Flymo SimpliVac Li User manual

EN Operators Manual
Battery Handheld Vacuum Cleaner
SimpliVac Li PNC 967986001
®
EN

A1
2
1
A2
3
;
O1
;
V
X
å
O2
ß
Fc
VX
å
O3
9
8
O4
45
O5
6
7
M1
1
276
90
8
q
3

1. SAFETY ...................................11
2. ASSEMBLY ................................13
3. OPERATION................................14
4. MAINTENANCE .............................14
5. STORAGE .................................15
6. TROUBLESHOOTING ........................15
7. TECHNICAL DATA ...........................15
8. ACCESSORIES .............................16
9. SERVICE / WARRANTY........................16
Original instructions.
This product may be used under
supervision, or if instruction
regarding the safe use of the product has
been provided and the resulting dangers
have been understood, by children aged
8and above, as well as by persons with
physical, sensory or mental disabilities or
a lack of experience and knowledge.
Children must not be allowed to play with
the product. Cleaning and user mainte-
nance must not be performed by children
without supervision. The use of this prod-
uct by young people under the age of
16is not recommended.
Intended use:
The FLYMO Handheld Battery Vacuum Cleaner
is intended to vacuum various dry and moist particles,
in private domestic gardens and allotments.
The product is not intended for continuous operation.
DANGER! Risk of injury!
Do not vacuum ash with the product, especially
hot ash.
1. SAFETY
IMPORTANT!
Read the operator’s manual carefully before use
and keep for future reference.
Symbols on the product:
Read operator’s manual.
Keep bystanders away.
Wear eye and ear protection.
Do not expose to rain.
For the charger:
Remove plug from the mains immediately
if the cable is damaged or cut.
Do not use the charging station outdoors.
General safety warnings
Electrical safety
DANGER! Electric shock!
Risk of injury due to electric shock.
The product must be supplied through a residual
current device (RCD) having a rated residual
operating current not exceeding 30 mA.
The machine may not be operated if persons, especially
children, or pets are in the area.
Walk, don't run.
Do not operate the machine in bad weather conditions,
especially when there is a risk of lightning.
Safe operating practices
1. Training
a) Read the instructions carefully. Be familiar with the
controls and the correct use of the machine.
b) Never allow children or people unfamiliar with these
instructions to use the machine. Local regulations can
restrict the age of the operator.
c) Keep in mind, that the operator or user is responsible
for accidents or hazards occurring to other people or
their property.
2. Preparation
a) Obtain ear protection and safety glasses. Wear them
at all times while operating the machine.
b) While operating the machine always wear substantial
footwear and long trousers. Do not operate the
machine when barefoot or wearing open sandals.
Avoid wearing clothing that is loose fitting or that
has hanging cords or ties.
c) Do not wear loose clothing or jewellery that can be
drawn into the air inlet. Keep long hair away from the
air inlets.
FLYMO Battery Handheld Vacuum Cleaner
SimpliVac Li
4
EN

