Flow-Rite QWIK-FILL MP-2000 Owner's manual

Package Contents
Installaon
Qwik-Fill On-Board Baery Watering System
Installaon and Operaon
Important
Prior to inial installaon, inspect
the exisng baery water level. If
they have been neglected and the
level is extremely low, manually ll
each cell so all plates are covered.
Then, charge the baeries, before
installing and using Qwik-Fill to top
o. Topping o a baery that has
been neglected and then charging
can cause the water level to expand
during the charging process resulng
in the loss of electrolyte. Once Qwik-
Fill is installed, monthly topping
o aer charging will prevent an
extremely low water level to occur.
1
Join two manifolds together as shown
using the appropriate size manifold jumper
for your baery group size. The manifold
jumpers are marked and can be easily cut
with a ulity knife or a pair of scissors.
2
Carefully remove your baery’s exisng
caps and insert a manifold assembly into
each baery. Press each assembly rmly in
place so that it ts ush with the baery
top.
4
Connect the water supply line to one end
of the baery “chain”. The 4’ of tubing
supplied may be cut to the desired length
or if a longer length is required 20’ of 1/4”
ID exible tubing is available in the Qwik-
Fill accessory pack. (sold separately)
3
Link mulple baeries together using the
clear tubing. If the baeries are separated
by several feet, allow the tubing to sag
between baeries. Ensure that the tops
of all baeries linked together are at the
same level. For opmum performance,
it is best to limit the number of baeries
connected to a single ll point to two.
5
Cover the remaining barb with a red end
cap and installaon is complete.
BL-186
11/11
Illustration purposes only. Actual product is subject to change.

Operaon
Typical Installaon Conguraons
Important
Baeries should only be lled aer
charging. 1
Insert the squeeze bulb ller assembly
into a jug of dislled water. Prime bulb by
squeezing unl it is lled with water.
2
Remove the dust cap from the water
supply line and connect it to the squeeze
bulb ller assembly by snapping the quick
couplers together.
4
Immediately disconnect the squeeze bulb
ller assembly from the water supply line
and replace the dust cap.
3
Squeeze the bulb with rm pressure to
begin pumping water into the baery cells.
When the bulb becomes hard, all cells are
full.
5
Any water remaining in the squeeze bulb
ller assembly may be pumped back into
the dislled water jug.
BL-186
11/11
Flow-Rite Controls • 960 74th St., Byron Center, MI 49315 • phone: [phone] • fax: [phone] • www.ow-rite.com
Patent Pending
Note: For general winterizing, drain excess water in water supply line by pushing the spring loaded buon on the end of the line. To
remove the clear tubing (if necessary), pinch the tubing next to ng, carefully twist and pull straight o.
The diagrams below show typical baery arrangements and how they might be plumbed with Qwik-Fill. The leers below each diagram
indicate which Qwik-Fill Kits would be required for that conguraon. Although the tubing between baeries can be up to a distance of 8’, it
may be more desirable to have separate ll points in the front and rear of the boat.
Fill Point
Battery
Required kit
