Peak Scientific Precision Series User manual

Precision Nitrogen User Manual Rev 4 RSID 226 EN 21/12/17
Precision Nitrogen (All Models)
User Manual

Contents
Change History 3
How to use this Manual 3
Introduction 4
Warranties and Liabilities 5
Safety Notices 6
Symbols 6
Safety Notice to Users 6
Declaration of Conformity 7
Environmental Declaration 8
Technical Specification 9
Unpacking 11
Fittings Kit Contents 12
Unpacking Instructions 12
Installation 13
Generator Environment 13
Generator Overview 14
Nitrogen General Dimensions 14
Nitrogen Trace General Dimensions 15
Nitrogen Rear Connections 16
Nitrogen Trace Rear Connections 17
Electrical Connection 18
Air Purity 19
Class 1 Particulate 19
Class 4 Water 19
Class 1 Oil 19
Start-Up Sequence 20
On Demand Gas 20
Unusual Operation 20
Connecting to the application 21
Tubing Lengths 21
Service Requirements 22
Service Schedule 22
Peak Protected 23
Cleaning 24
Troubleshooting 25
Page 2

Page 3
Change History
Rev Comment Name Date
1 Release Liam Couttie 14/12/2016
2 Technical Specification Update Liam Couttie 08/02/2016
3 Nitrogen Headspace Added Liam Couttie 06/09/2016
4 Product Overview Correction Liam Couttie 21/12/2017
How to use this Manual
This manual is intended for end users and has been written as a reference document
where you can skip to the relevant information.
Users can refer to the contents page to find the relevant information.
Please review each of the following sections carefully.
Thank you for selecting Peak Scientific to meet your gas generation needs, and should
you require any further assistance or support please do not hesitate to contact Peak
Scientific or the Peak Partner from which you purchased your generator.

Page 4
Introduction
Precision is a modular system with differing flow rates that allows you to add multiple
generators as your gas and analysis demands change. The Precision Series will keep
your gas flowing with consummate accuracy and reliability, whatever your needs, while
fitting neatly into any lab space.
The Precision Nitrogen, Headspace and Nitrogen Trace Generators provide a constant
and consistent source of Nitrogen for detector make-up gas for GC applications, as
well as headspace vial pressurization, purge and trap, tube conditioning for thermal
desorption and sample blow down. In addition to these applications, the Precision
Nitrogen Trace model can be used for carrier gas in GC applications as it also removes
hydrocarbons by means of catalytic oxidation.
Other features include:
• Generates Nitrogen on demand from compressed air.
• Regenerative PSA Carbon Molecular Sieve to ensure Oxygen and Moisture removal.
• Minimum maintenance with only a filter change per annum.
• Small and Stackable.
With the Precision Nitrogen based on proven technology, it removes moisture and
oxygen to leave Ultra High Purity Nitrogen. The Nitrogen Trace further removes
Hydrocarbons (as Methane) to <0.05ppm.
To ensure these generator models meet our high expectations with regards to reliability
and performance, we have tested them extensively at our manufacturing plant and with
end users around the world to ensure reliability and longevity of the system.

