Fleetwood 2008 Southwind User manual

,
~.
FLEE7WOOD.
Driven to Explore
©2007 by Fleetwood Enterprises, Inc. All rights reserved. No part of this publication may be reproduced or
transmitted in any form or by
any means, electronic or mechanical, including photocopying, recording, or by any
information storage or retrieval system without written permission from Fleetwood Enterprises, Inc.
IMPORTANT -PLEASE READ: Product information, photography and illustrations included in this manual were as
accurate as possible at the time of publication. Materials, design, and specifications are subject to change without
notice. Fleetwood has designed its recreational vehicles for a variety
of customer uses. Each vehicle features optimal
seating, sleeping, storage, and fluid capacities. The user is responsible for selecting the proper combination ofloads
(Le. occupants, equipment, fluids, cargo, etc.) to ensure that the vehicle's weight capacities are not exceeded.
Manufacturing subsidiaries
of Fleetwood Enterprises, Inc. build the following motor homes and travel trailers:
American
Eagle' American Heritage' American Tradition' Bounder' Bounder Diesel' Dakota' Discovery·
Excursion' Expedition· Fiesta' Gearbox· Jamboree' Lynx· Mallard' Nitrous' Orbit· Pace Arrow' Pegasus'
Pioneer' Providence' Prowler' Redline • Revolution LE • Southwind • Terra' Terry· Tioga' Wildemess •Yukon

This page intentionally blank.

TABLE OF CONTENTS
INTRODUCTION . .................... .01-1 Cargo
Canying Capacity Lobel ........ OS-S
Inspect and Maintain ................... 01-2
Cargo Canying Capacity and Load
Planning and Preparation ................ 01-2
Owner's Information Package ............ 01-2
Chassis and Vehicle Identification ......... 01-3
SuspensionAlignment and Tire Balance .... 01-3
Distribution ...................... 05-6
How to Weigh Your Loaded Motor Home .. OS-6
Dangers of Overloading .............. OS-8
Loading Tips ....................... OS-8
Tires ................................ OS-9
After-Market Steering Aid Devices ........ 01-4
Tire Inflation ....................... OS-9
Warnings, Terms and Concepts for
Air Pressure . ...................... 0S-1O
Safe Operation of Your Motor Home .... 01-4 Underinflation
..................... 0S-1O
Event Data Recording Device
Air Pressure Check . ................ OS-10
(If Equipped) ....................... 01-6
Tire Replacement . .................. 0S-11
Drivers License Requirements ........... 01-6
If You Get a Flat Tire . ............... 0S-11
WARRANTY ..............................................02-1 Changing a Flat
Tire ................ 0S-11
Seats and Seat Belts .................. 0S-11
Coverage Provided .................... 02-1
Air Bags (If Equipped) .............. OS-12
What is Not Covered by This Warranty .... 02-1 Combination Lap and Shoulder Belts .
.. OS-12
Limitations ........................... 02-2
Safety BeltMaintenance ............. OS-12
Your Rights Under State Law ............ 02-2
Safety Restraints for Children . ........ OS-12
Dealer's Obligations ................... 02-2
Safety Belts for Children ............. 0S-13
Owner's Obligations ................... 02-2
Child Seat Tethers .................. 0S-13
Manufacturer's Obligations .............. 02-2
Warranty Service ...................... 02-3
Driving and Vehicle Control ............ OS-14
Using the Engine to Slow the
Motor Home
.. ................... OS-14
Ownercare Card ....................... 02-4
Reporting Safety Defects ................ 02-4
Maneuvering in Traffic ................ OS-14
Rear View Video Monitor (If Equipped) ... 0S-IS
IMPORTANT NOTICES ............... .03-1 Body Undercoating
................... OS-16
SOUTHWIND INFORMATION . ........ .04-1 Fuel and Fuel Systems
................. OS-16
Safe Refueling Guidelines . ........... OS-16
Lamps and Bulbs ...................... 04-1 Fuel Types and Driveability Issues
..... OS-17
Motor Home Fuses and Circuit Breakers ... 04-1 API Refueling Advisory
............... OS-17
Driver's Controls ...................... 04-2
Engine Fan .......................... OS-18
ON THE ROAD ...............................................05-1 Exhaust System Heat
.................. OS-18
Motor Home Loading .................. 0S-1 Engine Temperature Gauges
............ OS-18
Responsibility for Proper Loading ...... 0S-1 Carbon Monoxide Safety Precautions
..... OS-18
Some Definitions First . ............... 0S-1 Carbon Monoxide
DetectodAlmm ..... OS-19
Towing a Vehicle or Trailer . ........... OS-2
Emergency Towing ................... OS-19
Dinghy Towing . ..................... OS-4
Windshield Wipers and Washers ......... OS-19
Trailer Hitch Connector Wiring ........ OS-4
00-1

