Fluidwell F093 User manual

F093-P
TACHOMETER MONITOR
ENGINE SPEED AND RUNNING HOURS
WITH ALARM OUTPUT
Signal input tachometer: pulse, Namur and coil
Alarm output: alarm on RPM and running hours
Options: Intrinsically Safe
F-Series - Field mounted indicators for safe and hazardous areas.
More info: www.fluidwell.com/fseries

Page 2
FW-F093-P-M_v0404_01_EN.docx
SAFETY INSTRUCTIONS
•Any responsibility is lapsed if the instructions and procedures as described in this manual
are not followed.
•LIFE SUPPORT APPLICATIONS: The F093-P is not designed for use in life support
appliances, devices, or systems where malfunction of the product can reasonably be
expected to result in a personal injury. Customers using or selling these products for use
in such applications do so at their own risk and agree to fully indemnify the manufacturer
and supplier for any damages resulting from such improper use or sale.
•Electro static discharge does inflict irreparable damage to electronics! Before installing or
opening the F093-P, the installer has to discharge himself by touching a well-grounded
object.
•The F093-P must be installed in accordance with the EMC guidelines (Electro Magnetic
Compatibility).
•Connect a proper grounding to the metal enclosure as indicated if the F093-P has an
incoming power or signal line which carries a hazardous live voltage.
The Protective Earth (PE) wire may never be disconnected or removed.
•Intrinsically Safe applications: follow the instructions as mentioned in Chapter 5.
Certificates and related documents are available on our website or from your distributor.
DISPOSAL OF ELECTRONIC WASTE
•The WEEE Directive requires the recycling of disposed electrical and electronic
equipment in the European Union. When the WEEE Directive does not apply to your
region, we support its policy and ask you to be aware on how to dispose of this product.
•The crossed out wheelie bin symbol as illustrated and found on our products tells that this
product shall not be disposed of into the general waste system or into a landfill.
•At the end of its life, equipment shall be disposed of according to the local regulations
regarding waste of the electrical and the electronic equipment.
• Technical
helpdesk for information on the product disposal.
SAFETY RULES AND PRECAUTIONARY MEASURES
•The manufacturer accepts no responsibility whatsoever if the following safety rules and
precautions, instructions and the procedures as described in this manual are not
followed.
•Modifications of the F093-P implemented without preceding written consent from the
manufacturer, will result in the immediate termination of product liability and warranty
period.
•Mounting, electrical installation, start-up and maintenance of this device may only be
carried out by trained persons authorized by the operator of the facility. Persons must
read and understand this manual before carrying out its instructions.
•This device may only be operated by persons who are authorized and trained by the
operator of the facility. All instructions in this manual are to be observed.
•Check the mains voltage and information on the manufacturer's plate before installing the
F093-P.
•Check all connections, settings and technical specifications of the various peripheral
devices with the F093-P supplied.
•Open the enclosure only if all leads are free of potential.
•Never touch the electronic components (ESD sensitivity).
•Never expose the system to heavier conditions than allowed according to the
classification of the enclosure (see manufacture's plate and chapter 4.2.).
•If the operator detects errors or dangers, or disagrees with the safety precautions taken,
he should inform the owner or principal responsible.
•The local labor and safety laws and regulations must be adhered to.

Page 3
FW-F093-P-M_v0404_01_EN.docx
ABOUT THE MANUAL
This operation manual is divided into two main sections:
•The daily use of the F093-
meant for users.
•The following chapters and appendices are exclusively meant for electricians/technicians.
These provide a detailed description of all software settings and hardware installation guidance.
This operation manual describes the standard F093-P as well as most of the options available. For
additional information, please contact your supplier.
A hazardous situation may occur if the F093-P is not used for the purpose it was designed for
or is used incorrectly. Please carefully note the information in this operating manual
indicated by the pictograms:
A "warning !" indicates actions or procedures which, if not performed correctly, may lead to
personal injury, a safety hazard or damage of the F093-P or connected instruments.
A "caution !" indicates actions or procedures which, if not performed correctly, may lead to
personal injury or incorrect functioning of the F093-P or connected instruments.
A "note !" indicates actions or procedures which, if not performed correctly, may indirectly
affect operation or may lead to an instrument response which is not planned.
WARRANTY AND TECHNICAL SUPPORT
For warranty and technical support for your Fluidwell products,
visit our internet site www.fluidwell.com or contact us at s[email protected]om.
Hardware version : 03.03.xx
Software version : 03.06.xx
Manual : FW-F093-P-M_v0404_01_EN.docx
© Copyright 2022 : Fluidwell B.V. - the Netherlands
Information in this manual is subject to change without prior notice. The
manufacturer is not responsible for mistakes in this material or for incidental
damage caused as a direct or indirect result of the delivery, performance or
use of this material.
© All rights reserved. No parts of this publication may be reproduced or used
in any form or by any means without written permission of your supplier.

