Flymo SimpliTrim Li 9679861 Series User manual

EN Operator’s manual
Battery Trimmer
SimpliTrim Li 9679861-xx
®
Remark: “xx” stands for customer and country
variants. The basic product number is before the
hyphen.
Page 1 width 2 mm less: 208 mm
42014-85.960.02.indd 142014-85.960.02.indd 1 15.09.21 09:5915.09.21 09:59

2
Fold-out Page width 5 mm less: 205 mm
Fold-out Page width 5 mm less: 205 mm
42014-85.960.02.indd 242014-85.960.02.indd 2 15.09.21 09:5915.09.21 09:59

3
Fold-out Page width 5 mm less: 205 mm
Fold-out Page width 5 mm less: 205 mm
A1
1
2
30
A2
12
4
5
3
A3
ß
A1
ß
A2
4
O1
X
V
ß
F
å
O2
1
5
2
O3
1 6 2
7
M1
8
8
4
T1
A
9
3
T2
B
3
9
42014-85.960.02.indd 342014-85.960.02.indd 3 15.09.21 09:5915.09.21 09:59

4
Page 2 width 2 mm less: 208 mm
EN Battery Trimmer
1. SAFETY ...............................................4
2. ASSEMBLY ............................................5
3. OPERATION............................................5
4. MAINTENANCE .........................................6
5. STORAGE .............................................6
6. TROUBLESHOOTING ....................................6
7. TECHNICAL DATA .......................................6
8. ACCESSORIES .........................................7
9. SERVICE / WARRANTY ...................................7
Original instructions.
This product may be used under super-
vision, or if instruction regarding the safe
use of the product has been provided and the
resulting dangers have been understood, by chil-
dren aged 8 and above, as well as by persons
with physical, sensory or mental disabilities or
a lack of experience and knowledge. Children
must not be allowed to play with the product.
Cleaning and user maintenance must not be per-
formed by children without supervision. The use
of this product by young people under the age
of 16 is not recommended.
Intended use:
The FLYMO Trimmer is intended to trim and to cut lawn and areas of grass
in private domestic gardens and allotments.
The product is not intended for long term use.
DANGER! Risk of injury!
v Do not use the product to cut lawns / lawn edges, to chop up
material or to make compost.
IMPORTANT!
Read the operator’s manual carefully before use and keep for future
reference.
Symbols on the product:
Read operator’s manual.
Keep bystanders away.
Always wear approved hearing protection.
Always wear approved eye protection.
Do not expose to rain.
For the charger:
Remove plug from the mains immediately if the cable
is damaged or cut.
General safety warnings
Electrical safety
DANGER! Electric shock!
Risk of injury due to electric shock.
v The product must be supplied through a residual current device (RCD)
having a rated residual operating current not exceeding 30 mA.
Do not overreach and keep the balance at all times. Always be sure of the footing
on slopes. Walk, never run.
Do not touch moving hazardous parts before the machine is disconnected from
the mains and the moving hazardous parts have come to a complete stop.
1. SAFETY
Always wear substantial footwear and long trousers while operating the machine.
Safe operating practices
1 Training
a) Read the instructions carefully. Be familiar with the controls and the correct
use of the machine.
b) Never allow children or people unfamiliar with these instructions to use the
machine. Local regulations can restrict the age of the operator.
c) Keep in mind that the operator or user is responsible for accidents or hazards
occurring to other people or their property.
2 Preparation
a) Before use check the supply and extension cord for signs of damage or
aging. If the cord becomes damaged during use, disconnect the cord from
the supply immediately. DO NOT TOUCH THE CORD BEFORE DISCON-
NECTING THE SUPPLY. Do not use the machine if the cord is damaged or
worn.
b) Before use, always visually inspect the machine for damaged, missing or
misplaced guards or shields.
c) Never operate the machine while people, especially children, or pets are
nearby.
3 Operation
a) Keep supply and extension cords away from cutting means.
b) Wear eye protection and stout shoes at all times while operating the machine.
c) Avoid using the machine in bad weather conditions especially when there is
a risk of lightning.
d) Use the machine only in daylight or good artificial light.
e) Never operate the machine with damaged guards or shields or without guards
or shields in place.
f) Switch on the motor only when the hands and feet are away from the cutting
means.
g) Always disconnect the machine from the power supply (i. e. remove the plug
from the mains, remove the disabling device or removable battery):
1) whenever the machine is left unattended;
2) before clearing a blockage;
3) before checking, cleaning or working on the machine;
4) after striking a foreign object;
5) whenever the machine starts vibrating abnormally.
h) Take care against injury to feet and hands from the cutting means.
i) Always ensure that the ventilation openings are kept clear of debris.
4 Maintenance and storage
a) Disconnect the machine from the power supply (i. e. remove the plug from the
mains, remove the disabling device or removable battery) before carrying out
maintenance or cleaning work.
b) Use only the manufacturer’s recommended replacement parts and acces-
sories.
c) Inspect and maintain the machine regularly. Have the machine repaired only
by an authorized repairer.
d) When not in use, store the machine out of the reach of children.
Additional safety warnings
Battery safety
DANGER! Fire risk!
The battery product to be charged must be placed on a nonflammable,
heat resistant and non-conductive surface while charging.
Keep corrosive, flammable and easily combustible objects clear of the
battery charger and the battery product.
Do not cover the battery charger and the battery product while charging.
Disconnect the battery charger immediately in the event of smoke formation
or fire.
Only use the original FLYMO Charger to charge the battery. The use of other
battery chargers may damage the batteries irreparably and even cause a fire.
Do not charge any third-party batteries. There is a risk of fire and explosion!
If you notice fire: Extinguish the flames with oxygen reducing materials.
DANGER! Risk of explosion!
Protect battery products from heat and fire. Do not leave on radiators or
expose to strong sunshine for long periods.
Do not operate in explosive atmospheres, such as in the presence of
flammable liquids, gases, or dust. Battery products may create sparks
which could ignite the dust or fumes.
Only charge and use the battery product in ambient temperatures of between
0°C and 40 °C. Allow battery to cool down after long periods of use.
Check the charging cable regularly for signs of damage or ageing (brittleness).
Only use it in perfect condition.
Do not stow or transport the battery product above 45 °C or in direct sunlight.
Ideally, the battery product should be stored below 25 °C so that self-discharge
is low.
42014-85.960.02.indd 442014-85.960.02.indd 4 15.09.21 09:5915.09.21 09:59

