Fluidwell F118-p User manual

F118-P

FLOW RATE MONITOR / TOTALIZER

WITH LINEARIZATION AND HIGH / LOW ALARMS

Signal input flowmeter: pulse, Namur and coil.

Signal outputs: (0)4-20mA / 0-10V ref. flow rate and pulse ref. total.

Alarm outputs: maximum three flow rate alarms

Options: Intrinsically Safe, Modbus communication

F-Series - Field mounted indicators for safe and hazardous areas.

More info: www.fluidwell.com/fseries

FW_F118P_v1901_02_EN.docx

Page 2

SAFETY INSTRUCTIONS

▪Any responsibility is lapsed if the instructions and procedures as described in this

manual are not followed.

▪LIFE SUPPORT APPLICATIONS: The F118-P is not designed for use in life support

appliances, devices, or systems where malfunction of the product can reasonably be

expected to result in a personal injury. Customers using or selling these products for

use in such applications do so at their own risk and agree to fully indemnify the

manufacturer and supplier for any damages resulting from such improper use or sale.

▪Electro static discharge does inflict irreparable damage to electronics! Before installing

or opening the unit, the installer has to discharge himself by touching a well-grounded

object.

▪This unit must be installed in accordance with the EMC guidelines (Electro Magnetic

Compatibility).

▪Do connect a proper grounding to the metal enclosure as indicated if the F118-P has an

incoming power line which carries a 115-230V AC. The Protective Earth (PE) wire may

never be disconnected or removed.

▪Intrinsically safe applications: follow the instructions as mentioned in Chapter 5 and

consult “Fluidwell F1..-..-XI - Documentation for Intrinsic safety”.

DISPOSAL OF ELECTRONIC WASTE

•The WEEE Directive requires the recycling of disposed electrical and electronic equipment in the

European Union. When the WEEE Directive does not apply to your region, we support its policy

and ask you to be aware on how to dispose of this product.

•The crossed out wheelie bin symbol as illustrated and found on our products tells that this

product shall not be disposed of into the general waste system or into a landfill.

•At the end of its life, equipment shall be disposed of according to the local regulations regarding

waste of the electrical and the electronic equipment.

•Please contact your local dealer, national distributor or the manufacturer’s Technical helpdesk for

information on the product disposal.

SAFETY RULES AND PRECAUTIONARY MEASURES

▪The manufacturer accepts no responsibility whatsoever if the following safety rules and

precautions instructions and the procedures as described in this manual are not followed.

▪Modifications of the F118-P implemented without preceding written consent from the

manufacturer, will result in the immediate termination of product liability and warranty period.

▪Mounting, electrical installation, start-up and maintenance of this device may only be carried out

by trained persons authorized by the operator of the facility. Persons must read and understand

this manual before carrying out its instructions.

▪This device may only be operated by persons who are authorized and trained by the operator of

the facility. All instructions in this manual are to be observed.

▪Check the mains voltage and information on the manufacturer's plate before installing the unit.

▪Check all connections, settings and technical specifications of the various peripheral devices

with the F118-P supplied.

▪Open the enclosure only if all leads are free of potential.

▪Never touch the electronic components (ESD sensitivity).

▪Never expose the system to heavier conditions than allowed according the classification of the

enclosure (see manufacture's plate and chapter 4).

▪If the operator detects errors or dangers, or disagrees with the safety precautions taken, then

inform the owner or principal responsible.

▪The local labor and safety laws and regulations must be adhered to.

FW_F118P_v1901_02_EN.docx

Page 3

ABOUT THE MANUAL

This manual is divided into two main sections:

▪The daily use of the unit is described in chapter 2 "Operation". These instructions are meant for

users.

▪The following chapters and appendices are exclusively meant for electricians/technicians. These

provide a detailed description of all software settings and hardware installation guidance.

This manual describes the standard unit as well as the available options. For additional information,

please contact your supplier.

A hazardous situation may occur if the F118-P is not used for the purpose it was designed for

or is used incorrectly. Please carefully note the information in this manual indicated by the

pictograms:

A "warning !" indicates actions or procedures which, if not performed correctly, may lead to

personal injury, a safety hazard or damage of the F118-P or connected instruments.

A "caution !" indicates actions or procedures which, if not performed correctly, may lead to

personal injury or incorrect functioning of the F118-P or connected instruments.

A "note !" indicates actions or procedures which, if not performed correctly, may indirectly

affect operation or may lead to an instrument response which is not planned.

WARRANTY AND TECHNICAL SUPPORT

For warranty and technical support for your Fluidwell products,

visit our internet site www.fluidwell.com or contact us at support@fluidwell.com.

Hardware version : 03.01.xx

Software version : 03.01.xx

Manual : FW_F118P_v1901_02_EN.docx

Information in this manual is subject to change without prior notice. The

manufacturer is not responsible for mistakes in this material or for incidental

damage caused as a direct or indirect result of the delivery, performance or

use of this material.

in any form or by any means without written permission of your supplier.


