General Information
The DAPS440 is a Video/Audio Switcher which takes 4 composite sources, and
amplifies and switches each to 4 outputs. In addition, the DAPS440 supplies 3
Amps of 12VDC of power available for other cabin entertainment products (i.e.
Wireless Audio, DVD player, Glareshield Camera, or LCD monitors).
Front View
Additional Information
The DAPS440 has 4 Audio & Video input source connections and four individual
Audio & Video output connections for each input. Switching is accomplished
with a ground switching system. The DAPS440 will support the installation of
four independent switches at four different seat locations. Each individual at
each of the four seat positions can independently access up to four audio and
video sources by pushing their button. Every time the button is pushed, the
audio and video source will sequence through sources 1, 2, 3 and 4.
For example, if you have installed our Moving Map, Glareshield Camera and two
DVD players, the DAPS440 can sequence output from Moving Map, to Camera,
to DVD1 and then to DVD2.
The DAPS440 is made of all metal components. DO-160 testing has been
completed and is available upon request.
All manuals and user guides at all-guides.com

6!!
Revision!E,!December!2009!
Specifications
Dimensions
9.5” (W) x 7.25” (H) x 1.25” (D)
Video System
NTSC/PAL
Input Sources
4 Audio/Video Channels
Output Sources
4 Audio/Video Each
Video Impedance
75 Ohms
Control Sequence
Source 1,2,3,4
Audio Impedance
8.2 KOhms
Weight
1 lbs 12 oz
Power
28VDC @ 1.0 Amps
Source Selection
Momentary Ground Switch (Not Incl.)
Materials
Aluminum
Mounting
6 points on flange
DO-160
Section 21 Category B
Installation Instructions
All cabin entertainment equipment, such as the DAPS440, should be installed on
a non-essential bus and have a dedicated circuit breaker. It is a requirement that
a switch be installed so that the pilot can de-energize the system should it
become necessary.
There are six mounting slots located on the sides of the housing. Four holes are
located at the four corners of the back and four holes are located two on each
side of the flange. It is sufficient to mount the display by two attach points. It is
recommended that you leave about ¼inch of space around the unit for air
circulation.
Audio/Video inputs are paired and listed on the same side of the unit as the
Power Input DB-15. From left to right the video/audio inputs are line 1,2,3,4.
Use the inputs sequentially as you would like them selected by the operator.
On the opposite side of the unit is the output side. Here you will find four paired
output jacks. The momentary ground is pined to the DB-15 to accomplish the
switch of the Audio/Video source.
Power
This is a 28VDC device that requires 1.0 Amps of power to operate.
All manuals and user guides at all-guides.com

DAPS440! ! !
7!!
Revision!E,!December!2009!
Video Wiring Suggestions
All shields should be grounded to the connector at the source, and floating at the
display.
Avoid routing video wiring parallel to:
•AC wiring
•Strobe wiring
•DC motor supply cables
•Inverter cabling
•Or any other potential noise source.
S-Video/Composite and Audio Wiring
Recommended cable for s-video/composite and audio purposes is PIC 75 Ohm
Coax, P/N V75268. This is a lightweight, flexible, and low signal loss cable which
meets FAA flammability requirements of FAR 23.1359(d), FAR 25.853(a) and
FAR 25.869(a)(4).
Similar aviation coaxial cable can be used from other vendors, as well.
Some aircraft are prone to AC noise - we recommend adding to the composite
source a 75Ohm video isolation transformer such as Deerfield Laboratory, Inc.
Part No. 162-1 (www.deerfieldlab.com, [phone]). In most cases this
should be added to the video output of the source.
Power and Ground Wiring
22 AWG wire is recommended for Power and Ground applications.
All manuals and user guides at all-guides.com
all-guides.com

8!!
Revision!E,!December!2009!
Pinout for High Density DB-15
Part Numbers for DB-15 connectors, manufactured by Tyco or Amp.
High density, D-sub, 15 contact receptacle (female) P/N 748565-1
HD15F pins P/N M39029/57-354
Wiring Diagram
Pin
Number
Description
1
28VDC Power In
2
28VDC Ground In
3
N/C
4
12VDC Power Out
5
12VDC Ground Out
6
12VDC Power Out
7
12VDC Ground Out
8
N/C
9
12VDC Power Out
10
12VDC Ground Out
11
N/C
12
Switch #4
13
Switch #3
14
Switch #2
15
Switch #1
All manuals and user guides at all-guides.com

