Fluidwell D Series User manual

Fluidwell D-Series Indicators - The better alternative for DIN panel mount indicators
D050-A
PRESSURE INDICATOR
Signal input sensor: (0)4-20mA

User manual D050-A Pressure Indicator
ii FW-D050-A-MAN-EN-V0101_02
Health and Safety Information
This instruction manual supplements the requirements of nationally accepted codes of
practice. All installations must comply with the relevant sections of these codes and/or
other comparable codes that applies in the region the D050-A is installed in.
In addition, particular industries or end users may have specific requirements relating to
the safety of their installations. These requirements must also be met.
Disposal
Caution:
The D050-A must only be installed, operated and maintained by competent personnel
that received proper training on regular basis, including instructions on the various
types of protection and installation practices, relevant rules and regulations, and the
general principles of area classification.
At the end of its life this product must be disposed of according to local regulations
regarding waste electronic equipment. If a battery is present in this product it must be
disposed of separately. The separate collection and recycling of your waste equipment
will help to conserve natural resources and ensure that it is recycled in a manner that
protects the environment.

FW-D050-A-MAN-EN-V0101_02 iii
Read Me First!
About This Guide
This manual describes all standard features and instructions related to the D050-A
Pressure Indicator.
This manual is intended for all personnel involved in the operation, configuration,
installation and troubleshooting of the D050-A Pressure Indicator.
Information in this manual is subject to change without prior notice. Fluidwell bv is not
responsible for mistakes in this material or for incidental damage caused as a direct or
indirect result of the delivery, performance or use of this material.
© All rights reserved. No parts of this publication may be reproduced or used in any
form or by any means without written permission of your supplier.
Prerequisites
All personnel working with the D050-A Pressure Indicator are assumed to fully
understand, be capable of and act according to the information provided in this manual.
All personnel working with the D050-A are further assumed to be authorized and
properly trained for the task at hand.
About Functions and Type Codes
Not all D050-A types share the same functions. Depending on the type codes on your
particular D050-A, some functions described in this manual may –or may not– be
available.
For details see this manual.
Conventions
The following conventions may have been used to emphasize information:
Note:
This version (FW-D050-A-MAN-EN-V0101_02) is written with a focus on
software version 03.03.34. For other versions contact your supplier.
Warning:
This icon warns about actions that, when not performed correctly, may lead to product
damage, personal injury or even death.
Warning:
Danger of electrical shock: this icon warns about actions that include the risk of
electrical shock, resulting in product damage, personal injury or even death.
Such actions are best performed with power removed or made inaccessible.
Caution:
This icon warns about actions or procedures that may lead to incorrect functioning of
the D050-A when not applied correctly.
Note:
This icon indicates a hint or provides important background information about the
consequences of the described procedure or action.
Example:
This icon indicates a solution for a hypothetic situation, intended to help you interpret
the related concept information.

User manual D050-A Pressure Indicator
iv FW-D050-A-MAN-EN-V0101_02
How To Read This Manual
This guide consists of the following main sections:
Power up, Power down and Storage of the D050-A
Your D050-A was shipped to you in a cardboard box and may be equipped with battery
power. During transport the unit was switched off (shelf mode).
• If your D050-A is equipped with a battery you can press SELECT twice to power it up.
• To power your D050-A down you must perform the following steps:
a Press and hold PROG for 7 seconds. (See "Password Protection" on page 14 when
password protected.)
b Setup is indicated. Use to go to Setup Menu 3 — "Power Management"
c Next press twice to go to 32 "Battery Mode" and press PROG
dYouenter menu 32. Select shelf and press PROG to switch the unit off.
Storage and Hot Spare Configuration
When storing or transporting the D050-A, put the unit back in shelf mode and store it
at room temperature, in a dry place and in the original box.
Caution:
• Before operating, configuring, opening or installing the D050-A you are expected to
have read and understood all relevant sections in this manual.
• Before operation the D050-A MUST be installed in compliance with the installation
instructions as described in "Installation Instructions" on page 7.
chapter 1: "Introduction" on page 1 Provides an introduction and technical overview of the
D050-A Pressure Indicator.
chapter 2: "Specifications of the D050-A" on page 5 Provides an overview of the D050-A specifications.
chapter 3: "Installation Instructions" on page 7 Providesmechanicalandelectricalinstallationinstructions.
chapter 4: "Configuring the D050-A" on page 13 Provides an overview of configuration commands and
programming sequence of the D050-A.
chapter 5: "Operating the D050-A" on page 23 Provides operating instructions for the daily use of the
D050-A.
chapter 6: "Maintenance" on page 26 Provides maintenance instructions.
Note:
Before storing you may want to consider configuring a spare unit with identical settings
as an active unit in the field. This way you have created a “hot spare” which can be
taken from shelf and field mounted within minutes by electrical engineers.
SETUP
SETUP

