BIKE OWNER’S MANUAL 2015
All rights reserved © 2014 SCOTT Sports SA
SCOTT Sports SA | 17 Route du Crochet | 1762 Givisiez | Switzerland
Distribution: SSG (Europe) Distribution Center SA
P.E.D Zone C1, Rue Du Kiell 60 | 6790 Aubange | Belgium
V4.3/19012015
SCOTT
WALKER

02 WALKER | BIKE OWNER’S MANUAL 2015 BIKE OWNER’S MANUAL 2015 | WALKER 03
www.scott-sports.com
ENGLISH ENGLISH
Congratulations on the purchase of your new SCOTT Walker!
We are confident that the Walker will exceed your expectations
for value, performance and ride quality.
We strongly recommend you take the time to read this manual
and familiarize yourself with this new toy.
Please also take time to ensure that your child understands the
safety information contained in this manual.
General Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 04
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 04
Before Riding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 05
Before Every Ride . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 05
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 06
Care Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 07
Spare Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 07
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 08
CONTENTS

04 WALKER | BIKE OWNER’S MANUAL 2015 BIKE OWNER’S MANUAL 2015 | WALKER 05
ENGLISH ENGLISH
GENERAL INTRODUCTION
BEFORE EVERY RIDE
SAFETY
Please ensure your SCOTT Walker is completely assembled by an authorized
SCOTT dealer.
This is very important for optimum performance and safety.
This SCOTT Walker meets the standards of European Standard EN 71.
Traffic laws demand that one checks all functions that concern safety.
Therefore, before every ride, check the air pressure of the tires (shown on the
sidewall of the tire) and ensure the nuts of the wheels are tightened properly.
Also make sure that the handlebar/stem and the seatpost/saddle are properly
bolted.
Ensure the seat height is set so that when your child is sitting on the saddle, they can
reach the ground with both feet.
The seat height can be adjusted using a 5mm allen key and by following these steps:
1. Loosen the seat post clamp bolt counterclockwise
2. Adjust the seat to the required height according to the need (upper or lower)
3. Align the saddle
4. Tighten the clamp bolt clockwise with a maximum torque of 5Nm/44 in/lbs
Please always respect the minimum insert depth shown on the seatpost and do
not pull out any further as this can loosen the seat post and cause injuries.
Ensure that your child can reach the handlebar easily.
The handlebar/stem height should be adjusted so that when your child is sitting on
the Walker, they can reach the handlebar easily.
The handlebar/stem height can be adjusted using a 13mm wrench key and by
following these steps:
1. Loosen the stem bolt counterclockwise
2. Adjust the handlebar/stem to the required height
3. Align the handlebar/stem
4. Tighten the stem bolt clockwise with a maximum torque of 10Nm/88 in/lbs
Please always respect the minimum insert depth shown on the stem and do not
pull out any further as this can loosen the stem and cause injuries.
MAKE SURE TO WEAR
SAFETYEQUIPMENT!
DO NOT USE IN PUBLICTRAFFIC!
The minimum age for a child to use this Walker is 1 year old.
The maximum load for a SCOTT Walker is 25kg/55lbs.
Your child must be supervised at all times while riding the SCOTT Walker.
Your child must be instructed on how to use the SCOTT Walker in the right way and
be made aware of any possible dangers.
This SCOTT Walker should be used with caution since skills are required to avoid falls
or collisions causing injury to the user or third parties.
This SCOTT Walker shall only be used in a playground or similar safe area.
Do not use the SCOTT Walker in traffic, public roads, near stairs, steep descents or
areas with open water (pools, ponds, etc).
Please make sure that your child wears clothing that is highly visible (bright colors,
reflective details or fabrics, etc) and wears shoes that protect the foot and toes.
Gloves and knee/elbow protectors will also help to avoid bruises or injuries.
The best way to avoid head injuries is to wear a helmet that fits.
The helmet should meet safety standard EN1078 and should have a CE label or
should match or exceed the national standards of your country. Choosing bright
colors will help to improve visibility and safety. Wearing such a helmet should be a
matter of course for all cyclists or children using bikes or Walkers.
In addition, the best way to instruct a child is to lead by example. So make sure you
follow basic safety rules and have fun!
BEFORE RIDING