Page 5
Warranties and Liabilities
1. The Company warrants that it has title to the Goods.
2. Subject to the provisions of this clause the Company warrants that the Goods
shall comply in all material respects with any specification referred to in the Order
Confirmation (as the same may be amended) and shall, subject thereto, be free
from defects in material and workmanship for the lesser of a period of twelve
months from the date of delivery or thirteen months from the date of dispatch
from the factory.
3. Save as provided in this clause and except where the Goods are sold to a person
dealing as a consumer (within the meaning of the Unfair Contract Terms Act
1977) all warranties, conditions or other terms implied by statute or common
law are hereby expressly excluded save to the extent they may not be lawfully
excluded. When the Goods are sold to a consumer within the meaning of the Unfair
Contract Terms Act 1977 their statutory rights are not affected by the provisions of
this clause.
4. In the event of the Customer making a claim in respect of any defect in terms of
clause 2 hereof the Customer must.
1. Reasonably satisfy the Company that the Goods have been properly installed,
commissioned, stored, serviced and used and without prejudice to the generality
of the foregoing that any defect is not the direct or indirect result of lack of repair
and/or servicing, incorrect repair and/or servicing, use of wrong materials and/or
incorrect spare parts
2. Allow the company to inspect the Goods and/or any installation and any relevant
packaging as and when reasonably required by the Company.
5. Subject to the Company being notified of any defect as is referred to in sub-
clause 2 hereof within a reasonable time of it becoming apparent and subject always
to the terms of sub-clause 4 hereof, the Company shall, in its option, replace or
repair the defective Goods or refund a proportionate part of the Price. The Company
shall have no further liability to the Customer (save as mentioned in sub-clause 6
hereof).
6. The Company shall be liable to indemnify the Customer in respect of any claim
for death or personal injury to any person in so far as such is attributable to the
negligence or breach of duty of the Company or any failure by the Company to
comply with the provisions of sub-clause 2 hereof.
7. Save as provided in sub-clause 2 hereof the Company shall not be liable in respect
of any claim by the Customer for costs, damages, loss or expenses (whether direct,
indirect, consequential or otherwise) or indemnity in any respect howsoever arising
including, but not by way of limitation, liability arising in negligence (other than
pursuant to clause 6 above) that may be suffered by the Customer or any third
party.

Page 6
Safety Notices
Peak Scientific Instruments cannot anticipate every possible circumstance which may
represent a potential hazard. The warnings detailed within this manual refer to the most
likely potential hazards, but by definition cannot be all inclusive. If the user employs
an operating procedure, item of equipment or a method of working which is not
specifically recommended by Peak Scientific, the user must ensure that the equipment
will not be damaged or become hazardous to persons or property.
Symbols
This manual uses the following symbols to highlight specific areas important to the safe
and proper use of the generator.
A WARNING notice denotes a hazard. It calls attention to an operating procedure,
process or similar, which if not correctly performed or adhered to, could cause
personal injury or in the worst case death. Do not proceed beyond a WARNING
notice until the indicated conditions are fully understood or met.
A CAUTION notice denotes a hazard. It calls attention to an operating procedure,
process or similar, which if not correctly performed or adhered to, could cause
damage to the generator or the application. Do not proceed beyond a CAUTION
notice until the indicated conditions are fully understood or met.
Caution, risk of electric shock. Ensure power to the generator has been removed
before proceeding.
Safety Notice to Users
These instructions must be read thoroughly and understood before
installation and operation of your Peak Generator. Use of the generator
in a manner not specified by Peak Scientific MAY impair the SAFETY
provided by the equipment.
When handling, operating or carrying out any maintenance, personnel
must employ safe engineering practices and observe all relevant local
health and safety requirements and regulations. The attention of UK
users is drawn to the Health and Safety at Work Act 1974, and the
Institute of Electrical Engineers regulations.
If the equipment is used in a manner not specified by the manufacturer,
the protection provided by the equipment maybe impaired.

Page 7
Declaration of Conformity
We Peak Scientific Instruments Ltd.
Of Fountain Crescent, Inchinnan, Renfrewshire, PA4 9RE
Declare that:
Equipment: Nitrogen Generator
Models: Precision Nitrogen 250cc, 600cc, 1000cc, Headspace
Precision Nitrogen Trace 250cc, 600cc, 1000cc
To which this declaration relates, is in conformity with the applicable EC directives,
harmonized standards, and other normative requirements.
• Low Voltage Directive 2006/95/EC
EN 61010-1: 2010 Electrical Equipment for measurement, control and laboratory use.
• Electromagnetic Compatibility Directive 2004/108/EC
EN 61326-1: 2013 Electrical Equipment for measurement, control and laboratory use.
• FCC47 CFR Part 15 Class B
Unintentional radiators; Conducted and Radiated emissions limits.
All evaluation, testing and certification issued by:
Nemko Canada Inc.
303 River Road, Ottawa
Ontario, Canada
K1V 1H2
Signed: Name: Chris Pugh
Date: 26/10/2015 Position: Engineering & Operations Director