v
FW-D05FW-D050-A-MAN-EN-V0101_02 v
Contents
Read Me First! iii
About This Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
About Functions and Type Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
How To Read This Manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iv
Power up, Power down and Storage of the D050-A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iv
Storage and Hot Spare Configuration. . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .. . . .. . . . . . . iv
1 Introduction 1
System Description of the D050-A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Functions and Features . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . .. . . 1
Field Input. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
The D050-A Display Functions. . . . . . . . . . .. . . .. . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . 2
Configuration of the D050-A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
EEPROM Memory . . . . . . . . . .. . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . .. .. . . .. . . . . . . 2
Options of the D050-A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Available D050-A configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 Specifications of the D050-A 5
General specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Panel Mount Enclosure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Approvals and compliances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Power supply . . . . . . . . . . . . . . . .. .. . . .. . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .. . . . . 5
Sensor excitation . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .. . . . . . . 6
Terminal connections . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .. . . 6
Data protection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Inputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Operational. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Operator functions . . . . . . . . . . . . . .. . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .. . . . . . . . . 6
Pressure. . . . . . . . . . . . . .. . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . 6
3 Installation Instructions 7
Mechanical Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Electrical installation – general. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Overview of Terminal Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Power Supply Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
External Power Supply wiring. . . . . . . . . . . .. . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . .. . . 9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Backlight. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
I/O wiring options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Loop Powered PressureIndicator Input Wiring Option Type A-PL. . . . . . . . . . . . . .. . . . . . 12

User manual D050-A Pressure Indicator
1–CONTENTS
vi FW-D050-A-MAN-EN-V0101_02
4 Configuring the D050-A 13
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
The D050-A Display Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
The D050-A Key Functions . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .. . . .. . . . . . . . . . . . . . . .13
Quick Reference Menu . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .. . 14
Password Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
4
Modes of Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Overview of Setup Functions and Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
The D050-A Setup Functions Explained . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Power Management . . . . . . . . .. . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .. . . . . . . . . . 19
Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Others . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. .22
5 Operating the D050-A 23
The D050-A button and display functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
The D050-A Display Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
The D050-A Key Functions . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .. . . .. . . . . . . . . . . . . . . .23
Operator functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Display pressure . .. . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . 24
Piegraph indication . . . . . . . . . . . . . . . . . .. . . .. . . .. . . .. . . .. . . . . .. . . .. . . .. . . .. . . . 24
Operator alarms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Low-battery alarm . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .. . . . 24
Range error . . . . . . . . . . . . . .. . . . . . . . . . . . . . . .. . . .. . . . . . . . . . . . . . . .. .. . . .. . . . . . 25
Alarm 01-03. . . . . . . . . . . . . .. . . . . .. . . .. . . .. . . .. . . .. . . .. . . . . .. . . .. . . .. . . . . . . . 25
6 Maintenance 26
General directions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Battery life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Replacing the Battery . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . ...26
Preventive maintenance checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Repairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Setup Configuration Examples 28
Troubleshooting the D050-A 31

FW-D050-A-MAN-EN-V0101_02 1
1
CHAPTER
Introduction
System Description of the D050-A
Functions and Features
The Pressure Indicator model D050-A is a microprocessor controlled device to display pressure.
The D050-A has been designed with a focus on:
• Ultra-low power consumption, to allow for battery operation of up to five years.
• Front panel mounting solution based on IP66/67 (Nema4X), suitable for harsh industrial
surroundings.
• Very easy and user-friendly installation and programming through an easy menu-driven
structure. Know one, know them all!
• Ability to process all type of signals.
Field Input
The “A” in D050-A indicates a 0(4)–20mA pressure sensor input. Other versions are available to
process 0–10V (U) pressure sensor signals.
•The D050-A can read one passive or active pressure sensor with a 0(4)–20mA output.
•To power the pressure sensor, several options are available.
Figure 1: Typical application of the D050-A

