Flexwatch FW1176 User manual

FW1176 User’s Manual
M4062-00 1 Seyeon Tech Co., Lt
FW1176 User’s Manual
(Product Guide)
Version 4.14(Rev.E)
pril 13, 2012
Class A Digital Device (industrial & commercial environment)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to CE and
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.

FW1176 User’s Manual
M4062-00 2 Seyeon Tech Co., Lt
FW1176 User’s Manual
Document Part Number: M4062-00
Document Version: 4.14(Rev.E)
Revise : April 13, 2012
About This Document
This ocument is prepare for users of FW1176 supplie by Seyeon Tech Co., Lt . It is assume that the
users are familiar with Microsoft Win ows operating systems an Web browsers such as Internet Explorer.
It is also assume that the users are well aware of how to install an use the network equipment such as
LAN, Hub, router, an having basic knowle ge of network terminologies. If you have any questions
regar ing network installations, please contact your network equipment ven or or network a ministrator
or Internet service provi ers.
For up ate contents, etaile features an other applications from Seyeon Tech, please refer to the user’s
manual in CD-ROM provi e with the pro uct you purchase , or visit Seyeon Tech’s Internet homepage at
http://www.flexwatch.com/.
Copyright Notice
Copyright © 2012 Seyeon Tech Co., Lt . All rights reserve .
No part of this ocument may be repro uce in any form or by any means without the prior written
permission of Seyeon Tech Co., Lt .
Disclaimer
Seyeon Tech Co., Lt . (Seyeon Tech) Makes no representations or warranties with respect to the contents
hereof. In a ition, information containe herein is subject to change without notice. Every precaution has
been taken in the preparation of this manual, nevertheless, Seyeon Tech assumes no responsibility for
errors or omissions or any amages resulting from the use of the information containe in this ocument.
Tra emarks
FlexWATCH
®
an FlexWATCH
®
Logo are tra emarks of Seyeon Tech Co., Lt .
Win ows an Internet Explorer are a tra emark of Microsoft Corporation.
All other tra emarks belong to their respective owners.
Technical Support
For technical support call, email, or visit our web site.
Telephone: [phone]~1
Email: [email protected]
Web site: http://www.flexwatch.com or http://www.seyeon.co.kr

FW1176 User’s Manual
M4062-00 3 Seyeon Tech Co., Lt
Contents
1. PRODUCT OVERVIEW ......................................................................................................................... 4
1.1. FW1176 .......................................................................................................................................................................... 4
1.2. K EY F EATURES ................................................................................................................................................................. 5
1.3. T ECHNICAL S PECIFICATION ........................................................................................................................................... 6
1.4. FW1176 P ACKING L IST ................................................................................................................................................ 9
2. HARDWARE DESCRIPTION .............................................................................................................. 10
2.1. F RONT V IEW UNDER D OME C OVER ......................................................................................................................... 10
2.1. R EAR V IEW UNDER D OME C OVER ............................................................................................................................ 11
2.1.1. CTL Port Description ......................................................................................................................................... 12
2.1.2. Speaker V-out Jack Description ................................................................................................................... 12
2.1.3. MIC Jack Description ........................................................................................................................................ 12
3. FW1176 INSTALLATION AND BASIC SETUP ................................................................................. 13
3.1. B EFORE I NSTALLATION ................................................................................................................................................. 13
3.2. F ACTORY D EFAULT S ETTINGS ..................................................................................................................................... 13
3.3. I NSTALLING FW1176 .................................................................................................................................................. 13