Page 4
FW-F093-P-M_v0404_01_EN.docx
CONTENTS MANUAL
SAFETY INSTRUCTIONS.................................................................................................................... 2
DISPOSAL OF ELECTRONIC WASTE............................................................................................... 2
SAFETY RULES AND PRECAUTIONARY MEASURES ................................................................... 2
ABOUT THE MANUAL ........................................................................................................................ 3
WARRANTY AND TECHNICAL SUPPORT........................................................................................ 3
CONTENTS MANUAL ......................................................................................................................... 4
1INTRODUCTION ..................................................................................................................... 6
1.1 System description of the F093-P............................................................................................6
2OPERATIONAL....................................................................................................................... 7
2.1 General information .................................................................................................................7
2.2 Control panel............................................................................................................................7
2.3 Operator information and functions .........................................................................................7
3CONFIGURATION................................................................................................................. 10
3.1 Introduction ............................................................................................................................10
3.2 Programming SETUP-level....................................................................................................10
3.2.1 Entering SETUP-level............................................................................................................10
3.2.2 Navigating through SETUP-level...........................................................................................10
3.2.3 Programming sequence.........................................................................................................11
3.2.4 Returning to OPERATOR-level .............................................................................................12
3.3 Configuration Settings............................................................................................................13
3.3.1 Overview functions SETUP level...........................................................................................13
3.3.2 Explanation of SETUP-menu 1 - Running hours...................................................................14
3.3.3 Explanation of SETUP-menu 2 - RPM...................................................................................14
3.3.4 Explanation of SETUP-menu 3 - Alarm.................................................................................15
3.3.5 Explanation of SETUP-menu 4 - Display...............................................................................16
3.3.6 Explanation of SETUP-menu 5 - Power management..........................................................17
3.3.7 Explanation of SETUP-menu 6 - Sensor...............................................................................17
3.3.8 Explanation of SETUP-menu 7 - Others................................................................................18
4INSTALLATION..................................................................................................................... 19
4.1 General directions..................................................................................................................19
4.2 Installation / surrounding conditions ......................................................................................19
4.3 Handling the F-Series enclosure ...........................................................................................20
4.3.1 Identification...........................................................................................................................20
4.3.2 Opening / Removing the cover ..............................................................................................22
4.3.3 Closing / Replacing the cover................................................................................................22
4.4 Mechanical installation...........................................................................................................23
4.4.1 Dimensions Aluminum and stainless steel enclosures.......................................................23
4.4.2 Dimensions Non-metallic enclosures..................................................................................24
4.4.3 Mounting ................................................................................................................................25
4.5 Electrical installation ..............................................................................................................26
4.5.1 Electrical safety......................................................................................................................26
4.5.2 Protective Earth (PE) connections.........................................................................................26
4.5.3 Field wiring connections.........................................................................................................27
4.5.4 Power supply wiring...............................................................................................................28
4.5.5 Tachometer supply ................................................................................................................28
4.6 Terminal connectors safe area applications Type PB / PX / PD ........................................29
4.6.1 Terminals 1-3: Tachometer input...........................................................................................29
4.6.2 Terminal 4-5: Power supply - type PX (default) and PD (option) ..........................................31
4.6.3 Terminal 6: Power supply type PD: 8.2V Tachometer supply...............................................31
4.6.4 Terminal 7-8: Alarm output Type OT..................................................................................32
4.6.5 Terminal 9-10: Power supply backlight - type ZB (option).....................................................32
4.7 Terminal connectors safe area applications Type PF / PM................................................33
4.7.1 Terminal GND-1-2: Power Supply .........................................................................................33
4.7.2 Terminal 3-4: Alarm output ....................................................................................................33
4.7.3 Terminals 5-7: Tachometer input...........................................................................................34
5INTRINSICALLY SAFE APPLICATIONS............................................................................. 37
5.1 Identification...........................................................................................................................37
5.2 Electrical installation in hazardous area ................................................................................38
5.2.1 General information and instructions.....................................................................................38