Table of Contents
LIVING WITHYOUR MOTOR HOME ... 06·1 PLUMBING SYSTEMS
Leveling System (IfEquipped) ........... 06-1 AND HOLDING TANKS
............... 07·1
Power Entry Step
(If Equipped) .......... 06-1 Fresh Water System
.................... 07-1
Entry and Screen Doors ................. 06-1
Patio Awning
(If Equipped) .............. 06-1
Windows ............................ 06-2
Emergency Exit Window(s) ............ 06-2
Remote Mirror Control (IfEquipped) ...... 06-2
External Fresh Water Hookup . ......... 07-1
Filling the On-Board Water Tank ....... 07-1
Draining the Fresh Water Tank . ........ 07-2
Water Pump . ....................... 07-2
Water Pump Filter . .................. 07-2
Low Point Drains . ................... 07-3
Sun Visors
(If Equipped) ............... 06-2 Troubleshooting the Fresh Water System
.. 07-3
Pull Shades (If Equipped) ............... 06-2 Leaks . ............................ 07-3
Day/NightShades (If Equipped) ........ 06-3 Sanitizing the Fresh Water System . ...... 07-3
Mini-Blinds (If Equipped) ............... 06-3 Exterior Shower
(If Equipped) ......... 07-4
Storage .............................. 06-3
Exterior Compartments . .............. 06-3
Whole Coach Water Filter System
(If Equipped) ..................... 07-4
Interior Storage ..................... 06-4 Waste Water System
................... 07-4
Slide-Out Rooms
(If Equipped) .......... 06-4
Interior and Furnishings ................ 06-4
Dinette Conversion (with Built-in Table)
(If Equipped) ..................... 06-4
Dinette Conversion (with Free-Standing
Toilet
............................. 07-4
Draining the Holding Tanks ........... 07-5
Black Tank Flush System (If Equipped) .. 07-6
Holding Tank Care .................. 07-6
Cold Weather Usage ................. 07-7
Table) (If Equipped) ............... 06-5 ELECTRICAL
SySTEMS ............... 08·1
Sofa COllversion (If Equipped) ......... 06-5 Batteries
............................. 08-1
Sleeper Sofa Conversion (If Equipped) ... 06-5
Folding Doors/Privacy Curtain Chassis 12-Volt Electrical System
......... 08-1
Chassis Bulbs and Fuses . ............. 08-1
Dividers . ........................ 06-5
Folding Chairs (If Equipped) .......... 06-5
Free-Standing Furniture (If Equipped) ... 06-5
Interior Lighting .................... 06-6
Overhead Vents ..................... 06-6
Monitor Panel ........................ 06-6
Fleetwood 12-Volt House and Automotive
System
............................ 08-1
Battery Disconnect (If Equipped) ....... 08-1
Battery Inspection and Care . .......... 08-2
Battery Charging . ................... 08-2
Solar Panel (If Equipped) ............. 08-3
Effects of Permanent Occupancy ......... 06-7 Selecting a ReplacementBattery .
....... 08-3
Condensation and How to Control It '" .06-7 Auxilimy Start System
(If Equipped) ..... 08-3
Dripping Ceiling Vents ............... 06-9 120-Volt System
...................... 08-3
Important Information .................. 06-9 Power Converter .
................... 08-4
What the RV Owner Can Do .......... 06-10 Ground Fault Circuit Interrupter (GFCI)
.. 08-4
Fire Safety .......................... 06-11 Generator
(If Equipped) .............. 08-4
Fire Safety Precautions .............. 06-11 Generator Operating Safety Precautions
.. 08-5
Smoke Detector/Alaml . .............. 06-12 Generator Fuel Supply
............... 08-6
Propane Generator (If Equipped) ....... 08-6
Generator Operations ................ 08-6
00-2

