Fluid 8004576 User manual
1
HDMI DVD Player
with USB
Instruction Manual
Please read this User Manual carefully to ensure proper use of this product and keep this manual for future reference.
8004576
Up
converting
DVD/DVD+/-R/
DVD+/-RW/CD/
CD-R/CD-RW/Kodak
picture formats
HDMI
1080p
1
Contents
Important Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5
FCC/ICES-003 .....................................................................2
About Discs..............................................................................6
Product Overview........................................................................7
Remote Control Overview ..............................................................8-9
Operating the Remote Control ..........................................................10
Battery Installation ...............................................................10
Remote Control Operation Range .................................................10
Connections ........................................................................ 11-13
Connecting To TV Through VIDEO Output Jacks ...................................11
Connecting To TV Through YUV Output Jacks .....................................11
Connecting To TV Through 5.1-CHANNEL Output Jacks............................12
Connecting To TV Through HDMI Output .........................................12
Connecting To TV Through COAXIAL Output Jack .................................13
Connecting To USB Port ..........................................................13
Operating Systems.................................................................. 14-17
Playback of a DVD ............................................................ 14-16
Playback of a CD .................................................................17
JPEG (picture) Discs Operation ....................................................17
System Setup ....................................................................... 18-20
Setup Menus .....................................................................18
Language Setup..................................................................18
Video Setup Page ................................................................18
Audio Setup Page ............................................................ 19-20
Care and Maintenance ..................................................................21
Troubleshooting ........................................................................22
Specifications...........................................................................23
Warranty ...............................................................................24
2
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
• THISDIGITALVIDEODISCPLAYEREMPLOYSA
LASERSYSTEM.
• TOENSUREPROPERUSEOFTHISPRODUCT,
PLEASEREADTHISOWNER`SMANUALCAREFULLY
ANDRETAINFORFUTUREREFERENCE.
• SHOULDTHEUNITREQUIREMAINTENANCE,
CONTACTANAUTHORIZEDSERVICEPROVIDER.
• MISUSEOFCONTROLS,ADJUSTMENTSTOTHE
UNITORTHEPERFORMANCEOFPROCEDURES
OTHERTHANTHOSESPECIFIEDHEREINMAY
RESULTINHAZARDOUSRADIATIONEXPOSURE.
• TOPREVENTDIRECTEXPOSURETOLASER
BEAM,DONOTTRYTOOPENTHEENCLOSURE.
VISIBLELASERRADIATIONMAYBEPRESENT
WHENTHEENCLOSUREISOPENED.
•DONOTSTAREINTOBEAM.
WARNING:
TOREDUCETHERISKOFFIREORELECTRICSHOCK,
DONOTEXPOSETHISPRODUCTTORAINOR
MOISTURE.
WARNING:
TOREDUCETHERISKOFFIREORELECTRIC
SHOCK,ANDANNOYINGINTERFERENCE,USETHE
RECOMMENDEDACCESSORIESONLY.
SURGE PROTECTORS:
It is recommended to use a surge protector for AC
connection.LightningandpowersurgesARENOT
covered under warranty for this product.
CAUTION:TOREDUCETHERISKOFELECTRICSHOCK,
DONOTREMOVECOVER(ORBACK).NOUSER-
SERVICEABLEPARTSINSIDE.REFERSERVICINGTO
QUALIFIEDSERVICEPERSONNEL.
The FCC Wants You to Know
This equipment has been tested and found to comply with the
limitsforaClassBdigitaldevice,pursuanttoPart15oftheFCC
Rules.These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
Thisequipmentgenerates,usesandcanradiateradio
frequencyenergyand,ifnotinstalledandusedinaccordance
withtheinstructions,maycauseharmfulinterferenceto
radiocommunications.However,thereisnoguaranteethat
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
televisionreception,whichcanbedeterminedbyturningthe
equipmentoffandon,theuserisencouragedtotrytocorrect
the interference by one or more of the following measures:
•Reorientorrelocatethereceivingantenna.
•Increasetheseparationbetweentheequipmentand
receiver.