d) Operate the machine in a recommended position and
only on a firm, level surface.
e) Do not operate the machine on a paved or gravel sur-
face where ejected material could cause injury.
f) Before using, always visually inspect to see, that the
shredding means, shredding means bolts and other
fasteners are secure, the housing is undamaged and
that guards and screens are in place. Replace worn
or damaged components in sets to preserve balance.
Replace damaged or unreadable labels.
g) Before use, check the supply and extension cord for
signs of damage or aging. If the cord becomes dam-
aged during use, disconnect the cord from the supply
immediately. DO NOT TOUCH THE CORD BEFORE
DISCONNECTING THE SUPPLY. Do not use the
machine if the cord is damaged or worn.
h) Never operate the machine while people, especially
children, or pets are nearby.
3. Operation
a) Before starting the machine, make certain that the
feeding chamber is empty.
b) Keep your face and body away from the feed intake
opening.
c) Do not allow hands or any other part of the body or
clothing inside the feeding chamber, discharge chute,
or near any moving part.
d) Keep proper balance and footing at all times. Do not
overreach. Never stand at a higher level than the
base of the machine when feeding material into it.
e) Always stand clear of the discharge zone when
operating this machine.
f) When feeding material into the machine be extremely
careful that pieces of metal, rocks, bottles, cans or
other foreign objects are not included.
g) If the cutting mechanism strikes any foreign objects
or if the machine should start making any unusual
noise or vibration, immediately shut off the power
source and allow the machine to stop. Disconnect
the machine from the supply and take the following
steps before restarting and operating the machine:
– inspect for damage;
– replace or repair any damaged parts;
– check for and tighten any loose parts.
h) Do not allow processed material to build up in the
discharge zone; this may prevent proper discharge
and can result in kickback of material through the
intake opening.
i) If the machine becomes clogged, shut-off the power
source and disconnect the machine from supply
before cleaning debris.
j) Never operate the machine with defective guards or
shields, or without safety devices.
k) Keep the power source clean of debris and other
accumulations to prevent damage to the power source
or possible fire.
l) Do not transport this machine while the power source
is running.
m) Stop the machine, and remove plug from the socket.
Make sure that all moving parts have come to a com-
plete stop
– whenever you leave the machine,
– before clearing blockages or unclogging chute,
– before checking, cleaning or working on the machine.
n) Do not tilt the machine while the power source is
running.
4. Maintenance and storage
a) When the machine is stopped for servicing, inspection,
or storage, or to change an accessory, shut off the
power source, disconnect the machine from the sup-
ply and make sure that all moving parts are come to
a complete stop. Allow the machine to cool before
making any inspections, adjustments, etc. Maintain
the machine with care and keep it clean.
b) Store the machine in a dry place out of the reach of
children.
c) Always allow the machine to cool before storing.
d) When servicing the shredding means be aware that,
even though the power source is switched off due
to the interlock feature of the guard, the shredding
means can still be moved.
e) Replace worn or damaged parts for safety. Use only
genuine replacement parts and accessories.
f) Never attempt to override the interlocked feature of the
guard.
Additional safety warnings
Battery safety
DANGER! Fire risk!
The battery product to be charged must be placed
on a nonflammable, heat resistant and non-conduc-
tive surface while charging.
Keep corrosive, flammable and easily combustible
objects clear of the battery charger and the battery
product.
Do not cover the battery charger and the battery
product while charging.
Disconnect the battery charger immediately in the event
of smoke formation or fire.
Only use the original FLYMO Charger to charge the
battery. The use of other battery chargers may damage
the batteries irreparably and even cause a fire.
Do not charge any third-party batteries. There is a risk
of fire and explosion!
If you notice fire: Extinguish the flames with oxygen
reducing materials.
DANGER! Risk of explosion!
Protect battery products from heat and fire. Do not
leave on radiators or expose to strong sunshine for
long periods.
Do not operate in explosive atmospheres, such as
in the presence of flammable liquids, gases, or dust.
Battery products may create sparks which could
ignite the dust or fumes.
Only charge and use the battery product in ambient
temperatures of between 0 °C and 40 °C. Allow battery
to cool down after long periods of use.
5
EN