Page 5
FW-F093-P-M_v0404_01_EN.docx
5.2.2 Installations based on FM or CSA certificate ........................................................................ 38
5.2.3 Electrical data Control drawing........................................................................................... 39
5.2.4 Installations based on ATEX or IECEx certificate ................................................................. 40
5.2.5 Electrical data Annex 1....................................................................................................... 41
5.2.6 Power supply wiring............................................................................................................... 42
5.2.7 Tachometer supply................................................................................................................ 42
5.3 Terminal connectors Intrinsically Safe applications .............................................................. 43
5.4 Configuration examples Intrinsically Safe applications ......................................................... 43
5.4.1 F093-P-(OT)-PC-(PX)-XI-(ZB) Battery powered - Ex ia IIC/IIIC............................................ 43
5.4.2 F093-P-OT-PX-XI-ZB - Ex ia IIC/IIIC..................................................................................... 44
5.4.3 F093-P-OT-PX-XI-(ZB) - Ex ia IIC/IIIC .................................................................................. 44
6MAINTENANCE.....................................................................................................................45
6.1 General directions ................................................................................................................. 45
6.2 Instructions for repair............................................................................................................. 45
6.3 Battery replacement .............................................................................................................. 46
6.3.1 Safety instructions ................................................................................................................. 46
6.3.2 Replace the battery ............................................................................................................... 47
6.3.3 Disposal of batteries.............................................................................................................. 47
TECHNICAL SPECIFICATION.................................................................................48
PROBLEM SOLVING ...............................................................................................51
DECLARATION OF CONFORMITY .........................................................................52
INDEX OF THIS MANUAL..................................................................................................................53
LIST OF FIGURES..............................................................................................................................54

Page 6
FW-F093-P-M_v0404_01_EN.docx
1 INTRODUCTION
1.1 SYSTEM DESCRIPTION OF THE F093-P
Functions and features
The Tachometer Monitor model F093-P is a microprocessor driven instrument designed to display
engine speed, running hours and accumulated running hours as well as the monitoring of the engine
speed and running hours for high / low values.
This product has been designed with a focus on:
•ultra-low power consumption to allow long-life battery powered applications (type PB / PC),
•intrinsic safety for use in hazardous applications (type XI),
•several mounting possibilities with GRP, aluminum or stainless steel 316L enclosures for
industrial surroundings,
•ability to process all type of Tachometer signals,
•transmitting possibilities with one configurable alarm output.
Tachometer input
This manual describes the unit with a pulse type input from the Tachometer "-P version".
One Tachometer with a passive or active pulse, Namur or coil signal output can be connected to the
F093-P. To power the sensor, several options are available.
Fig. 1: Typical application for the F093-P.
Configuration of the F093-P
The F093-P has been designed to be implemented in many types of applications. For that reason, a
SETUP-level is available to configure your F093-P according to your specific requirements.
It includes several important features, such as K-factor, signal selection etc. All settings are stored in
EEPROM memory and will not be lost in the event of a power failure. To extend the battery-life time,
please make use of the power-management functions as described in chapter 3.3.6.
Display information
The unit has a large transflective LCD screen with all kinds of symbols and digits to display
measuring units, status information, trend-indication and key-word messages.
Engine speed (RPM) and running hours can be displayed either with the small 8mm digits or with
the 17mm digits. A backup of the running hours in EEPROM memory is made every minute.
Options
The following options are available: intrinsic safety, mechanical relay or active outputs, power- and
sensor-supply options, panel-mount, wall-mount and weather-proof enclosures, flame proof
enclosure and LED backlight.
RPM
alarm output
Overview typical application F093

Page 7
FW-F093-P-M_v0404_01_EN.docx
2 OPERATIONAL
2.1 GENERAL INFORMATION
This chapter describes the daily use of the F093-P. This instruction is meant for users / operators.
•The F093-P may only be operated by personnel who are authorized and trained by the
operator of the facility. All instructions in this manual are to be observed
•Take careful notice of the "Safety rules, instructions and precautionary measures" in the
front of this manual.
2.2 CONTROL PANEL
The control panel has three keys. The following keys are available:
Fig. 2: Control panel.
Functions of the keys
PROG-key
This key is used to program and save new values or settings.
The PROG-key is also used to gain access to SETUP-level; please read chapter 3.
SELECT-key
This key is used to SELECT the displayed information.
CLEAR-key
This key is used to CLEAR the value of total.
2.3 OPERATOR INFORMATION AND FUNCTIONS
In general, the F093-P will always function at Operator level. The information displayed is dependent
upon the SETUP-settings. The signal from the connected tachometer is processed by the F093-P in
the background, whichever screen refresh rate setting is chosen. After pressing a key, the display
will be updated very quickly during a 30 second period, after which it will slow-down again.
Fig. 3: Example of display information during process.
Autotoggle