5
Page 2 width 2 mm less: 208 mm
2. ASSEMBLY
DANGER! Risk of injury!
Cut injury when the product starts accidentally.
v Wait for the plastic blades to stop before you assemble the
product.
To assemble the additional handle [ Fig. A1 ]:
vSlide the additional handle 1on the top part of the handle 2until it
audibly engages (click).
The scope of delivery includes 5 plastic blades 3. There are 4 spare pla-
stic blades in the magazine 0.
For the assembly of the plastic blade into the blade holder,
see 6. TROUBLESHOOTING “To replace the plastic blade”.
Do not expose the battery product to rain or wet conditions. Water entering
a battery product will increase the risk of electric shock.
If usage of the battery is not planned for a certain time (winter period) reload
the battery to avoid a deep discharge.
Do not store the battery product in places where static electricity is present.
Electrical safety
DANGER! Cardiac arrest!
This product makes an electromagnetic field while it operates. This field
may under some conditions interfere with active or passive medical
implants. To decrease the risk of conditions that can possibly injure or
kill, we recommend persons with medical implants to speak with their
physician and the medical implant manufacturer before you operate the
product.
Thoroughly inspect the area where the product is to be used and remove all
wires and other foreign objects.
Before using the product and after any impact, check for signs of wear or
damage and repair as necessary.
If the product can no longer be switched off in the event of a defect, place the
product on a solid surface and monitor it until the battery is empty. Send the
defective product to our FLYMO Service Centre.
Never attempt to use an incomplete product or one with an unauthorised modifi-
cation.
Stop the product if the product starts to vibrate abnormally. Check immediately.
Excessive vibration can cause injury.
Do not use the product nearby a water.
Do not operate next to swimming pools or garden ponds.
Personal safety
DANGER! Risk of suffocation!
Small parts can be easily swallowed. There is also a risk that the polybag
can suffocate toddlers. Keep toddlers away when you assemble the
product.
DANGER! Risk of injury!
If the device switches off due to an empty battery (charging control
lamp ;flashes green), it may happen that the battery recovers after
a certain time. The device is then ready for operation again.
Use personal protective equipment.
Wear gloves for cleaning the cutting device.
Always wear eye protection.
Protective equipment such as gloves, non-skid safety shoes, or hearing protec-
tion used for appropriate conditions will reduce personal injuries.
Be careful during adjustment of the product to prevent entrapment of the fingers
between moving and fixed parts of the machine.
Don’t use water, or chemical substances for cleaning the guard or other parts of
the trimmer.
Keep all nuts, bolts and screws tight to be sure the product is in a safe working
condition.
Do not disassemble the product further than the delivery status.
Warning! When wearing hearing protection, and due to the noise produced by
the product, the operator may not notice persons approaching.
While operation and transport pay special attention to the hazard for other
people.
Stay alert, watch what you are doing and use common sense when operating
a power tool.
Do not use a power tool while you are tired or under the influence of drugs,
alcohol or medication.
A moment of inattention while operating power tools may result in serious
personal injury.
To assemble the protective cover [ Fig. A2 /A3 ]:
DANGER!
The product may only be used when the protective cover
is assembled.
1. Put the protective cover 4to the trimmer head 5while you feed the
plastic blade 3through the opening in the protective cover 4.
2. Rotate the protective cover 4until it can be completely pushed on
(the arrows ß
A1
/ ß
A2
face each other).
3. Rotate the protective cover 4anti-clockwise until the connection
audibly engages. (click).
3. OPERATION
DANGER! Risk of injury!
Cut injury when the product starts accidentally.
v Wait for the plastic blade to stop before you transport the
product.
To charge the battery [ Fig. O1 ]:
CAUTION!
Overvoltage damages the battery and the charging power
supply.
v Make sure that you use the correct mains voltage.
Before you use the battery the first time, the battery must be completely
charged.
The lithium-ion battery can be charged in any state of charge and the
charging process can be disconnected at any time without to damage
the battery (no memory effect).
1. Connect the charging power supply Xinto a mains socket.
The power LED åilluminates red.
2. Connect the battery charger cable Vto the charging socket ß
F
.
When the charging control lamp ß
F
at the charging socket
flashes green, the battery is being charged.
When the charging control lamp ß
F
at the charging socket
illuminates green, the battery is completely charged
(Charging time see 7. TECHNICAL DATA).
3. Examine the charge status regularly while you charge.
4. When the battery is completely charged, disconnect the battery charger
cable Vfrom the charging socket ß
F
.
5. Disconnect the charging power supply Xfrom the mains.
Work position [ Fig. O2 ]:
vHold the product by the additional handle 1and the main handle 2
so that the trimmer head 5is tilted a small distance forward.
Avoid contact of the plastic blade and the blade carrier with hard objects
(walls, stones fences etc.) to prevent the plastic blade and the blade car-
rier from wearing or breaking.
To start the trimmer [ Fig. O3 ]:
DANGER! Risk of injury!
Risk of injury if the product does not stop when you
release the start lever.
v Do not bypass the safety devices or switches. For example do
not attach the start lever to the handle.
To start:
The product is provided with a two-switch safety device (start lever
with starting lockout) to prevent the product from being turned on
by accident.
1. Hold the additional handle 1with one hand.
2. Hold the main handle 2with the other hand, push the starting
lockout 6forward and pull the start lever 7.
The trimmer starts.
3. Release the starting lockout 6again.
To stop:
vRelease the start lever 7.
The trimmer stops in a few seconds.
42014-85.960.02.indd 542014-85.960.02.indd 5 15.09.21 09:5915.09.21 09:59