FW1176 User’s Manual
M4062-00 4 Seyeon Tech Co., Lt
1. Product Overview
1.1. FW1176
FlexWATCH® 1176 is a stand-alone device transmitting vdeo from built-in megapixel camera over
IP(Internet Protocol) network. FW1176 model is divided into 3 different types: DS, MS and FS.
It can transmit up to 30fps@D1(DS)/1.3M(MS)/2M(FS) over the existing network. You can monitor
video of FW1176 through web browser(ie. MS Internet Explorer), if FW1176 is connected to network.
FW1176 supports video compression both MJPEG and H.264 simultaneously so that user can choose
appropriate video compression for the purpose. For both MJPEG and H.264, FW1176 provides 6 levels of
video quality. FW1176 also supports both ONVIF and PSIA.
Built-in SD card slot for full-blown DVR functionality is optional.
Picture 1 : FW1176

FW1176 User’s Manual
M4062-00 5 Seyeon Tech Co., Lt
1.2. Key Features
Standalone device with a built-in web server
10M/100M Auto-Sensing Ethernet
Configuring and controlling through Web browser
Max 30 fps transmission speed on TCP/IP network
Effective Bandwidth & Bit-rate Control (VBR/CBR) by H.264
Supports Dual Streaming in MJPEG and H.264
1ch Voice Encoding/1ch Voice Decoding
Support Dynamic IP network by IPCCTVDNS Server
Support various PTZ (Pan/Tilt/Zoom) devices
Support Sensor Input and Digital Output
Support Transparent Mode
Built-in 2 way Audio transmission (1ch A-in, 1 A-out)
Encryption function by user authentication
Image transmission function via FTP and Email
Support both ONVIF/PSIA

FW1176 User’s Manual
M4062-00 6 Seyeon Tech Co., Lt
1.3. Technical Specification
FW1176-DS FW1176-MS FW1176-FS
Hardware
32bit Embedded CPU
NAND Flash 128Mbytes/DDR2: 128Mbytes
Linux version 2.6.xx operating system
Battery backed up real-time clock
Image sensor
1/3” CCD (ICX638,ICX639)
Resolution: 560 TV Lines
S/N ratio: 52dB or more
(AGC OFF, Weight ON)
Electronic shutter speed :
1/60(50) ~ 1/120,000 sec
Sens-up :
AUTO/FIXED/OFF
(selectable limit x2 ~ x256)
White Balance:
ATW/AWC/Manual/Outdoo
r(1800K~10,500K)/Indoor(
4500K ~8500K)
1/3” progressive scan MOS
Active pixels 1280H x
1024V, 1.31M
Effective pixels 1376H x
1070V, 1,47M
Pixel size: 3.75 (H) µm ×
3.75 (V) µm
Color filter Bayer
arrangement of primary
colors: R, G, B
Bit number of internal
ADC: 12 bits
Parallel output: 54 MHz, 12
bits
Output frame rate: 30 fps
1/2.8” progressive scan
CMOS
Active pixels 2080H x
1553V, 3.23M
Effective pixels 2096H x
1561V, 3.27M
Pixel size : 2.5 (H) µm ×
2.5 (V) µm
Color filter Bayer
arrangement of primary
colors: R, G, B
Bit number of internal
ADC: 10/12 bits
Parallel output: 37.125
MHz, 10/12 bits
Maximum frame rate in all-
pixel scan mode: 60 fps
Lens Auto IRIS & Vari-focal
2.8 - 10.5 mm F1.2
Auto IRIS & Vari-focal
for Megapixel
3.6 - 16.0 mm F1.2
Auto IRIS & Vari-focal
for 2Megapixel
2.8 - 10.0 mm F1.2
Minimum illumination Color: 0.15 Lux (F1.2) B/W: 0.002 Lux (F1.2)
(Sens-up: x128)
Color: 0.5 Lux(F1.2)
B/W: 0.02 Lux(F1.2) Color: 2 Lux(F1.2) B/W: 0.01 Lux(F1.2)
Video related special
functions
Color mode (Coler/Gray)
Hue/Saturation/Contrast/Br
ightness Control
Day & Night (Auto/B&W/Off)
Auto White Balance
Noise Filter (Off/On)
Brightness/Contrast/Sharpness/AGC Gain Control
Lens Type (DC/Manual)
Shutter (Manual/Auto)
Vertical/Horizontal Flip
Frequency Control (50/60)
Video compression MJPEG
H.264
Video Standards ONVIF
PSIA
Resolution
720x480,
704x480,
352x240,
176x112
1280x1024,
704x480,
352x240,
176x112
1920x1080,
1280x720
640x352,
320x176,
160x96