Page 8
FW-F093-P-M_v0404_01_EN.docx
For the Operator, the following functions are available:
•Display engine speed / running hours or engine speed only or running hours only
This is the main display information of the F093-P. After selecting any other information, it will
always return to this main display automatically.
Running hours is displayed on the upper-line of the display and engine speed on the bottom
line.
It is possible to display engine speed only with the large 17mm digits; in this instance press
the SELECT-key to read the running hours.
When "-------" is shown, then the engine speed value is too high to be displayed. The arrows
indicate the increase/decrease of the engine speed trend.
•Clear running hours
The value for running hours can be re-initialized. To do so, press CLEAR twice. After
pressing CLEAR once, the flashing text "PUSH CLEAR" is displayed. To avoid re-initialization
at this stage, press another key than CLEAR or wait for 20 seconds.
Re-initialization of running hours DOES NOT influence the accumulated running hours.
If pressing CLEAR twice does not clear the running hours, the F093-P is configured not to
allow this in Operation mode.
•Display accumulated running hours
When the SELECT-key is pressed, running hours and accumulated running hours are
displayed. The accumulated running hours cannot be re-initialized. The value will count up to
99,999,999,999. The unit and number of decimals are displayed according to the
configuration settings for running hours.
•Programming the engine speed or running hours alarm values (in Operation mode)
This function might not be available due to configuration settings.
When the SELECT-key is pressed a few times, following engine speed and running hours
alarm values are displayed:
-low engine speed alarm: enter here 830 RPM for example,
-high engine speed alarm: enter here 5000 RPM for example,
-accumulated running hours, enter here 1000 HOURS for example.
To change the alarm value, the following procedure must be executed:
1) press PROG: the word "PROGRAM" will flash or a password will be requested,
2) use to select the digits and to increase that value,
3) confirm the new alarm value by pressing ENTER.
Fig. 4: Example of display information during programming minimum engine speed.
When data is altered but ENTER has not been pressed yet, then the alteration can still be
cancelled by waiting for 20 seconds or by pressing ENTER during three seconds: the former
value will be reinstated.
•Engine speed alarm
When the actual engine speed is outside the allowed range, an alarm message will be
displayed indicating the type of alarm: "RPM LO" or "RPM HI".
The alarm is terminated automatically as soon as the engine speed is within its range again.
•Running hours alarm
When the total running hours have reached the allowed range, an alarm message will be
displayed indicating the type of alarm.
PROGRAM

Page 9
FW-F093-P-M_v0404_01_EN.docx
•Low-battery alarm
When the battery voltage drops, it must be replaced. At first "low-battery" will flash, but as
soon as it is displayed continuously, the battery MUST be replaced shortly after!
The remaining lifetime after the first moment of indication is generally several days up to some
weeks. See paragraph 6.3 for further information on battery replacement.
Fig. 4: Example of low-battery alarm.
•Alarm 01-03
When "alarm" is displayed, please consult Appendix B: problem solving.

Page 10
FW-F093-P-M_v0404_01_EN.docx
3 CONFIGURATION
3.1 INTRODUCTION
This and the following chapters are exclusively meant for electricians and non-operators. In these,
an extensive description of all software settings and hardware connections are provided.
•Mounting, electrical installation, start-up and maintenance of the instrument may only be
carried out by trained personnel authorized by the operator of the facility. Personnel must
read and understand this Operating Manual before carrying out its instructions.
•The F093-P may only be operated by personnel who are authorized and trained by the
operator of the facility. All instructions in this manual are to be observed.
•Ensure that the measuring system is correctly wired up according to the wiring diagrams.
The housing may only be opened by trained personnel.
•Take careful notice of the "Safety rules, instructions and precautionary measures" in the
front of this manual.
3.2 PROGRAMMING SETUP-LEVEL
Changing the settings of the F093-P may have an influence on the current operation of the
device, even when SETUP-level is still active.
Make sure that the unit is not being used for any application when altering the settings.
3.2.1 ENTERING SETUP-LEVEL
Configuration of the F093-P is done at SETUP-level, which can be reached at all times while the
F093-P remains fully operational. At SETUP-level the display will deactivate the RUN indicator and
activate the SETUP indicator.
Use the control panel to access SETUP-level
PROG-key
To enter SETUP-level, press the PROG-key for 7 seconds at OPERATOR-level.
During this time, the symbols  will be displayed.
When SETUP-level is entered, a password might be required to continue. You can
enter the password by following the procedure for programming values as described in
the following paragraphs.
A password may be required to enter SETUP.
Without this password access to SETUP is denied.
3.2.2 NAVIGATING THROUGH SETUP-LEVEL
Each function has a unique menu-number, which is displayed near the SETUP indicator at the
bottom of the display. The menu-number is a combination of two figures, e.g. 1.2. The first number
indicates the function-group and the second number indicates the function. Additionally, each
function and function-group is expressed with a keyword.
Fig. 5: SETUP matrix structure
1.1
1.2
2.1.
2.1
1.3
2.2
3.1
3.
FUNCTION GROUP
FUNCTION
FW-4100-000001-001-EN