•Connecttheequipmentintoanoutletonacircuitdifferent
from that to which the receiver is connected.
•Consultthedealeroranexperiencedradio/TVtechnicianfor
additional suggestions.
Anychangesormodicationsnotexpresslyapprovedby
the party responsible for compliance could void the user’s
authority to operate the equipment.Where shielded interface
cables have been provided with the product or specified
additional components or accessories elsewhere defined to
beusedwiththeinstallationoftheproduct,theymustbe
used in order to ensure compliance with FCC regulation.
This Class B digital apparatus complies with Canadian
ICES-003.
The lightning flash with arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of uninsulated
dangerous voltage within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
Theexclamationpointwithinanequilateraltriangleisintended
to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature accompanying
the appliance.
DANGER:Invisibleandhazardouslaserradiationwhenopenand
interlockfailedordefeated.Avoiddirectexposuretobeam.
Important Safety Instructions
WARNING:
USEUNDERSUPERVISIONOFANADULTDUETOLONGCORD
ThisunithasalongACcordorotherlongcordthatcaneasilybetrippedonorpulledon,causinginjury,
Pleasemakesureitisarrangedsoitwillnotdrapeoveratabletop,etc.whereitcanbepulledonby
children or tripped over accidentally.
EXERCISE CAUTION AS UNIT HAS SHARP POINTS.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
3
Beforeusingtheunit,besuretoreadalloperatinginstructionscarefully.Pleasenotethatthesearegeneral
precautionsandmaynotpertaintoyourunit.Forexample,thisunitmaynothavethecapabilitytobe
connected to an outdoor antenna.
1) Read these instructions.
All the safety and operating instructions should be read before the product is operated.
2) Keep these instructions.
The safety and operating instructions should be retained for future reference.
3) Heed all warnings.
All warnings on the product and in the operating instructions should be adhered to.
4) Follow all instructions.
All operating and use instructions should be followed.
5) Do not use this apparatus near water.
Donotusethisproductnearwaterandmoisture,forexample:nearabathtub,washbowl,kitchensinkor
laundry tub; in a wet basement; or near a swimming pool.
6) Clean only with dry cloth.
Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
Use a dry cloth for cleaning.
7) Do not block any ventilation openings. Install in accordance with the manufacturers instructions.
Slots and openings in the cabinet and in the back or bottom are provided for ventilation to ensure reliable
operation of the product and to protect it from overheating. These openings must not be blocked or
covered.Theopeningsshouldneverbeblockedbyplacingtheproductonabed,sofa,rugorothersimilar
surface. This product should never be placed near or over a radiator or heat source.This product should not
be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the
manufacturer’s instructions have been adhered to.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your safety. If the provided plug does not
fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
Anapplianceandcartcombinationshouldbemovedwithcare.Quickstop,excessiveforce
and uneven surfaces may cause the appliance and cart combination to overturn.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
Toprotectyourproductfromalightningstorm,orwhenitisleftunattendedandunusedforlongperiods
oftime,unplugitfromthewalloutletanddisconnecttheantennaorcablesystem.Thiswillprevent
damage to the product due to lightning and power-line surges.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture or does
not operate normally, or has been dropped.
15) Power source
This product should be operated only from the type of power source indicated on the marking label.
Ifyouarenotsureofthetypeofpowersupplytoyourhome,consultyourappliancedealerorlocalpower
company.
Forproductsintendedtooperatefrombatterypower,orothersource,refertotheoperationinstructions.
16) Power lines
An outside antenna system should not be located in the vicinity of overhead power lines or other electric
lightorpowercircuits,orwhereitcanfallintosuchpowerlinesorcircuits.Wheninstallinganoutside
antennasystem,extremecareshouldbetakentokeepfromtouchingsuchpowerlinesorcircuitsas
contact with them might be fatal.
Important Safety Instructions
4
17) Overloading
Donotoverloadwalloutletsandextensioncordsasthiscanresultinariskofreorelectricshock.
18) Object and liquid entry
Neverpushobjectsofanykindintotheproductthroughopeningsastheymaytouchdangerousvoltage
pointsorshortoutpartsthatcouldresultinreorelectricshock.Neverspillorsprayanytypeofliquidon
the product.