Check the charging cable regularly for signs of damage or
ageing (brittleness). Only use it in perfect condition.
Do not stow or transport the battery product above 45 °C
or in direct sunlight. Ideally, the battery product should be
stored below 25 °C so that self-discharge is low.
Do not expose the battery product to rain or wet condi-
tions. Water entering a battery product will increase the
risk of electric shock.
If usage of the battery is not planned for a certain time
(winter period) reload the battery to avoid a deep dis-
charge.
Do not store the battery product in places where static
electricity is present.
Electrical safety
DANGER! Cardiac arrest!
This product makes an electromagnetic field while
it operates. This field may under some conditions
interfere with active or passive medical implants.
To decrease the risk of conditions that can possibly
injure or kill, we recommend persons with medical
implants to speak with their physician and the medi-
cal implant manufacturer before you operate the
product.
Before using the product and after a powerful impact, check
for signs of wear or damage and repair as necessary.
If the product can no longer be switched off in the event
of a defect, place the product on a solid surface and
monitor it until the battery is empty. Send the defective
product to our FLYMO Service Centre.
Never attempt to use an incomplete product or one with
an unauthorised modification.
Do not charge a damaged product. Please contact the
FLYMO service department.
Personal safety
DANGER! Risk of suffocation!
Small parts can be easily swallowed. There is also
a risk that the polybag can suffocate toddlers. Keep
toddlers away when you assemble the product.
Know how to stop the product quickly in an emergency.
Only work in the daylight or when visibility is good.
Check your product before each use. Always visually
inspect your Hedge Trimmer before each use. Check that
the ventilation slots are not obstructed in any way.
If the product got hot while operation, let it cool down
before storage.
Do not overload the product.
Warning! When wearing hearing protection, and due to
the noise produced by the product, the operator may not
notice persons approaching.
Inspect the filter cage for damages before usage.
Do not use the product with a damaged, or without the
filter cage. The filter cage can be ordered through the
FLYMO service.
Do not use the product without the debris container
assembled.
Do not vacuum any hot, or corrosive materials.
Do not vacuum water.
Do not use the product while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while you operate the product may result
in serious personal injury.
Wait for the engine to stop before you
assemble the product.
To assemble the nozzle [ Fig. A1 ]:
2 nozzles are in the scope of delivery:
– Crevice nozzle, long
– Brush nozzle
To assemble the nozzle:
v Slide the nozzle 1into the suction connection 2until
the nozzle is firmly seated.
If required, the brush head can be slid forward at the brush
nozzle.
To remove the nozzle:
v Remove the nozzle 1from the suction connection 2.
To assemble the charging station on the wall [ Fig. A2 ]:
The screws (diameter 3.5 mm) are not in the scope of
delivery. Suitable fixing material is available from your
specialist store.
v Assemble the charging station to the wall by using the
two holes 3(hole distance 42.6 mm).
If the charging station is mounted on the wall, the nozzle
must be removed to charge the vacuum cleaner (otherwise
the vacuum cleaner will not engage correctly in the charg-
ing station).
The nozzles can be attached to the side of the charging
station.
2. ASSEMBLY
3. OPERATION
Wait for the engine to stop before you adjust
or transport the product.
To charge the battery [ Fig. O1 / O2 ]:
CAUTION!
Overvoltage damages the battery and
the charging power supply.
6
EN

4. MAINTENANCE
Wait for the engine to stop before you main-
tain the product.
To clean the vacuum cleaner [Fig. M1 ]:
DANGER! Risk of injury!
Risk of injury and risk of damage to the
product.
1. Do not clean the product with water or with a
water jet (in particular high-pressure water jet).
2. Do not clean with chemicals including petrol
or solvents. Some can destroy critical plastic
parts.
The airflow slots qmust always be clean.
1. Remove the nozzle 1from the suction connection 2.
2. Push the unlock button 6and pull off the debris
container 7.
3. Empty the debris container 7.
4. Turn the filter cage 8anti-clockwise and remove
the coarse filter cage 8(bayonet lock).
5. Remove the filter 9.
6. Clean all removed parts under running water.
7. Clean the suction opening 0, the airflow slots q
and the motor unit with a dry cloth.
8. Reassemble all parts in reverse order.
To clean the charger:
Make sure that the surface and the contacts of the
charging socket and the charger always are clean and
dry before you connect the charger.
Do not use running water.
Clean the contacts and the plastic parts with a soft and
dry cloth.
v Make sure that you use the correct mains
voltage.
Before you use the battery the first time, the battery must
be completely charged.
The lithium-ion battery can be charged in any state of
charge and the charging process can be disconnected at
any time without to damage the battery (no memory effect).
If the vacuum cleaner switches off during operation, the
battery is empty and must be charged (it may be possible
that the vacuum cleaner can be started again briefly after-
wards, but then switches off automatically immediately).
When the battery charging cable Vis connected to the
charging station, the vacuum cleaner can be charged via
the charging station.
v Insert the vacuum cleaner into the charging station.
1. Connect the charging power supply Xinto a mains
socket.
2. Connect the battery charger cable Vto the charg-
ingsocket of the vaccum ;– or – of the charging
station ß
Fc .
When the battery charging indicator åflashes green,
the battery is being charged.
When the battery charging indicator åilluminates
green, the battery is completely charged
(charging time, see 7. TECHNICAL DATA).
3. Examine the charge status regularly while you charge.
4. When the battery is completely charged, disconnect the
battery charger cable Vfrom the charging socket ;.
5. Disconnect the charging power supply Xfrom the
mains.
Areas of application [ Fig. O3 ]:
To replace the filters, see 4. MAINTENANCE
Clean the vacuum cleaner.
1. For outdoor and indoor use:
With coarse filter 9.
The filter cage 8must not be mounted without the
filter 9.
To start the vacuum cleaner [ Fig. O4 ]:
To start:
v Hold the handle 4and slide the start switch 5forward.
(The start switch remains locked and does not have to
be held).
The vacuum cleaner starts.
To stop:
v Pull the start switch 5backwards.
The vacuum cleaner stops.
To empty the debris container [ Fig. O5 ]:
1. Hold the vacuum cleaner downwards, push the unlock
button 6and pull off the debris container 7.
2. Empty the debris container 7.
3. If necessary, clean the filter (see 4. MAINTENANCE).
4. Place the debris container 7on the bottom of the
vacuum cleaner.
5. Push the debris container 7against the top of the
hand vacuum cleaner until the unlock button 6audibly
engages.
5. STORAGE
To put into storage:
The product must be stored away from children.
1. Charge the battery.
2. Clean the vacuum cleaner and the charging power
supply (see 4. MAINTENANCE).
7
EN

