Fluidwell F Series User manual

F114-P
Ratio monitor / totalizer
with high / low alarms and analog outputs
Signal input flowmeter: pulse, Namur and coil
Signal outputs: 4-20mA ref. ratio or flow rate
Alarm outputs: maximum four flow rate alarms
Options: Intrinsically Safe, Modbus communication
F-Series - Field mounted indicators for safe and hazardous areas.
More info: www.fluidwell.com/fseries

FW_F114P_v1702_02_EN
Page 2

FW_F114P_v1702_02_EN
Page 3
SAFETY INSTRUCTIONS
Any responsibility is lapsed if the instructions and procedures as described in this
manual are not followed.
LIFE SUPPORT APPLICATIONS: The F114-P is not designed for use in life support
appliances, devices, or systems where malfunction of the product can reasonably be
expected to result in a personal injury. Customers using or selling these products for
use in such applications do so at their own risk and agree to fully indemnify the
manufacturer and supplier for any damages resulting from such improper use or sale.
Electro static discharge does inflict irreparable damage to electronics! Before installing
or opening the unit, the installer has to discharge himself by touching a well-grounded
object.
This unit must be installed in accordance with the EMC guidelines (Electro Magnetic
Compatibility).
Do connect a proper grounding to the metal enclosure as indicated if the F114-P has an
incoming power line which carries a 115-230V AC. The Protective Earth (PE) wire may
never be disconnected or removed.
Intrinsic safe applications: follow the instructions as mentioned in Chapter 5 and consult
“Fluidwell F1..-..-XI - Documentation for Intrinsic safety”.
DISPOSAL OF ELECTRONIC WASTE
The WEEE Directive requires the recycling of disposed electrical and electronic equipment in the
European Union. When the WEEE Directive does not apply to your region, we support its policy
and ask you to be aware on how to dispose of this product.
The crossed out wheelie bin symbol as illustrated and found on our products tells that this
product shall not be disposed of into the general waste system or into a landfill.
At the end of its life, equipment shall be disposed of according to the local regulations regarding
waste of the electrical and the electronic equipment.
Please contact your local dealer, national distributor or the manufacturer’s Technical helpdesk for
information on the product disposal.
SAFETY RULES AND PRECAUTIONARY MEASURES
The manufacturer accepts no responsibility whatsoever if the following safety rules and
precautions instructions and the procedures as described in this manual are not followed.
Modifications of the F114-P implemented without preceding written consent from the
manufacturer, will result in the immediate termination of product liability and warranty period.
Mounting, electrical installation, start-up and maintenance of this device may only be carried out
by trained persons authorized by the operator of the facility. Persons must read and understand
this manual before carrying out its instructions.
This device may only be operated by persons who are authorized and trained by the operator of
the facility. All instructions in this manual are to be observed.
Check the mains voltage and information on the manufacturer's plate before installing the unit.
Check all connections, settings and technical specifications of the various peripheral devices
with the F114-P supplied.
Open the enclosure only if all leads are free of potential.
Never touch the electronic components (ESD sensitivity).
Never expose the system to heavier conditions than allowed according the classification of the
enclosure (see manufacture's plate and chapter 4).
If the operator detects errors or dangers, or disagrees with the safety precautions taken, then
inform the owner or principal responsible.
The local labor and safety laws and regulations must be adhered to.

FW_F114P_v1702_02_EN
Page 4
ABOUT THE MANUAL
This manual is divided into two main sections:
The daily use of the unit is described in chapter 2 "Operation". These instructions are meant for
users.
The following chapters and appendices are exclusively meant for electricians/technicians. These
provide a detailed description of all software settings and hardware installation guidance.
This manual describes the standard unit as well as the available options. For additional information,
please contact your supplier.
A hazardous situation may occur if the F114-P is not used for the purpose it was designed for
or is used incorrectly. Please carefully note the information in this manual indicated by the
pictograms:
A "warning !" indicates actions or procedures which, if not performed correctly, may lead to
personal injury, a safety hazard or damage of the F114-P or connected instruments.
A "caution !" indicates actions or procedures which, if not performed correctly, may lead to
personal injury or incorrect functioning of the F114-P or connected instruments.
A "note !" indicates actions or procedures which, if not performed correctly, may indirectly
affect operation or may lead to an instrument response which is not planned.
WARRANTY AND TECHNICAL SUPPORT
For warranty and technical support for your Fluidwell products,
visit our internet site www.fluidwell.com or contact us at s[email protected].
Hardware version : 03.01.xx
Software version : 03.01.xx
Manual : FW_F114P_v1702_02_EN
© Copyright 2017 : Fluidwell B.V. - the Netherlands
Information in this manual is subject to change without prior notice. The
manufacturer is not responsible for mistakes in this material or for incidental
damage caused as a direct or indirect result of the delivery, performance or
use of this material.
© All rights reserved. No parts of this publication may be reproduced or used
in any form or by any means without written permission of your supplier.

