Flylink JF-H-42H User manual

FOLDiNG TREADMiLL
USER MANUAL
Please put the red safety key on the digital panel before turning on, otherwise
the treadmill will display E07 problem.

FITSHOW Installation Procedure
1. Scan the QR code on the right
2. http://tshow.com/qr
3. Reprinted to the App Store to download and install, open the App, allow the
permissions according to the system prompts
4. Connect to (FS-XXXXXX-A)
5. Login to the App, please use the mobile number or email to register for the new
user
6. Start Using FITSHOW
Attentions:
Please fill in the correct email or mobile phone number to make
sure you can retrieve your password and username via them.

1
EN
CATALOG
Product Brief Introduction 2
Safety Precautions and Warning Instructions 3
Main parameters and conguration list 4
Product Installation Instructions 5
Folding and Inclines Adjustment Instructions 6
Fitness Advice and Guidelines 7
Product Instructions 8
Product Maintenance 10
Common Troubleshooting Methods 13
...................................................................
.....................................
...............................................
..........................................................
.....................................
............................................................
............................................................................
..........................................................................
....................................................

2
EN
Product Brief Introduction
Product Model: JF-H-42H
Mobile Phone
Bracket Dashboard
Components
Left Handrail
Tube Right Handrail Tube
Right Upright Tube
Left Upright
Tube
Acrylic Motor
Cover
Torx Knob
Forefoot Pad
Move Wheel
Running Belt
Manual Inclines
Handle Latch Pin
Rear Corner
Guard
Sidebar
Safety Key

3
EN
Safety Precautions and Warning Instructions
Please read the instructions carefully before use and pay attention to the
following security precautions:
■ The treadmill is suitable to be placed indoors to avoid moisture,do not splash water on the treadmill,and do not place
any foreign objects.
■ Before exercising, please wear suitable sportswear and sports shoes. It is strictly forbidden to exercise on the treadmill
without wearing shoes, and it is best to stretch the whole body before exercise.
■ The power plug must be grounded reliably, and the socket must have a dedicated loop to avoid sharing it with other
electrical equipment.
■ Kids should stay away from the machine to avoid accidents.
■ Should avoid long-time overload operation, otherwise, it will cause damage to the motor and controller, accelerate the
aging of the bearing, running belt, and running board, Do the maintenance of this machine reqularly.
■ Reduce indoor dust, maintain a certain indoor humidity. and avoid strong static electricity,otherwise, it may interfere
with the normal operation of the electronic watch and controller.
■ Please turn o󰀨 the power of the treadmill after exercise.
■ Please keep indoor air circulation when using the treadmill.
■ Please clip the safety key to the garment liner during exercise,so as to stop the machine safely and quickly in an
emergency.
■If you feel unwelor have abnormalities during use, please stop exercising immediately and consult a doctor.
■ After using silicone oil, it must be placed out of the reach of children to avoid serious consequences by accidental
ingestion.
Prohibited!
■ Do not use the product in a state where the outside of the product is cracked, damaged, or peeled o󰀨 (the internal
structure is exposed), or when the welding part is peeled o󰀨., In order to avoid accidents or injuries.
■ Do not jump up and down during exercise. Otherwise, you may fall and get injured.
■ Do not use or store the machine in wet places such as outdoors. near bathrooms.and places exposed to water
droplets.
■ Do not use or store it in places exposed to direct sunlight. hiah-temperature places such as around stoves.or on
heating appliances such as electric heating carpets. Otherwise, it may cause electric leakage or re.
■ Do not use it when the power cord or power plug is damaged or the jack of the socket is loose. Otherwise, it may
cause electric shock, short circuit, or re.
■ Do not damage or forcibly bend or twist the power cord. At the same time, don't place heavy objects on it, and don't let
the line be pinched. So as not to cause re or electric shock.
■ Do not use this machine by two or more people at the same time, and please be careful not to let people around you
get close to the machine during use. Otherwise, it may cause accidents or injuries due to falling.
■ Do not use it if you cannot express your consciousness or operate it yoursef, In order to avoid accidents or injuries.
■ Avoid contact with water and liquids! Do not expose the main body or operating parts to water or liquids. Otherwise, it
may cause electric shock or re.
■ People who do not usually exercise should not do vigorous exercise suddenly.
■ Do not use this product after eating, feeling tired, just after exercise, or when vour physical strength is abnormal.
Otherwise, it may harm your health,
■ This product is suitable for family use, not suitable for schools, gvmnasiums, and other places with a large number of
people. Otherwise, there is a risk of injury.
■ Do not use it while eating or doing other activities.
■ Do not use it after drinking alcohol or when you feel that your behavior has become dul, So as not to cause an accident
or injury.
■ Do not put hard objects in your clothing pockets. Please take o󰀨 valuables such as watches,bracelets, mobile phones,
and sharp obiects such as kevys and knives before use to avoid damage to the items or cause physical iniury.
■ Before use, please check whether foreign objects such as needles, trash, or water are attached to the power plug. So
as not to cause electric shock, short circuit, or re.
■ Do not use it with wet hands! Do not unplug or insert the power plug with wet hands. So as not to cause electric shock
or injury.
■ Pull out the power plug! When not in use, pull out the power plug from the socket. In order to avoid the deterioration of
the insulation due to dust and moisture,which may lead to electric leakage and res.