Table of Contents
Energy Management System -50 AMP For MAINTENANCE
....................... 11-1
Additional Application ............... 08-6 Exterior
........................... .. 11-1
Electrical Wiring Diagrams
.............. 08-6 Stains
............................. 11-1
Motor Home Fuses and Circuit Breakers
... 08-7 Exterior Graphics Care .
.............. 11-2
Vinyl Front End Mask
(If Equipped) ..... 11-2
PROPANE SYSTEM .•.•.••..•...•...••. 09-1 Windows, Doors, Vents and Locks .
...... 11-2
Propane Safety Precautions .............. 09-1 TPO
Roof System ..................... 11-2
System Components
................... 09-2 Cleaning .
.......................... 11-2
Hoses .
............................ 09-2 Care .
............................. 11-2
Propane Regulator . .................. 09-2 Sealant Renewal
.................... 11-3
Accessory PlVpane Supply Exterior Sealants
...................... 11-3
(If Equipped) ..................... 09-2
DoO/; Window, Roof Component
Using Propane System at
Low and Molding Resealing ............. 11-3
Temperatures
....................... 09-3 AClylic Assist Handles
(If Equipped) ..... .11-3
Filling Propane Tanks
.................. 09-3 Interior
.............................. 11-3
Propane System Check ................. 09-3 Fabrics .
........................... 11-3
Propane Leak Detector/Alarm ............ 09-3 Solid SUlface
Top Care (If Equipped) .... 11-4
Lighting PropaneAppliances
............ 09-4 Laminate
Top Care (If Equipped) ....... 11-4
Walls and Ceiling Panels .
............. 11-4
APPLIANCES ......................... 10 .. 1 AttachingAccessories to
YOUI'
Water Heater ........................ .1 0-1 Motor Home .
..................... 11-4
Water Heater Bypass Valve
............ 10-1 Plastic/Fiberglass Shower Stall .
........ 11-4
Refrigerator
.. . . . . . . . . . . . . . . . . . . . . . . . .10-1 Floors
and Carpeting ................ 11-4
Furnace
.............................1 0-1 Wood Floor
(If Equipped) ............. 11-5
Range
............................... 10-2
Range Exhaust Hood .................. .10-2
Air Conditioner(s) (If Equipped) .......... 10-2
Engine Access ...................... 11-5
Generator Filters
..................... .11-5
Maintenance Guideline
................. 11-5
VCR, Televisions, DVD Player STORAGE
............................ 12-1
(IfEquipped) ...................... .10-3 Storage Checklists
............ ' ......... 12-1
Additional 12-Volt Equipment
.......... .10-3 Short-Term Storage (Less than
60 days) .. 12-1
Video Equipment
...................... 10-3 Long-Term Storage (Over 60 days)
..... 12-2
Video Control Center
................... 10-3 Winterization
......................... 12-2
TV Antenna .......................... 10-3 Water System Winterizing
............. 12-3
Antenna Operating Instructions
........... 10-3
Satellite Dish Antenna
(If Equipped) ...... 10-4
Reactivating the Motor Home
After Storage
....................... 12-4
Telephone Jack
....................... 10-4 GLOSSARY
........................... 13 .. 1
Microwave Oven (If Equipped) ........... 10-4
WasherlDryer-Ready
................... 10-4
Miscellaneous Appliances
............... 10-4
00-3

This page intentionally blank.

Welcome to the recreational vehicle life-style
and the growing family
of motor home owners.
We sincerely thank you for choosing a
Fleetwood motor home!
NOTE I
This manual describes many features ofyour RV and
includes some instructions for its safe use. This man-
ual, including photographs and il/ustrations, is of agen-
eral nature only. Some equipment
and features
described
or shown in this manual may be optional or
because of the continuous program of productchange
conducted
by Fleetwood, itispossible thatrecentprod-
uctchanges maynotbe included.
.II NOTE I
Throughout this manual the term "RV" represents a
"Recreational Vehicle" as defined by the NFPA 1192.
This includes motor homes, fifth wheel trailers, travel
trailers, camping trailers, recreational
park trailers,
and truck campers.
A WARNING
Failure to follow proper procedures or install proper
equipment can result in property damage, injury
and/or death.
INTRODUCTION
Your motor home has been designed to provide
you with years
of carefree, pleasant traveling
and vacationing.
It conforms with, or exceeds,
applicable National Fire Protection Association
(NFPA), Canadian Standards Association (CSA)
(units built for Canada only), Federal Motor
Vehicle Safety Standards (FMVSS), Environ-
mental Protection Agency (EPA) and Califol7lia
Air Resources Board (CARB) regulations. The
seal attached
just outside the entty door indi-
cates compliance with NFPA
or CSA standards.
Like all equipment, your motor home will require
care and regular maintenance
in order to deliver
maximum value and pelformance. The dealer will
give you basic operating and maintenance instmc-
tions. However, supplement this by reading all
instmctional material(s) fumished with the motor
home in the Owner's Information Package and
the motor home Chassis Operator's/
Owner's Guide/Manual. This information out-
lines important areas
of operation and mainte-
nance for you
to follow for safe, trouble-free serv-
ice from your motor home. Study these materials
carefully. A good working knowledge
of your
motor home and how to care for it will help you
enjoy many miles and years
of recreational living.
01-1