19) Outdoor antenna grounding
Ifanoutsideantennaisconnectedtotheproduct,be
sure the antenna system is grounded so as to provide
some protection against voltage surges and built up
staticcharges.Section810oftheNationalElectricCode
ANSI/NFPA70providesinformationwithrespectto
propergroundingofthemastandsupportingstructure,
grounding of the lead-in wire to an antenna discharge
product,sizeofgroundingconductors,locationof
antenna-dischargeproduct,connectiontogrounding
electrodes and requirements for the grounding
electrodes.
20) Service
Donotattempttoservicethisproductyourselfasopeningorremovingcoversmayexposeyouto
dangerousvoltageorotherhazards.Referallservicingtoqualiedservicepersonnel.
21) Replacement parts
Whenreplacementpartsarerequired,besuretheservicetechnicianusesreplacementpartsspecied
bythemanufacturerorthosethathavethesamecharacteristicsastheoriginalparts.Unauthorized
substitutionsmayresultinreorelectricshockorotherhazards.
22) Safety check
Uponcompletionofanyserviceorrepairstothisproduct,asktheservicetechniciantoperformsafety
checks to determine that the product is in proper operating condition.
23) Wall or ceiling mounting
The product should be mounted to a wall or ceiling only as recommended by the manufacturer.
24) Damage requiring service
Unplug this product from the wall outlet and refer service to qualified service personnel under the
following conditions.
a) When the power-supply cord or plug is damaged.
b) Ifliquidhasbeenspilledorobjectshavefallenintotheproduct.
c) Iftheproducthasbeenexposedtorainorwater.
d) Iftheproductdoesnotoperatenormallybyfollowingtheoperatinginstructions.Adjustonlythose
controlsthatarecoveredbytheoperatinginstructions,asanadjustmentofothercontrolsmayresult
indamageandwillrequireextensiveworkbyaqualiedtechniciantorestoretheproducttoits
normal operation.
e) If the product has been dropped or the cabinet has been damaged.
f) Whentheproductexhibitsadistinctchangeinperformance-thisindicatesaneedforservice.
25) Note to CATV system installer
ThisreminderisprovidedtocalltheCATVsysteminstaller’sattentiontoArticle820-40oftheNECthat
providesguidelinesforpropergroundingand,inparticular,speciesthatthecablegroundshallbe
connectedtothegroundingsystemofthebuilding,asclosetothepointofcableentryaspractical.
NOTE:
Refer all servicing to qualified service personnel. Servicing is required when the unit has been damaged
in any way such as the following: the power-supply cordor plug has been damaged, liquid has been
spilled into unit, the unit has been exposed to rain or moisture, the unit has been dropped or the unit
does not operate normally.
Important Safety Instructions
5
NOTES ON HANDLING:
• WhenshippingtheDVDplayer,alwaysusethe
original shipping carton and packing materials.
Formaximumprotection,repacktheunitasit
was originally packed at the factory.
• Donotusevolatileliquids,suchasinsect
spray,neartheDVDplayer.Donotleave
rubber or plastic products in contact with the
DVD player for a long time. They will leave
marks on the finish.
• The top and rear panels of the DVD player
may become warm after a long period of use.
This is normal and not a malfunction.
• WhentheDVDplayerisnotinuse,besureto
remove the disc and turn off the power.
NOTES ON LOCATING THE DVD
PLAYER:
• When you place this DVD player near a
TV,radioorVCR,theplaybackpicture
may become poor and the sound may be
distorted.Inthiscase,movetheDVDplayer
awayfromtheTV,radioorVCR.
NOTES ON CLEANING:
Useasoft,dryclothforcleaning
• Forstubborndirt,soaktheclothinaweak
detergentsolution,wringwellandwipe.Usea
dry cloth to wipe it dry. Do not use any type
ofsolvent,suchasthinnerandbenzene,asthis
may damage the surface of the DVD player.
• If you use a chemical-saturated cloth to clean
theunit,followthatproduct’sinstructions.