6
4. MAINTENANCE
DANGER! Risk of injury!
Cut injury when the product starts accidentally.
v Wait for the plastic blade to stop before you maintain the
product.
To clean the Trimmer [ Fig. M1 ]:
DANGER! Risk of injury!
Risk of injury and risk of damage to the product.
v Do not clean the product with water or with a water jet
(in particular high-pressure water jet).
v Do not clean with chemicals including petrol or solvents.
Some can destroy critical plastic parts.
The airflow slots must always be clean.
1. Clean the airflow slots 8with a soft brush (do not use a screwdriver).
2. Clean all movable parts after each operation. Especially remove any
grass and dirt from the protective cover 4.
To clean the charging power supply:
Make sure that the contacts of the charging socket and the charging
power supply always are clean and dry before you connect the charging
power supply.
Do not use running water.
v Clean the contacts and the plastic parts with a soft and dry cloth.
5. STORAGE
To put into storage:
The product must be stored away from children.
1. Charge the battery.
2. Clean the trimmer and the charging power supply
(see 4. MAINTENANCE).
3. Store the trimmer and the charging power supply in a dry, enclosed
and frost-free place.
Disposal:
(in accordance with RL2012/19/EC / S.I. 2013 No. 3113)
The product must not be disposed of to normal household
waste. It must be disposed of in line with local environmental
regulations.
Li-ion
The FLYMO battery contains lithium-ion cells that should
not be disposed of with normal household waste at the
end of its life.
IMPORTANT!
v Dispose of the product through or via your municipal recycling collection
centre.
6. TROUBLESHOOTING
DANGER! Risk of injury!
Cut injury when the product starts accidentally.
v Wait for the plastic blade to stop before you troubleshoot
the product.
To replace the plastic blade [ Fig. T1 / T2 ]:
DANGER! Risk of cutting injuries!
v Do not use metal cutting elements or spare parts and
accessories not intended for use by FLYMO.
The plastic blades may only become worn to half the original
length at most. Only use original FLYMO Spare Blades FLY083.
Spare plastic blades are available from your FLYMO dealer or
direct from FLYMO Service.
• FLYMO Spare Blades for SimpliTrim Li FLY083 – PNC 598523101
To remove the plastic blade:
1. Turn the trimmer over.
2. Push the end of the plastic blade down slightly (A), slide the plastic
blade 3inside through the blade carrier 9(B) and pull out.
To insert the plastic blade:
vSlide the new plastic blade 3from inside through the slot in metal of
the blade carrier 9until it audibly engages (click).
When the new plastic blade is correctly inserted, it can be moved more
easily.
Problem Possible Cause Remedy
Trimmer is not cutting
cleanly or not cutting at all
Plastic blade is worn or too
short.
v Replace the plastic blade.
Plastic blade is broken off. v Replace the plastic blade.
Trimmer vibrates severely Plastic blade is excessively
worn and creates an unbalance.
v Replace the plastic blade.
Blade carrier is worn. v Replace the blade carrier.
Trimmer does not start.
Charging control lamp ;
flashes green
Under voltage. v Charge the battery.
Trimmer does not start.
Charging control lamp ;
flashes red
Battery overload. v Release the start lever.
Start again.
Engine is blocked. v Remove the obstacle.
Start again.
Battery temperature is out of
range.
v Use the battery in surround-
ings where temperatures are
between 0 °C and 40 °C.
Power LED åon the
charging power supply
does not illuminate
Charging power supply is not
plugged in correctly.
v Plug the charging power
supply into a wall outlet.
NOTE: For any other malfunctions please contact the FLYMO service depart-
ment. Repairs must only be done by FLYMO service departments or specialist
dealers approved by FLYMO.
7. TECHNICAL DATA
Battery Trimmer Unit Value (9679861-xx)
Cutting width cm 23
Rpm of blade carrier R/min. 9500
Weight kg 1.7
Sound pressure level LpA
1)
Uncertainty kpA
dB(A) 70.2
2.5
Sound power level LWA
2):
measured/guaranteed
Uncertainty kWA
dB(A)
84 / 88
4
Hand/arm vibration avhw
1)
Uncertainty ka
m/s2< 2.5
1.5
Measuring process complying with: 1) EN 50636-2-91 2) RL 2000/14/EC / S.I. 2001 No.1701
NOTE: The stated vibration emission value has been measured according to
a standardized test procedure and can be used for comparison of one electric
power tool with another. It can also be used for preliminary evaluation of
exposure. The vibration emission value can vary during actual use of the electric power
tool.
Battery Unit Value
Battery voltage V (DC) 14.4
Battery capacity Ah 2.0
Battery charging time
80 % / 100 % (approx.) min. 160 / 200
Charging Power Supply Unit Value (PNC 598446701)
Mains voltage V (AC) 100 – 240
Mains frequency Hz 50 – 60
Rated Power W 15
Output voltage V (DC) 18.5
Max. output current mA 600
42014-85.960.02.indd 642014-85.960.02.indd 6 15.09.21 09:5915.09.21 09:59