FW_F114P_v1702_02_EN
Page 5
CONTENTS MANUAL
Safety instructions.......................................................................................................... 3
Disposal of electronic waste.......................................................................................... 3
Safety rules and precautionary measures..................................................................... 3
About the manual............................................................................................................ 4
Warranty and technical support..................................................................................... 4
Contents manual............................................................................................................. 5
1. Introduction.......................................................................................................... 6
1.1. System description ....................................................................................................6
2. Operational........................................................................................................... 7
2.1. Control panel .............................................................................................................7
2.3. Operator information and functions...........................................................................7
3. Configuration....................................................................................................... 9
3.1. How to program the F114-P......................................................................................9
3.1.1. Setup menu - Settings.............................................................................................11
3.1.2 Explanation of SETUP-menu 1 - Total-A.................................................................12
3.1.3 Explanation of SETUP-menu 2 - Flow rate-A.........................................................12
3.1.4 Explanation of SETUP-menu 3 - Total-B.................................................................13
3.1.5 Explanation of SETUP-menu 4 - Flow rate-B..........................................................13
3.1.6 Explanation of SETUP-menu 5 - Ratio....................................................................13
3.1.7 Explanation of SETUP-menu 6 - Alarm...................................................................14
3.1.8. Explanation of SETUP menu 7 - Display.................................................................15
3.1.9 Explanation of SETUP-menu 8 - Power management............................................15
3.1.10 Explanation of SETUP-menu 9 - Flowmeter ...........................................................15
3.1.11 Explanation of SETUP-menu A - Analog output......................................................16
3.1.12. Explanation of SETUP menu B - Relays.................................................................17
3.1.13 Explanation of SETUP-menu C - Communication (option) .....................................17
3.1.14 Explanation of SETUP-menu D - Others.................................................................18
4. Installation.......................................................................................................... 18
4.1. General directions....................................................................................................18
4.2. Installation - surrounding conditions........................................................................18
4.3. Dimensions- Enclosure............................................................................................19
4.4. Installing the hardware ............................................................................................21
4.4.1. General installation guidelines.................................................................................21
4.4.2. Aluminum enclosure - Field mounted......................................................................22
4.4.3. Aluminum enclosure - Panel mounted.....................................................................22
4.4.4. Plastic (GRP) enclosure ..........................................................................................23
4.4.5. Terminal connectors................................................................................................24
5. Intrinsically safe applications........................................................................... 32
5.2. Terminal connectors Intrinsically safe applications .................................................33
5.3. Configuration examples Intrinsically Safe applications ...........................................35
5.4 Battery replacement instructions .............................................................................37
5.4.1. Safety instructions ...................................................................................................37
5.4.2. Replace the battery (hazardous area).....................................................................37
5.4.3. Disposal of batteries................................................................................................37
6. Maintenance....................................................................................................... 38
6.1. General directions....................................................................................................38
6.2 Repair......................................................................................................................38
6.3. Repair policy............................................................................................................38
Appendix A: Technical specificationS................................................................... 39
Appendix B: Problem solving................................................................................. 42
Appendix C: Communication variables ................................................................. 43
Appendix D: Declaration of conformity.................................................................. 47
Index of this manual ..................................................................................................... 48
List of figures in this manual........................................................................................ 49

FW_F114P_v1702_02_EN
Page 6
1. INTRODUCTION
1.1. SYSTEM DESCRIPTION
Functions and features
The function of the F114-P is to calculate, show and monitor the ratio between two flows as well as
the flow rates and the totals.
This product has been designed with a focus on:
ultra-low power consumption to allow long-life battery powered applications (type PB/PC),
intrinsic safety for use in hazardous applications (type XI);
several mounting possibilities with aluminum or GRP enclosures for harsh industrial
surroundings;
ability to process all types of flowmeter signals;
transmitting possibilities with analog / alarm and communication outputs.
Flowmeter input
This manual describes the unit with a pulse input from the flowmeter. Other versions are available to
process (0)4-20mA signals.
Two flowmeters with a passive or active pulse, Namur or sine wave (coil) signal output can be
connected to the F114-P. To power the sensor, several options are available.
Standard outputs
Max. four configurable alarm outputs: flow rate alarm, high-, low-, high-high- or low-low-flow rate
alarm. Switched as long as the flow rate is too high or too low.
Linear (0)4-20mA or 0-10V analog output to represent the actual flow rate as programmed. The
(0)4-20mA or 0-10V signal limits can be tuned.
Fig. 1: Typical application
Configuration of the unit
The F114-P is designed for use in many types of applications. For that reason, a setup menu is
available to program the F114-P according to your specific requirements.
The setup includes several important features, such as K-Factors, engineering units, signal
selection, power management (to extend battery life-time), etc. All settings are stored in a non-
volatile memory and therefore kept in the event of a power failure or an exhausted battery.

FW_F114P_v1702_02_EN
Page 7
Display information
The unit has a LCD with (optional) backlight to show the process information, status and alarm messages.
The display refresh rate is programmed in the setup menu. At a key press, the display refresh rate will
switch to FAST for 30 seconds. When 'OFF' is selected, the display goes off after 30 seconds after
the last key press. The display temporarily comes on after a key press.
Options
The following options are available: isolated or active (0)4-20mA / 0-10V analog output, full Modbus
communication RS232/485/TTL (also battery powered), intrinsic safety, mechanical relay or active
output, power- and sensor-supply options, panel -mount, wall-mount and weather-proof enclosures,
flame proof enclosure and LED backlight.
2. OPERATIONAL
This device may only be operated by persons who are authorized and trained by the
operator of the facility. All instructions in this manual are to be observed.
Take careful notice of the "Safety rules, instructions and precautionary measures" in the
front of this manual.
This chapter describes the daily use of the F114-P . This instruction is meant for users / operators.
2.1. CONTROL PANEL
The control panel has three keys. The available keys are:
Fig. 2: Control Panel
Functions of the keys
This key is used to program and save new values or settings.
The PROG/ENTER key is also used to gain access to the setup menu (read
chapter 3).
This key is used to select the flow rates, the (accumulated) total and the alarm
messages.
The SELECT/key is also used to increase a value after the PROG/ENTER key has
been pressed (read chapter 3).
This key is used to reset the total.
The CLEAR/key is also used to select a digit or an option after the PROG/ENTER
key has been pressed (read chapter 3).
2.3. OPERATOR INFORMATION AND FUNCTIONS
In general, the F114-P operates in the operator mode. The shown information depends on the
settings which are made in the setup menu. The signal from the connected sensor is processed by
the F114-P in the background, independent from the selected display refresh rate.
Not all information can be shown at once, but first after pressing the select-key. At the bottom-left of
the display, the actual liquid number (A or B) is shown when necessary.
Fig. 3: Process information (typical)