4
EN
Main parameters and conguration list
The main technical parameters
Serial number Description Parameter name
1Rated voltage US:120V/60Hz; UK:220-240V/50-60 Hz
2Control method Meter touch type, APP
3Display method LED, APP
4Incline 3 Manual Incline
5Speed range 0.6-10 MHP(1-16km/h)
6Running belt size 430*1100mm (L.*W.)
7Product unfolded size 1375*750*1250mm(L.*W.*H.)
8Product weight N.W:39kg G.W.:45kg
9Package size 1470*800*280mm(L.*W.*H.)
10 FCC ID 2A48IJF-H-42H
Accessories package list
Serial number Name Quantity
1Safety key 1
2L-type wrench (6mm) 1
3Power cord 1
4Product manual 1
5Mobile Phone Bracket 1
6Torx Knob 2
Packing materials list
Serial number Name Quantity
1Main engine 1PCS
2Accessory package 1PCS

5
EN
Product Installation Instructions
Step1. Take the product out of the box, remove
the outer PE bag, and place it on at ground.
Step2. Take out the torx knob in the
accessories bag. Grasp the upright pipe by
your hand and and turn it up in the direction
of the arrow. After reach-ing the designated
position, use the torx knob and align it with the
screw hole to tighten it clockwise direction until
the upright pipe does not shake.(The same
method on the other side)
Step3. Take out the mobile phone holder and
safety lock from the accessory bag.Flip the
left and right armrest clockwise to level in the
direction of the arrow. Align the mobile phone
holder with the instrument panel and insert it
into the rectangular card slot. Place the safety
lock in the center of the yellow position.
Safety Key
Step4. Insert it into the frame tube socket
according to the direction, plug it in tightly,
insert the other end into the 120Vsocket and
turn the power switch to the symbol position
"—".After the light is on, you can start using the
product.

6
EN
Folding and Inclines Adjustment Instructions
1. When the product is not in use, it can be put away. When folded, support the rear tail cover
with your hand and lift it up until the support rod is supported. To lay down, touch the middle
connection of the support rod with the top of the foot, and lay down slowly. (When putting
down the treadmill, be careful not to have anything around, people should be 1.5 meters
away from the treadmill to avoid injury)
2. Grasp the position of the rear corner guard with your hands and lift it up into a stowed
state, pull out the latch with the handle, pull the adjustable incline outwards, adjust to the
desired treadmill height, then use the latch to buckle into the hole to x it does not shake (same
left and right)
Adjustable Inclines
Using your foot rmly push against
the cylinder to release the folding
mechanism.