NOTES ON MOISTURE CONDENSATION:
Moisture condensation damages the DVD
player. Please read the following carefully.
• Moisturecondensationoccurs,forexample,when
you pour a cold drink into a glass on a warm day.
Drops of water form on the outside of the glass.
Inthesameway,moisturemaycondenseonthe
opticalpick-uplensinsidethisunit,oneofthe
most crucial internal parts of the DVD player.
Moisture condensation occurs during the
following cases:
• When you bring the DVD player directly from a cold
place to a warm place.
• When you use the DVD player in a room where you
justturnedontheheater,oraplacewherethecold
wind from the air conditioner directly hits the unit.
• lnthesummer,whenyouusetheDVDplayerina
hotandhumidplacejustafteryoumovedtheunit
from an air conditioned room.
• When you use the DVD player in a humid place.
Do not use the DVD player where moisture
condensation may occur.
• lfyouusetheDVDplayerinsuchasituation,itmay
damagediscsandinternalparts.Removethedisc,
connect the power cord of the DVD player to the
walloutlet,turnontheDVDplayerandleaveitON
fortwoorthreehours.Aftertwoorthreehours,the
DVD player will have warmed up and evaporated
any moisture. Keep the DVD player connected to
the wall outlet and moisture condensation will
seldom occur.
Important Safety Instructions
Power Source
Insert the AC plug (with 2 blades) into a conveniently located AC outlet rated at
120V~60Hz.
NOTE: The AC plugsuppliedwiththeunitispolarizedtohelpminimizethe
possibilityofelectricshock.IftheACplugdoesnottintoanonpolarizedAC
outlet,donotleorcutthewideblade.Itistheuser’sresponsibilitytohavean
electrician replace the obsolete outlet.
Warning:
Cleaningandadjustmentoflensesand/or
other components of playback mechanism
should be performed by a qualified service
technician.
WHAT’S IN THE BOX?
1xInstructionManual
1xRemoteControl
2xAAASizeBatteriesfor
Remote Control
1xAVConnectionCable
6
PLAYABLE DISCS:
The following discs can be played back on this DVD player:
DISC TYPES:
DVD
Data on most DVDs is divided into sections called titles and
thenintosubsectionscalledchapters,eachofwhichisgiven
a title or chapter number. Some features of this DVD player
will not operate with some DVD discs as they are preset. If
afunctionyouselecteddoesnotrunasdesired,refertothe
manual accompanying the DVD disc.
Compatible with DVD/DVD±R/DVD±RW/Kodak Picture
JPEG/MP4.
AUDIO CD:
DataonanaudioCDisdividedintosectionscalledtracks,
each of which is given a track number.
Compatible with CD/CD-R/CDRW/MP3.
IMPORTANT:
ItisimportantthatyoureadthemanualthataccompaniestheDVDdisc,astherearefeaturesthat
areontheDVDplayerthatcannotbeusedwithcertainDVDs.Therearealsoextrafeaturesonthe
DVDdiscthataredifferentforeachDVDdisc,sotheyarenotexplainedinthisowner’smanual.
This player conforms to the NTSC and PAL color systems. However, if you are in the USA,
Canada or Mexico, leave this setting on NTSC. If incorrectly set to PAL, theTV picture may roll
vertically. In this case, set the TV system to NTSC as specified on page 18.
Notes on Copyright:
Itisforbiddenbylawtocopy,broadcast,show,broadcastoncable,playinpublicandrent
copyrightedmaterialwithoutpermission.DVDvideodiscsarecopyprotected,andanyrecordings
made from these discs will be distorted. This product incorporates copyright protection technology
that is protected by method claims of certain U.S. Patents and other intellectual property rights
ownedbyMacrovisionCorporation,andisintendedforhomeandotherlimitedviewingusesonly,
unlessotherwiseauthorizedbyMacrovisionCorporation.Reverseengineeringordisassemblyis
prohibited.