FW_F114P_v1702_02_EN
Page 8
For the Operator, the following functions are available:
Display ratio:
This is the main display information of the F114. After selecting other information, it will return to
the main display automatically. The ratio is calculated by measuring the flow A and flow B. The
shown ratio can indicate:
-the actual flow rate of the additive compared to the flow rate of the main flow, or
-the actual flow rate of the additive compared to the total flow (summed additive + main flow).
The arrows indicate the increase/decrease of the ratio trend.
Display flow rate:
When enabled in the setup menu, the display shows the flow rate only. When you press the
select key, the total shows momentarily.
When "-------" is shown, then the flow rate value is too high to be shown. The arrows indicate
the increase/decrease of the flow rate trend.
Programming the ratio alarm values
When enabled in the setup menu,
When you press the SELECT/key several times, the following ratio alarm values are shown:
low-low ratio alarm (LL): enter here 1-0.010 for example,
low ratio alarm (LO): enter here 1-0.2 for example,
high ratio alarm (HI): enter here 1-1.0 for example,
high-high ratio alarm (HH): enter here 1-1.2 for example.
To change the alarm value, the following procedure must be executed:
1. Press the PROG/ENTER key to access the submenu.
2. Use the SELECT/key to increase the digit. Use the CLEAR/key to go to the next
number.
3. Confirm the new alarm value by pressing ENTER.
If you do not press the PROG/ENTER key to confirm, your selection is not saved.
Fig. 4: Examples display information in % and 1:x during programming the high ratio value
Ratio alarm
When the actual ratio is outside the allowed range, an alarm message will be shown indicating
the type of alarm. The alarm is terminated automatically as soon as the ratio is within its range
again.
Display total:
The actual total quantity of each flowmeter is shown after pressing select several times.
Clear total:
The value for total can be reset. To do so, press the CLEAR/key twice. When the key is
pressed once, the text "PUSH CLEAR" is shown. To avoid a reset at this stage, press another
key other than the CLEAR/key or wait for 20 seconds. A reset of the total does not influence
the accumulated total.
Low battery alarm
Only use original batteries. Original batteries can be ordered at the manufacturer.
The use of unapproved batteries will void the warranty.

At the end of the battery’s life-time, the
voltage starts to drop. When the voltage
becomes too low, the battery indicator
comes on. When the battery indicator is
on, install a new and fresh battery as
soon as possible.
Fig. 5: Low-battery alarm (typical)
Alarm
When the alarm indicator is shown, refer to Appendix B: Problem Solving.
RUN RUN
RUN

FW_F114P_v1702_02_EN
Page 9
3. CONFIGURATION
This and the following chapters are exclusively meant for electricians and non-operators. In these,
an extensive description of all software settings and hardware connections are provided.
Mounting, electrical installation, start-up and maintenance of this device may only be
carried out by trained persons authorized by the operator of the facility. Persons must
read and understand this manual before carrying out its instructions.
This device may only be operated by persons who are authorized and trained by the
operator of the facility. All instructions in this manual are to be observed.
Make sure, the measuring system is correctly wired up according to the wiring diagrams.
Protection against accidental contact is no longer assured when the housing cover is
removed or the panel cabinet has been opened (danger from electrical shock). The
housing may only be opened by trained persons authorized by the operator of the facility.
Take careful notice of the "Safety rules, instructions and precautionary measures" in the
front of this manual.
The setup menu is used to program the F114-P.
The setup menu is accessible at all times while the F114-P remains fully operational. Be aware that
in this case any change to the settings may have an influence on the operation.
It is possible to prevent access to the setup menu with a password. A password may be
required to enter the setup menu. Without this password, access is denied.
3.1. HOW TO PROGRAM THE F114-P
The setup menu has different
submenus. Each submenu has an
unique number which is shown in
front of the menu name.
Each setting has an unique two-
digit number which is shown in
front of the setting. The first digit
refers to the submenu and the
second digit refers to the setting.
Note that sometimes the name of
the setting is shown on the upper
line of the display.
How to enter the setup menu
When the setup menu is protected by a password, the F114-P asks for a password to access the
setup menu. When in the operator mode, press and hold the PROG/ENTER key for 7 seconds to
access the setup menu.
How to navigate in the setup menu
The setup menu has different submenus to program the F114-P. For navigation, the submenus
and the settings are identified with numbers (for the submenu: e.g. 1; for the setting: e.g. 12.).
The CLEAR/key and the PROG/ENTER key are used for navigation. The explanation
assumes that you are in the submenu TOTAL.
Action
Result
Remark
1
Press the CLEAR/key to
select the next submenu.
The submenu FLOW
RATE shows
-
2
Press again to go to the
next submenu.
The submenu DISPLAY
shows.
-
3
Momentarily, press the
PROG/ENTER key to
select the previous
submenu.
The submenu FLOW
RATE shows
The PROG/ENTER key is
used as a ◄key.
4
Press again to go to the
previous submenu.
The submenu TOTAL
shows
The PROG/ENTER key is
used as a ◄key.