7
EN
Fitness Advice and Guidelines
Warm-up 5 to 10 minutes of warm-up exercise before each use of the machine.
Breathing
Breathing should not be shielded during exercise. In general, inhale
through the nose and exhale through the mouth when preparing to restore
the movement.Breathing and movement should be coordinat-ed, If you
feel short of breath, stop exercising immediately.
Frequency There should be a 48-hour rest for the muscles after exercising, and it is
best to do the same training at intervals of one day.
Intensity The training content is determined according to the individual's physical
condition, and then practice with the principle of gradual loading. The
soreness wil slowly disappear while exercising.
Diet
In order to protect the digestive system, after eating, vou must wait more
than one hour before vou can exercise.After training, you must wait more
than half an hour before eating. Drink less water during exercise, especialy
avoid drinking a lot of water, so as not to increase the burden on the heart
and kidneys.
Stretching exercises:
No matter what speed you run. it's best to do stretching exercises first to warm your body and
stretch your muscles more easil. So walk for 5 to 10 minutes to warm up. then stop and do stretching
exercises 5 times as follows, each leg do it for 10 seconds or more each time. Do it again after the
exercise is over.
1. Stretch Down
Bend your knees slightly, and bend your body slowly, letting your back and shoulders
relax, and repeat 3 times. (See Picture 1)
2. Hamstring Stretch
Sit on a clean cushion, straighten one leg and retract the other leg so that it is close
to the inner side of the straight leg. Try to touch the toes with your hands, hold for 10-
15 seconds. Then relax, each leg repeats this three times. (See Picture 2)
3. Stretching the Calf and Achilles Tendon
Stand with both hands supporting the wall or table, with one foot behind, keep your
hind legs upright and your heels on the ground, tilt towards the wall or table, hold for
10-15 seconds. Then relax, each leg repeats this three times. (See Picture 3)
4. Ankle Extension
Hold xed support with your right hand to grasp the balance, then stretch your left
hand to your back, grab your left ankle and slowly pull up to the hip position until you
feel the muscles in front of your thighs are tight, hold for 10-15 seconds. Then relax,
each leg repeats this three times. (See Picture 4)
5. Stretching the Inner Thigh Muscles
Sit with the bottom of the legs facing each other, with the knees facing outwards,grasp
the feet with both hands and pull them towards the groin, hold for 10-15 seconds.
Then relax, and repeat the procedure 3 times. (See Picture 5)

8
EN
Product Instructions
a. Brief Description
This electronic meter is easy to use and has few adjustment parameters.
Treadmill parameters: speed value.
Sports parameters: distance value, calorie value,time value.
Sports mode: default mode, program mode, manual mode.
Default mode: customize exercise amount
Program mode: Fixed exercise amount
Classify countdown mode: single value to set the amount of exercise
b.LED Digital Display
1.Distance display
2.Speed display
3.Time display
4. Calorie display
c.Smart Button
The product button design is as follows:
d. Operating parameters
1. Power supply voltage: 120V/60Hz;
2. The minimum speed:0.6 mph;
3. The maximum speed:10 mph;
4. Manual mode exercise time range in : 5-99 minutes;
5. Automatic mode the maximum exercise time in is 99 minutes;
6.Automatic mode the highest calorie consumption is 990 kcal.
The product button design is as follows:
1. Start/Stop button:
2. Program button:
3. Speed minus button:
4. Speed plus button:
5. Mode button:
6. Speed shortcut button: 2, 4, 5, 6, 8

9
EN
e. Sport Mode
1. Default Mode:
Before running the product, check whether the power plug is in good contact with the socket,
whether the safety lock is in place, and whether the main power switch is turned on. When the
product is in standby state, the window displays 0:00, press the switch button, the product starts
to count down for 3 seconds, the speed window displays 0.6 mph, the time window displays
0:00 by default, press the speed shortcut keys (2, 4, 5, 6, 8) value, the window will display the
corresponding digital speed, and the calorie value will increase cumulatively.
2. Program Mode:
In standby state, the window displays 0:00, press the PR0G key on the panel, the window
displays P-01 mode, press the panel continuously to flash P-02-P-12 mode, press again to
reset 0:00.Under the program of P-01 - PT-12, the time window will ash 30 minutes, and the
addition and subtraction of time can be adjusted before starting. The time range is 5-99 minutes.
After nishing the setting,press the start/stop button on the panel to start 3 seconds countdown
movement.
3. Classify Countdown Mode:
The window displays 0:00 in the standby state.
(1) Press the MODE button on the panel, the window displays H-01, and the window time
ashes 30 minutes. Press the plus and minus speed button on the panel to adjust the addition
and subtraction of the time. The time range is 5-99 minutes.
(2) Press the MODE button again, the window displays H-02, the window distance flashes 1
miles, press the plus and minus speed button on the panel to adjust the distance, the distance
range is 1-99 miles.
(3) Press the MODE button again, the window displays H-03, the window calorie ashes 50 kcal,
press the plus and minus keys on the panel to adjust the calorie, the calorie range is 20-990
kcal.
After nishing the setting,press the start/stop button on the panel to start 3 seconds countdown
movement.