Region management information:
This DVD Player is designed and manufactured to respond to the Region Management Information
that is recorded on a DVD disc. If the Region number described on the DVD disc does not
correspondtotheRegionnumberofthisDVDplayer,thisDVDplayercannotplaythatdisc.Youmay
not be able to play back some DVD video discs on this player if they were purchased from outside
yourgeographicareaormadeforbusinesspurposes.Whenyoutrytoplaybackanunauthorized
disc,WrongRegionappearsontheTVscreen.
About Discs
THEREGIONNUMBERFORTHISDVDPLAYERIS:
See below for information regarding region numbers. 1
7
Product Overview
Front View
Rear View
1. ( )PowerON/Standby
Button
2. Disc Tray
3. Remote Control Receiver
4. LED Display
1. Left Audio Output Jack
2. Right Audio Output Jack
3. Composite Video Output Jack
4. Y/PbCb/PrCrOutputJack
5. HDMIOutput
6. DigitalCoaxialAudioOutputJack
7. 5.1 Channel Jack
8. PowerCableto120V~60HzPowerSource
5. ( ) Open/Close Button
6. USB Port
7. ( ) Previous Button
8. ( ) Play/Pause Button
9. ( )NextButton
8
Remote Control
1. ( ) OPEN/CLOSE BUTTON
Opens and closes the disc tray.
2. 0-9 BUTTONS
To locate a title / chapter / track /specific time
or enter parental control.
10+ Button To select and switch to a track
that is higher than 10.
3. MENU BUTTON
To display the DVD root menu.
4. BUTTONS
Press to navigate and make selections for
on-screen menus.
ENTER Button
To confirm the selection or current operation.
5. PREV / NEXT BUTTONS
Toskiptotheprevious/nexttitle/chapter/
track.
6. F.RWD / F.FWD BUTTONS
To perform fast reverse / fast forward playback.
7. PLAY/PAUSE ( ) BUTTON
To start and pause the playback.
8. OSD BUTTON
To display the current playback information.
9. SUBTITLE BUTTON
To select one of the subtitle languages
programs on a DVD (if available).
10.DVD/USB
1. Power-on the unit.
2. Make sure no disc has been inserted.
3. Insert a USB memory inside the USB slot.
4. Press USB button the player will read the
multimedia files located on the USB memory .
11. ANGLE BUTTON
To switch between multiple camera angles
programmed on a DVD (if available).
12. ZOOM BUTTON
To enlarge a picture on the screen.
13. REPEAT BUTTON
To toggle between different repeat modes.
14. A-B BUTTON
To repeat the playback from point A to point B
on a disc.
15. PROGRAM BUTTON
To play the contents of the disc in the order you
want by programming the track to be played.
16. CLEAR BUTTON
Erases all programmed content in memory.
ss t
9
Remote Control
17. POWER BUTTON
Turns the power on or restores the DVD player to
standby mode.
18. VOL +/– BUTTONS
To increase and decrease volume.
19. MUTE BUTTON
To mute and restore your DVD sound output.
20. SETUP BUTTON
ToaccessorexittheSETUPmenu.
21. TITLE BUTTON
Go to title menu.
22. AUDIO BUTTON
To change the audio mode.
23. ( ) STOP BUTTON
To stop the playback.
24. VIDEO BUTTON
To change the video output mode.
25. WIDE BUTTON
Adjuststheaspectratio.
26. STEP BUTTON
To play or move the playback forward frame by
frame.
27. SLOW BUTTON
Pressrepeatedlytoenterslowplayback,andcycle
between different speeds.
28. TIME BUTTON
To skip directly to a specific time / title / chapter /
track on a DVD.
29. RANDOM BUTTON
Press to select a random chapter.
10
Battery Installation
1. Press the tabs on the back door and lift off.
2. InserttwoAAAsizebatteries(included)intothebattery
compartment as shown in the illustration and follow the (+) and
(–) polarity symbol markings inside the battery compartment.
3. Replace the battery door.
BATTERY PRECAUTIONS:
• Improperorincorrectuseofbatteriesmaycausecorrosion
orbatteryleakage,whichcouldcausere,personalinjuryor
damage to property.
• Onlyusethebatterytypeindicatedinthismanual.