FW_F118P_v1901_02_EN.docx
Page 4
CONTENTS MANUAL
Safety instructions ................................................................................................................................2
Disposal of electronic waste.................................................................................................................2
Safety rules and precautionary measures............................................................................................2
About the manual..................................................................................................................................3
Warranty and technical support............................................................................................................3
Contents manual...................................................................................................................................4
Introduction ..............................................................................................................................5
1. System description 5
Operational ..............................................................................................................................6
1. Control panel 6
3. Operator information and functions 6
Configuration............................................................................................................................8
1. How to program the F118-P 8
1.1. Setup menu - Settings 10
1.2. Explanation of Setup menu 1 - Total 11
1.3. Explanation of Setup menu 2 - Flow rate 11
1.4. Explanation of Setup menu 3 - Alarm 12
1.5. Explanation of Setup menu 4 - Display 12
1.6. Explanation of Setup menu 5 - Power management 13
1.7. Explanation of Setup menu 6 - Flowmeter 13
1.7. Explanation of Setup menu 7 - Linearize 13
1.8. Explanation of Setup menu 8 - Analog output 14
1.9. Explanation of Setup menu 9 - Relays 16
1.10. Explanation of Setup menu A - Communication (option) 16
1.11. Explanation of Setup menu B - Others 16
Installation..............................................................................................................................17
1. General directions 17
2. Installation / surrounding conditions 17
3. Dimensions- Enclosure 18
4. Installing the hardware 20
4.1. General installation guidelines 20
4.2. Protective Earth (PE) connections 21
4.3. Aluminum enclosure - Field mounted 22
4.4. Aluminum enclosure - Panel mounted 22
4.5. Plastic (GRP) enclosure 23
4.6. Terminal connectors 24
4.7. Sensor supply 24
Intrinsically safe applications .................................................................................................31
1. General information and instructions 31
1. Terminal connectors Intrinsic safe applications 33
2 Configuration Examples 35
3 Battery replacement instructions 37
3.1. Safety instructions 37
3.2. Replace the battery (hazardous area) 37
3.3. Disposal of batteries 37
Maintenance ..........................................................................................................................38
1. General directions 38
2. Repair 38
3. Repair policy 38
Appendix A: Technical specification.........................................................................................39
Appendix B: Problem solving ...................................................................................................42
Appendix C: Communication variables ....................................................................................43
Appendix D. Declaration of Conformity ....................................................................................47
Index of this manual............................................................................................................................48
List of figures in this manual...............................................................................................................49


FW_F118P_v1901_02_EN.docx

Page 5

1. INTRODUCTION

1.1. SYSTEM DESCRIPTION

Functions and features

The flow rate monitor / totalizer, model F118-P is a microprocessor driven instrument designed to

linearize the flowmeters flow curve and to show the flow rate, the total and the accumulated total.

This product has been designed with a focus on:

▪ultra-low power consumption to allow long-life battery powered applications (type PB/PC),

▪intrinsic safety for use in hazardous applications (type XI);

▪several mounting possibilities with aluminum or GRP enclosures for harsh industrial

surroundings;

▪ability to process all types of flowmeter signals;

▪transmitting possibilities with analog / pulse and communication outputs.

Flowmeter input

This manual describes the unit with a pulse input from the flowmeter. Other versions are available to

process (0)4-20mA signals.

One flowmeter with a passive or active pulse, Namur or sine wave (coil) signal output can be

connected to the F118-P. To power the sensor, several options are available.

Standard outputs

▪Max. three configurable alarm / pulse outputs: flow rate alarm, high- or low-flow rate alarm. Switched

as long as the flow rate is too high or too low.

▪Pulse output to transmit a pulse that represents a linearized totalized quantity as programmed.

▪Linear (0)4-20mA or 0-10V analog output to represent the actual, linearized, flow rate as

programmed. The (0)4-20mA or 0-10V signal limits can be tuned.

Fig. 1: typical application

Configuration of the unit

The F118-P is designed for use in many types of applications. For that reason, a setup menu is

available to program the F118-P according to your specific requirements.

The setup includes several important features, such as K-Factors, engineering units, signal

selection, power management (to extend battery life-time), etc. All settings are stored in a non-

volatile memory and therefore kept in the event of a power failure or an exhausted battery.

Display information

The unit has a LCD with (optional) backlight to show the process information, status and alarm messages.

The display refresh rate is programmed in the setup menu. At a key press, the display refresh rate will

switch to FAST for 30 seconds. When 'OFF' is selected, the display goes off after 30 seconds after

the last key press. The display temporarily comes on after a key press.

A backup of the total and accumulated total in EEPROM memory is made every minute.