User manual D050-A Pressure Indicator
1–INTRODUCTION
2FW-D050-A-MAN-EN-V0101_02
The D050-A Display Functions
The D050-A has a very large transflective LCD with a number of symbols and digits to display
measuring units, status information, trend indication and keyword messages.
Configuration of the D050-A
"Available D050-A configurations" on page 3 shows that this unit is available in various hardware
configurations to support a wide range of applications. Other models of this type have other
configurations. Contact your reseller for details.
The configuration mode of the D050-A allows you to configure and shape your D050-A towards
your specific requirements. The configuration mode supports all available hardware
configurations of the D050-A and includes several important features such as , measurement
units, signal settings, etc.
All setting as are stored in EEPROM memory and will not be lost in case of power breakdown or in
the event of an empty battery.
EEPROM Memory
The D050-A contains EEPROM memory that does not loose its data upon power loss.
All configuration settings remain stored in case of a power failure or deactivation of the unit (e.g.
during transport or storage).
Options of the D050-A
The following section describes the configuration options this particular D050-A may have been
equipped with. Other models of this type have other options. Contact your reseller for details.
Figure 2: The display functions of the D050-A
D050-A status indicators Numerical 26mm (1”) large
display readout
Pie graph indicator Measuring units large display readout
Note:
You may optimize battery-life time (type PB only) by optimizing the power-
management functions as described in "Power Management" on page 19.

User manual D050-A Pressure Indicator
INTRODUCTION – 1
FW-D050-A-MAN-EN-V0101_023
Available D050-A configurations
Your D050-A model is available in a number of hardwired configuration options.
A product label on the backside of the unit identifies which configuration options are included in
your D050-A.
The following table identifies the options that may apply to your D050-A.
Note:
A combination of configuration options is not always possible: some options rule others
out and some options require others to be included. Consult the product label on your
D050-A enclosure to see which options are included on your particular unit.
Standard confuguration: D050-A-HB-PX-ZX
Coding information D050-_ -HB -P_ -Z_
pressure sensor input signal(s)
A(0)4—20mA input.
Panel mount enclosure - IP66/67 (NEMA4X)
HB Aluminum DIN 43700 / IEC 61554 front panel
Power supply
PB Long life lithium battery
PD 24V DC/AC + sensor supply
PL Input loop powered from sensor signal 4 - 20mA - requires type A.
PM 115 - 230V AC + sensor supply
PX Basic power supply 8 - 30V DC (no real sensor supply)
Other options
ZB Bi-color backlight green/amber
ZX No options
The bold marked text contains the standard configuration.

User manual D050-A Pressure Indicator
1–INTRODUCTION
4FW-D050-A-MAN-EN-V0101_02
This page is left blanc intentionally.

FW-D050-A-MAN-EN-V0101_02 5
2
CHAPTER
Specifications of the D050-A
General specifications
Display
Type High intensity reflective numeric and alphanumeric LCD, UV-
resistant.
Digits 5½ very large 26mm (1”) digits. Various symbols and
measuring units.
Refresh rate User definable: 8 times/sec - 30 secs - 1 time/30 secs - off.
Type ZB Transflective LCD with bi-color LED backlight; green / amber.
Intensity and color can be adjusted in the configuration menu.
Good readings in full sunlight and darkness.
Panel Mount Enclosure
General Die-cast ALU (aluminum) enclosure with Polycarbonate
window and silicone.
UV stabilized and flame retardant material. GRP back cover.
Control Keys Three industrial micro switch keys. UV-stabilized silicone
keypad
Painting UV-resistant 2-component industrial paint
Dimensions 144 x 72 x 71.4mm (5.67" x 2.83" x 2.81") – LxHxD
Weight 325 gr.
Classification IP66, IP67 (NEMA4x) at the front-side
Panel cutout 138 x 68mm (5.43" x 2.68") – LxH
Panel thickness Max. 6mm (¼")
Type HB Die-cast ALU panel-mount enclosure according: DIN 43700 /
IEC 61554
Temperature
Operating -40°C to +80°C (-40°F to +176°F) ambient
Approvals and compliances
EMC compatibility Compliant ref: EN 61326 (1997), EN 61010-1 (1993).
Power supply
Type PB 3,6V Lithium battery life-time depends upon settings and
configuration – up to 5 years.
Type PD 24V AC / DC + 10%. Power consumption max. 5 Watt.
Type PL Input loop powered from sensor signal 4-20mA (type A).
Type PM 115-230V AC + 10%. Power consumption max. 15 Watt.
Type PX 8-30V DC. Power consumption max. 0.3 Watt.
Type ZB 20 - 30V DC. Power consumption max. 1 Watt.
With type PD - PM: Internally powered