Page 8
Environmental Declaration
We Peak Scientific Instruments Ltd.
Of Fountain Crescent, Inchinnan, Renfrewshire, PA4 9RE
Declare that:
Equipment: Nitrogen Generator
Models: Precision Nitrogen 250cc, 600cc, 1000cc, Headspace
Precision Nitrogen Trace 250cc, 600cc, 1000cc
Is fully compliant with the following Directives
• 2012/19/EU WEEE (Waste of Electrical and Electronic Equipment)
• 2011/65/EU RoHS 2 (Restriction of Hazardous Substance)
Peak Scientific Instruments Ltd fully complies with its obligations towards the European
WEEE (Waste of Electrical and Electronic Equipment) Directive 2012/19/EU. These
obligations are being met within the B2B compliance group.
Peak Scientific Instruments Ltd has developed all reasonable ‘due diligence’ controls to
ensure that our products comply with the principles and requirements of the European
recast RoHS (Restriction of Hazardous Substances) Directive 2011/65/EU. Similar
directives in the United States and China, for example, have also been captured within
this program.
Where a specific certificate of compliance is required, this can be requested, on
a product serial number basis, directly from Peak Scientific Instruments Ltd, by
contacting us through our website on www.peakscientific.com
Signed: Name: Chris Pugh
Date: 10/06/2015 Position: Engineering & Operations Director

Page 9
Technical Specification
Precision Nitrogen
Environment
250cc 600cc 1000cc
Minimum Operating Ambient Temperature 5°C (41°F)
Maximum Operating Ambient Temperature 35°C (95°F)
Maximum Altitude 2000 m
Maximum Relative Humidity 70% Non-Condensing
Minimum Storage Temperature* -20°C (-4°F)
Maximum Storage Temperature* 60°C (140°F)
Inlet Conditions
Inlet Air Pressure Min-Max 6.9-8.3 bar (100-120 psi)
Minimum Air Inlet Flow 35 l/min
Minimum Air Inlet Quality ISO 8573-1:2010 Class[1.4.1]
Particles <0.01µm
Generator Outlets
Maximum Gas Output Pressure 5.5 bar (80 psi)
Maximum Outlet Flow Rate 250cc 600cc 1000cc
Start-up time 1.5 Hours
Particles <0.01µm
Phthalates NONE
Suspended Liquids NONE
Gas Outlets 1 x ¼” BSPP
For optimum performance from your Precision Nitrogen generator, the inlet gas supply pressure should be
30PSI greater than the required output pressure.
Electrical Requirements
Voltage 100-240v
Frequency 50/60 Hz
Current 0.4-0.2A
Input Connection C14 Plug
Power Cord (Supplied) C13 Socket to Local Connection
Pollution Degree 2
Insulation Category II
General
Dimensions cm (inches) WxDxH 38.0 (14.9) x 54.0 (21.2) x 25.6 (10.0)
Generator Weight Kg (lbs) 21 (46.2) 26 (57.3)
Shipping Weight Kg (lbs) 24 (53) 29 (64)

