Flying Eye DJI MATRICE 300 RTK User manual

Parachute system and
Circuit breaker
DJI MATRICE 300 RTK
Before using the parachute system, please read this manual carefully.

Flying Eye has been your partner specialised in drone technology since 2009. We have been
developing parachute systems since the drone regulaons appeared in 2012. It’s a pyrotechnic sys-
tem based on aviaon technology, making it the most ecient and lightest system on the market.
Flying Eye could not be responsible for any malfuncon or operaon deemed to be inecient.
Contact us for any technical or commercial informaon you may require.
USER MANUAL
PRESENTATION
FLYSAFE-M3 12/11/2020 Version 1.00
Hardware version 1.04
FLYSAFE-M3 12/11/2020

Flying Eye may suspend the guarantee and disclaim all liability to any person who fails to comply
with the basic safety instrucons set out below. Flying Eye declines all responsibility for damage or injuries
directly or indirectly related to the use pyrotechnic cartridges that do not conform to the safety require-
ments and standards.
• It is forbidden to carry out any operaon other than those specied in the manual.
• The device should only be used by (or supervised by) a responsible adult. Always keep the device out of
the hands of children. Do not allow children to play with it.
• In any case, you must not dismantle the various elements of the device, except during the maintenance
provided for this purpose and in accordance with the indicaons provided in this manual..
• Do not place the device in a humid or wet environment and keep it away from UV light.
• Do not expose the system to high or low temperatures, strong shocks, risk of shocks, contact with
chemicals, acids, long-term storage in high humidity or dust. Inappropriate use can cause the pyrotech-
nic cartridges to explode and endanger your life. The maximum operang temperature is 40°C and the
minimum operang temperature is -15°C.
• The condion of the parachute system must be checked before each use. Do not use the device if it is
damaged or malfuncons. If this is the case, contact your retailer.
• The parachute cannot prevent the drone from malfunconing.
• Any ight with a drone implies the existence of a risk for the equipment and people in the area, with or
without a parachute.
• The use of a parachute must not under any circumstances increase your risk.
• The parachute must be triggered manually by the user. Regular training is necessary to be able to react
correctly in an emergency. For the safety of the equipment make dummy releases of ground exercises
regularly.
• The ejecon system only works once. It must be returned to your dealer for recharging.
• Aer the device has been triggered, it is recommended that each component be carefully inspected to
ensure its integrity. If you have any doubts, please contact your dealer.
USER MANUAL
WARNINGS
FLYSAFE-M3 12/11/2020 Version 1.00
Hardware version 1.04

DESCRIPTION :
Reliable and lightweight safety system for S2 and S3
approval of the DJI MATRICE 300 RTK. It includes an ul-
tra-fast double parachute, a circuit breaker, an alarm
and a secure radio release which is aached to the pilot
radio control.
The parachutes can be removed in a few seconds. The
centre of gravity of the Matrice 300 RTK is retained. Re-
dundancy of the parachutes for a totally infallible sys-
tem. The MATRICE 300 RTK returns to its starng po-
sion when the parachutes are released, to avoid the
breakage of an arm or landing gear.
TECHNICAL SPECIALISATIONS :
• Weight of the complete system: 710g
• Impact energy: 64 Joules
• Homologaon for 8kg
• Redundancy of the power cut-o electronics
• Double release buon on the remote control
• Encrypted frames (256-bit) - checksum to authencate the frame. Associaon in both direcons.
• Logs on micro-sd card in the remote control (text le readable by the user and unalterable containing:
date/me/min/sec, recepon quality, trigger requested by the user, trigger received by the receiver,
remote control acknowledgement, drone baery voltage, voltage and current passing through the 2
circuit breaker chips, and remote control baery voltage)
• Remote control autonomy of 40 hours (1800mAh lipo baery rechargeable by micro-USB)
• Auto power O (aer 30 minutes without connecon)
• Baery voltage display on the remote control (4 LEDs)
• Emergency power supply allowing parachutes to be triggered up to 1 minute aer a loss of UAV power
• Firmware update via micro-USB
• Securely turns the remote control on and o (like a DJI baery)
• Possibility to pair up to 4 remote controls per drone
USER MANUAL
TECHNICAL DESCRIPTION
Works properly from a height of 15 metres thanks to the pyrotechnic technology borrowed from microlight
aircra.
Very low coecient of penetraon in the air so that no vibraons are generated at high speed and thus a
perfectly stable image is maintained.
Reliable, robust and lightweight high-tech materials.
Assembly and disassembly of the system is feasible by the customer. The system does not alter the integrity
of the DJI MATRICE 300 RTK. The DJI manufacturer’s guarantee is retained. Fits in the original case of the
MATRICE 300 RTK.
FLYSAFE-M3 12/11/2020 Version 1.00
Hardware version 1.04
FLYSAFE-M3 12/11/2020

CONTENT :
USER MANUAL
• 2 parachute containers
• 1 insert module le
• 1 right-hand spacer module
• 1 cradle (landing gear support)
• 2 load plugs
• 2 pyrotechnic charges
• 1 remote control
• 1 micro USB cable
• 1 baery latch
FLYSAFE-M3 12/11/2020 Version 1.00
Hardware version 1.04