Options

The following options are available: isolated or active (0)4-20mA / 0-10V analog output, full Modbus

communication RS232/485/TTL (also battery powered), intrinsic safety, mechanical relay or active

output, power- and sensor-supply options, panel -mount, wall-mount and weather-proof enclosures,

flame proof enclosure and LED backlight.

FW_F118P_v1901_02_EN.docx

Page 6

2. OPERATIONAL

•This device may only be operated by persons who are authorized and trained by the

operator of the facility. All instructions in this manual are to be observed.

•Take careful notice of the "Safety rules, instructions and precautionary measures" in the

front of this manual.

This chapter describes the daily use of the F118-P. This instruction is meant for users / operators.

2.1. CONTROL PANEL

The control panel has three keys. The available keys are:

Fig. 2: Control Panel

Functions of the keys

This key is used to program and save new values or settings.

The PROG/ENTER key is also used to gain access to the setup menu (read

chapter 3).

This key is used to select the accumulated total.

The SELECT/key is also used to increase a value after the PROG/ENTER key has

been pressed (read chapter 3).

This key is used to reset the total.

The CLEAR/key is also used to select a digit or an option after the PROG/ENTER

key has been pressed read chapter 3).

2.3. OPERATOR INFORMATION AND FUNCTIONS

In general, the F118-P operates in the operator

mode. The shown information depends on the

settings which are made in the setup menu.

The signal from the connected sensor is processed

by the F118-P in the background, independent from

the selected display refresh rate.

Fig. 3: Process information (typical)

For the Operator, the following functions are available:

▪Display flow rate / total or flow rate

This is the main display information of the F118-P. After the selection of any other information, it

will always return to this main display automatically. Total is shown on the upper line of the

display and flow rate on the bottom line. When selected in the setup menu, the display shows the

flow rate only. When you press the select key, the total shows momentarily.

When "-------" is shown, then the flow rate value is too high to be displayed. The arrows 

indicate the increase/decrease of the flow rate trend.

▪Clear total

The value for total can be reset. To do so, press the CLEAR/key twice. When the key is

pressed once, the text "PUSH CLEAR" is shown. To avoid a reset at this stage, press another

key other than the CLEAR/key or wait for 20 seconds. A reset of the total does not influence

the accumulated total.

RUN

FW_F118P_v1901_02_EN.docx

Page 7

▪Display accumulated total

When the SELECT/key is pressed, total and accumulated total are shown. The accumulated

total cannot be reset. The value will count up to 99,999,999,999. The unit and number of

decimals are shown according to the settings for the total.

▪How to program the alarm thresholds

The F118-P can give an alarm message on the display. When set to on, at the same time, the

digital outputs can give a signal for processing by an external device. Note that it is also possible

to set or change the alarm thresholds from the setup menu.

This procedure is applicable to all the alarm thresholds. Only the procedure for ALARM LO is

given. From any operator page, press the SELECT/▲ key, to find the required submenu.

Action

Result

Remark

From any operator page,

press the SELECT/key, to

find the submenu:

ALARM LO.

•The submenu shows:

ALARM LO.

Press the PROG/ENTER key

to access the submenu:

ALARM LO.

•The PROGRAM indicator

blinks continuously.

If you wait too long, the

program mode goes off and

changes are not saved, this

is normal behavior.

Use the SELECT/key to

increase the digit. Use the

CLEAR/key to go to the

next number.

•The PROGRAM indicator

blinks continuously.

•You can select the

required alarm threshold.

The 0 (zero) in front of the

number will not show when

the setting is saved.

The alarm is only shown on

the display. For an alarm on

an external device, set also

the function of the digital

output.

Press the PROG/ENTER key

to confirm the selection.

•The PROGRAM indicator

goes off.

•The selection is saved.

•The display shows the

selected alarm threshold.

If you do not press the

PROG/ENTER key to

confirm, your selection is not

saved.

▪Flow rate alarm

When the actual flow rate is outside the allowed range, the F118-P can give an alarm message

on the display. When set to on, at the same time, the digital outputs can give a signal for

processing by an external device.

The alarm is terminated automatically as soon as the flow rate is within its range again.

▪Low-battery alarm

Only use original batteries. Original batteries can be ordered at the manufacturer.

The use of unapproved batteries will void the warranty.

•

At the end of the battery’s life-time, the

voltage starts to drop. When the voltage

becomes too low, the battery indicator

comes on. When the battery indicator is on,

install a new and fresh battery as soon as

possible.

Fig. 4: Low-battery alarm (typical)

▪Alarm

When the alarm indicator is shown, refer to Appendix B: Problem Solving.

FW_F118P_v1901_02_EN.docx

Page 8

3. CONFIGURATION

This and the following chapters are exclusively meant for electricians and non-operators. In these,

an extensive description of all software settings and hardware connections are provided.

•Mounting, electrical installation, start-up and maintenance of this device may only be

carried out by trained persons authorized by the operator of the facility. Persons must

read and understand this manual before carrying out its instructions.