Page 10
Technical Specification
Precision Nitrogen Headspace
Environment
Minimum Operating Ambient Temperature 5°C (41°F)
Maximum Operating Ambient Temperature 35°C (95°F)
Maximum Altitude 2000 m
Maximum Relative Humidity 70% Non-Condensing
Minimum Storage Temperature* -20°C (-4°F)
Maximum Storage Temperature* 60°C (140°F)
Inlet Conditions
Inlet Air Pressure Min-Max 8.3-8.6 bar (120-125 psi)
Minimum Air Inlet Flow 18 l/min
Minimum Air Inlet Quality ISO 8573-1:2010 Class[1.4.1]
Particles <0.01µm
Generator Outlets
Maximum Gas Output Pressure 6.9 bar (100 psi)
Maximum Outlet Flow Rate 250cc
Start-up time 3 - 3.5 Hours
Particles <0.01µm
Phthalates NONE
Suspended Liquids NONE
Gas Outlets 1 x ¼” BSPP
For optimum performance from your Precision Nitrogen generator, the inlet gas supply pressure should be 30PSI greater than the
required output pressure.
Though the Precision Headspace Generator delivers nitrogen at a purity suitable for most non- trace applications, we would
recommend the installation of oxygen and hydrocarbon traps for analysis at lower detection limits (<1000ppm).
Electrical Requirements
Voltage 110-230v ±10%
Frequency 50/60 Hz
Current 0.37 -0.17 A
Input Connection C14 Plug
Power Cord (Supplied) C13 Socket to Local Connection
Pollution Degree 2
Insulation Category II
General
Dimensions cm (inches) WxDxH 38.0 (14.9) x 54.0 (21.2) x 25.6 (10.0)
Generator Weight Kg (lbs) 21 (46.2)
Shipping Weight Kg (lbs) 24 (53)

Page 11
Technical Specification
Precision Nitrogen Trace
Environment
250cc 600cc 1000cc
Minimum Operating Ambient Temperature 5°C (41°F)
Maximum Operating Ambient Temperature 35°C (95°F)
Maximum Altitude 2000 m
Maximum Relative Humidity 70% Non-Condensing
Minimum Storage Temperature* -20°C (-4°F)
Maximum Storage Temperature* 60°C (140°F)
Inlet Conditions
Inlet Air Pressure Min-Max 8.3-10 bar (120-145 psi)
Minimum Air Inlet Flow 18 l/min 22 l/min
Minimum Air Inlet Quality ISO 8573-1:2010 Class[1.4.1]
Particles <0.01µm
Generator Outlets
Maximum Gas Output Pressure 5.5 bar (80 psi)
Maximum Outlet Flow Rate 250cc 600cc 1000cc
Start-up time 1.5 Hours
Particles <0.01µm
Phthalates NONE
Suspended Liquids NONE
Gas Outlets 1 x ¼” BSPP
Electrical Requirements
Voltage 115 VAC ±10% 230VAC ±10%
Frequency 60 Hz 50 Hz
Current 4.4A 2.1A
Input Connection C14 Plug
Power Cord (Supplied) C13 Socket to Local Connection
Pollution Degree 2
Insulation Category II
General
Dimensions cm (inches) WxDxH 38.0 (14.9) x 54.0 (21.2) x 40.6 (15.8)
Generator Weight Kg (lbs) 38 (83.6) 38 (83.6) 36(79.2)
Shipping Weight Kg (lbs) 42 (92.4) 42 (92.4) 40(88)

Page 12
Unpacking
Although Peak Scientific takes every precaution with safe transit and packaging, it is
advisable to fully inspect the unit for any sign of transit damage.
Check ‘SHOCKWATCH’ and ‘TIP-N-TELL’ labels for signs of rough handling prior to
unpacking.
Any damage should be reported immediately to the carrier and Peak Scientific or the
Peak Partner from where the unit was purchased.
Follow the unpacking instructions posted on the side of the crate. It will require two
people to remove the unit from the shipping crate and to manoeuvre the generator
onto the bench.
Please save the product packaging for storage or future shipment of the generator.
Note: Included with the generator is a “Fittings Kit” containing mains power leads for
UK, EU & US and also all the required fittings and warranty registration card. Be careful
not to discard these with the packaging.
Page 12