Page 11
FW-F093-P-M_v0404_01_EN.docx
Use the control panel to navigate through SETUP-level
PROG-key
When a function is selected, this key is used to start the programming sequence.
When only a function group is selected (and no function), this key is used to scroll back
a function group (e.g. 3 →2 →1 →3).
SELECT-key
This key is used to select the next function in the list (e.g. 1 →1.1 →1.2 →1). When
the top of the list is reached, it will wrap around and return to the function group
selection.
CLEAR-key
This key is used to select the previous function in the list (e.g. 1.2 →1.1 →1 →2).
When the bottom of the list is reached, it will return to the function group selection.
When only a function group is selected (and no function), this key is used to scroll to
the next function group. (e.g. 1 →2 →3 →1).
3.2.3 PROGRAMMING SEQUENCE
After selecting a function at SETUP-level, a new value can be programmed using the control panel.
A function either contains a value (a number with optionally a decimal point, e.g. 123.45) or a list
with items (e.g. Disable Enable).
For each function that needs to change, navigate to that function and follow the steps indicated
below. During the programming sequence, the display will deactivate the SETUP indicator and
activate the PROGRAM indicator.
When programming new values, alterations will only be set after the PROG-key has been
pressed to confirm the new value! (STEP 3)
Step 1: Starting the programming sequence
PROG-key
When a function is selected at SETUP-level, this key is used to start the programming
sequence.
Step 2a: Changing a value
SELECT-key
This key is used to increment the selected digit.
When the entered value is out of range, the increase sign or decrease-sign will
be displayed while you are programming. If this value is confirmed by pressing the
PROG-key, the value will be brought within a valid range automatically.
CLEAR-key
This key is used to select the next digit. If a decimal point can be set, this will be
included in the sequence as well (e.g. [decimal point] →digit 1 →digit 2→digit 3 →
[decimal point].
SELECT-key + CLEAR-key
The combination of the SELECT-key and CLEAR-key is used to select a negative
value. When a value can also be entered as a negative number, pressing the SELECT-
key and CLEAR-

Page 12
FW-F093-P-M_v0404_01_EN.docx
Step 2b: Changing the selected item in a list
SELECT-key
This key is used to select the next item in the list (e.g. Disable →Enable).
At the end of the list, the selection will wrap around to the first selection.
CLEAR-key
This key is used to select the previous item in the list (e.g. Enable →Disable ).
At the bottom of the list, the selection will wrap around to the last selection.
Step 3: Finishing the programming sequence
PROG-key
During the programming sequence, this key is used to confirm the new value and
return to SETUP-level. To cancel the operation, either press the PROG-key for 3
seconds or wait for 20 seconds: the programming sequence is cancelled and the
former value is reinstated.
3.2.4 RETURNING TO OPERATOR-LEVEL
When all settings are configured correctly, the unit can be returned to OPERATE-level.
Please keep a record of all settings for later reference.
Use the control panel to return to OPERATE-level
PROG-key
In order to return to the operator level, press the PROG-key for three seconds.
When no keys are pressed for 2 minutes, SETUP-level will be left automatically.

Page 13
FW-F093-P-M_v0404_01_EN.docx
3.3 CONFIGURATION SETTINGS
All settings of the F093-P can be set via the control panel.
The following paragraphs give a detailed description of each setting.
3.3.1 OVERVIEW FUNCTIONS SETUP LEVEL
SETUP FUNCTIONS AND VARIABLES
1
HOURS
1.1
CLEAR
Push Clear –Enter - Cleared
1.2
DECIMALS
0 - 1 (Ref: displayed value)
1.3
FREQ MIN
0.01 –999,99 Hz
2
RPM
2.1
DECIMALS
0 - 1 (Ref: displayed value)
2.2
K-FACTOR
0.000010 - 9,999,999
2.3
DECIMALS K-FACTOR
0 - 6
2.4
CALCULATION
per 1 - 255 pulses
2.5
CUT-OFF
0.1 - 999.9 seconds
3
ALARM
3.1
ALARM
disable - enable
3.2
RPM ZERO
default - no relays - ignore
3.3
ALARM LO
0000.000 - 9,999,999
3.4
ALARM HI
0000.000 - 9,999,999
3.5
DELAY LO
0.1 - 999.9 seconds
3.6
DELAY HI
0.1 - 999.9 seconds
3.7
ALARM HR
0 - 9999
3.8
REL OUT
hi - lo –hi lo –hours - off
4
DISPLAY
4.1
FUNCTION
hours - rpm
4.2
DISPLAY
all –toggle –hand
4.3
CLR HRS
operator - setup
4.4
ALARM SET
operator - setup
4.5
ACC HRS
display - hide
4.6
BACKLIGHT (optional)
off - on
4.7
BL ALARM (optional)
off - on - flash
4.8
BRIGHTNS (optional)
1 - 5
5
POWER MANAGEMENT
5.1
LCD NEW
fast - 1 sec - 3 sec - 15 sec - 30 sec - off
5.2
BATTERY MODE
operational - shelf
6
SENSOR
6.1
SIGNAL
npn - npn_lp - reed - reed_lp - pnp - pnp_lp - namur - coil_hi - coil_lo -
active
7
OTHERS
7.1
TYPE / MODEL
F093-P
7.2
SOFTWARE VERSION
03.xx.xx
7.3
SERIAL NO.
xxxxxxx
7.4
PASS CODE
0000 - 9999
7.5
TAGNUMBER
0000000 - 9999999