•This device may only be operated by persons who are authorized and trained by the

operator of the facility. All instructions in this manual are to be observed.

•Make sure, the measuring system is correctly wired up according to the wiring diagrams.

Protection against accidental contact is no longer assured when the enclosure cover is

removed or the panel cabinet has been opened (danger from electrical shock). The

enclosure may only be opened by trained persons authorized by the operator of the

facility.

•Take careful notice of the "Safety rules, instructions and precautionary measures" in the

front of this manual.

The setup menu is used to program the F118-P.

The setup menu is accessible at all times while the F118-P remains fully operational. Be aware that

in this case any change to the settings may have an influence on the operation.

It is possible to prevent access to the setup menu with a password. A password may be

required to enter the setup menu. Without this password, access is denied.

3.1. HOW TO PROGRAM THE F118-P

The setup menu has different

submenus. Each submenu has an

unique number which is shown in

front of the menu name.

Each setting has an unique two-

digit number which is shown in

front of the setting. The first digit

refers to the submenu and the

second digit refers to the setting.

Note that sometimes the name of

the setting is shown on the upper

line of the display.

How to enter the setup menu

When the setup menu is protected by a password, the F118-P asks for a password to access the

setup menu. When in the operator mode, press and hold the PROG/ENTER key for 7 seconds to

access the setup menu.

How to navigate in the setup menu

The setup menu has different submenus to program the F118-P. For navigation, the submenus

and the settings are identified with numbers (for the submenu: e.g. 1; for the setting: e.g. 12.).

The CLEAR/key and the PROG/ENTER key are used for navigation. The explanation

assumes that you are in the submenu TOTAL.

Action

Result

Remark

Press the CLEAR/key to

select the next submenu.

•The submenu FLOW

RATE shows

Press again to go to the

next submenu.

•The submenu DISPLAY

shows.

Momentarily, press the

PROG/ENTER key to

select the previous

submenu.

•The submenu FLOW

RATE shows

The PROG/ENTER key is

used as a ◄key.

Press again to go to the

previous submenu.

•The submenu TOTAL

shows

The PROG/ENTER key is

used as a ◄key.

FW_F118P_v1901_02_EN.docx

Page 9

The SELECT/key and the CLEAR/key are used for navigation.

The explanation assumes that you are in the submenu TOTAL. When you are:

•in the first setting and you navigate to the previous setting, the F118-P goes back to the related

main menu.

•in the last setting and you navigate to the next setting, the F118-P goes to the related main

menu.

Action

Result

Remark

Press the SELECT/key

to select the first setting.

•The setting UNIT shows.

Press the SELECT/key

again to go to the next

setting.

•The setting DECIMALS

shows.

Press the CLEAR/key to

select the previous setting.

•The setting UNIT shows.

Press the CLEAR/key

again to go to the previous

setting.

•The submenu TOTAL

shows

This is normal behavior

because the setting UNIT is

the first setting of the

submenu TOTAL.

How to make a setting

Changes are only saved when you press the PROG/ENTER key.

The explanation assumes that you are in the submenu TOTAL and the setting UNIT. When you do

not want to save the change, wait for approximately 20 seconds or press and hold the

PROG/ENTER key for approximately 3 seconds.

Action

Result

Remark

Momentarily, press the

PROG/ENTER key.

•The PROG indicator blinks.

•The engineering unit L shows.

To access the setting.

Press the SELECT/key to

select the next engineering

unit.

•The PROG indicator blinks.

•The engineering unit m3shows.

If you wait too long, the

program mode goes off and

changes are not saved, this

is normal behavior.

Press the SELECT/key to

select the next engineering

unit.

•The PROG indicator blinks.

•The engineering unit US GAL

shows.

Press the CLEAR/key to

select the previous

engineering unit

•The PROG indicator blinks.

•The engineering unit m3shows.

To confirm the changes:

Momentarily, press the

PROG/ENTER key.

•The PROG indicator goes off.

•The change is saved.

•The engineering unit m3shows.

If you do not press the

PROG/ENTER key to

confirm, your selection is not

saved.

To discard the changes:

Press and hold the

PROG/ENTER key for

approximately 3 seconds.

•The PROG indicator goes off.

•The change is discarded.

•The engineering unit L shows.