7
8. ACCESSORIES
FLYMO Charging Power
Supply
Charger to charge the internal batteries. PNC 598446701
FLYMO Spare Blades for
SimpliTrim Li
As replacement for consumed plastic blades. Art. FLY083
PNC: 598523101
9. SERVICE / WARRANTY
Service:
Please contact the address on the back page.
Warranty statement:
In the event of a warranty claim, no charge is levied to you for the services
provided.
Husqvarna UK Ltd. grants a warranty for all original FLYMO new products
for two years from the date of original purchase from the retailer, provided
that the devices have been for private use only. This manufacturer’s
warranty does not apply to products acquired second hand. This warranty
includes all significant defects of the product that can be proved to be
material or manufacturing faults. This warranty is fulfilled by supplying
afully functional replacement product or by repairing the faulty product
sent to us free of charge; we reserve the right to choose between these
options. This service is subject to the following provisions:
• The product has been used for its intended purpose as per the recom-
mendations in the operating instructions.
• Neither the purchaser nor a third party has attempted to open or repair
the product.
• Only Original FLYMO replacement parts and wear parts have been used
for operation.
• Presentation of the receipt.
Normal wear and tear of parts and components (such as blades, blade
fixing parts, turbines, light bulbs, V-belts / toothed belts, impellers, air
filters, spark plugs), visual changes, wear parts and consumables are
excluded from the warranty.
This manufacturer’s warranty is limited to replacement and repair of
products in accordance with the abovementioned conditions. The
manufacturer’s warranty does not constitute an entitlement to lodge
other claims against us as a manufacturer, such as for damages.
This manufacturer’s warranty does not, of course, affect statutory and
contractual warranty claims against the dealer / retailer.
The manufacturer’s warranty is governed by the law of the Federal
Republic of Germany.
In case of a warranty claim, please return the faulty product, together
with a copy of the receipt and a description of the fault, with postage
paid to the service address.
Consumables:
The plastic blades are consumables and are not included in the warranty.
42014-85.960.02.indd 742014-85.960.02.indd 7 15.09.21 09:5915.09.21 09:59