FW1176 User’s Manual
M4062-00 7 Seyeon Tech Co., Lt
Frame rate
(each channel) Up to 30/25 fps @4CIF (Other Stream at QCIF) Up to 30 fps @ 1024p (Other Stream at QCIF) Up to 30 fps @ 1080p (Other Stream at QCIF)
Video Streaming MJPEG and H.264 Dual Streaming (Simultaneously)
Controllable frame rate and bandwidth
Image setting Compression levels: 6 (MJPEG, H.264)
Color: color, black & white
Voice 8 bit PCM (G.711-u-low), Sampling rates 8KHz, Mono Audio
1ch in & 1ch out
LAN interface 10/100BaseT Ethernet auto sensing IEEE 802.3af Built-in POE (optional)
IEEE 802.11b/g Built-in wireless (optional)
SD card slot Option
Alarm I/O Interface 1 Photo-coupled inputs and 1 Relay output
Video Output 1 loop through analog
video outputs - -
Audio Input(MIC)
Input Impedence : 4 KOhm
Pantom Power : 3.3 Volt
Gain : 20 dB
Jack : 3.5mm Mono
Input Impedence : 4 KOhm
Pantom Power : 5 Volt
Gain : 20 dB
Jack : 3.5mm Mono
Audio Output(SPK)
Output Impedence : 130 Ohm
Output Power : 50 mWatt
Output Voltage : Peek To Peek 1 Volte
Jack : 3.5mm Stereo
Power Over Ethernet Option
Serial Interface COM Port: RS-232, COM ports for console, serial input/output device
Max Baudrate: 115,200 bps
Security features Multi user level protection for camera access, Alarm I/O
Advanced Service Up to 5.6M memory for Pre/Post alarm buffer E-Mail, FTP, IP notification, Alarm Notification to e-mail
CGI Call by event or schedule
Built-in Motion detections Accuracy: 12x12=144 blocks
Motion Sensitivity : -100 ~ 100 : 100 is hypersensitive
Others Transmit External data(EX:POS) transfer with Video
IP notification by e-mail
Management Configurable by serial, web or telnet
Remote system update via telnet, FTP OR web browser
Developer support Provides HTTP CGI API
ActiveX control development kit
PWR Supply SMPS Input: 100~240VAC, AC 50/60Hz, 300mA
Output: DC 12 Volt, 1A
PWR Consumption DC 12Volt Max 600 mA
Operating Environment Temperature : 32°~ 122°F (0°~ 50°C)
Humidity : 20 ~ 80% RH(non-condensing)

FW1176 User’s Manual
M4062-00 8 Seyeon Tech Co., Lt
Miscellaneous Work with Smart NVR(CMS software)
Dynamic IP support through IPCCTVDNS Server
Simultaneous users Live-cast for up to 16 clients
Installation, management
and maintenance Installation CD and web-based configuration Firmware upgrades over HTTP, telnet & FTP, firmware available at homepage
Video access from Web
browser Video access from Web browser
Minimum Web browsing
requirements
Pentium 4, 2 GHz, 2GB(RAM) or higher
Video Card: 256MB RAM, 1024x768 resolution or higher
100Mbps Network Adaptor or faster
Windows XP Pro or later
Internet Explorer 6.x or later
System integration support
Powerful API for software integration available at http://www.flexwatch.com, including
Simple Viewer API, FlexWATCH Control SDK, event trigger data in video stream,
embedded scripting and access to serial port peripherals over HTTP/TCP
User can be installed user program daemon for event notification or sending image
Embedded operating system: Linux 2.6
Supported protocols HTTP, RTP/RTSP, TCP/IP, FTP, Telnet, RARP, PPPoE, SNMP, PAP, CHAP, DHCP,
NTP, SMTP client
Approvals
KCC
FCC : Class A
CE : Class A
RoHS
Dimensions (HxWxD) and
weight (1lbs = 454g)
148Ø x 121(H) (in mm)
About 0.560kg without power supply
Plastic
* All specifications are subject to change without prior notice.
Table 1 : FW1176 Data Sheet