FW_F118P_v1901_02_EN.docx

Page 10

3.1.1. SETUP MENU - SETTINGS

TOTAL

unit

L; m3; kg; lb; GAL; USGAL; bbl; no unit

decimals

0000000; 111111.1; 22222.22; 3333.333

K-factor:

0.000010 - 9999999

decimals K-factor

0 - 6

FLOWRATE

unit

mL; L; m3; mg; g; kg; ton; gal; bbl; lb; cf; rev; - - - - (no unit); scf; nm3;

nL; p

time

/sec; /min; /hour; /day

decimals

0000000; 111111.1; 22222.22; 3333.333

K-factor

0.000010 - 9,999,999

decimals K-factor

0 - 6

calculation

per 1 - 255 pulses

cut-off

0.1 - 999.9 seconds

ALARM

flowzero

default; no relay; ignore

alarm lo

0000.000 - 9999999

alarm hi

0000.000 - 9999999

delay lo

0.1 - 999.9

delay hi

0.1 - 999.9

DISPLAY

function

total; rate

alarm set

operator; setup; hidden

light

0% (off); 20%; 40%; 60%;- 80%; 100% (full brightness)

POWER MAN

LCD new

fast; 1 sec; 3 sec; 15 sec; 30 sec; off

battery mode

operational; shelf

FLOWMETER

signal

npn; npn-lp; reed; reed-lp; pnp; pnp-lp; namur; coil-hi; coil-lo; 8-1 DC;

12 DC; 24 DC

LINEARIZE

freq. / m-factor 1

0.1 –9999.9 Hz / 0.000001 –9.999999

freq. / m-factor 2

0.1 –9999.9 Hz / 0.000001 –9.999999



freq. / m-factor 10

0.1 –9999.9 Hz / 0.000001 –9.999999

linearization

enable; disable

decimals frequency

0000000; 111111.1; 22222.22; 3333.333

ANALOG

output

disable; enable

rate-min

000.000 - 999999

rate-max

000.000 - 999999

cut-off

0.0 - 9.9%

tune-min

0 - 9999

tune-max

0 - 9999

filter

01 - 99

RELAYS

relay 1

off; lo-lo; lo; hi; hi-hi; all; pulse

relay 2

off; lo-lo; lo; hi; hi-hi; all; pulse

relay 3

off; lo-lo; lo; hi; hi-hi; all; pulse

width

0.001 - 9.999

decimals

0.001 - 9

amount

0.001 - 9999999

COMMUNICATION

speed

1200; 2400; 4800; 9600

address

1 - 247

mode

bus-rtu; bus-asc; off

OTHERS

model

F118-P

software version

nn:nn:nn

serial no.

nnnnnnn

password

0000 - 9999

tag-nr

0000000 - 9999999

FW_F118P_v1901_02_EN.docx

Page 11

3.1.2. EXPLANATION OF SETUP MENU 1 - TOTAL

UNIT

This setting is used to select the engineering unit for the indication of the total, the

accumulated total and the pulse output.

When you change the engineering unit, you must recalculate and reprogram

the K-factor for the (accumulated) total. When you recalculate and

reprogram the K-Factor, the history for (accumulated) total is not correct

anymore, because the (accumulated) total is not recalculated. For future

reference, best practice is to make a note of the accumulated total before

you program the recalculated K-Factor.

DECIMALS

This setting is used to set the amount of digits behind the decimal point for the

(accumulated) total indication.

K-FACTOR

This setting is used to set the K-Factor for the total. With the K-Factor, the

flowmeter pulse signals are converted to a quantity. The K-Factor is based on the

number of pulses generated by the flowmeter per selected engineering unit, for

example m3. A more accurate K-Factor (more decimals, as set in decimals

K-Factor) allows for a more accurate operation of the system.

Example 1: Calculating the K-Factor.

The flowmeter generates 2.4813 pulses per liter and the selected unit is m3. A

cubic meter consists of 1000 liter which gives 2.4813 pulses*1000 liter=2481.3

pulses per m3. So, the K-Factor is 2481.3. Enter for the Flowmeter K-Factor:

24813 and for the flowmeter K-Factor decimals: 1.

Example 2: Calculating the K-Factor.

The flowmeter generates 6.5231 pulses per gallon and the selected engineering

unit is gallons. So, the K-Factor is 6.5231. Enter for the Flowmeter K-Factor:

65231 and for the Flowmeter K-Factor decimals: 4.

When you recalculate and reprogram a new K-Factor, the history for

(accumulated) total is not correct anymore, because the

(accumulated) total is not recalculated. For future reference, best

practice is to make a note of the accumulated total before you

program the recalculated K-Factor.

DECIMALS K-FACTOR

This setting is used to set the amount of digits behind the decimal point for the

K-Factor.

3.1.3. EXPLANATION OF SETUP MENU 2 - FLOW RATE

The settings for total and flow rate are entirely separate. In this way, different engineering units can

be used for each e.g. cubic meters for total and liters for flow rate.

UNIT

This setting is used to select the engineering unit for the indication of the flow rate.

Alteration of the engineering unit will have consequences for

operator and setup values, they will not be automatically

recalculated to the value of the new selected unit. The K-Factor has

to be adapted as well; the calculation is not done automatically.

TIME

This setting is used to set the time unit for the flow rate calculation. Note that the

flow rate is given in engineering unit/time unit, e.g. liters/minute (l/min).

DECIMALS

When you change this setting, also recalculate and change the settings

for the analog rate-min and analog rate-max.

K-FACTOR

This setting is used to set the amount of digits behind the decimal point for the

flow rate indication.