10
EN
Product Maintenance
Lubricating
After the running belt has been used for a period of time, it must be lubricated with 100% silicone
treadmill lubricant oil.
1.Recommendations:
--Use less than 3 hours per week, lubricate once every 5 months.
--Use 4-7 hours a week, lubricate once every 2 months
--Use more than 7 hours a week, lubricate once a month
Don'tuse an excessive amount of lubricating agent.It is not that the more lubricant, the better
e󰀨ect. Reasonable lubrication is an important factor to increase the service life of the treadmill.
2. Lubrication method
The way to check whether you need to add lubricant is to grab the running belt and touch the
center of the back of the running belt with your hands as much as possible. If there is silicone oil (a
litte damp feeling)inside the running bet, it means no need to add lubricant. If the running board
is dry and no silicone is felt in the running belt, you need to add lubricant.
(1) The steps of applying lubricant to the running board;(As shown as picture)
(2) Stop the running belt and fold the machine;
(3) Lift the running belt on the back of the mainframe, extend the oil can into the running belt
movement position as much as possible. Spray silicone oil on the inside of the treadmill, and
apply silicone oil on both sides of the running belt, then start the treadmill with a speed 0.6 mph
to evenly spread the lubricant. Liahtly step on the running belt from left to right, the lubricant can
be completely absorbed by the running belt after a few minutes.
Running belt
Running board
Running board
Lubrication oil

11
EN
4. Running belt deviation adjustment
All treadmils need to be adjusted before they are shipped from the factory and after they are
installed.However, after a period of time, they may stll run o󰀨 the track. There may be several
reasons for this phenomenon:
(1) The host is not placed at;
(2) The user's feet are not in the center of the running belt during exercise;
(3) When the user exercises, the feet are not evenly stressed, which will artificially cause
the running belt to deviate. It can be restored to a normal state after a few minutes of noload
running. For the deviation of the running belt that cannot be automatically restored, you can use
the 6mm wrench in the accessory kit to gradually adjust it in quarters of a circle as the unit. The
running belt deviation does not belong to the range of warranty, and it is mainly up to the user to
maintain and maintain according to the instructions. Deviation will seriously damage the running
belt, and it must be detected and corrected in time.
a.Running belt skidding:When a person is running, the running belt has the phenomenon of
sliding or momentary pause;
b. Adjusting the running belt: Tighten the screws on the left and right sides of the running belt,
turn it clockwise three times, and then adjust according to the deviation direction of the running
bet. If it shifts to the right, adjust the right side; if it shifts to the left, adjust to the left side, until the
running belt is centered.
The running belt shifts to the right,
tighten the right side
Fine adjustment of the left and right
balance
Fine adjustment of the left and right
balance
The running belt shifts to the left,
tighten the left side

12
EN
FCC ID: 2A48IJF-H-42H
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment o󰀨 and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.

13
EN
Common Troubleshooting Methods

13
DE
KATALOG
Produkt kurze Einführung 14
Sicherheitsvorkehrungen und Warnhinweise 15
Hauptparameter und Kongurationsliste 16
Produktinstallationsanleitung 17
Anweisungen zur Falt- und Neigungseinstellung 18
Fitness-Ratschläge und Richtlinien 19
Produktanweisungen 20
Produktpege 22
Allgemeine Methoden zur Fehlerbehebung 24
...................................................................
.....................................
.............................................
..............................................................
................................
.....................................................
..........................................................................
.....................................................................................
........................................

14
DE
Produkt kurze Einführung
Produktmodell: JF-H-42H
Handyhalterung Dashboard-
Komponenten
Linkes
Handlaufrohr
Rechtes Handlaufrohr
Rechtes Standrohr
Linkes
Standrohr
Motorabdeckung
aus Acryl
Torx-Knopf
Fußpolster
Bewegliches Rad
Laufgürtel
Manuelle Steigungen
Gri󰀨 Verriegelungsstift
Eckenschutz
hinten
Seitenleiste
Sicherheitsschloss