6. TROUBLESHOOTING
Problem Possible Cause Remedy
Vacuum cleaner vacuums poorly Debris container is full. v Empty the debris container.
Filter is dirty. v Clean the filter.
Suction material falls out of
the suction opening
Rubber valve of the debris container
is blocked e.g. by small branches or
leaves.
v Remove blocking suction material
from the rubber valve.
Rubber valve is no longer centered in
the debris container holder.
v Loosen the screw of the valve, cent-
er it and tighten the screw again.
Vacuum cleaner does not start Vacuum cleaner was just discon-
nectedfrom the charger socket.
v Wait approx. 4 Sec. after discon-
necting from the charger socket.
Charging station is mounted on
the wall – vacuum cleaner is not
charging
Nozzle was not removed from
vacuum cleaner.
v Remove the nozzle for charching.
Charging control lamp åon
the charging power supply does
not illuminate
Charging power supply is not
plugged in correctly.
v Plug the charging power supply into
a wall outlet.
Charging control lamp åon
the charger flashes red
Battery temperature is out of range. v Use the battery in surroundings
where temperatures are between
0°C and 40 °C.
NOTE: For any other malfunctions please contact the FLYMO service department.
Repairs must only be done by FLYMO service departments or specialist dealers approved
by FLYMO.
Wait for the engine to stop before you
troubleshoot the product.
7. TECHNICAL DATA
Handheld Battery Vacuum Cleaner Unit Value (PNC 967986001)
Rated current A 8
Suction power l/min. 1500
Weight kg 1.3
Sound pressure level * LPA
1)
Uncertainty kPA
dB (A) 78
2.5
Sound power level * LWA
2)
measured/guaranteed
Uncertainty kWA
dB (A) 86 / 89
3
Hand/arm vibration* avhw
1)
Uncertainty ka
m/s2< 2.5
1.5
Measuring process complying with: 1) EN 50636-2-100 2) RL 2000/14/EC
3. Store the vacuum cleaner and the charging power
supply in a dry, enclosed and frost-free place.
Disposal:
(in accordance with RL2012/19/EC)
The product must not be disposed of to normal
household waste. It must be disposed of in line
with local environmental regulations.
The FLYMO battery contains lithium-ion
cells that should not be disposed of with
normal household waste at the end of its
life. Li-ion
IMPORTANT!
Dispose of the product through or via your municipal
recycling collection centre.
8
EN