06 WALKER | BIKE OWNER’S MANUAL 2015 BIKE OWNER’S MANUAL 2015 | WALKER 07
ENGLISH ENGLISH
We recommend periodical care in order to keep your Walker functioning well and in
good condition.
Doing so maintains the value of the Walker and helps to prevent corrosion or other
damages.
- Clean using a soft brush, water and soft towel. Do not use a high pressure cleaner,
otherwise bearings, colors or decals may become damaged
- Do not use aggressive cleaning additives
- Repair any damages as soon as possible
- Grease or oil all metal parts especially during winter use
Please use biodegradable bicycle cleaners and degreasers which are available from
your local SCOTT dealer.
When buying spare parts we strongly recommend visiting your local SCOTT dealer
as they will be best equipped with the knowledge, advice and specific parts that are
correct for your Walker.
By doing so you can avoid using wrong or incorrectly installed parts that could
damage your Walker or cause personal injuries.
Please only use original spare parts as only these can guarantee optimum function
and safety while riding.
Never use adapter solutions on parts such as wheels, seat/seatpost, stem/handlebar!
CARE INSTRUCTIONS
SPARE PARTS
MAINTENANCE
In addition to the checks listed in the Safety section, please check your Walker
regularly according to the following maintenance check list.
If you are ever in doubt, please contact your local SCOTT dealer to avoid potential
damage or injury, and ensure your Walker continues to be safe and fun to ride.
Maintenance Checklist:
PART DESCRIPTION OK
General visual check All parts without visible damage. Replace parts if necessary.
All screws, nuts and bolts tightened according to the
recommended tightening torques.
Saddle/seatpost Check for minimum insertion line (min.55mm!)
Saddle tightened on seatpost
Seatpost tightened in frame
Handlebar/stem The play of the headset. If necessary re-adjust it
Check for minimum insertion (min. 65mm!)
Stem tightened on fork steerer
Bar tightened on stem
Handlebar grips are fixed to the handlebar
Easy to reach
Tires Profile ok
Air pressure on the tires according to the recommendation
of the producer (shown on the sidewall of the tire)
Wheels Spoke tension ok and equalized
Axle nuts/quick release tightened
Reflectors Tight fixed and adjusted
Clean and without cracks
Tightening Torques for SCOTT Walkers:
PART MOUNTING BOLTS MAX. TORQUE
Stem M5
M6
5. 6-7. 8 Nm
9.8-13.7 Nm
Seatpost-seatclamp M4
M5
M6
2.8-3.9 Nm
5. 6-7. 8 Nm
9.8-13.7 Nm

08 WALKER | BIKE OWNER’S MANUAL 2015 BIKE OWNER’S MANUAL 2015 | WALKER 09
SCOTT Bikes
Gambler, Voltage FR, Volt-X
5
ENGLISH ENGLISH
How Do You Make a Claim Under This Limited Warranty?
To make a claim under this limited warranty, you must notify SCOTT of the claimed defect
within the warranty period and timely return the Product to SCOTT at your expense for
inspection. Please contact your authorized SCOTT dealer, call SCOTT’s customer service
or the national SCOTT distributor (dealer locator: www.scott-sports.com). All returned
Products must be accompanied by proof of purchase (receipt) from an authorized
SCOTT dealer or this limited warranty will not apply. In case of replacement or refund,
returned Product becomes the property of SCOTT.
A protocol for the handing over of the Product (which you will find at the end of the
manual) will remain in copy at the SCOTT dealer after acceptance and signature of
the consumer. It is obligatory to show this protocol of handing over together with the
defective part in case of a warranty claim given that it provides evidence of purchase or
this limited warranty will not apply.
How Do State Laws Affect Your Rights Under This Limited Warranty?
This limited warranty gives you specific legal rights, and you may also have other rights,
which vary from state to state.
Recommendation
We strongly recommend that you use only authorized SCOTT dealers for yearly
maintenance services and for repairs, as improper or incorrectly performed maintenance
or repairs voids this limited warranty. Costs for maintenance service have to be borne by
the consumer.
What is Covered?
This warranty covers defects in materials and workmanship at the time of transfer of risks
in frames, swingarms and forks (provided it is a fork of SCOTT) on SCOTT branded bikes
sold completely assembled by SCOTT or an authorized SCOTT dealer (“Product”).
How Long Does Coverage Last?
This voluntary manufacturer’s warranty is limited to five years for frames and swingarms,
respectively two years for forks, from the date of purchase of the Product and is limited
to the first purchaser of the Product. Transfer of the Product from the first purchaser to
another person terminates this limited warranty.
The limited warranty of five years for the frames and swingarms shall only be granted
in case once a year a maintenance service has been effected according to maintenance
requirements as set forth in the manual. The effected annual maintenance service shall
be confirmed by stamp and signature. In case such an annual maintenance service has
not been effected the warranty of five years for the frame shall be reduced to three years.
Costs for maintenance and service have to be borne by the owner of the Product. On
Gambler, Voltage Fr and Volt-X the warranty period is limited to two years.
Repaired or replaced Products are covered for the remainder of the original warranty
period and subject to the conditions outlined in the original warranty, to the extent
permitted by law.
Hereby SCOTT grants a worldwide voluntarily manufacturer’s warranty. To the extent
permitted by law and unless a shorter duration is stipulated by law, any warranties
implied by law are limited in duration to maximum five, respectively two years, from the
date of purchase of the Product and are limited to the first purchaser of the Product.
What Will SCOTT Do?
SCOTT will replace by similar kind and quality or repair any defective Product, or will
refund your purchase price (as evidenced by your tendered receipt of purchase of the
Product), at SCOTT’s option. You must pay charges in connection with replacement of
any non-defective parts. In such a case, you will be alerted to the advisability of replacing
non-defective parts, so you can pre-authorize the costs.
What Does This Limited Warranty Not Cover?
This limited warranty does not cover defects which did not exist before the transfer of
risks. This limited warranty does not cover Products used in rental operations. This limited
warranty does not cover purchases of not completely assembled bikes. This limited
warranty does not cover any defect caused by “wear and tear” (a complete list of all parts
of “wear and tear” can be found in the manual), accident, neglect, improper handling,
abuse, misuse, an act of God, improper assembly, non-compliance with recommended
maintenance and care procedures, improper or incorrectly performed maintenance or
repairs performed by someone other than an authorized SCOTT dealer, use of parts or
devices not consistent with the Product, and alteration of the Product. All Products come
with a manual; please carefully follow the instructions located there or affixed elsewhere
to the Product. To the extent permitted by law, consequential and incidental damages are
not recoverable under this limited warranty.
