
Right Bar Holder (No. 16) clock-
wise to install onto Upright Post
(No. 4).
Hold the Left Bar Holder (No. 15)
horizontally with the bracket on the
left. Insert Left Bar Holder (No.
15) into Upright Post (No. 4) at
desired height. Turn the Left Bar
Holder (No. 15) counterclockwise
to install onto Upright Post (No.
4).
Make sure the Bar Holders are set
at the same level.
Repeat the above steps to install
the Right and Left Safety Bars
(No. 13 & 14) into the Upright
Posts (No. 4).
Make sure the Safety Bars are set
at the same level.
The assembly is complete!

9
MAINTENANCE
IMPORTANT:
Safe and effective use can only be achieved if the equipment is assembled, maintained
and used properly. It is your responsibility to ensure that the equipment is maintained
regularly. Any components found to be worn and/or damaged should be replaced before
continuing use of the equipment. Equipment should only be used and stored indoors,
prolonged exposure to weathering and changes in temperature and humidity may have
a severe impact on
parts of the machine.
Daily Maintenance:
-Clean and remove sweat and moisture after each use.
-Perform inspection of all nuts and bolts associated with moving parts of the equipment,
tighten as required.
-Check the mobility of moving parts and components on the equipment, lubricate if
required.
-Clean plastic parts of the equipment using a damp cloth, clean metal parts of the
equipment using a dry cloth. Do not use cleaning products to clean the equipment.
Weekly Maintenance:
-Thoroughly inspect the parts of the equipment; nuts, bolts, screws, etc. Tighten or
replace parts as required.
Monthly Maintenance:
-Inspect the frame and inner working components for wear and tear as well as damage.
Perform maintenance or replace as required.
OPTIONAL:
This power rack has floor anchors to mount the rack to the floor. Mounting the rack to the
floor is optional. It increases stability for equipment that are used with heavy weight.
Installation hardware is not included, but you can get it at a local hardware store. Make
sure to use the proper installation hardware for your floor type.
WARNING:
Always add or remove equal amounts of weight on each side of the barbell.
Do not store your barbell with weight on the power rack for an extended period of time.
Version 1.1