• Whenthebatteriesareexhausted,theremotewillnotfunction.Replaceboth
batteries at the same time with new ones.● Do not install new batteries with used
onesanddonotmixdifferenttypesofbatteries.
• Donotdisposeofusedbatteriesasdomesticwaste.Disposeoftheminaccordance
with local regulations.
HANDLING THE REMOTE CONTROL:
• Takecareofyourngernailswhenyoupressandholdthebatteryreleasetab.
• Donotdroporcauseimpacttotheremotecontrol.
• Donotspillwateroranyliquidontheremotecontrol.
• Donotplacetheremotecontrolonawetobject.
• Donotplacetheremotecontrolunderdirectsunlightornearsourcesofexcessive
heat.
• Removethebatteryfromtheremotecontrolwhennotinuseforalongperiodof
time,asitcouldcausecorrosionorbatteryleakageandmayresultinphysicalinjury
and/or property damage including fire.
Remote Control Operation Range
Point the remote control at the DVD player no more than 5 metres from the remote
control sensor and within 60° of the front of the DVD player.The operating distance may
vary depending on the brightness of the room.
Operating the Remote Control
11
Connecting To TV Through VIDEO Output Jacks
(connection cable included)
Connecting To TV Through YUV Output Jacks
(YUVconnectioncableNOTincluded)
Connections
12
Connections
Connecting To TV Through 5.1-CHANNEL Output Jacks
(5.1-ChannelconnectioncableNOTincluded)
Connecting To TV Through HDMI OUTPUT
(connectioncableNOTincluded)
13
Connections
Connecting To An External Audio Amplifier
Through Coaxial Output Jack
(with built-in digital audio decoder)
Connecting to USB Port
Selecting USB/ memory card mode:
•Ifadiscisloaded,stopplay
•PresstheDVD/USBbutton
You can now select a different mode.
To return to disc mode:
•PresstheDVD/USBbuton
•SelecttheDISCoption.
The player will return to disc mode.
14
Playback of a DVD
Unless otherwise stated, all operations described are based on Remote Control use.
1. Insert the AC plug (with the two blades) from the DVD player to a conveniently located
AC outlet. The POWER indicator on the front of the cabinet will light.
2. ConnecttheDVDplayertotheexternalTV(seeillustrationsonpages11to13).
Turn on the TV and set to the corresponding input source.
3. Press the POWER button to turn the player on.
4. Press the OPEN/CLOSE button to open the disc tray. Place the disc in the center of
tray with the label side face up. Close the tray by pressing the OPEN/CLOSE button.
The unit will start playback automatically.
5. Press the STOP button to stop playback. The player will remember the point where
disc was stopped. If you press the STOPbuttonagain,playbackwillstartfromthis
point.Tostopplaybackcompletelyortostartagainfromthebeginning,pressthe
STOP button twice.
Note:Iftheplayerwillnotbeusedforalongperiodoftime,turnofftheplayerby
unpluging the AC Cord from the wall outlet.
SEARCH
Duringplayback,presseitherthe F.FWD button or the F.RWD to move the DVD
forwardorbackwardatdouble(x2)speedtolocateaspecicsection.Repeatedlypress
thesebuttonsandthespeedwillincreasetox4,x8,x16,thenresumenormalplayback.You
can also resume normal playback by pressing the PLAY/PAUSE button on the remote
control or the PLAY/PAUSE button on the unit.
Note: This function is not available on all discs.
SKIP
Whileadiscisplaying,youcanskipforwardorbackwardachapterortrackatanytimeby
pressing the PREV or NEXT button.
For DVD Program
DuringDVDplayback,pressthePROG (program) button. The setting menu will appear on
the screen as shown in Fig. A.
• Usethenumericanddirectionbuttonstoenterthedesiredtitleandchapter.Thetitleis
enteredinthesecondcolumnandthechapterinthelastcolumn,asshowninFigB.
• Usethedirectionbuttonstoselectandhighlightthe PLAY/PAUSE button then press
the ENTER button to start program playback.
• Duringediting,usethedirectionsbuttonstoselectandhighlight“ClearProgram”inthe
menu. Press the ENTER button to clear the programs.