Introduction
If you have any questions regarding operation,
maintenance, or service, please contact your
dealer immediately so he can assist you. Your
dealer's Service or Sales Department will handle
any normal problems which might occur.
Some equipment and features described or
shown in this manual may be optional or not
available on some models.
Because
of the continuous program of product
improvement conducted by Fleetwood, it is pos-
sible that recent product changes may not be
included in this manual. Specifications may
change without notice. Product information,
illustrations and photography included in this
Owner's Manual were
as accurate as possible at
the time
of publication, and are representative of
function and mayor may not be specific in their
depiction
of actual equipment, fabrics, interior
or exterior decor or design options as installed
on or in your recreational vehicle.
The instructions included in this manual are
intended
as a guide, and in no respect extend the
responsibilities
of the manufacturing subsidiaty,
parent company or affiliates beyond the standat'd
written warranty as presented in this manual.
Fleetwood has designed its recreational vehicles
to provide a variety
of uses for its customers.
Each vehicle features optimal seating, sleeping,
storage and fluid capacities. The user is respon-
sible for selecting the proper combination of
loads to ensure that the recreational vehicle's
capacities are not exceeded.
INSPECT AND MAINTAIN
Follow a consistent schedule of inspection and
maintenance for your motor home. Your contin-
uing safety and comfort depend on it. This man-
ual includes a section outlining maintenance
intervals.
If you follow the maintenance guide-
lines, you will minimize the possibility of fail-
ure of any important system or part of your
motor home.
01-2
PLANNING AND PREPARATION
Each year millions of Americans embark on
trips using some type
of recreational vehicle.
Proper planning
of your trip will ensure a pleas-
urable experience. A thorough knowledge of
your RV is important if you are going to get the
most out
of the convenience and safety items
built into your motor home. Be
as familiar with
it as you are with your personal car or truck. If
you have trouble or have questions, please con-
sult your dealer.
OWNER'S INFORMATION
PACKAGE
This package contains valuable documents about
your motor home and its equipment and systems.
This Owner's Manual and the Chassis
Operator's Manual are in the package. Since this
manual does not cover every possible detail
of
equipment and options installed on or in your
motor home, there are booklets and instructional
matetial in the package that will help you safely
operate, maintain and troubleshoot those items.
Be sure you read all this information alld
understandthe safety alldoperating instructions
included in thepackage. Additionally, you must
follow all maintenance instructions to insure full
warranty coverage.
If you decide to sell or trade
your motor home, be sure the new owner receives
all the material in this package.
.I, NOTE ,
If your Owner's Information Package does not con-
tain these items, even if you purchased your motor
home "used," please call or
write Fleetwood and
request
the desired or missing information.
Fleetwood OwnerRelations
P.O. Box 1007
Decatur, IN 46733
1-800-322-8216

