Flebi SUPRA 3.0 User manual

User manual

Index
Unpacking & assembly
1. Box content
2. Introduction of the set handlebar
3. Packed in original box
Start up
4. Handlebar adjustment
5. Saddle adjustment
6. Disc Brake adjustment
7. Nexus 3 / 7 changes
8. Tyre inflation
9. Chain placement
Electrical operation
10. Battery removal
11. Battery recharge
12. Operation C300U display
13. Throttle operation (optional)
Folding & Unfolding
14. Unfolding the bike
15. Folding the bike
16. Swingarm operation
17. Opening/Closing the frame
18. Folding/Unfolding the pedals
19. Handlebar folding mechanism
20. Quick fold easy-folding
21. Drag on the training wheels
Parts of Flebi Supra 3.0
22. Discovering your Flebi

Unpacking & assembly
Box contents
Assembling your Flebi Supra 3.0 is very easy!
Flebi Supra 3.0 is equipped with a 36 V / 250
W motor and reaches a top speed of 25
km/h.
Take the bike out of the box
- Remove the protections
- Save the battery keys
- Unfold the bike (see 14)
- Insert the handlebar assembly (see 2)
- Place the seat post on the frame
Check thebox contents:
-Flebi Supra 3.0 bicycle with integrated
battery in the frame and security keys
- Battery charger
- Rear light with battery
1Video: https://youtu.be/40EJnKaZ7ZA

Unpacking & assembly
Introduction of the set
handlebar
2Video: https://youtu.be/I1Ea4KkzVsI
To install the assembly made up of the
handlebar and the telescopic seatpost
that allows you to adjust the height, you
simply have to insert it into the stem of
the handlebar following the guides that
you'll find.
Once inside, take it to the mark and
tighten the closing key firmly.

Unpacking & assembly
Packing in original box
In the event that you have to repackage
your bike in its original box to send it to
Flebi's technical service, we recommend
that you follow the steps below to protect
it as best as possible and avoid bumps and
scratches during transport:
- Cover the parts with protections
- Remove the seat post and remove the
handlebar assembly
- Fold the bike (see 15)
- Put it in the box
- Place the cork fixing the front wheel
- Rest the pedal on a protection
- Put the front folding lever inwards
3Video: https://youtu.be/4y2VZKfr4pA

Start up
Handlebar adjustment
You can adjust the height of the
handlebar to accommodate your height.
To do this, open the telescopic closure
and place the seatpost in the desired
position, taking care not to exceed the
safety mark. Then tighten the clasp
firmly so it doesn't move.
You can also use this same adjustment
to correct slight deviations in the
direction of the bike. Open the lock, turn
the handlebar left or right looking for
the right one alignment, and retighten
the closing.
4Video: https://youtu.be/Kh6tNZ4Ac-8

Start up
Saddle adjustment
You can also adjust the height of the
saddle to perfectly adapt it to your
height. To adjust the hardness you must
tighten the thread according to your
tastes.
Check that it is not too loose or the
seatpost will move.
To modify the angle of the saddle, you
can use a number 13 wrench to decide
the inclination of the saddle. Remember
to tighten it well.
5Video: https://youtu.be/lNBEfWJ4lWI

Start up
Disc brake adjustment Tektro
CAUTION: The brakes on the Supra 3.0/3.0+
are fully adjusted at the factory and no
adjustment is necessary unless they loosen
with use.
To adjust the mechanical disc brake, we will
first loosen the mounting bolts, to allow
some movement for the caliper.
Then, you will have to act on the regulator of
the pad on the inside.
Finally, you must press the brake to take up
the slack in the cable and thus compress the
caliper on the disc to align it, without
releasing the brake cable.
6Video: https://youtu.be/zNEUnS3a_Uc

Start up
Uso de los cambios Nexus 3 / 7
Supra 3.0 and 3.0+ are equipped with Shimano
Nexus 3v and 7v derailleurs respectively (the Supra
3.0 lite is single speed), integrated into the rear
wheel hub. This system allows shifting when
stationary without the chain slipping or crossing.
The gears, in grip mode, will help you overcome any
obstacle. The Shimano Nexus 7 drivetrain offers a
range of 245%, which is 30% more than that of the
Nexus 3.
Supra 3.0: Supra 3.0+:
7Video: https://youtu.be/WqIKTUUACfM
Speed 1: for hills
Speed 2: for stationary starting
Speed 3: for normal driving
Speed 1: for hills
Speed 2: minor slopes
Speed 3: intermediate speed
Speed 4: for normal riding
Speed 5: intermediate speed
Speed 6: for downhills
Speed 7: for more favourable downhills