Page 14
FW-F093-P-M_v0404_01_EN.docx
3.3.2 EXPLANATION OF SETUP-MENU 1 - RUNNING HOURS
SETUP FUNCTIONS AND VARIABLES
1
TOTAL
1.1
CLEAR
In the CLEAR menu you can reset the running hours to zero:
Press PROG, press CLEAR-
-
running hours will be 0.
This can normally also be done by pressing CLEAR twice in
Operation mode when SETUP 4.ENABLE. SETUP 1.1 -
CLEAR will always function. The following can be selected:
Push Clear Enter - Cleared
1.2
DECIMALS
The decimal point determines for running hours and accumulated
running hours the number of digits following the decimal point. The
following can be selected:
0000000 - 111111.1
1.3
FREQ MIN
At MINimum FREQuency you set the minimum frequency value at
which the running hours are being registered. By setting a value
disturbances are filtered out. The following can be selected:
0.01 999,99 Hz
3.3.3 EXPLANATION OF SETUP-MENU 2 - RPM
The settings for running hours and engine speed are entirely separate. The display update time for
engine speed (RPM) is one second or more.
These settings also influence the alarm output functions.
SETUP FUNCTIONS AND VARIABLES
2
RPM
2.1
DECIMALS
This setting determines for engine speed the number of digits
following the decimal point. The following can be selected:
00000 - 1111.1
2.2
K-FACTOR
With the K-factor, the Tachometer pulse signals are converted to
an engine speed (RPM).
The K-factor is based on the number of pulses generated by the
Tachometer per RPM. The more accurate the K-factor, the more
accurate the functioning of the system will be.
2.3
DECIMALS K-FACTOR
This setting determines the number of decimals for the K-factor
(SETUP 2.2). The following can be selected:
0 - 1 - 2 - 3 - 4 - 5 - 6
Please note that this SETUP - influences the accuracy of the K-
factor indirectly. This setting has NO influence on the displayed
number of digits for "engine speed" (SETUP 2.1)!

Page 15
FW-F093-P-M_v0404_01_EN.docx
2.4
CALCULATION
The engine speed is calculated by measuring the time between a
number of pulses, for example 10 pulses. The more pulses the
more accurate the engine speed will be. The maximum value is
255 pulses.
This setting does influence the update time for the analog output
directly (maximum update 10 times a second). If the output
response is too slow, decrease the number of pulses.
The lower the number of pulses, the higher the power
consumption of the unit will be (important for battery powered
applications).
For low frequency applications (below 10Hz): do not program
more than 10 pulses else the update time will be very slow.
For high frequency application (above 1kHz) do program a value
of 100 or more pulses.
2.5
CUT-OFF
With this setting, you determine a minimum RPM requirement
threshold, if during this time less than XXX-pulses (SETUP 2.4)
are generated, the engine speed will be displayed as zero.
The cut-off time has to be entered in seconds - maximum time is
999 seconds (about 15 minutes).
3.3.4 EXPLANATION OF SETUP-MENU 3 - ALARM
SETUP FUNCTIONS AND VARIABLES
3
ALARM
3.1
ALARM
With this setting you determine whether the alarm system is active or
not. The individual alarms can also be activated or not.
The following can be selected:
DISABLE - ENABLE
3.2
RPM ZERO
When the engine speed is zero, then it is possible to ignore or disable
the engine speed monitoring. The following settings can be selected:
DEFAULT: in case of a low-engine speed alarm, it will switch the
alarm output and indicate the alarm on the display.
NO RELAY: in case of a low-engine speed alarm, it won't switch the
alarm output but will indicate the alarm on the display
only.
IGNORE: in case of a low-engine speed alarm, it won't switch the
alarm output and nothing will be indicated on the
display.
3.3
ALARM LO
The low alarm is set with this setting. An alarm will be generated as
long as the engine speed is lower as this value.
With value 0.0 this function is disabled.
3.4
ALARM HI
The high alarm is set with this setting. An alarm will be generated as
long as the engine speed is higher as this value.
With value 0.0 this function is disabled.
3.5
DELAY LO
An alarm generated by SETUP 3.-time
period. If the actual engine speed is still incorrect after this delay time,
then an alarm will be generated.
3.6
DELAY HI
An alarm generated by SETUP 3.-
time period. If the actual engine speed is still incorrect after this delay
time, then an alarm will be generated.
3.7
ALARM HR
The running hours alarm is set with this setting. An alarm will be
generated when this value of running hours is met.
With value 0.0 this function is disabled.
3.8
REL OUT
One transistor or relay output is available to transmit the alarm
condition. Assign with this function the type of alarm to be transmitted:
low engine speed alarm, high engine speed alarm, both these alarms
or total running hours.