FW_F114P_v1702_02_EN
Page 10
The SELECT/key and the CLEAR/key are used for navigation.
The explanation assumes that you are in the submenu TOTAL. When you are:
in the first setting and you navigate to the previous setting, the F114-P goes back to the related
main menu.
in the last setting and you navigate to the next setting, the F114-P goes to the related main
menu.
Action
Result
Remark
1
Press the SELECT/key
to select the first setting.
The setting UNIT shows.
-
2
Press the SELECT/key
again to go to the next
setting.
The setting DECIMALS
shows.
-
3
Press the CLEAR/key to
select the previous setting.
The setting UNIT shows.
-
4
Press the CLEAR/key
again to go to the previous
setting.
The submenu TOTAL
shows
This is normal behavior
because the setting UNIT is
the first setting of the
submenu TOTAL.
How to make a setting
Changes are only saved when you press the PROG/ENTER key.
The explanation assumes that you are in the submenu TOTAL and the setting UNIT. When you do
not want to save the change, wait for approximately 20 seconds or press and hold the
PROG/ENTER key for approximately 3 seconds.
Action
Result
Remark
1
Momentarily, press the
PROG/ENTER key.
The PROG indicator blinks.
The engineering unit L shows.
To access the setting.
2
Press the SELECT/key to
select the next engineering
unit.
The PROG indicator blinks.
The engineering unit m3shows.
If you wait too long, the
program mode goes off and
changes are not saved, this
is normal behavior.
3
Press the SELECT/key to
select the next engineering
unit.
The PROG indicator blinks.
The engineering unit US GAL
shows.
-
4
Press the CLEAR/key to
select the previous
engineering unit
The PROG indicator blinks.
The engineering unit m3shows.
-
5
To confirm the changes:
Momentarily, press the
PROG/ENTER key.
The PROG indicator goes off.
The change is saved.
The engineering unit m3shows.
If you do not press the
PROG/ENTER key to
confirm, your selection is not
saved.
To discard the changes:
Press and hold the
PROG/ENTER key for
approximately 3 seconds.
The PROG indicator goes off.
The change is discarded.
The engineering unit L shows.
-

FW_F114P_v1702_02_EN
Page 11
3.1.1. SETUP MENU - SETTINGS
1
TOTAL A
11
unit
L; m3; kg; lb; GAL; USGAL; bbl; no unit
12
decimals
0000000; 111111.1; 22222.22; 3333.333
13
K-factor:
0.000010 - 9999999
14
decimals K-factor
0 - 6
2
FLOW RATE A
21
unit
mL; L; m3; mg; g; kg; ton; gal; bbl; lb; cf; rev; - - - - (no unit); scf; nm3;
nL; p
22
time
/sec; /min; /hour; /day
23
decimals
0000000; 111111.1; 22222.22; 3333.333
24
K-factor
0.000010 - 9,999,999
25
decimals K-factor
0 - 6
26
period
0.1 - 99.9 seconds
3
TOTAL B
31
K-Factor
0.000010 - 9999999
32
decimals K-Factor
0 - 6
4
FLOW RATE B
41
K-Factor
0.000010 - 9999999
42
decimals K-Factor
0 - 6
5
RATIO
51
ratio
b/a; b/a+b;- b-a/a;- b-a/b;- b/a-b
52
function
1:_ - percentage
53
decimals
0000000; 111111.1; 22222.22; 3333.333
54
filter
0 - 99
6
ALARM
61
flowzero
default; no relay; ignore
62
ratio ll
0000.000 - 9999999
63
ratio lo
0000.000 - 9999999
64
ratio hi
0000.000 - 9999999
65
ratio hh
0000.000 - 9999999
66
delay ll
0.1 - 999.9
67
delay lo
0.1 - 999.9
68
delay hi
0.1 - 999.9
69
delay hh
0.1 - 999.9
7
DISPLAY
71
function
disabled; rate; total; both
72
alarm set
operate; setup; hidden; disabled
73
light
0% (off); 20%; 40%; 60%;- 80%; 100% (full brightness)
74
bl alarm
off; on; flash
8
POWER MANAGEMENT
81
LCD new
fast; 1 sec; 3 sec; 15 sec; 30 sec; off
82
battery mode
operational; shelf
9
FLOWMETER
91
signal A
npn; npn-lp; reed; reed-lp; pnp; pnp-lp; namur; coil-hi; coil-lo; 8-1 DC;
12 DC; 24 DC
92
signal B
npn; npn-lp; reed; reed-lp; pnp; pnp-lp; namur; coil-hi; coil-lo; 8-1 DC;
12 DC; 24 DC
A
ANALOG
A1
output
disable; enable
A2
output select
ratio; flow A; flow B
A3
ana-min
00000.00 –999.99
A4
ana-max
00000.00 –999.99
A5
cut-off
0.0 - 9.9%
A6
tune-min
0 - 9999
A7
tune-max
0 - 9999
A8
filter
00 - 99
B
RELAYS
B1
relay 1
off; lo-lo; lo; hi; hi-hi; all
B2
relay 2
off; lo-lo; lo; hi; hi-hi; all
B3
relay 3
off; lo-lo; lo; hi; hi-hi; all
B4
relay 4
off; lo-lo; lo; hi; hi-hi; all