FW1176 User’s Manual
M4062-00 9 Seyeon Tech Co., Lt
1.4. FW1176 Packing List
FW1176 1ea
Power Supply Unit
(Power Cable & SMPS DC12V 1.0A Adapter) 1ea
CD (User’s Manual, IP Installer and etc) 1ea
Table 2 : FW1176 Packing List
Note: Please check all the listed items are included in your package. For any missing items,
please contact your local distributor.

FW1176 User’s Manual
M4062-00 10 Seyeon Tech Co., Lt
2. Hardware Description
2.1. Front View under Dome Cover
Picture 2 : Front View
Name Description
A Bolt for positioning module
(Up and Down) Move the position of Module up and down (Fix the position when install)
B Camera Module Camera module to input Video
C Bolt for positioning module
(Right and Left) Move the position of Module right and left (Fix the position when install)
D Main Body Mainboard and Camera Module
Table 3 : FW1176 Front View
B
A
C
D

FW1176 User’s Manual
M4062-00 11 Seyeon Tech Co., Lt
2.1. Rear View under Dome Cover
Picture 3 : FW1176Rear View
A B C D E F
Name Description
A LAN LAN Connector.
B CTL Conn. CTL Port (RS-485, RS-232, DI, DO)
C Cable Hole Hole for cable out
D SPEAKER ,V-OUT Conn. Speaker Port ,Video Output Port
E MIC Conn. MIC Port
F Power Conn. Power Connector.
Table 4 : FW1176 Rear View

FW1176 User’s Manual
M4062-00 12 Seyeon Tech Co., Lt
2.1.1. CTL Port Description
It’s RS-232 port for Serial input device, Modem or Console (Hyperterminal.connection). For RS-232
connection, RXD,TXD and GND are used. For connection to PC, RXD and TXD are used. RXD and TXD
should be cross to communicate properly
Picture 4 : CTL Port Description
2.1.2. Speaker V-out Jack Description
Jack information for Mono Speaker or Video Out Jack.
1 : GND
2 : SPK
3 : V-OUT
Picture 5 : V-out Jack
2.1.3. MIC Jack Description
Jack information for MIC
1 : GND
2 : NC
Picture 6 : MIC Jack

FW1176 User’s Manual
M4062-00 13 Seyeon Tech Co., Lt
3. FW1176 Installation and Basic Setup
3.1. Before Installation
 Read carefully User's Manual.
 Check User’s Network (IP Address, Network Mask and default gateway)
 Secure IP address for FW1176.
3.2. Factory Default Settings
The following table shows the factory default condition. Please refer to this when you need to change
the values on admin menu.
Factory Default
Admin ID root
Admin password root
IP address 10.20.30.40
Network mask 255.255.255.0
Gateway 10.20.30.1
Table 5 : Factory Default
Note: Factory default Admin ID and Password are all lower case letters. You can change the
password with Capital letters.
3.3. Installing FW1176
Following steps are the physical installation process for FW1176.
1. Fix the FW1176 in place
2. Connect the FW1176 to the Internet cable through the LAN port.
3. Connect the power supply of FW1176.
After that, you need to follow the steps below.
 Network Configuration: Refer to “IP Installer User’s Manual”
 Camera Configuration: Refer to “FlexWATCH Admin Menu User’s Manual”
 Service Configuration: Refer to “FlexWATCH Admin Menu User’s Manual”