CHASSIS AND VEHICLE
IDENTIFICATION
Several numbers are used to identify the vehicle
and components used on the vehicle.
The
V.I.N. or Vehicle Identification Number is
assigned by the chassis manufacturer and is the
number used for vehicle registration. The V.IN.
is found on the Federal Certification Tag attached
in the driver's compartment. Refer
to this infor-
mation when ordering parts from the chassis
manufacturer or chassis dealer service center.
The
F.I.N. orFleetwoodIdentification Number
is located on the tag just outside the main entry
door or on the outside left front side of the motor
home. Use this number when ordering parts
through your Fleetwood dealer.
(Example)
FEDERAL CERTIFICATION TAG
MFD BY:
DATEMFD:
INC VEH MFD BY:
DATE OF VEH MFD:
GVWR: KGS ( LBS)
FRONT GAWR:
KGS (
LBS)
WITH: RIMS
TIRES AT: KPA COLD SINGLE
( PSI)
INTERMEDIATE
KGS ( LBS)
GAWR: WITH: RIMS
TIRES AT: KPA COLD DUAL
( PSI)
GAWR REAR: KGS ( LBS)
WITH: RIMS
TIRES AT: KPA COLD SINGLE
( PSI)
GAWR COMBINED
INTERMEDIATE
AND REAR: KGS ( LBS)
This vehicle conforms to all applicable U.S. Federal Motor
Vehicle Safety Standards in effect on the date of manufacture
shown above:
V.I.N.
TYPE VEHICLE: MULTI-PURPOSE PASSENGER VEHICLE
The tires and wheels with sizes and ratings designated above
have been equipped with this vehicle by Fleetwood. Any
replacement tIres Installed must meet the same specifications
and minimum load requirements.
W15-OO16
Located ill the driver's compartment.
Introduction
SUSPENSION ALIGNMENT
AND TIRE BALANCE
The front suspension and steering system of this
vehicle was accurately aligned at the factory
before delively to the dealership. However, after
you have fully loaded the vehicle according to
your personal needs, have the alignment
checked and adjusted,
if necessaty. To help pre-
vent uneven tire wear, check the front-end align-
ment periodically.
Please note thatfront-end alignment after
retail delivery
is the owner's responsibility and
is not covered under the warranty.
(Example)
FLEETWOOD.
MOTOR HOMES
OF
PLAN APPROVAL NO.
r- F.I.N.
MFD.ID.NO.
DATE OF MFR. MO:
INC.
MODEL
YR:
Located Oil the exterior leftfrollt side
of the motor home.
- F.I.N. (Fleetwood Identification No.)
01-3

Introduction
Excessive or abnormal tire wear may indicate
worn
or misaligned suspension or steering com-
ponents, unbalanced or improperly inflated
tire(s) or some other tire/suspension problem.
Alignment can be affected by worn steering/sus-
pension Palts or road hazards such as hitting a
curb, pothole, railroad track, etc. Improper
alignment can cause tires to roll at an angle and
wear unevenly.
It may also cause the vehicle to
"pull" to the right or left.
Out-of-balance tires will not roll smoothly and
will cause annoying vibrations and uneven tread
wear such as cupping or flat spots.
If you see
uneven tire tread wear or if the vehicle ride
comfort decreases, the tires may need to be
balanced.
See the Chassis Operator's/Owner's Guide/
Manual for more information.
AFTER-MARKET STEERING AID
DEVICES
Fleetwood does not sanction or condone the
installation
of any steering aid device that is not
approved
by our chassis manufacturer's. Any
add-on device of this type may void the chassis
manufacturer's warranty on the item
or items
affected.
WARNINGS, TERMS AND
CONCEPTS FOR SAFE
OPERATION OFYOUR MOTOR
HOME
Vehicle Crash
01-4
Like any other vehicle you may drive, your
motor home can be involved
in a vehicle
crash, including a rollover. The motor home
will be dalUaged and you and others can be
injured or killed. Drive defensively at all
times.
DO Nor drive ifyou are tired, have
been drinking alcoholic beverages, are under
the influence
of any controlled substance, or
are taking any medication or drugs that may
impair your sight, hearing, judgmentor coor-
dination. Pull offthe road and park in a safe
al'ea until you can drive safely.
Vehicle Handling
Your motor home is longer, wider and
higher than a typical car
or truck you may
be accustomed to driving. Keep this in
mind as you become familiar with driving
your motor home. New motor
home own-
ers should take special care to learn the
driving and handling characteristics
of your
vehicle in safe and familiar surroundings.
The distribution of the weight of your
motor home is designed so it will handle
safely while being driven.
• When loading the motor home, balance
the loadfront-to-rear
and side-to-side.
• Load
and secure heavier items lower in
the storage areas than lighter items.
If you fail to properly load your belongings and
supplies, you will defeat the load distribution
design
of the motor home, possibly leading to
handling problems and a vehicle crash.
Vehicle Response
When you, the driver, accelerate, brake or
steer the motor home,
it responds to these
inputs. If you are faced with an emergency
while driving, the way
you respond to the
emergency and the way the motor home
responds becomes more critical.
If you
load, alter
or maintain your motor home
improperly, it will not respond as
it did
when you first received it in an unloaded
condition. Improper loading, alteration,
maintenance
and improper driver
responses to emergency conditions can
lead to handlingproblems
and vehicle
crashes.
Vehicle Towing
Your motor home can be equipped with a
hitch designed to allow you to tow vehicles