FW_F114P_v1702_02_EN
Page 12
C
COM-MODB
C1
speed
1200; 2400; 4800; 9600; 9600HP; 19200; 38400
C2
address
1 –247
C3
mode
bus-rtu; bus-asc; off
C4
databits
8 bits; 7 bits
C5
parity
none; even; odd
D
OTHERS
D1
model
F114-P
D2
software version
nn:nn:nn
D3
serial no.
nnnnnnn
D4
password
0000 - 9999
D5
tag-nr
0000000 - 9999999
3.1.2 EXPLANATION OF SETUP-MENU 1 - TOTAL-A
UNIT
11
This setting is used to select the engineering unit for the indication of the
differential total, total (A and B), the accumulated total (A and B), and the pulse
output.
When you change the engineering unit, you must recalculate and
reprogram the K-factor for the (accumulated) total. When you
recalculate and reprogram the K-Factor, the history for
(accumulated) total is not correct anymore, because the
(accumulated) total is not recalculated. For future reference, best
practice is to make a note of the accumulated total before you
program the recalculated K-Factor.
DECIMALS
12
This setting is used to set the amount of digits behind the decimal point for the
(accumulated) total indication (A and B).
K-FACTOR
13
The K-Factor A determines the calculation factor for the forward total !
This setting is used to set the K-Factor for the total (A). With the K-Factor, the
flowmeter pulse signals are converted to a quantity. The K-Factor is based on the
number of pulses generated by the flowmeter per selected engineering unit, for
example per m3. A more accurate K-Factor (more decimals, as set in decimals
K-Factor) allows for a more accurate operation of the system.
Example 1: Calculating the K-Factor.
The flowmeter generates 2.4813 pulses per liter and the selected unit is m3. A
cubic meter consists of 1000 liter which gives 2.4813 pulses*1000 liter=2481.3
pulses per m3. So, the K-Factor is 2481.3. Enter for the Flowmeter K-Factor:
24813 and for the flowmeter K-Factor decimals: 1.
Example 2: Calculating the K-Factor.
The flowmeter generates 6.5231 pulses per gallon and the selected engineering
unit is gallons. So, the K-Factor is 6.5231. Enter for the Flowmeter K-Factor:
65231 and for the Flowmeter K-Factor decimals: 4.
When you recalculate and reprogram a new K-Factor, the history for
(accumulated) total is not correct anymore, because the
(accumulated) total is not recalculated. For future reference, best
practice is to make a note of the accumulated total before you
program the recalculated K-Factor.
DECIMALS K-FACTOR
14
This setting is used to set the amount of digits behind the decimal point for the
K-Factor (A).
3.1.3 EXPLANATION OF SETUP-MENU 2 - FLOW RATE-A
The settings for total and flow rate are entirely separate. In this way, different engineering units can
be used for each e.g. cubic meters for total and liters for flow rate.
UNIT
21
This setting is used to select the engineering unit for the indication of the flow rate
(A and B).
Alteration of the engineering unit will have consequences for
operator and setup values, they will not be automatically
recalculated to the value of the new selected unit. The K-Factor has
to be adapted as well; the calculation is not done automatically.

FW_F114P_v1702_02_EN
Page 13
TIME
22
This setting is used to set the time unit for the flow rate calculation (A and B). Note
that the flow rate is given in engineering unit/time unit, e.g. liters/minute (l/min).
When you change this setting, also recalculate and change the settings
for the analog rate-min and analog rate-max.
DECIMALS
23
This setting is used to set the amount of digits behind the decimal point for the
flow rate indication (A and B).
K-FACTOR
24
This setting is used to set the K-Factor for the flow rate (A). With the K-Factor, the
flowmeter pulse signals are converted to a quantity. The K-Factor is based on the
number of pulses generated by the flowmeter per selected engineering unit, for
example per m3. A more accurate K-Factor (more decimals, as set in decimals
K-Factor) allows for a more accurate operation of the system.
DECIMALS K-FACTOR
25
This setting is used to set the amount of digits behind the decimal point for the
K-Factor (A).
Period
26
This setting is used to calculate the flow rate by counting the number of pulses
within a certain time, for example 1 second. The longer the time the more
accurate the flow rate will be.
This setting does influence the update time for the analog output directly. If the
output response is too slow, decrease the number of pulses.
The shorter the update time, the higher the power consumption of the unit will
be (important for battery powered applications).
3.1.4 EXPLANATION OF SETUP-MENU 3 - TOTAL-B
For Total, you can only set the K-Factor B when in the flowmeter menu the K-Factor is set to Dual.
Per default setting, the K-Factor is set to single (K-Factor A = K-Factor B). When Dual is selected,
the Total-B settings are not visible (editable). This is normal behavior.
K-FACTOR
31
K-Factor B determines the calculation factor for the reverse total !
This setting is used to set the K-Factor for the total (B). With the K-Factor,
the flowmeter pulse signals are converted to a quantity. The K-Factor is
based on the number of pulses generated by the flowmeter per selected
engineering unit, for example per m3. A more accurate K-Factor (more
decimals, as set in decimals K-Factor) allows for a more accurate
operation of the system.
DECIMALS K-FACTOR
32
This setting is used to set the amount of digits behind the decimal point for the
(accumulated) total indication (B).
3.1.5 EXPLANATION OF SETUP-MENU 4 - FLOW RATE-B
For Flow rate, you can only set the K-Factor B when in the flowmeter menu the K-Factor is set to
Dual. Per default setting, the K-Factor is set to single (K-Factor B = K-Factor A). When Dual is
selected, the Total-B settings are not visible (editable). This is normal behavior.
K-FACTOR
41
K-Factor B determines the calculation factor for the reverse flow rate !
This setting is used to set the K-Factor for the flow rate (B). With the K-
Factor, the flowmeter pulse signals are converted to a quantity. The K-
Factor is based on the number of pulses generated by the flowmeter per
selected engineering unit, for example per m3. A more accurate K-Factor
(more decimals, as set in decimals K-Factor) allows for a more accurate
operation of the system.
DECIMALS K-FACTOR
42
This setting is used to set the amount of digits behind the decimal point for the
K-Factor (B).
3.1.6 EXPLANATION OF SETUP-MENU 5 - RATIO
The definition of the ratio shown is set with this function. The ratio can be expressed as:
1) the flow rate of the "additive flow"
compared to the flow rate of the "main flow", or as
2) the flow rate of the "additive flow"
compared to the flow rate of the "total flow"
Further, it is necessary to take the position of flowmeter "A" and flowmeter "B" into account.With the
K-factor, the flowmeter pulse signals are converted to a flow rate.