DECIMALS K-FACTOR

This setting is used to set the K-Factor for the flow rate. With the K-Factor, the

flowmeter pulse signals are converted to a quantity. The K-Factor is based on the

number of pulses generated by the flowmeter per selected engineering unit, for

example m3. A more accurate K-Factor (more decimals, as set in decimals

K-Factor) allows for a more accurate operation of the system.

FW_F118P_v1901_02_EN.docx

Page 12

CALCULATION

The flow rate is calculated by measuring the time between a number of

pulses, for example 10 pulses. The more pulses the more accurate the

flow rate will be. The maximum value is 255 pulses.

This setting does influence the update interval for the flowrate and thus,

indirectly the update interval of the analog output.. (maximum update

10 times a second). If the output response is too slow, decrease the

number of pulses. For low frequency applications (< 10Hz): do not

program more than 10 pulses, else the update time will be very slow.

For high frequency applications (> 1kHz): do program 50 or more pulses.

CUT-OFF

This setting is used to set the threshold for a minimum flow. If during this

time less than XXX-pulses are generated (refer to Calculation), the flow

rate will be shown as zero. The cut-off has to be entered in seconds.

3.1.4. EXPLANATION OF SETUP MENU 3 - ALARM

These settings determine how the flow rate is monitored and how the F118-P will process the alarm

conditions. For the setup of the configurable outputs, refer to setup menu: Relays.

FLOWZERO

When the flow rate is zero, then it is possible to ignore or disable the flow rate

monitoring. The following settings can be selected:

DEFAULT: in case of a low-flow rate alarm and zero flow, it will switch the

alarm output and indicate the alarm on the display.

NO RELAY: in case of a low-flow rate alarm and zero flow, it won't switch the

alarm output but will indicate the alarm on the display only.

IGNORE: in case of a low-flow rate alarm and zero flow, it won't switch the

alarm output and nothing will be indicated on the display.

ALARM LO

This submenu is used to activate the related alarm condition and to set the

threshold value for a this flow alarm. The setting 0.0 disables this alarm.

ALARM HI

This setting is used to activate the related alarm condition and to set the

threshold value for a this flow alarm. The setting 0.0 disables this alarm.

DELAY LO

This setting is used to set a delay time for the related alarm. When the

alarm condition is still valid after the delay time, an alarm is given.

DELAY HI

This setting is used to set a delay time for the related alarm. When the

alarm condition is still valid after the delay time, an alarm is given.

3.1.5. EXPLANATION OF SETUP MENU 4 - DISPLAY

FUNCTION

This setting can be set to display total or rate.

•When 'total' is selected, simultaneously, total is shown with the large

digits and flow rate with the smaller digits. When SELECT is pressed,

the accumulated total is shown temporarily.

•When 'rate' is selected, only flow rate will be shown with the large

digits together with its measuring unit. When SELECT is pressed, the

total and the accumulated total are shown temporarily.

ALARM SET

This setting is used to determine in which menu you can change the

alarm settings. When programmed for setup menu only, the alarm

settings in the operator menu are read-only.

LIGHT

The backlight brightness can be adjusted from 0% (off) to 100% (full

brightness) in steps of 20%.

When the F118-P is only loop powered, the backlight is disabled. An

external power supply is required to supply the backlight.

FW_F118P_v1901_02_EN.docx

Page 13

3.1.6. EXPLANATION OF SETUP MENU 5 - POWER MANAGEMENT

When used with the internal battery option (type PB/PC), the user can expect reliable measurement

over a long period of time. The F118-P has several smart power management functions to extend

the battery life time significantly. Two of these functions can be set.

LCD NEW

The calculation of the display-information influences the power

consumption significantly. When the application does not require a fast

display refresh rate, it is strongly advised to select a slow refresh rate.

Please understand that NO information will be lost; every pulse will be

counted and the output signals will be generated in the normal way. At a

key press, the display refresh rate will switch to FAST for 30 seconds.

When 'OFF' is selected, the display goes off after 30 sec. after the last

key press. The display temporarily comes on after a key press.

Example battery life-time with a coil pick-up:

•1kHz pulse and FAST update: about 2 years;

•1kHz pulse and 1 sec update: about 5 years.

BATTERY MODE

The F118-P has two modes: operational or shelf.

After "shelf" has been selected, the F118-P can be stored for several years; it will

not process the sensor signal; the display is switched off but all settings and totals

are stored. In this mode, power consumption is extremely low.

To wake up the F118-p again, press the select/key two times.

3.1.7. EXPLANATION OF SETUP MENU 6 - FLOWMETER

SIGNAL

With this setting the type of flowmeter output is selected. The settings with

LP (low-pass) filter are used to apply a build-in noise reduction.

Selections "active pulse" offer a detection level of 50% of the supply

voltage.

TYPE OF SIGNAL

EXPLANATION

RESISTANCE

FREQ./MV

REMARK

NPN

NPN input

100 kΩ pull-up

max.6 kHz.