Page 16
FW-F093-P-M_v0404_01_EN.docx
3.3.5 EXPLANATION OF SETUP-MENU 4 - DISPLAY
SETUP FUNCTIONS AND VARIABLES
4
DISPLAY
4.1
FUNCTION
The large 17mm digits can be set to display running hours or engine
speed (RPM).
When "running hours" is selected, both running hours and engine
speed are displayed simultaneously.
When "engine speed" is selected, only engine speed will be displayed
with its measuring unit while running hours will be displayed after
pressing SELECT. The following can be selected:
HOURS - RPM
4.2
DISPLAY

will show both the 
automatically swap every 3 seconds between RPM and HOURS and

following can be selected:
ALL TOGGLE HAND
4.3
CLR HRS
This function, Clear Hours, determines if the running hours can be
reset to zero at Operator level (by clicking CLEAR twice) or only at
SETUP-level, (SETUP 1.1 CLEAR). The following can be selected:
DISABLE - ENABLE
4.4
ALARM SET
This function determines if the RPM alarm values can be set at both
Operator level and SETUP-level or at SETUP-level only.
If SETUP has been selected, the alarm values are still visible for the
Operator but cannot be changed. The following can be selected:
OPERATE - SETUP
4.5
ACC HRS
This function determines if the ACCumulated running HouRS are

DISPLAY - HIDE
The functions below will only effect the optional LED-backlight.
4.6
BACKLIGHT (optional)
If a LED backlight has been supplied, it can be turned on or off.
4.7
BL ALARM (optional)
In case the F093-P generates any alarm, the backlight can be set to
change to red. Following selections are available:
OFF: during alarm the color is according to setting 4.6.
ON: during alarm the color is red.
FLASH: during alarm the color flashes red and the color as per
setting 4.6.
4.8
BRIGHTNS (optional)
The brightness of the backlight can be set in following range:
1 - 5
One is minimum and five is maximum brightness

Page 17
FW-F093-P-M_v0404_01_EN.docx
3.3.6 EXPLANATION OF SETUP-MENU 5 - POWER MANAGEMENT
When used with the internal battery option, the user can expect reliable measurement over a long
period of time. The F093-P has several smart power management functions to extend the battery life
time significantly. Two of these functions are available.
SETUP FUNCTIONS AND VARIABLES
5
POWER MANAGEMENT
5.1
LCD NEW
The calculation of the display-information influences the power
consumption significantly. When the application does not require a
fast display update, it is strongly advised to select a slow refresh
rate. Please understand that NO information will be lost; every pulse
will be counted and the output signal will be generated in the normal
way.
The following can be selected:
Fast - 1 sec - 3 sec - 15 sec - 30 sec - off.
Example battery life-time with a coil pick-up:
•1kHz pulse and FAST update: about 2 years.
•1kHz pulse and 1 sec update: about 5 years.
After a button has been pressed by the operator - the display refresh
rate will always switch to FAST for 30 seconds. When "OFF" is
selected, the display will be switched off after 30 seconds and will be
switched on as soon as a button has been pressed.
5.2
BATTERY MODE
The F093-P has two modes: operational or shelf.
After "shelf" has been selected, the F093-P can be stored for several
years; it will not process the sensor signal; the display is switched off
but all settings and running hours are stored. In this mode, power
consumption is extremely low.
To wake up the F093-P again, press the SELECT/key twice.
3.3.7 EXPLANATION OF SETUP-MENU 6 - SENSOR
The F093-P is able to handle several types of input signal. The type of tachometer pickup / signal is
selected with SETUP 6.1. Read also paragraph 4.6.1 Terminals 1-3: Tachometer input.
SETUP FUNCTIONS AND VARIABLES
6
SENSOR
6.1
SIGNAL
TYPE OF SIGNAL
EXPLANATION
RESISTANCE
FREQ. / mV
REMARK
NPN
NPN input
100 kΩ pull-up
6 kHz.
(open collector)
NPN - LP
NPN input with
low pass filter
100 kΩ pull-up
1.2 kHz.
(open collector)
less sensitive
REED
Reed-switch input
1 mΩ pull-up
600 Hz.
REED - LP
Reed-switch input
with low pass
filter
1 mΩ pull-up
120 Hz.
Less sensitive
PNP
PNP input
47 kΩ pull-down
6 kHz.
PNP - LP
PNP input with
low pass filter
100 kΩ pull-down
1.2 kHz.
Less sensitive
NAMUR
Namur input
820 Ω pull-down
4 kHz.
External power
required
COIL HI
High sensitive coil
input
-
20 mV p.t.p.
Sensitive for
disturbance!
COIL LO
Low sensitive coil
input
-
90 mV p.t.p.
Normal sensitivity
ACTIVE
Active pulse input
detection level
1.2V DC
47 kΩ
10 kHz.
External power
required