• Duringplayback,pressthe STOP button twice to cancel the program playback.
Operating Systems
Fig. A Fig. B
15
For CD or JPEG Discs
The following menu appears on the screen.
1. Instopmode,pressthe , , , directionbuttonstohighlight“EditMode”onthe
screen,thenpresstheENTERbuttontoconrm.
2. Press the the , , , directionbuttonstohighlightthedesiredtracks,thenpress
the ENTER button to confirm.A will appear on the left side of the selected track.
3. Repeat the same procedures until all the specific tracks are selected.
4. Press the , , , direction buttons to highlight “Add To Program”,thenpressthe
ENTER button to confirm.
5. Press the , , , direction buttons to highlight “Program View” then press the
ENTER button to confirm. The list of selected tracks will appear on the screen.
6. Press the PLAY/PAUSE button to start playback of the selected tracks.
7. To cancel the program: press the STOP buttontostopplayback,thenpressthe
OPEN/CLOSE button to open the disc tray. The preset program will be deleted.
AUDIO:
Press the AUDIO button repeatedly to selected the available language/sound channels.
This function is not available on all discs
SUBTITLE:
Press the SUBTITLE button repeatedly to select the subtitle language or turn the subtitle
menu off. This function isnot available on all discs.
DVD MENU:
Press the MENUbutton,themenuofthecurrentDVDwillappearonthescreen.Pressthe
, , , directionbuttonstoselectthedesiredoption,andthenpresstheENTER button
to confirm the selection. This function is not available on all discs.
TITLE
Press the TITLEbutton,thetitlemenuofthecurrentDVDwillappearonthescreen.
Use the , , , directionbuttonstoselectthedesiredoption,thenpresstheENTER
button to confirm the selection. This function is not available on all discs.
Operating Systems
16
Operating Systems
OSD (ON SCREEN DISPLAY)
Duringplayback,presstheOSD button repeatedly to read the information of playback status.
ZOOM
Duringmovieplayback,presstheZOOMbuttonrepeatedlytozoominthepicture(Q1,Q2,
Q3,OFF).Pressthe , , , directionbuttonstoselectthepartsofthezoomedpicture
to watch. This function is not available on all discs.
ANGLE
Ifthemulti-angleicon“ ”appearsonthescreen,itmeansmorethanonesceneis
available on the current DVD. Press the ANGLE button repeatedly to select the desired
scenes. This function is not available on all discs.
MUTE
Totemporarilymutetheplaybacksound,presstheMUTE button. Press again to resume
normal playback.
VIDEO
Press the STOP button to stop playback.
Press the VIDEObuttonrepeatedlytosetthevideooutputmodestoYUV,YPbPr,HD.
Notes:
• SettoYUVifyouconnectedtheTVviatheYUVjackontheplayerandYUVINjackson
the TV as the figure on page 11.
• SettoYPbPr ifyouconnectedtheTVviatheYUVjackontheplayerandYUVINjackson
the TV (TV also set to Progressive Video input mode) as the figure on page 11.
• SettoHDifyouconnectedtheTVviatheHDMIOutputontheplayerandHDMIporton
theTV(TValsosettoHDMIinputmode)asthegureonpage12.
• Ifthesettingsareincorrect,theTVscreenwillnotdisplayproperly.
Press the MODE button repeatedly until the screen displays normally.
STEP
Duringmovieplayback,presstheSTEP button repeatedly to play the movie frame by
frame.Resume normal playback by pressing the PLAY/PAUSE button on the remote
control or play/pause button on the unit.
AUDIO
Press to change the audio language or sound tracks. This function not available on all discs.
17
Operating Systems
Playback of a CD
1. Press the POWER button to turn the player on.
2. Press the OPEN/CLOSE button to open the disc tray. Place the disc in the center of
tray with the label side face up. Close the tray by pressing the OPEN/CLOSE button.
The unit will start playback automatically.
3. Press the STOP button to stop playback. The player will remember the point where
disc was stopped. If you press the STOPbuttonagain,playbackwillstartfromthis
point.Tostopplaybackcompletelyortostartagainfromthebeginning,pressthe
STOP button twice.
