FlexLink 5113441-01 Operator's manual

5113004

AGS
Power supply
Voltage: 400 VAC (Controlled)
Phases: 3
Frequency: 50 Hz
Current: 0.5 A

AGS
CE marking location
The CE marking is located on the outside of the door, in
the upper left corner.
Electricians
Electricians must have:
Experience from similar installations
Sufficient knowledge to work from drawings and
wiring diagrams
Knowledge of local safety regulations for electrical
power and automation
Knowledge in english language
To avoid risks, only experienced personnel with technical
knowledge and experience may perform repair work on
the machine's electronics components.
Application of usage
The Power box is to be used for controlling FlexLink
Guide units as a complement to the FlexLink Control box
in a AGS-system. which fixed installation according to
2004/108/EC Electromagnetic Compatibility Directive
(EMC).
The Power box must be controlled/powered by a FlexLink
Control box.
The Power box should not be used for any other purpose
than controlling FlexLink Guide rails.
The installation must be regarded as a fixed installation
according to 2004/108/EC Electromagnetic Compatibility
Directive (EMC).
Safety
The voltage in the box is 400V for Europe or 480V for US.
Ensure that the box is closed and locked after working in
the box.
The box can only be opened using a tool.
Only authorised personnel may open electrical units.
Incorrect use of the equipment can cause personal
injury.
Do not stand or climb on the equipment.
Only use recommended spare parts.
Before working in the box, the main switch must be
turned off and locked.
Assembly
The box is equipped with two aluminium beams on the
backside to facilitate mechanical assembly.
Installation
The incoming power, supplied by the FlexLink Control
box, should be connected to terminal group X30101.
Protective earth should be connected to PE terminal.
Note: The phases of the power supply are controlled by
the Control box, shifting the rotation direction and starting
the motors inside Guide units.
Electrical supply data, Europe-version:
Voltage: Controlled 400 VAC
Phases: 3
Frequency: 50 Hz
Current: 0.5 A
Electrical supply data, US-version:
Voltage: Controlled 460-480 VAC
Phases: 3
Frequency: 60 Hz
Current: 0.5 A
Connect the Guide unit's included cable to connector
X31103 or X31104.

EC Declaration of Conformity
_________________________________________________________________________
FlexLink Components AB Flexlink Components AB
______________________ ________________________
Svante Anderholm Anders Jonsson
Chief Operating Officer Responsible Technical file
_________________________________________________________________________
FlexLink Components A
B
Telephone: [phone] SE-415 50 Göteborg
Fax: [phone] Sweden
www.flexlink.com
FlexLink Components AB
SE-41550 Göteborg
Sweden
declares that the following product(s) is in line with the essential requirements of the below
directive(s)
•AGS Power box 5113441
Corresponding EC directives:
Low Voltage Directive 2006/95/EC
According to 2004/108/EC Electromagnetic Compatibility Directive (EMC), the listed device
is not indepentently operable product, but intended as part of a given fixed installation.
Compliance of the directive requires the correct installation of the product, the observance of
specific installation notes and product documentation.

Spare parts list Power box 5113441
Pos Des Name Manufacturer Manufacturer item nr Qty Comment
Q30103 Miniature circuit breaker Merlin Gerin C60N 1P C6A Q30105 Miniature circuit breaker Merlin Gerin C60N 1P C6A
T30103 Transformer FlexLink 5058593 T30103 Fuse Littlefuse 1A, 5x20mm T30105 Transformer FlexLink 5058593 T30105 Fuse Littlefuse 1A, 5x20mm
K30104 Relay Finder 40.51.8.024 K30104 Relay socket Finder 95.05.SMA K30106 Relay Finder 40.51.8.024 K30106 Relay socket Finder 95.05.SMA X30103 Connector Wieland 96.031.1053.1 X30104 Connector Wieland 96.031.1053.1