Page 18
FW-F093-P-M_v0404_01_EN.docx
3.3.8 EXPLANATION OF SETUP-MENU 7 - OTHERS
SETUP FUNCTIONS AND VARIABLES
7
OTHERS
7.1
TYPE / MODEL
For support and maintenance it is important to have information about
the characteristics of the F093-P.
Your supplier will ask for this information in the case of a serious
breakdown or to assess the suitability of your model for upgrade
considerations.
7.2
SOFTWARE VERSION
7.3
SERIAL NO.
7.4
PASS CODE
All SETUP-values can be pass code protected.
This protection is disabled with value 0000 (zero).
Up to and including 4 digits can be programmed, for example 1234.
7.5
TAGNUMBER
For identification of the F093-P and communication purposes, a
unique tag number of maximum 7 digits can be entered.

Page 19
FW-F093-P-M_v0404_01_EN.docx
4 INSTALLATION
4.1 GENERAL DIRECTIONS
•Mounting, electrical installation, start-up and maintenance of this instrument may only be
carried out by trained personnel authorized by the operator of the facility. Personnel must
read and understand this Operating Manual before carrying out its instructions.
•The F093-P may only be operated by personnel who are authorized and trained by the
operator of the facility. All instructions in this manual are to be observed.
•Make sure that the measuring system is correctly wired up according to the wiring
diagrams. Protection against accidental contact is no longer assured when the enclosure
cover is removed or the panel cabinet has been opened (danger from electrical shock).
The enclosure may only be opened by trained persons authorized by the operator of the
facility.
•Take careful notice of the "Safety rules, instructions and precautionary measures" at the
front of this manual.
The F0-Series can be supplied as suitable for Safe Area or Hazardous Area. This is indicated in the
model code (shown on the product label) by the Type X* designator, with following options:
•Type XX: Suitable for safe area applications only (e.g. F093-P-XX)
Follow the mechanical and electrical installation instructions shown in chapter 4.
•Type XF: Suitable for explosion proof / flame proof applications (e.g. F093-P-XF)
Follow the electrical installation instructions as shown in chapter 4 and
the mechanical installation instructions of the enclosure that are supplied separately.
•Type XI: Suitable for intrinsically safe applications (e.g. F093-P-XI)
Follow the general mechanical and electrical installation instructions of chapter 4
and the specific installation instructions of chapter 5.
4.2 INSTALLATION / SURROUNDING CONDITIONS
Take the relevant IP classification of the
enclosure into account (see identification plate).
Even an enclosure rated for IP67 / TYPE 4(X)
should NEVER be exposed to strongly varying
(weather) conditions.
When used in very cold surroundings or varying
climatic conditions, inside the instrument case,
take the necessary precautions against moisture.
Mount the F-Series onto a solid structure to avoid
vibrations.
For use in Safe and Hazardous Areas (or Locations), the following conditions apply:
Relative humidity:
< 90% RH
Outdoor use:
suitable for outdoor use
IP and NEMA rating:
IP65 (panel mount), IP67 (field mount) and Type 4X
Supply voltage fluctuation:
As indicated by the supply range (e.g. 10V to 30V),
otherwise +/- 10% unless stated otherwise
Means of protection:
Intrinsically safe:
IS
Ordinary locations:
Class I (PE connected metal enclosure)
Class II (non-metallic enclosure)
Over-voltage category:
II (when supplied from mains)
Pollution degree:
2 (internal environment), 3 (external environment)
Ambient:
Intrinsically safe:
-40 °C to +70 °C, -40 °F to +158 °F
(limited to +50 °C, 122 °F for EPL Da)
Ordinary locations:
-40 °C to +80 °C, -40 °F to +176 °F
Altitude:
up to 2000 m

Page 20
FW-F093-P-M_v0404_01_EN.docx
4.3 HANDLING THE F-SERIES ENCLOSURE
4.3.1 IDENTIFICATION
The F0-Series can be supplied as suitable for Safe Area or Hazardous Area.
Suitability for Intrinsic Safety is indicated in the model code by Type XI (e.g. F093-P-XI).
For Intrinsically Safe applications: Installation and identification labels are shown in chapter 5.
Identification label
To identify your F0-Series device, all field mount enclosures have a weatherproof identification label
placed on the outside of the unit.
Fig. 6: Identification Example of F0-Series identification label (safe area)
Installation label
A second label is located on the inside and shows additional installation data. For panel mount
enclosures, the outside label is not available, so the inside label also serves as identification label.
After installation, the inside label is only visible from the rear side of the panel.
Fig. 7: Identification Example of F0-Series installation label (safe area - Type PB, PX or PD)