JPEG (picture) Discs Operation
1. Press the POWER button to turn the player on and place the disc into the player as
previously instructed.The folder/file list will appear on the screen.
2. Use the , , , directionbuttonstohighlightthedesiredfolder,thenpressthe
ENTER button to confirm.The file list will appear on the screen.
3. Use the , , , directionbuttonstohighlightthedesiredle,thenpressthe
ENTER button to start playback.
REPEAT
Duringplayback,presstheREPEAT button repeatedly to select.
Repeat Single: Plays the current track/picture repeatedly.
Repeat Folder: Plays the track/picture in the current folder repeatedly.
Repeat Off: Resumes normal playback.
Notes:
The disc loading period of JEPG discs may be longer than loading DVD discs.
The operation is similar to DVD disc playing.
Important Notes:
• Somediscsmaytakeafewsecondstoload.Ifadiscisinsertedincorrectly,dirty,or
damaged,“NODISC”willappearinthedisplay.
• Alwaysholdthediscwithouttouchingeitherofitssurfaces.Wheninsertingadisc,
positionitwiththeprintedtitlesidefacingup,alignitwiththeguidesandplaceitin
its proper position.
• ItisimportantthatyoureadthemanualthataccompaniestheDVDdiscasthereare
features that are on this DVD player that cannot be used with certain DVDs. There are
alsoextrafeaturesthataredifferentforeachDVDdiscthatarenotexplainedinthis
owner’s manual.
18
System Setup
Setup Menus
PresstheSETUPbutton,thesettingmenuwill
appear on the screen as shown.
Use the direction buttons to select and
highlightthefunctionyouwishtoset,then
press the direction button to enter.
Press the , directionbuttonstoset,then
press the ENTER button to confirm the
selection. Press the SETUP button to save the
settingsandexit.
Language Setup
Press the , directionbuttontoselectLanguage,Subtitle,AudioLanguageandDVD
menu then press the direction button to enter.
1. If OSD LANGUAGE (On Screen Display Language)isselected,pressthe direction
button to enter. Press the , buttons to select the desired language then press the
ENTER button to confirm your selection. Press the SETUP button to save the setting
andexit.
2. If Subtitle, Audio or DVDmenuisselected,pressthe direction button to enter.
Press the , buttons to select the desired language then press the ENTER button
to confirm your selection. Press the SETUPbuttontosavethesettingandexit.Thisis
not available on all discs.
Video Setup Page
Press the , directionbuttonstoselectAspectRatio,TVSystem,VideoOutorHD
Resolution,thenpressthe direction button to enter.
1. If Aspect Ratioisselected,pressthe direction button to enter. Press the , buttons
toselect4:3PS,4:3LBor16:9tomatchtheaspectratioofyourTVthenpresstheENTER
button to confirm your selection. Press the SETUPbuttontosavethesettingandexit.
Notes:
• 4:3 :Selectwhentheunitisconnectedtoanexternal4:3TV.
• 16:9:Selectwhentheunitisconnectedtoanexternalwide-screenTV.
2. IfTVsystemisselected,pressthe direction button to enter. Press the , buttons to
selecttheformatofoutputsignalstoNTSC,PALorAUTO,thenpresstheENTER button
to confirm your selections.Press the SETUPbuttontosavethesettingandexit.
Notes:
• SettoNTSCifthecolorsystemofyourTVisNTSC.
(Defaultsetting.TheTVsignalsinUS,CanadaandMexicoisNTSC).
•SettoPAL if the color system of your TV is PAL.
• SettoAUTO if the color system of your TV is multi-system.
3. If Video Outisselected,pressthe direction button to enter. Press the , buttons to
selectvideooutputmodestoYUV,YPbProrHD.
• SettoYUVifyouconnectedtheTVviatheYUVjackontheplayerandYUVINjackson
the TV as shown in the figure on page 11.
• SettoYPbPrifyouconnectedtheTVviatheYUVjackontheplayerandYUVINjacks
on the TV (TV also set to Progressive Video input mode) as the figure on page 11.
Table of contents
Other Fluid DVD Player manuals