8
In accordance with the German Product Liability Act, we hereby expressly declare that we accept no liability for damage incurred from our products
where said products have not been properly repaired by a FLYMO-approved service partner or where original FLYMO parts or parts authorised by
FLYMO were not used.
PRODUCT LIABILITY
The undersigned hereby certifies as the authorized representative of the manufacturer, Husqvarna AB, 561 82 Huskvarna, Sweden, that, when leaving
our factory, the unit(s) indicated below is / are in accordance with the harmonised EU guidelines, EU standards of safety and product specific standards.
This certificate becomes void if the unit(s) is / are modified without our approval.
EC DECLARATION OF CONFORMITY
Description of the product: Lawn Trimmer SimpliTrim
Product type: Li
Article-Number: 9679861-xx
CE-Directives: 2006/42/EC
2014/30/EU
2011/65/EU
2000/14/EC
Charger:
2014/35/EU
Harmonised EN: EN ISO 12100
EN 60335-1
EN 50636-2-91
Charger:
EN 61558-1
EN 61558-2-16
Deposited Documentation: GARDENA Technical Documentation,
M. Jäger, 89079 Ulm
Conformity Assessment according to: 2000/14/EC Procedure: art. 14 Annex VI
Noise level: measured / guaranteed 84 dB (A) / 88 dB (A)
Ulm, 07.09.2021
Authorised representative:
Reinhard Pompe
Vice President Products
Wolfgang Engelhardt
Vice President Supply Chain
42014-85.960.02.indd 842014-85.960.02.indd 8 15.09.21 09:5915.09.21 09:59

9
UKCA DECLARATION OF CONFORMITY (ONLY FOR UK)
The manufacturer: Husqvarna AB SE 561 82 Huskvarna, Sweden hereby certifies, when leaving our factory, the unit(s) indicated below is/are in accord-
ance with the UKRegulations, designated standards of safety and product specific designated standards. This certificate becomes void if the units are
modified without our approval.
Description of the Product: Lawn Trimmer SimpliTrim
Product type: Li
Article Number: 9679861-xx
UK regulations: S.I. 2008/1597
S.I. 2016/1091
S.I. 2012/3032
S.I. 2001/1701
Charger:
S.I. 2016/1101
Designated Standards: EN ISO 12100
EN 60335-1
EN 50636-2-91
Charger:
EN 61558-1
EN 61558-2-16
Authorised Representative: Husqvarna UK Limited
Deposited Documentation: Preston Road,
Aycliffe,
County Durham
UK
DL5 6 UP
Noise level: measured / guaranteed 84 dB(A) / 88 dB(A)
Conformity Assessment according to: According to S.I. 2001/1701 Art, 11 Schedule 9
Aycliffe, 07.09.2021
Authorised Representative:
John Thompson
Director
42014-85.960.02.indd 942014-85.960.02.indd 9 15.09.21 09:5915.09.21 09:59

10
42014-85.960.02/0921
Husqvarna AB
S-561 82 Huskvarna
Sweden
Our policy of continuous improvement means that the specification of products may be altered from time to time without prior notice.
Copyright © 2021 Flymo S.A. All rights reserved.
Flymo®and other product and feature names are registered or unregistered trademarks of Flymo S.A.
Service Address and Importer to
Great Britain
Husqvarna UK Ltd
Preston Road
Aycliffe Industrial Park
Newton Aycliffe
County Durham
DL5 6UP
Phone:[phone]
[email protected]
42014-85.960.02.indd 1042014-85.960.02.indd 10 15.09.21 09:5915.09.21 09:59