FW_F114P_v1702_02_EN
Page 14
RATIO
51
The ratio is shown as a percentage (PCT) or a ratio as 1-____.
This setting also influences the analog output refl. the ratio.
FUNCTION
52
The ratio or percentage will be shown with maximum of five digits:
1 : xxxxx or 99999%.
If you have a ratio of 1:5 than two or three decimals might be required.
If you have a ratio of 1:1000, than you might prefer no decimals.
If you have a ratio of 2% than two or three decimals might be required.
If you have a ratio of 120%, than you might prefer no decimals.
DECIMALS
53
This setting is used to set the amount of digits behind the decimal point for
the ratio.
FILTER
54
This setting is used to stabilize the calculated ratio between both flows. With the
help of this digital filter a more stable but less actual representation of the flow rate
can be obtained.
The filter principal is based on three input values: the filter level (01-99), the last
calculated flow rate and the last average value. The higher the filter level, the longer
the response time on a value change will be..
3.1.7 EXPLANATION OF SETUP-MENU 6 - ALARM
These settings determine how the flow rate is monitored and how the F114-P will process the alarm
conditions. For the setup of the configurable outputs, refer to setup menu: Relays.
FLOWZERO
61
When the flow rate is zero, then it is possible to ignore or disable the flow
rate monitoring. The following settings can be selected:
DEFAULT: in case of a low-flow rate alarm and zero flow, it will switch the
alarm output and indicate the alarm on the display.
NO RELAY: in case of a low-flow rate alarm and zero flow, it won't switch
the alarm output but will indicate the alarm on the display only.
IGNORE: in case of a low-flow rate alarm and zero flow, it won't switch
the alarm output and nothing will be indicated on the display.
RATIO LL
62
This setting is used to activate the related alarm condition and to set the
threshold value for a this ratio alarm. The setting 0.0 disables this alarm.
RATIO LO
63
This submenu is used to activate the related alarm condition and to set the
threshold value for a this ratio alarm. The setting 0.0 disables this alarm.
RATIO HI
64
This setting is used to activate the related alarm condition and to set the
threshold value for a this ratio alarm. The setting 0.0 disables this alarm.
RATIO HH
65
This setting is used to activate the related alarm condition and to set the
threshold value for a this ratio alarm. The setting 0.0 disables this alarm.
DELAY LL
66
This setting is used to set a delay time for the related alarm. When the alarm
condition is still valid after the delay time, an alarm is given.
DELAY LO
67
This setting is used to set a delay time for the related alarm. When the alarm
condition is still valid after the delay time, an alarm is given.
DELAY HI
68
This setting is used to set a delay time for the related alarm. When the alarm
condition is still valid after the delay time, an alarm is given.
DELAY HH
69
This setting is used to set a delay time for the related alarm. When the alarm
condition is still valid after the delay time, an alarm is given.

FW_F114P_v1702_02_EN
Page 15
3.1.8. EXPLANATION OF SETUP MENU 7 - DISPLAY
FUNCTION
71
Additionally to the ratio, the flow rate and a resettable totalizer of channel
A and channel B can be shown. Following can be selected:
disabled: total and flow rate will not be shown.
rate: only flow rate A and B will be shown
total: only total A and B will be shown.
both: all flow rates and totals will be shown.
ALARM SET
72
This setting is used to determine in which menu you can change the
alarm settings. When programmed for setup menu only, the alarm
settings in the operator menu are read-only.
LIGHT
73
The backlight brightness can be adjusted from 0% (off) to 100% (full
brightness) in steps of 20%.
When the F114-P is only loop powered, the backlight is disabled. An
external power supply is required to supply the backlight.
BL ALARM
74
This setting is used to set the behavior of the backlight (bl) during an alarm
condition.
3.1.9 EXPLANATION OF SETUP-MENU 8 - POWER MANAGEMENT
When used with the internal battery option (type PB/PC), the user can expect reliable measurement over a long
period of time. The F114-P has several smart power management functions to extend the battery life time
significantly. Two of these functions can be set.
LCD NEW
81
The calculation of the display-information influences the power consumption
significantly. When the application does not require a fast display refresh rate, it is
strongly advised to select a slow refresh rate. Please understand that NO
information will be lost; every pulse will be counted and the output signals will be
generated in the normal way.
At a key press, the display refresh rate will switch to FAST for 30 seconds. When
'OFF' is selected, the display goes off after 30 seconds after the last key press.
The display temporarily comes on after a key press.
Example battery life-time with a coil pick-up:
1kHz pulse and FAST update: about 2 years;
1kHz pulse and 1 sec update: about 5 years.
BATTERY-MODE
82
The F114-P has two modes: operational or shelf.
After "shelf" has been selected, the F114-P can be stored for several years; it will
not process the sensor signal; the display is switched off but all settings and totals
are stored. In this mode, power consumption is extremely low.
To wake up the F114-P again, press the SELECT/key two times.
3.1.10 EXPLANATION OF SETUP-MENU 9 - FLOWMETER
The F114-P is able to handle several types of input signal. The pickup / signal is selected with:
SETUP 91 (Input A), Read also chapter 4
SETUP 92 (Input B), Read also chapter 4.
The selections "active pulse" offer a detection level of 50% of the supply voltage.
SIGNAL A
91
TYPE OF SIGNAL
EXPLANATION
RESISTANCE
FREQ./MV
REMARK
NPN
NPN input
100 kΩ pull-up
max.6 kHz.
(open collector)
NPN - LP
NPN with low pass filter
100 kΩ pull-up
max.1.2 kHz.
(open collector)
less sensitive
REED
Reed-switch input
1 MΩ pull-up
max.1.2 kHz.
REED - LP
Reed-with low pass filter
1 MΩ pull-up
max.120 Hz.
Less sensitive
PNP
PNP input
100K pull-down
max.6 kHz.
PNP - LP
PNP with low pass filter
100K pull-down
max.1.2 kHz.
Less sensitive