User manual D050-A Pressure Indicator
2–SPECIFICATIONS OF THE D050-A
6FW-D050-A-MAN-EN-V0101_02
Sensor excitation
Sensor exitation specifications relate to the power supply
type.
Type PB / PX Not available
Type PD / PM Dipswitch adjustable sensor supply:
8.2V DC. Iout max 35mA @ 20°C
12V DC. Iout max 50mA @ 20°C
24V DC. Iout max 75mA @ 20°C (this voltage can vary
depending on the input supply voltage).
Terminal connections
Type Removable plug-in terminal strip.
Wire max. 1.5mm2and 2.5mm2solid / stranded.
Screw thread M3
Tightening torque 0.5-0.6 Nm
Data protection
Memory type EEPROM; data retention >10 years
Automatic backup of settings upon change & running totals
every minute
Access restriction Via configurable 4 digit numerical pass code
Inputs
Sensor
Type A 0(4)–20mA - with signal calibration feature at any voltage
within range.
Accuracy Resolution: 16 bit. Error < 0.01mA / ±0.05% FS. Low level
cut-off programmable.
Offset -99,999 to +199,999 units
Span 0.00001 - 199,999 with variable decimal position.
Update time Four times a second
Voltage drop 2.6 Volt
Load impedance 3kOhm
Relationship Linear calculation.
Note: External power to sensor is required; e.g. type PD/PM.
Operational
Operator functions
Displayed functions • pressure.
• measuring unit
• piegraph 0-100%
Pressure
Units mbar - bar - PSI - mPA - PA - no unit
Digits 5 ½ digits
Displayed decimals 0 - 1 - 2 - 3 - 4 or 5

FW-D050-A-MAN-EN-V0101_02 7
3
CHAPTER
Installation Instructions
Mechanical Installation
To extend life of your unit:
• Mount the D050-A on a solid base to avoid vibrations.
• Provide sufficient slack on cables to prevent stress on cable entries.
• Make sure the seal is mounted properly between the housing and the panel.
• The IP66, IP67 (NEMA4X) classification is valid for the front enclosure only.
• Do not expose the casing to strongly varying (weather) conditions, not even when rated IP67.
Note:
This section describes various hardware configurations of the D050-A. Your particular
model of the D050-A may not support all configuration options described.
Figure 3: Mechanical mounting precautions
Figure 4: Panel cut-out dimensions
@@Panel cut-out dimensions D-series
68mm (2.68")
138 mm (5.43")
10.2 mm (0.4”)
72 (2.83”)
144 mm (5.67”)
55,3mm (2.18”)
15,6mm (0.61”)

User manual D050-A Pressure Indicator
3–INSTALLATION INSTRUCTIONS
8FW-D050-A-MAN-EN-V0101_02
Electrical installation – general
Overview of Terminal Connectors
To gain access to the connectors open the panel containing the D050-A. You now see the battery
cover with the battery and the connectors at the back side of the display unit as shown below.
The actual number and size of connectors depends on your particular model.
Figure 5: Connector location D050-A
pressure sensor and Power
A 6-pole Classic COMBICON connector connects the
pressure sensor and (optional) power supply.
Mains Power Supply
A3-poleClassicCOMBICON connector connects the mains
power supply.(110/230V) (PM)
Figure 6: Pin layout options of main connector(s) –availability depends on model ID
AC power
supply
(option)
Pressure out
(option) Voltage
switch
8.2/12/24V
input
0(4)-20mA sensor
supply DC power supply
Analog out /
HART
(option)
R1 R2 R3 S1 S2 S3 S4 P3 P4 A1 A2
⊥+↑A
B
A
B⊥I+↑3.0V↓8.2/12/
24V↓⊥+↑
OT: NPN A: 0(4)-20mA PD:24V DC
⊥+↑+↓ ⊥ +↑ ⊥ +↑
OH: PNP / NPN A-PL: 4-20mA
(input loop powered) PX: 8-30Vdc
COM
⊥NO NC
OR: make-and-
break relay
Figure 7: Voltage switch positions
8.2V 12V 24V
A
B
A
B
A
B
A
B
A
or
B
A
B
P0 P1 P2
∼∼
PD:24V AC
L1 N
PM: 115-
230V AC