15
DE
Sicherheitsvorkehrungen und Warnhinweise
Bitte lesen Sie die Gebrauchsanweisung vor Gebrauch sorgfältig durch
und beachten Sie die folgenden Sicherheitsvorkehrungen:
■ Das Laufband ist für die Aufstellung in Innenräumen geeignet, um Feuchtigkeit zu vermeiden, kein Wasser auf das Laufband
zu spritzen und keine Fremdkörper abzulegen.
■ Bitte tragen Sie vor dem Training geeignete Sportkleidung und Sportschuhe. Es ist strengstens verboten, ohne Schuhe auf
dem Laufband zu trainieren, und es ist am besten, den ganzen Körper vor dem Training zu dehnen.
■ Der Netzstecker muss zuverlässig geerdet sein, und die Steckdose muss eine eigene Schleife haben, damit sie nicht mit
anderen elektrischen Geräten geteilt wird.
■ Kinder sollten sich von der Maschine fernhalten, um Unfälle zu vermeiden.
■ Vermeiden Sie einen Langzeit-Überlastbetrieb, da dies sonst zu Schäden am Motor und der Steuerung führt und die Alterung
der Lager, des Laufbands und des Trittbretts beschleunigt. Führen Sie die Wartung dieser Maschine regelmäßig durch.
■ Reduzieren Sie Staub in Innenräumen, halten Sie eine gewisse Luftfeuchtigkeit in Innenräumen aufrecht. und vermeiden Sie
starke statische Elektrizität, da dies sonst den normalen Betrieb der elektronischen Uhr und des Controllers beeinträchtigen
kann.
■ Bitte schalten Sie das Laufband nach dem Training aus.
■ Bitte halten Sie die Raumluftzirkulation aufrecht, wenn Sie das Laufband benutzen.
■ Bitte befestigen Sie den Sicherheitsschlüssel während des Trainings an der Bekleidungseinlage, um die Maschine im Notfall
sicher und schnell anzuhalten.
■Wenn Sie sich unwohl fühlen und Anomalien während des Gebrauchs haben, hören Sie bitte sofort mit dem Training auf und
konsultieren Sie einen Arzt.
■ Nach der Verwendung von Silikonöl muss es außerhalb der Reichweite von Kindern aufbewahrt werden, um schwerwiegende
Folgen durch versehentliches Verschlucken zu vermeiden.
Verboten!
■ Verwenden Sie das Produkt nicht in einem Zustand, in dem das Äußere des Produkts gerissen, beschädigt oder abgelöst ist (die
innere Struktur liegt frei) oder wenn das Schweißteil abgelöst ist., Um Unfälle oder Verletzungen zu vermeiden.
■ Springen Sie während des Trainings nicht auf und ab. Andernfalls können Sie stürzen und sich verletzen.
■ Verwenden oder lagern Sie das Gerät nicht an feuchten Orten, wie z. B. im Freien. in der Nähe von Badezimmern und Orten,
die Wassertropfen ausgesetzt sind.
■ Verwenden oder lagern Sie es nicht an Orten, die direkter Sonneneinstrahlung ausgesetzt sind. Stellen mit hoher Temperatur,
z. B. in der Nähe von Öfen, oder auf Heizgeräten, z. B. elektrischen Heizteppichen. Andernfalls kann es zu Kriechströmen oder
Bränden kommen.
■ Verwenden Sie es nicht, wenn das Netzkabel oder der Netzstecker beschädigt ist oder die Buchse der Steckdose lose ist.
Andernfalls kann es zu Stromschlägen, Kurzschlüssen oder Bränden kommen.
■ Beschädigen oder biegen oder verdrehen Sie das Netzkabel nicht. Stellen Sie gleichzeitig keine schweren Gegenstände
darauf und lassen Sie die Schnur nicht einklemmen. Um keinen Brand oder Stromschlag zu verursachen.
■ Verwenden Sie dieses Gerät nicht gleichzeitig mit zwei oder mehr Personen, und achten Sie bitte darauf, dass Personen
in Ihrer Umgebung während des Gebrauchs nicht in die Nähe des Geräts kommen. Andernfalls kann es zu Unfällen oder
Verletzungen durch Herunterfallen kommen.
■ Verwenden Sie es nicht, wenn Sie Ihr Bewusstsein nicht ausdrücken oder es nicht selbst bedienen können, um Unfälle oder
Verletzungen zu vermeiden.
■ Kontakt mit Wasser und Flüssigkeiten vermeiden! Setzen Sie das Hauptgehäuse oder die Betriebsteile nicht Wasser oder
Flüssigkeiten aus. Andernfalls kann es zu Stromschlägen oder Bränden kommen.
■ Personen, die normalerweise keinen Sport treiben, sollten nicht plötzlich kräftig trainieren.
■ Verwenden Sie dieses Produkt nicht nach dem Essen, wenn Sie sich müde fühlen, direkt nach dem Training oder wenn Ihre
körperliche Kraft nicht normal ist. Andernfalls kann es Ihrer Gesundheit schaden,
■ Dieses Produkt ist für den Familiengebrauch geeignet, nicht geeignet für Schulen, ö󰀨entliche Einrichtungen und andere Orte
mit vielen Menschen. Andernfalls besteht Verletzungsgefahr.
■ Verwenden Sie es nicht beim Essen oder bei anderen Aktivitäten.
■ Verwenden Sie es nicht, nachdem Sie Alkohol getrunken haben oder wenn Sie das Gefühl haben, dass Ihr Verhalten stumpf
geworden ist, um keinen Unfall oder Verletzungen zu verursachen.
■ Stecken Sie keine harten Gegenstände in Ihre Kleidertaschen. Bitte legen Sie Wertgegenstände wie Uhren, Armbänder,
Mobiltelefone und scharfe Gegenstände wie Kevys und Messer vor dem Gebrauch ab, um Schäden an den Gegenständen oder
körperliche Verletzungen zu vermeiden.
■ Bitte prüfen Sie vor Gebrauch, ob Fremdkörper wie Nadeln, Abfall oder Wasser am Netzstecker haften. Um keinen
Stromschlag, Kurzschluss oder Brand zu verursachen.
■ Nicht mit nassen Händen verwenden! Ziehen Sie den Netzstecker nicht mit nassen Händen heraus oder stecken Sie ihn ein.
Um keinen Stromschlag oder Verletzungen zu verursachen.
■ Netzstecker ziehen! Ziehen Sie bei Nichtgebrauch den Netzstecker aus der Steckdose. Um die Verschlechterung der
Isolierung durch Staub und Feuchtigkeit zu vermeiden, was zu elektrischen Leckagen und Bränden führen kann.