DAPS440! ! !
9!!
Revision!E,!December!2009!
Troubleshooting
Video Noise
Check for an incorrect ground in the installation wiring. See specific examples of
video noise below, or visit http://flightdisplay.com/Grounding.pdf
Snow or Sweeping Lines
Lines that slowly sweep up and down are a result of AC noise. This AC noise
can be generated by a power cart on the aircraft. Take the power cart off of the
aircraft. Be careful of inverter wiring, which can also cause noise. Stand off the
wires, if necessary.
If snow or sweeping lines persist, it is possible that the ground is at an incorrect
point in the aircraft. Try moving the ground to another location.
No power to Monitor, or No video Input
•Verify correct wiring. Check the base receptacle connectors for possibly
damaged pins.
•Check that the video source is:
1. Powered on,
2. In Play mode, and
3. Displaying video.
Color Distortion
•Adjust brightness and contrast settings using the buttons on the monitor.
All manuals and user guides at all-guides.com

10!!
Revision!E,!December!2009!
Technical Support
Should you have any questions concerning this product or other Flight Display
Systems products, please contact our Product Support representatives at (678)
867-6717.
Flight Display Systems
1765 Grassland Parkway
Alpharetta, GA 30004
Phone: [phone]
Fax: [phone]
Email: [email protected]
For further product information, technical data and sample wiring diagrams,
please click on the Dealers section of our web site at www.flightdisplay.com
Instructions for Continued Airworthiness
The DAPS440 is designed not to require regular general maintenance.
All manuals and user guides at all-guides.com

DAPS440! ! !
11!!
Revision!E,!December!2009!
Warranty Information
Flight Display Systems warrants the DAPS440 against material or manufacturing
defects for a *two-year period (effective 1/1/2009 on all equipment shipped with
2009 pricing). Warranty begins on date of installation. *The warranty registration
card must be returned upon installation in order to validate the two-year
warranty. Any warranty registration not returned during this time period will
default to the date of purchase as the warranty start date.
If product support is required, please call our Technical Support team at 678-
867-6717 to obtain assistance. If the return of the unit to the factory is required,
an RMA number will be issued at that time. Flight Display Systems will, upon
receipt of the failed hardware, remanufacture or replace the unit at our
discretion.
Flight Display Systems will pay Ground Shipping charges for warranted items.
Charges for express shipment will be the responsibility of the sender.
This warranty is not transferable. Any implied warranties expire at the expiration
date of this warranty. We shall not be liable for incidental or consequential
damages.
This warranty does not cover a defect or failure that has resulted from improper
or unreasonable installation, use or maintenance, as determined by Flight
Display Systems. This warranty is void if there is any attempt to disassemble or
open this product without factory authorization.
Any labor charges associated with the removal of product or related
troubleshooting by a firm other than Flight Display Systems or its designee will
not be covered.
All manuals and user guides at all-guides.com

12!!
Revision!E,!December!2009!
Assembly Drawing
All manuals and user guides at all-guides.com
all-guides.com

DAPS440! ! !
13!!
Revision!E,!December!2009!
Index
Coaxial Cable.....................................6
Color Distortion.................................8
Continued Airworthiness ................9
DB-15...................................................7
Flammability......................................6
Noise ...................................................8
Power ..................................................8
Shields.................................................6
Support ...........................................8, 9
Warranty ..........................................10
Wiring.................................................6
Diagram..............................................7
Power and Ground ...........................6
All manuals and user guides at all-guides.com

14!!
Revision!E,!December!2009!
Log of Revisions
Rev
Date
Page
Description
A
01/25/2007
---
---
B
01/16/2008
8
Swapped pinout of Switch Inputs.
C
06/20/2008
8
Removed “Remote Control Inoperable” from troubleshooting
D
04/14/2009
6,11
Updated specifications, warranty info
E
12/11/2009
12
Revised Assembly Drawing