Start up
Tyre inflation
To check the amount of air in the tires,
remember that the Supra ECO has 3.5 bar of
pressure, so it is convenient to use an inflator
with a pressure gauge.
The Supra ECO is very comfortable, since you
can inflate the wheels in the semifolded
position, without the need to support it on
the wall or turn it over.
8Video: https://youtu.be/WqIKTUUACfM

Start up
Chain placement
To return the chain of your Flebi Supra 3.0 /
3.0+ to its natural position. You have to the
chain to the pinion and pay attention to the
pulley, carrying the crowns in the exact way
that we tell you in the explanatory video.
Check that it does not come out again with
the folding position.
9Video: https://youtu.be/r-F6gStevVs

Electrical operation
Removal and insertion of the
battery
Supra 3.0 battery can be removed to
recharge off the bike, or to be replaced
with another.
To remove it from the box, you just have
to open the security lock with one of the
keys, and then carefully pull the ring.
To insert it again, carry out the opposite
process: gently slide it into the frame in
the correct position, fold the ring and
lock the lock with the key.
10
Video: https://youtu.be/WTMDipxja9k

Electrical operation
Recharging the battery
The Supra 3.0 battery can be recharged
both inside the frame (uncovering the
triangular cover to access the
connector) and outside of it.
In both cases you must plug the charger
into the mains, and the charger
connector to the battery.
The LED light on the charger will remain
red while charging. Once fully charged
(about 3 hours), it will turn green.
11
Video: https://youtu.be/WTMDipxja9k
There is a USB port on the battery that
can be used to charge any device you
plug in, such as a telephone.

Electrical operation
C300U display operation
The C300U LCD display is activated by
pressing the power button M located in
the center of it.
To run the bike, you must turn on the
battery.
Once turned on, we will have several
fields: speed, engine load, battery,
assistance levels (6), etc.
For the electric assistance to start
working, you have to pedal and the
motor will assist you with the selected
assistance level (use the buttons + /- to
move between them).
12
Video: https://youtu.be/5ZNszel_3MM

Electrical operation
Throttle operation (optional)
The throttle on the Supra 3.0 has the
same operation and installation as on
the Supra ECO.
Unlike the PAS (Pedal Assist System), the
accelerator makes the motor work
without the need to pedal.
In order for the trigger-type accelerator
to work, you must turn on the display
and set the assistance level to 0.
From this state, you must press the –
button to remove any level of
assistance.
Then the throttle is already operational
and it will work by pressing the trigger.
Video: https://youtu.be/v3EkLS2K82s 13
The accelerator is an option that we install
under the responsibility of the user, since
this mode of operation is not compatible
with the European standard EN15194 that
regulates bicycles electrical.

Folding & Unfolding
Unfolding the bike
The steps to unfold your Flebi Supra 3.0
are:
-Place the seat post inside the frame
-Unfold the frame, tighten the front
closure and place the safety (see 17)
-Raise the stem of the handlebar,
close the folding lever and insert the
safety
-Tilt the rear part of the frame until it
returns to its natural position. Once
engaged, it locks automatically
-Unfold the pedals (see 18)
Video: https://youtu.be/NNdWT0ItzAE 14

Folding & Unfolding
Folding the bike
The steps to fold your Flebi Supra 3.0
are:
-Release the swingarm by pressing the
lever next to the yellow elastometer
(see 16)
-Remove the safety and release the
front folding lever to then open the
frame (see 17) and fold the pedals
(see 18)
-Reduces the potential of the
handlebar, removing the safety first
and making sure that the cables are
not tense
-Extract the seat post and place it
between the frame parts
Video: https://youtu.be/NNdWT0ItzAE 15

Folding & Unfolding
Swingarm operation
One of the main advantages of Supra
3.0 is its comfortable and effective
folding mechanism, since with a simple
movement you can semi-fold and
reduce its length by half, very practical
for rolling it.
To do this, you just have to act on the
folding lever located on the back.
To unfold it again, you just have to
return it to its position and the system is
automatically locked.
Video: https://youtu.be/V55_kJvUzy8 16

Folding & Unfolding
Opening/Closing the frame
To open or close the front of the frame,
you just have to remove the safety in
case of opening it and put it in case of
closing it. And release the lever of the
fold out to open it, and press it inward
to close it.
Video: https://youtu.be/W7uTmxfI1VY 17

Folding & Unfolding
Folding/Unfolding the pedals
To fold or unfold each Wellgo pedal you
must press the control outwards and, at
the same time, bend the pedal inwards
(folded) or outwards (unfolded) until you
feel the clic.
Video: https://youtu.be/V55_kJvUzy8 18
