S1PBZ2G
IP66 Outdoor Power Box
Check www.irsecurity.com/pro for the latest compatibility list.
www.irsecurity.com/pro
Package Contents
Dimensions (units: mm)
Weight (power box only): 1.7Kg / 3.7lbs
Allen Key 1pcs
Power Box 1pcs Rubber Plug 1pcs Waterproof
Cap 3pcs
S1PBZ2G_INSTALLATION_DIAGRAM_EN_R1
Make sure to install the product in an area that can support the
weight of the power box plus cameras and accessories.
Make sure to seal the box and all cable entrances according to
the instructions in this document.
Installation
Power Box Overview
Mounting Bolt M8x70 4pcs
Anchor 4pcs
Anchor Cap 4pcs
Large Flat Washer 4pcs
Hex Screw M6x25 4pcs
Spring Washer 4pcs
Small Flat Washer 4pcs
1Loosen M6 screws (x2) on the left side of the top panel and open the power
box. Loosen the M6 screws (x2) inside the power box and remove the
mounting plate.
M6 screws inside power box (x2)
2Use the mounting plate to mark holes for the mounting bolts (x4) and any
cables you are running through the mounting surface. Use outer holes to
mount power box to wall.
UP arrow on mounting plate should
be pointed up and away from the
mounting surface.
You must leave at least 30mm of
clearance from all sides of the
mounting plate to leave space to
install the power box.
3Drill holes for the mounting bolts (x4) and cables. Insert the anchors (x4)
and anchor caps (x4) into the holes as shown below. Run cables through
the mounting surface.
NOTE: If installing power box on corner mount or pole mount, attach mounting
plate to the mount using the bolts supplied with the corner or pole mount. Skip
to step 5. Illustrations of complete installation shown below.
1 Mounting plate
2 Bottom cover
3 Top cover
4 Electrical safety cover
5 Rail
6 Loop buckle
7 Shaft
8 Conduit cap
9 M6 screw
10 Gasket
11 Gasket
12 Rubber plug
13
14 Retaining ring
Waterproof lm
Bottom cover
Mounting plate
Anchor and
anchor cap (x4)
M20 P1.5 / G 1/2”
84.0
70.0
48.0
12-M6
248.0
160.0
84.0
30.0
297.2
119.0
170.0
8- 10.0
119.0
90.0
70.0
107.0
4Place the mounting plate over the holes. Insert the mounting bolts (x4) and
large at washers (x4) to secure the mounting plate to the mounting
surface.
5Run cables through rear gaskets or bottom conduit holes.
You must install the connector after pushing the cable through the gasket.
You cannot push nished cables through the gaskets. The diameter of
cables run through the gaskets must be between 3.5mm and 12mm.
To run cables through rear gaskets:
1. Poke a hole in the gasket with a nail or pin.
2. Run the cable through the gasket.
3. Attach the connector to the cable on the inside of the gasket.
Follow all instructions below. Incorrect installation of cables may impact
the weatherproof rating of the power box.
To run cables through bottom conduit holes:
1. Run cable without connector through the weatherproof cap.
2. Screw weatherproof cap into one of the bottom conduit ports.
3. Attach connector to cable inside power box.
6Place the power box over the mounting plate and slide into place. Tighten
the M6 screws (x2) inside the power box to secure it to the mounting plate.
M6 screws inside power box (x2)
7Run the required cabling for the camera through the rubber plug on the top
cover of the power box.
Rubber plug
Install any required equipment inside the power box. Install the mount (not
included) and camera (not included) to the front of the power box with the
hex screws (x4), spring washer (x4), and small at washers (x4).
The below images show examples of items that can be installed to the power
box. All items below are not included with power box. Check
www.irsecurity.com/pro for the latest compatibility list.
8
9Push the top cover up about 2mm and then close the power box. Tighten
the M6 screw (x4) on the front of the power box to secure the top cover and
seal the power box.
Push up to close
top cover
NOTE: Width of the rail is 35mm.
Cable
Weatherproof cap
NOTE: Bottom conduit
diameter ts size
G 1/2” or M20-P1.5.
Bottom cover
Mounting plate
Mouting bolt and
large at washer (x4)
Connector
Gasket
Cable
Lightning
protection
module
Heater
module
Power
module
Air switch
M6 screw (x4)
Hex screw, spring
washer, and small
at washer (x4)