User manual D050-A Pressure Indicator
INSTALLATION INSTRUCTIONS – 3
FW-D050-A-MAN-EN-V0101_029
Connector Types and Wiring Sizes
The following connector types are fitted. Wires are connected using a flat head screw driver:
Classic COMBICON
A screw connector with 5.08mm pitch, suitable for 0.2—2.5mm2 or AWG
24—12 wire. Max. torque 0.5Nm.
Power Supply Wiring
Below section describes the available power supply types for the D050-A. Which types are
available in your particular D050-A depends on the ordering code.
Battery equipped models switch their internal battery off when an external supply is active.
The following power supply options are available:
• Battery powered. see "Battery powered type PB" on page 9 for details.
• Input loop powered, see "Loop Powered Pressure Indicator Input Wiring Option Type A-PL" on
page 12 for details.
• Externaly powered, see ""External Power Supply wiring" on page 9" for details.
Battery powered type PB
Type PB is internally battery powered and does not require any external wiring.
When power supply PX is available (see below) the internal battery is switched off. This extends
battery life and guarantees higher availability during power outages.
• A healthy battery has a life expectancy of several years, depending on its use and
configuration settings. For details see "Battery life" on page 26.
• When installing verify that the battery is in good working condition by running the power-up
sequence on page iv of this manual. If the battery needs to be replaced follow the battery
replacement instructions delivered with the new battery.
External Power Supply wiring
The D050-A can be equipped with a power supply, type PX or PD.
• For type PX or PD DC your D050-A must be equipped with a 6 pole connector.
Type PD can also power your pressure sensor in the field, see "Power supply" on page 4 for
details.
Note:
• Type PX < 16V does not foresee in the (optional) backlight power; see "Backlight" on
page 11.
• The internal battery is on standby, when external power is supplied. Note that the
internal battery cannot be used to power a pressure sensor with 8.2V (pin S4)!
Caution:
The D050-A and it’s field devices are functionally isolated to a maximum of 500V!

User manual D050-A Pressure Indicator
3–INSTALLATION INSTRUCTIONS
10 FW-D050-A-MAN-EN-V0101_02
Power wiring type PX
Connect the “-”, GND or “0V” wire of your external power supply to pin P3. Connect the “+” wire
to pin P4.
With power wiring type PX pin S4 offers 8.2V to power a device in the field
Power wiring type PD
Figure 8: Power wiring type PX
D050-A
P4
8-30Vdc
P3
With power wiring type PD / PM pin S4 offers a limited sensor supply (8.2/12/24V) to power the
flowmeter in the field.
Figure 9: Power wiring type PD DC / AC – with flowmeter supply
D050-A
P4
24Vdc ±10%
P3
S4 Power supply to flowmeter,seeFigure
7: "Voltage switch positions" for settings
P2
24Vac 50/60Hz
P1
0V
+
++
-
+
0V
++
-
~
~
ground - yellow /green
P0

User manual D050-A Pressure Indicator
INSTALLATION INSTRUCTIONS – 3
FW-D050-A-MAN-EN-V0101_02 11
Power wiring type PM
Type PM is a galvanically isolated highpower switching power supply, converting 115–230Vac
mains (50/60Hz) to power the D050-A,the backlight (option) and provides up to 24V sensor
supply to the field.
Backlight
For those applications where readability during day and night is an issue, a bi-color backlight is
available. The background color can be set to green or amber and the intensity can be adjusted
in the configuration menu, see 22 "Backlight" on page 19
Backlight requires a power supply of at least 16V and is internally powered by options PD, PM or
PX above 16V.
Warning
•HIGH VOLTAGE! Danger of electrical shock: remove power from the supply lines
before connecting.
Warning
• Never connect 24V AC and DC together on the same unit, this will damage the unit.
Figure 10: Power wiring type PM
D050-A
S4 Supplies up to 24Vdc@75mA sensor
power, see Figure 7: "Voltage switch
positions" for settings
P3/
S1
P2
115–230Vac 50/60Hz
+
0V
N
P1
L1
P0 ground - yellow /green