FW_F114P_v1702_02_EN
Page 16
NAMUR
NAMUR input
820 Ω pull-down
max.4 kHz.
External power
required
COIL-HI
High sensitive coil input
-
min. 20 mVpp
Sensitive for
interference!
COIL-HI (type ZF)
min. 10 mVpp
COIL-HI (type ZG)
min. 5 mVpp
COIL LO
Low sensitive coil input
-
min. 80 mVpp
Normal
sensitivity
8-1 DC
Active pulse input
detection level 8.2V DC
3K9
max.10KHz.
External power
required
12 DC
Active pulse input
detection level 12V DC
4K
max.10KHz.
External power
required
24 DC
Active pulse input
detection level 24V DC
3K
max.10KHz.
External power
required
SIGNAL B
92
The secondary signal B is used to detect the direction of flow.
In most applications, the type of signal for input B will be the same type as
the main signal A (setting 71). For selection, read setting 71.
3.1.11 EXPLANATION OF SETUP-MENU A - ANALOG OUTPUT
A linear 4-20mA signal (option AB: 0-20mA or option AU: 0-10V) output signal is generated that
represents the flow rate. The settings for the flow rate influence the analog output directly. The
relationship between the flow rate and the analog output is set with the following settings.
OUTPUT
A1
If the analog output is not used, select disable to minimize the power consumption
(e.g. save battery life-time).
Option AP: When a power supply is available but the output is disabled, a 3.5mA
signal will be generated.
OUTPUT SELECTION
A2
This setting determines if the analog output is according the actual ratio,
flow rate A or flow rate B.
ANA-MIN
A3
Enter here the flow rate at which the output should generate the minimum signal
(0)4mA or 0V - in most applications at zero flow. The number of decimals shown
depend upon setup 23. The engineering units/time (e.g. L/min) are dependent upon
setup 21 and 22.
ANA-MAX
A4
Enter here the flow rate at which the output should generate the maximum signal
(20mA or 10V) - in most applications at maximum flow. The number of decimals
shown depend upon setup 23. The engineering units/time (e.g. L/min) are dependent
upon setup 21 and 22.
CUT-OFF
A5
To ignore leakage of the flow for example, a low flow cut-off can be set as a
percentage of the full range of 16mA, 20mA or 10V.
When the flow is less than the required rate, the current will be the minimum signal
(0)4mA or 0V.
Example: Calculate the cut-off.
Rate-min: 0L/min [4mA], Rate-max: 100 L/min [16mA], Cut-off: 2%
Required rate [L/min]: (rate-max - rate-min)*cut-off: (100-0)*2%=2.0L/min
Output [mA]: rate-min + (rate-max*cut-off): 4+(16*2%)=4.32mA
TUNE-MIN
A6
The (0)4mA or 0V value can be tuned precisely with this setting. The initial minimum
analog output value is (0)4mA or 0V. However, this value might differ slightly due to
ambient influences such as temperature for example.
Before tuning the signal, make sure that the analog signal is idle (not used) for
any application!
After pressing PROG, the current will be about 4mA (0mA or 0V). The current can be
increased / decreased with the arrow keys and is directly active. Press ENTER to
store the new value.
If required, you can program the analog output 'up-side-down'. The (0)4mA or 0V
represents the maximum flow rate and the 20mA or 10V represents the minimum
flow rate.