16
DE
Hauptparameter und Kongurationsliste
Technische Hauptparameter
Seriennummer Beschreibung Parametername
1Nennspannung 220-240V/50-60Hz
2Steuerungsmethode Meter-Touch-Typ, APP
3Anzeigemethode LED, APP
4Steigung 3 Manuelle Steigung
5Geschwindigkeitsbereich 1-16km/h
6Laufbandgröße 430*1100mm (L.*W.)
7Produkt entfaltete Größe 1375*750*1250mm(L.*W.*H.)
8Produktgewicht N.W:39kg G.W.:45kg
9Verpackungsgröße 1470*800*280mm(L.*W.*H.)
10 FCC ID 2A48IJF-H-42H
Zubehörpaketliste
Serial number Name Quantity
1Sicherheitsschlüssel 1
2L-Schlüssel (6 mm) 1
3Netzkabel 1
4Produkthandbuch 1
5Handyhalterung 1
6Torx-Knopf 2
Verpackungsmaterialliste
Seriennummer Name Menge
1Hauptmaschine 1PCS
2Zubehörpaket 1PCS

17
DE
Produktinstallationsanleitung
Schritt 1. Nehmen Sie das Produkt aus der
Verpackung, entfernen Sie den äußeren PE-
Beutel und legen Sie es auf einen ebenen
Boden.
Schritt 2. Nehmen Sie den Torx-Knopf aus
dem Zubehörbeutel. Halten Sie das Standrohr
von Hand und drehen Sie es in Pfeilrichtung,
nehmen Sie dann den Torx-Knopf heraus und
richten Sie ihn mit dem Schraubenloch aus,
um ihn im Uhrzeigersinn zu verriegeln, damit
das Standrohr fest sitzt und nicht wackelt. (Die
Installationsmethode ist für links und rechts
gleich)
Schritt 3. Nehmen Sie den Handyhalter und
das Sicherheitsschloss aus der Zubehörtasche.
Klappen Sie die linke und rechte Armlehne
im Uhrzeigersinn, um sie in Pfeilrichtung
auszurichten. Richten Sie den Handyhalter an
der Instrumententafel aus und stecken Sie ihn
in den rechteckigen Kartenschlitz. Bringen Sie
das Sicherheitsschloss in der Mitte der gelben
Position an.
Sicherheitsschlüssel
Schritt 4. Nehmen Sie das Netzkabel aus der
Zubehörtasche, führen Sie es entsprechend
der Richtung in die Rahmenrohrbuchse ein und
stecken Sie es fest ein, stecken Sie das andere
Ende in die 220-240-V-Steckdose und drehen
Sie den Netzschalter auf die Symbolposition
"—". Nachdem das Licht an ist, können Sie
beginnen Verwendung des Produkts.