Radio control charge level :
To nd out the charge level, press the buon once.
«POWER», indicator lights appear.
Switching on :
To switch on the parachute radio control, press and hold the «POWER» buon. The le-hand light will light
up green, the rst right-hand light will light up red and will go out when the radio control is paired with the
drone’s internal receiver.
Triggering :
The parachute is released by pressing the 2 «FIRE» buons simultaneously.
USER MANUAL
PARACHUTE REMOTE CONTROL
FLYSAFE-M3 12/11/2020 Version 1.00
Hardware version 1.04
FLYSAFE-M3 12/11/2020

USER MANUAL
Lighted Flashing light O
FLYSAFE-M3 12/11/2020 Version 1.00
Hardware version 1.04

MODE OF OPERATION
Open the cover of dongle 4G.
Unscrew the two ring fastening screws (red arrow)
USER MANUAL
INSTALLATION OF PARACHUTE RADIO CONTROL
Remove the ring and posion it on the parachute remote
control, then screw it on.
Posion the parachute remote control on the
SmartController radio remote control: Aach the
ring and aim
Close the cover of dongle 4G.
FLYSAFE-M3 12/11/2020 Version 1.00
Hardware version 1.04
FLYSAFE-M3 12/11/2020

USER MANUAL
INSTALLATION
Installaon of the parachute cradle :
In order to be able to posion the parachutes on the drone you must:
Unscrew the two landing gear supports
Posion the cradle in place and place the cradle under the drone. Fix it with the 4 screws on each
side (USB connector towards the front).
Installing the Baery Buery :
In order to be able to lock the baeries with
the presence of the circuit breakers, it is neces-
sary to change the baery locking buery.
Place an adhesive tape on each side of
the push piece under the throle valve to hold
it in place during disassembly.
Unscrew the central screw of the
throle valve: CAUTION with the washers, re-
move the screw and the throle valve.
Replace the screw in the new buery
valve, the washers and then screw.
Remove the adhesive tape.
Installaon of the pyrotechnic charges :
Before seng up the «parachute» containers, please
place the two pyrotechnic charges on each side of the
drone on the intended locaons (landing gear base, red
connector). Place the load correctly thanks to the two
lateral lugs.
FLYSAFE-M3 12/11/2020 FLYSAFE-M3 12/11/2020 Version 1.00
Hardware version 1.04

Installaon of the circuit breaker modules :
To place the circuit-breaker modules on each side in the baery slots, insert them from the rear by sliding
them forwards.
Slide the modules all the way to the front as far as they will go to ensure a good connecon on the connec-
tor. The fuse modules can remain in place for storage in the M300 RTK case.
Installing the Parachute Pods :
Install the two «parachute» pods on each side of the drone by capping the pyro-
technic charges and screwing them ght.
Installaon of the drone baeries:
Install the two TB60 baeries normally by sliding them from the rear,
then lock them using the «buery» type rotang fastener.
USER MANUAL
FLYSAFE-M3 12/11/2020
Version 1.00
Hardware version 1.04

Before each ight, you must check all the components of the system and verify its integrity. If an anomaly is
found, do not ight and contact your retailer.
Funconality test on the ground:
• Make sure that the enre drone system is powered down. Baery TB60 disengaged.
• Remove the drone’s propellers.
• Remove the «parachute» pods by unscrewing them.
• Remove the 2 pyrotechnic charges.
• Install the 2 TB60 baeries and lock.
• Switch on the drone’s radio control.
• Switch on the «parachute» radio control.
• Switch on the drone, the led 4 of the «parachute» radio-control goes out.
• Remove the safety pin, LED 1 goes out.
• Switch on the drone’s engines.
• Acvate the «parachute» system by pressing the 2 «FIRE» buons:
• The four engines stop.
The 110dB buzzer sounds.
The four red lights on the «parachute» radio control blink.
• The buzzer connues to sound as long as the TB60 baeries are in place (allows you to nd your drone).
• Unlock and remove the TB60 baeries:
The system will remain powered for about one minute and the buzzer will stop.
• Switch o both radio controls.
FUNCTIONAL TEST
USER MANUAL
Safety pin in posion
FLYSAFE-M3 12/11/2020 FLYSAFE-M3 12/11/2020 Version 1.00
Hardware version 1.04

ANNUAL MAINTENANCE
Change of pyrotechnic charges.
Venlaon of the canopy for 24 hours, inspecon of the canopy, lines and folding. Annual mainte-
nance of the canopy is essenal for opmal system operaon.
SPECIFIC INTERVIEW:
You must dry the canopy immediately aer any contact with moisture or water to avoid any deterioraon.
Contact with solvents, chemicals, or fuel may alter the mechanical properes of the canopy.
The parachute and lines should be cleaned only with soap-free water and then dried
GUARANTEE :
We guarantee our parachutes for one year from the date of purchase against any defect in workmanship or
design that may occur under normal use of the product.
Any abusive or incorrect use, any exposure to aggressive factors (high humidity, too high temperature...)
which would lead to damage will invalidate this warranty
MAINTENANCE
STORAGE AND GUARANTEE
USER MANUAL
FLYSAFE-M3 12/11/2020
Version 1.00
Hardware version 1.04

Contact us :
Flying Eye
80 route des lucioles
Bat. I14
06560 SOPHIA ANTIPOLIS
Mail : info@yingeye.fr
Tel : [phone]
FLYSAFE-M3 12/11/2020