FW_F114P_v1702_02_EN
Page 17
TUNE-MAX
A7
The 20mA or 10V value can be tuned precisely with this setting. The initial maximum
analog output value is 20mA or 10V However, this value might differ slightly due to
ambient influences such as temperature for example.
Before tuning the signal, make sure that the analog signal is idle (not used) for
any application!
After pressing PROG, the current will be about 20mA or 10V. The current can be
increased / decreased with the arrow keys and is directly active. Press ENTER to
store the new value.
If required, you can program the analog output 'up-side-down'. The (0)4mA or 0V
represents the maximum flow rate and the 20mA or 10V represents the minimum
flow rate.
FILTER
A8
This setting is used to stabilize the output signal. With the help of this digital filter a
more stable but less actual representation of the flow rate can be obtained.
The filter principal is based on three input values: the filter level (01-99), the last
calculated flow rate and the last average value. The higher the filter level, the longer
the response time on a value change will be.
3.1.12. EXPLANATION OF SETUP MENU B - RELAYS
The outputs are configurable, they can be set to a specific alarm output.
There are four outputs in the submenu, but the amount of outputs can vary due to regulations
or chosen options. Standard, there are three outputs, option XI has only two outputs and
option OS has four outputs.
RELAY 1
B1
This setting is used to set the function of related output R1..
RELAY 2
B2
This setting is used to set the function of related output R2.
RELAY 3
B3
Not available for type: XI:
This submenu is used to set the function of related output R2.
RELAY 4
B4
Only available for option OS: This submenu is used to set the function of
related output R4.
3.1.13 EXPLANATION OF SETUP-MENU C - COMMUNICATION (OPTION)
This product is designed for the connection to a communication network. Products with a
communication option do not include cyber security functions. Fluidwell cannot take any
responsibility for the cyber security, omissions or errors in the communication safety. To maintain a
secure operation, automation and control, it is the sole responsibility of the owner to install and
manage the appropriate safety measures to protect the network, the product and the communication
against any kind of security breaches.
The functions described below deal with hardware that is not part of the standard delivery.
Programming of these functions does not have any effect if this hardware has not been installed.
Consult Appendix C and the Modbus communication protocol description for a detailed explanation.
SPEED
C1
This setting is used to set the Baudrate.
9600 is a low power setting, 9600HP is a high power setting (Modbus compliant).
ADDRESS
C2
This setting is used to set the communication address for the F114-P.
MODE
C3
This setting is used to set the Modbus transmission mode. Select OFF to disable
the communication.
DATABITS
C4
This setting determines for communication the number of data bits.
Select 8 bit for BUS-RTU and 7 bits for BUS-ASC.
PARITY
C5
As demanded by the connected equipment, select a parity bit (odd, even or none).

FW_F114P_v1702_02_EN
Page 18
3.1.14 EXPLANATION OF SETUP-MENU D - OTHERS
For support and maintenance it is important to have information about the characteristics of the F114-P. Your
supplier will ask for this information when support is required.
MODEL
D1
This setting shows the model name.
SOFTWARE VERSION
D2
This setting shows the version number of the firmware (software).
SERIAL NO.
D3
This setting shows the serial number.
PASSWORD
D4
This setting is used to set a password (pin code) to limit the access for the setup
menu. Only persons who know the pin code can access the setup menu. The pin
code 0000 disables the pin code to allow for access by any person.
TAG-NR
D5
This setting is used to set a tag number for the F114-P.
4. INSTALLATION
4.1. GENERAL DIRECTIONS
Mounting, electrical installation, start-up and maintenance of this device may only be
carried out by trained persons authorized by the operator of the facility. Persons must
read and understand this manual before carrying out its instructions.
This device may only be operated by persons who are authorized and trained by the
operator of the facility. All instructions in this manual are to be observed.
Make sure, the measuring system is correctly wired up according to the wiring diagrams.
Protection against accidental contact is no longer assured when the housing cover is
removed or the panel cabinet has been opened (danger from electrical shock). The
housing may only be opened by trained persons authorized by the operator of the facility.
Take careful notice of the "Safety rules, instructions and precautionary measures" at the
front of this manual.
4.2. INSTALLATION - SURROUNDING CONDITIONS
Take the relevant IP classification of the
enclosure into account (see identification plate).
Even an enclosure rated for IP67 / TYPE 4(X)
should NEVER be exposed to strongly varying
(weather) conditions.
When panel-mounted, the front panel of the
F114-P is rated for IP65 / TYPE 4(X)!
When used in very cold surroundings or varying
climatic conditions, inside the instrument case,
take the necessary precautions against moisture.
Mount the F114-P onto a solid structure to avoid
vibrations.

FW_F114P_v1702_02_EN
Page 19
4.3. DIMENSIONS- ENCLOSURE
Fig. 6: Aluminum enclosures - Dimensions
75 mm (2.95")
130 mm (5.12") 112 mm (4.40")
120mm(4.72”)
M20 x 1,5
PG9 PG9
30mm 30mm
M20 x 1,5
M16 x 1,5 M16 x 1,5
30mm 30mm
M20 x 1,5
M20 x 1,5 M20 x 1,5
25mm 25mm
1/2"NPT
0.9”
3x 1/2"NPT
0.12" 0.12"
HA
HM
HN
HO
HP
HT
HU
6 x M12
12mm 12mm
24mm24mm
36mm
36mm
14mm17mm
115 mm (4.53”)
HB
29.1 mm (1.15”)
31 mm
(1.22”)
HZ
4x M20 x 1,5
15 15
HV
2323
16
mm
1/2"NPT 1/2"NPT
25mm 25mm
22,5mm
HL
22,5mm22,5mm22,5mm22,5mm
0.9”
15
60mm(2.36”)
98mm(3.86”)

FW_F114P_v1702_02_EN
Page 20
Fig. 7: GRP enclosures - Dimensions
75 mm (2.95")
130 mm (5.12") 112 mm (4.40")
60 mm (2.36")
120 mm (4.72")
HD
HK
HK back box:
(flat bottom)
HE
HF
HG
HH
D=12mm
12mm 12mm
24mm24mm
36mm
36mm
14mm 17mm
22,5mm
30mm 30mm
D=16mm
D=20mm
0.9"
D=22mm (0.866")
22,5mm
25mm 25mm
D=20mm D=20mm
D=16mm
HC
75 mm (2.95") 118 mm (4.65”)
104 mm (4.09”)
HJ
0.9”
0.12” 0.12”
3x D=22mm (0.866”)
115 mm (4.53”)
98 mm (3.86”)
29.1 mm (1.15”)
31 mm
(1.22”)