(open collector)

NPN - LP

NPN with low pass filter

100 kΩ pull-up

max.1.2 kHz.

(open collector)

less sensitive

REED

Reed-switch input

1 MΩ pull-up

max.1.2 kHz.

REED - LP

Reed-with low pass filter

1 MΩ pull-up

max.120 Hz.

Less sensitive

PNP

PNP input

100K pull-down

max.6 kHz.

PNP - LP

PNP with low pass filter

100K pull-down

max.1.2 kHz.

Less sensitive

NAMUR

NAMUR input

820 Ω pull-down

max.4 kHz.

External power

required

COIL-HI

High sensitive coil input

min. 20 mVpp

Sensitive for

interference!

COIL-HI (option ZF)

min. 10 mVpp

COIL-HI (option ZG)

min. 5 mVpp

COIL LO

Low sensitive coil input

min. 80 mVpp

Normal

sensitivity

8-1 DC

Active pulse input

8.2V DC

3K9

max.10KHz.

External power

required

12 DC

Active pulse input

12V DC

max.10KHz.

External power

required

24 DC

Active pulse input

24V DC

max.10KHz.

External power

required

3.1.7. EXPLANATION OF SETUP MENU 7 - LINEARIZE

The linearization function is available to approach the real flow curve better as with the general

K-Factor (KF0). This to obtain a more accurate flow rate, total and accumulated total as well as the

analog and pulse output at any flowmeter frequency. A maximum of 15 linearization-positions can be

entered while the interpolation will calculate any other position in-between.

For each linearization position, the frequency and a Meter Factor (MF) must be entered. The lowest

frequency and MF you enter will be valid from 0Hz. The highest frequency and MF will be valid till

10KHz. It is advised to enter the frequencies in increasing order, however it is not necessary. Please

have a look at following example to understand the calculation and the method of linearization:

FW_F118P_v1901_02_EN.docx

Page 14

FREQUENCY /

M-FACTOR

71 TO 7A

The frequency is shown at the bottom line of the display. The maximum

frequency is 9999.9 Hz. With value 0.0Hz, the M-Factor is disabled. The M-

Factor (MF) is shown at the top-line of the display. The minimum value to be

entered is 0.000001 and the maximum value is 9.999999.

The MF is mostly a figure around 1.000000, like 0.945354 or 1.132573 and

always has six decimals, but the decimal separator is not shown.

LINEARIZE

This setting is used to enable or disable the linearization function.

DECIMALS

FREQUENCY

This setting is used to set the amount of digits behind the decimal point for the

frequency.

3.1.8. EXPLANATION OF SETUP MENU 8 - ANALOG OUTPUT

A linear 4-20mA signal (option AB: 0-20mA or option AU: 0-10V) output signal is generated that

represents the flowrate. The settings for the flow rate influence the analog output directly. The

relationship between the flow rate and the analog output is set with the following settings.

OUTPUT

If the analog output is not used, select disable to minimize the power

consumption (e.g. save battery life-time).

Option AP: When a power supply is available but the output is disabled, a

3.5mA signal will be generated.

RATE-MIN

Enter here the flow rate at which the output should generate the minimum

signal (0)4mA or 0V - in most applications at zero flow. The number of

decimals shown depend upon setup 23. The engineering units/time (e.g.

L/min) are dependent upon setup 21 and 22.

RATE-MAX

Enter here the flow rate at which the output should generate the maximum

signal (20mA or 10V) - in most applications at maximum flow. The number

of decimals shown depend upon setup 23. The engineering units/time

(e.g. L/min) are dependent upon setup 21 and 22.

CUT-OFF

To ignore leakage of the flow for example, a low flow cut-off can be set as

a percentage of the full range of 16mA, 20mA or 10V.

When the flow is less than the required rate, the current will be the

minimum signal (0)4mA or 0V.

Example: Calculate the cut-off.

Rate-min: 0L/min [4mA], Rate-max: 100 L/min [16mA], Cut-off: 2%

Required rate [L/min]: (rate-max - rate-min)*cut-off: (100-0)*2%=2.0L/min

Output [mA]: rate-min + (rate-max*cut-off): 4+(16*2%)=4.32mA

FW_F118P_v1901_02_EN.docx

Page 15

TUNE-MIN

The (0)4mA or 0V value can be tuned precisely with this setting. The

initial minimum analog output value is (0)4mA or 0V. However, this value

might differ slightly due to ambient influences such as temperature for

example.

Before tuning the signal, make sure that the analog signal is idle

(not used) for any application!

After pressing PROG, the current will be about 4mA (0mA or 0V). The

current can be increased / decreased with the arrow keys and is directly

active. Press ENTER to store the new value.

If required, you can program the analog output 'up-side-down'. The

(0)4mA or 0V represents the maximum flow rate and the 20mA or 10V

represents the minimum flow rate.