User manual D050-A Pressure Indicator
3–INSTALLATION INSTRUCTIONS
12 FW-D050-A-MAN-EN-V0101_02
I/O wiring options
Pressure Indicator Input Wiring Options Type A
The D050-A requires a 0(4)–20mA input signal which will be processed 4 times a second with a
16 bit accuracy.
Sensors that are not externally/self powered can by powered by the sensor supply terminal,
when the D050-A is equipped with power supply type PD.
Explanation of symbol ‘cable shielding’
Loop Powered Pressure Indicator Input Wiring Option Type A-PL
The D050-A with type PL requires a 4-20mA pressure sensor signal which has a double function:
The signal will be processed 4 times a second with a 16 bits accuracy and the unit will be
powered from the sensor signal (loop power). The input is not isolated and not intrinsically safe.
cable shielding
Figure 11: 0(4)–20mA signal input
D050-A sensor supply
(only with type PD) S4
Option 1: powered by
sensor supply
Option 2: self / externally
powered
0(4)–20mA S2
S1
1
2
Figure 12: 4–20mA loop powered signal input
D050-A Loop power provided by externally powered sensor
4–20mA
S2
S1

FW-D050-A-MAN-EN-V0101_02 13
4
CHAPTER
Configuring the D050-A
General
The D050-A has three buttons and four modes of operation, one of which is “off”.
The active modes are displayed by status indicators. Configuration of the D050-A is possible via
the Setup and Program modes, which are indicated by and .
• Familiarize yourself with the next sections on display functions, keypad functions and the
quick reference menu –before accessing the D050-A configuration modes.
• Also familiarize yourself with the sections on the D050-A setup functions and what immediate
impact they have on its response, before attempting to modify them.
The D050-A Display Functions
The D050-A has a very large transflective LCD with a number of symbols and digits to display
measuring units, status information, trend indication and keyword messages.
The D050-A Key Functions
The following keys are available:
SETUP
PROGRAM
Warning:
Not understanding the effect of your changes can cause unexpected system responses,
resulting in process inefficiency, product spilling and downtime.
Figure 13: The display functions of the D050-A
D050-A status indicators Numerical 26mm (1”) large
display readout
Pie graph indicator Measuring units large display readout
This key is used to access various configuration modes, program items and enter
values.
Use this key when you see PROG or ENTER in the text.
This key is used to browse setup items and to change blinking values and states.
Use this key when you see SELECT or in the text.
This key is used to power up the unit and to select a setup item or digit for change.
Use this key when you see CLEAR or in the text.

User manual D050-A Pressure Indicator
4–CONFIGURING THE D050-A
14 FW-D050-A-MAN-EN-V0101_02
Quick Reference Menu
Password Protection
If Setup mode is password protected you get below screen when trying to access: Password and
0000 are displayed, the left digit is blinking.
1 Press repeatitly until the correct number in the blinking digit is displayed.
2 Press to move to the next digit and repeat above step for all four digits.
3 When done with all four digits press ENTER to confirm:
- When correct, you enter Setup mode and the indicator lights up.
- When incorrect, you return to Operator mode: Try again.
See "No access (unknown password)" on page 35 for troubleshooting information.
Shelf mode Mode to deactivate the unit for storage. The unit is switched off.Press SELECT
twice to switch the unit on and perform a self test.
Operator mode Setup mode Program mode
Default operation mode of the unit.
Display indicators: or
(optional).
Mode to select setup items and see
their settings. Display indicator:
.
Mode to change settings. Display
indicators: and (blinking)
.
• Unit always returns to
this menu when not oper-
ated for 20 seconds.
• Operator functions and
rights depend on settings
and available options of
your unit.
• To access press and hold
PROG 7 seconds. While
waiting the display shows
.
• You may have to use
and to enter a 4-digit
password. Confirm with-
PROG.
• To select an item use
buttons and .
• To exit press and hold
PROG 3 seconds or wait 20
seconds.
• To access the selected
item press PROG.
• To change an item use
buttons and .
• To save changes and exit
press ENTER.
• To cancel press and hold
PROG 3 seconds or wait 20
seconds.
Figure 14: Enter a password to continue
RUN
READY
SETUP
SETUP
PROGRAM
RUN
LOW BATTERY
SET-UP PAUSE ALARM
PROGRAM
READY
SETUP