Page 13
Fittings Kit Contents
Supplied in the Fittings Kit are all the fittings required to connect the generator to the
application. The contents of the Fittings Kit are as follows:
1. Teflon Tubing x 3m
2. ¼” Compression Fitting x 1
3. 1⁄8” Compression Fitting x 1
4. UK Mains Power Cable x 1
5. EU Mains Power Cable x 1
6. US Mains Power Cable 110v x 1
7. US Mains Power Cable 230v x 1
All of the generators output ports are located on the output panel at the rear of the
unit.
Unpacking Instructions
The unit weight constitutes a two person lift and as such, safe lifting practices should
be employed; do not attempt to lift on your own, as you will significantly increase the
chance of injury & damage to yourself and others around you.
1. Remove the screws encircled in red around the bottom of the crate lid and lift
upwards.
2. Next, with someone on either side of the unit, position your hands underneath the
unit ready to lift.
3. Ensuring your knees are bent and your back is straight, lift the unit to the desired
location.

Page 14
Installation
Generator Environment
The generator is designed for indoor use only. It should be installed adjacent to
the application(s) it is supplying. If this is not convenient then the unit can be sited
elsewhere, however, consideration should be made of the lengths of pipe runs as
pressure drops can result from extended runs of pipe.
Performance of the generator (like all sophisticated equipment) is affected by ambient
conditions. Note should also be taken to the proximity of Air Conditioning outlets.
These can sometimes give rise to “pockets” of air with high relative humidity. Operation
of the unit within such a pocket could adversely affect its performance. Consideration
should also be given to the air flow around the unit. It is recommended that an air gap
of 75mm (3”) should be maintained down both sides and at the rear of the unit. Please
refer to the drawing below for the general dimensions of the unit.
Minimum Operating Ambient Temperature: 5 °C (41 °F)
Maximum Operating Ambient Temperature: 35 °C (95 °F)

Page 15
Generator Overview
Nitrogen General Dimensions
The generator must always be placed on a flat, level surface. Failure to
do so will affect the performance of the generator.
380 mm / 14.9”
540 mm / 21.2”
256 mm / 10"

Page 16
Nitrogen Trace General Dimensions
The generator must always be placed on a flat, level surface. Failure to
do so will affect the performance of the generator.
380 mm / 14.9”
540 mm / 21.2”
406mm / 15.9”

Page 17
Nitrogen/Headspace Rear Connections
Power Inlet
¼" Compression Fitting
1⁄8”Compression Fitting
Mains Cable

Page 18
Nitrogen Trace Rear Connections
Power Inlet
¼" Compression Fitting
1⁄8”Compression Fitting
Mains Cable

Page 19
Electrical Connection
Connect the generator to an appropriate 110 or 230 volt single-phase supply, refer to
the generator serial plate for input specification and ensure your supply matches the
requirements.
If the appropriate power cord is not supplied; a new plug, rated to at least 12 amps, can
be fitted by a qualified electrician.
This unit is classified as SAFETY CLASS 1. THIS UNIT MUST BE
EARTHED. Before connecting the unit to the mains supply, please
check the information on the serial plate. The mains supply must be of
the stated AC voltage and frequency.
EARTH/GROUND (E):- Green & Yellow or Green
LIVE (L):- Brown or Black
Neutral (N):- Blue or White
Electrical requirements are 110 or 230VAC nominal +/- 10% depending on chosen
model. However, running continuously at voltages outwith this is not recommended.
Extended periods at extremes can have a detrimental effect on the operation and life of
the generator.
If the equipment is used in a manner not specified by the manufacturer,
the protection provided by the equipment maybe impaired.

Page 20
Air Purity
The Precision Nitogen Series generator should be connected to an air supply that, as a
minimum, meets ISO8753-1:2010 Class 1.4.1
Class 1 Particulate
In each cubic metre of compressed air, the particulate count should not exceed 20,000
particles in the 0.1 - 0.5 micron size range, 400 particles in the 0.5 - 1 micron range and
10 particles in the 1 - 5 micron size range.
Class 4 Water
A pressure dew point (PDP) of +3°C or better is required and no liquid water is allowed.
Class 1 Oil
In each cubic metre of compressed air, not more than 0.01mg of oil is allowed. This is a
total level for liquid oil, oil aerosol and oil vapour.
