Flitework FW3536/900 User manual

- 1 -
FLWA8052
FLWA8074
FLWA8024
FLWA8064
FLWA8084
Instruction sheet
Drive set FW3536/900 for
Flitework Pilatus PC6-S
(FLWA8004)
Distributed by www.hobbico.de
Please read the instruction manual carefully and take notice of the safety guidelines.
If the model is given to a third party, always include this instruction manual to the model
Technical data:
Battery 3s 2200mAh 20-30C
Rotation speed [email protected]
4-blade
Current ~ 40A
Thrust 22 N (2,2kg)

- 2 -
ŸRead this manual, the manual of the ESC and the
safety precautions carefully!
ŸKeep this manual and if you give the drive set to
a third party, put this manual to the model.
ŸTake care, that you are familiar with your transmit-
ter and all electronic components, used in your
plane.
ŸTake care of all safety instructions of tools, which
are you using to install this drive kit.
ŸBefore assembling please check all parts of this
kit. If some parts are missing or have a mistake,
please call our service center.
The symbols on the package means, that the
partsof the drive set should not be put to waste.
All electric and electronic parts should be de-
posed to places of waste management.
Batteries and accumulators must
be removed from the devices and
should be deposed to the correct
waste management organisation.
Environment protection infos
General informations
Content of delivery
Safety precautions
ŸNever start the drive in your workshop or
inside a room!
ŸNo person should be beside or in front of the
propeller.
ŸIf you arm the ESC, the plane should be held
in a safe position by an assistant.
ŸCheck, that the fail safe position of the throttle
channel is OFF!!
ŸSome radios have an inverted throttle chan-
nel. You must reverse before using it!
ŸAlways use a good quality charger for charg-
ing your batteries!
ŸYou should charge your batteries in a fire-
proof environment.
ŸDuring charging your batteries you should
supervise them!
ŸFor connecting batteries or motor to the ESC,
use adequate connectors.
ŸThe length of the wires between battery and
ESC should not be longer than 25 cm!
ŸRead the safety precautions of your battery
manufacturer!
ŸTake care, that the transmitter- and receiver
battery is in good condition!
Technical data FW3536/900
Technical data FW-Control 40
Introduction
The drive set FW3536/900 is specially designed for the Flitework Pilatus PC6-S and its
4-bladed scale prop. The drive set is very powerfull and allows a long time of soft
power cruising. But there is thrust enough to climb up vertically, if necessary.
We wish you much fun with the Flitework drive set.
FLWA8024 Motor FW3536/900
FLWA8052 FW-Control 40, 40A, 3A BEC
preprogrammed (p&p), incl.
manual
FLWA8064 FW 10.5” x 8” 4-bladed prop.
FLWA8074 Accessory set
FLWA8084 Spinner chrome platet or alumini-
um 52 mm for 4-bladed prop.
●Weight 36 g
●DC input 2 - 4 LiPo
●Cont. current 40A
●Max. current 55 A (10 sec.)
●Timing automatic / high / low
●Pulse width 8 kHz / 16 kHz
●BEC 3 A
●Temperature protection
●Fail save: Motor off at lost signal
●Weight 115g
●Motor poles 14
●Spec. rotations 900 KV
●Diameter 35 mm
●Length 36 mm
●Motor shaft 4 mm
●Max. current 45 A (10s)
●Max. power 450 W
●internal resistance 36 mOhm
Flitework GmbH
Geymannstrasse 27
A-4713 Gallspach / AUSTRIA
Phone: [phone]
Mail: [email protected]