TUNE-MAX

The 20mA or 10V value can be tuned precisely with this setting. The initial

maximum analog output value is 20mA or 10V However, this value might

differ slightly due to ambient influences such as temperature for example.

Before tuning the signal, make sure that the analog signal is idle

(not used) for any application!

After pressing PROG, the current will be about 20mA or 10V. The current

can be increased / decreased with the arrow keys and is directly active.

Press ENTER to store the new value.

If required, you can program the analog output 'up-side-down'. The

(0)4mA or 0V represents the maximum flow rate and the 20mA or 10V

represents the minimum flow rate.

FILTER

This setting is used to stabilize the output signal. With the help of this

digital filter a more stable but less actual representation of the flow rate

can be obtained.

The filter principal is based on three input values: the filter level (01-99),

the last calculated flow rate and the last average value. The higher the

filter level, the longer the response time on a value change will be.

FILTER VALUE

RESPONSE TIME ON STEP CHANGE OF ANALOG VALUE.TIME IN SECONDS

INFLUENCE

50%

75%

90%

99%

filter disabled

0.1 sec

0.2 sec

0.4 sec

0.7 sec

0.2 sec

0.4 sec

0.6 sec

1.2 sec

0.4 sec

0.7 sec

1.1 sec

2.1 sec

0.7 sec

1.4 sec

2.2 sec

4.4 sec

1.4 sec

2.8 sec

4.5 sec

9.0 sec

2.1 sec

4 sec

7 sec

14 sec

3.5 sec

7 sec

11 sec

23 sec

5.2 sec

10 sec

17 sec

34 sec

6.9 sec

14 sec

23 sec

45 sec

FW_F118P_v1901_02_EN.docx

Page 16

3.1.9. EXPLANATION OF SETUP MENU 9 - RELAYS

The outputs are configurable, they can be set to a specific alarm output, a scaled pulse output

according accumulated total or to off (energy saving when not used).

There are three outputs in the submenu, but the amount of outputs can vary due to

regulations or chosen options.

RELAY 1

This setting is used to set the function of related output R1.

Mind that when set to pulse, the output has a maximum frequency of 5Hz

to prevent contact bounce.

For intrinsic safe applications (XI):

The setting in this submenu is overridden by the setting of relay 3.

RELAY 2

This setting is used to set the function of related output R2.

Mind that this output has a maximum frequency of 500Hz.

RELAY 3

This submenu is used to set the function of related output R3.

Mind that this output has a maximum frequency of 500Hz.

For intrinsic safe applications (XI): The setting of this output (fast output)

is assigned to R1 (option XI has only two outputs).

WIDTH

The pulse width determines the time that the output will be active; in other words

the pulse duration. Value “zero” will disable the pulse output. The pulse signal

always has a 50% duty cycle, hence the minimum time between the pulses is

equal to the pulse width setting. If the frequency should go out of range –when

the flow rate increases for example –an internal buffer will be used to “store the

missed pulses”: As soon as the flow rate slows down, the buffer will be “emptied”.

It might be that pulses will be missed due to a buffer-overflow, so it is advised to

program this setting within its range!

DECIMALS

This setting is used to set the amount of digits behind the decimal point for the

amount.

AMOUNT

A pulse will be generated every time a certain quantity is added to the total. Enter

this quantity here while taking the decimals for pulse into account.

3.1.10. EXPLANATION OF SETUP MENU A - COMMUNICATION (OPTION)

This product is designed for the connection to a communication network. Products with a

communication option do not include cyber security functions. Fluidwell cannot take any

responsibility for the cyber security, omissions or errors in the communication safety. To maintain a

secure operation, automation and control, it is the sole responsibility of the owner to install and

manage the appropriate safety measures to protect the network, the product and the communication

against any kind of security breaches.

The functions described below deal with hardware that is not part of the standard delivery.

Programming of these functions does not have any effect if this hardware has not been installed.

Consult Appendix C and the Modbus communication protocol description for a detailed explanation.

SPEED

This setting is used to set the Baudrate.

ADDRESS

This setting is used to set the communication address for the F118-P.

MODE

This setting is used to set the Modbus transmission mode. Select OFF to disable

the communication.

3.1.11. EXPLANATION OF SETUP MENU B - OTHERS

For support and maintenance it is important to have information about the characteristics of the F118-P . Your

supplier will ask for this information when support is required.

MODEL

This setting shows the model name.

SOFTWARE VERSION

This setting shows the version number of the firmware (software).

SERIAL NO

This setting shows the serial number.

PASSWORD

This setting is used to set a password (pin code) to limit the access for the setup

menu. Only persons who know the pin code can access the setup menu. The pin

code 0000 disables the pin code to allow for access by any person.

TAG-NR

This setting is used to set a tag number for the F118-P.

FW_F118P_v1901_02_EN.docx

Page 17

4. INSTALLATION

4.1. General directions