9. SERVICE / WARRANTY
Service:
Please contact the address on the back page.
Warranty statement:
In the event of a warranty claim, no charge is levied to you
for the services provided.
Husqvarna UK Ltd. grants a warranty for all original FLYMO
new products for two years from the date of original pur-
chase from the retailer, provided that the devices have been
for private use only. This manufacturer’s warranty does not
apply to products acquired second hand. This warranty
includes all significant defects of the product that can be
proved to be material or manufacturing faults. This warranty
is fulfilled by supplying afully functional replacement prod-
uct or by repairing the faulty product sent to us free of
charge; we reserve the right to choose between these
options. This service is subject to the following provisions:
• The product has been used for its intended purpose as
per the recommendations in the operating instructions.
• Neither the purchaser nor a third party has attempted to
open or repair the product.
• Only Original FLYMO replacement parts and wear parts
have been used for operation.
• Presentation of the receipt.
Normal wear and tear of parts and components (such
as blades, blade fixing parts, turbines, light bulbs, V-belts /
toothed belts, impellers, air filters, spark plugs), visual
changes, wear parts and consumables are excluded from
the warranty.
This manufacturer’s warranty is limited to replacement and
repair of products in accordance with the abovementioned
conditions. The manufacturer’s warranty does not consti-
tute an entitlement to lodge other claims against us as
a manufacturer, such as for damages. This manufacturer’s
warranty does not, of course, affect statutory and con-
tractual warranty claims against the dealer / retailer.
The manufacturer’s warranty is governed by the law of the
Federal Republic of Germany.
In case of a warranty claim, please return the faulty prod-
uct, together with a copy of the receipt and a description
of the fault, with postage paid to the service address.
Consumables:
The filters and nozzles are consumables and are not
included in the warranty.
8. ACCESSORIES
FLYMO Spare Filter (coarse filter) To replace the coarse filter. PNC 593962401
NOTE: The stated vibration emission value has been measured according to a standardized test
procedure and can be used for comparison of one electric power tool with another. It can also be
used for preliminary evaluation of exposure. The vibration emission value can vary during actual
use of the electric power tool.
Battery Unit Value
Battery voltage V (DC) 18
Battery capacity Ah 2.6
Battery charging time 80 % / 100 %
(approx.) min. 205 / 280
Charging Power Supply Unit Value (PNC 598444901)
Mains voltage V (AC) 100 – 240
Mains frequency Hz 50 – 60
Rated Power W 16
Output voltage V (DC) 21
Max. output current mA 600
9
EN

In accordance with the German Product Liability Act, we
hereby expressly declare that we accept no liability for
damage incurred from our products where said products
have not been properly repaired by a FLYMO-approved
service partner or where original FLYMO parts or parts
authorised by FLYMO were not used.
PRODUCT LIABILITY
The undersigned hereby certifies as the authorized
representative of the manufacturer, Husqvarna AB,
561 82 Huskvarna, Sweden, that, when leaving our
factory, the unit(s) indicated below is / are in accordance
with the harmonised EU guidelines, EU standards of safety
and product specific standards. This certificate becomes
void if the unit(s) is / are modified without our approval.
EC DECLARATION OF CONFORMITY
Description of the product: Accu Vacuum Cleaner
Product type SimpliVac Li
Article-Number 9679860-01
CE-Directives 2006/42/EC
2014/30/EU
2011/65/EU
2000/14/EC
2014/35/EU
Harmonised EN EN ISO 12100
EN 60335-1
EN 60335-2-2
IEC 60335-2-100
EN 60335-2-29
Deposited Documentation GARDENA Technical Documentation,
M. Kugler, 89079 Ulm
Conformity Assessment according to 2000/14/EC Procedure: art. 14 Annex V
Year of CE marking: 2019
Noise level: measured / guaranteed 86 dB (A) / 89 dB (A)
Ulm, 29.10.2019
Authorised representative:
John Thompson
Product and Marketing Director EUAP
10

F9340-20.960.01/1019
Husqvarna AB
S-561 82 Huskvarna
Sweden
Our policy of continuous improvement means that the specification of products may be altered from time to time without prior notice.
Copyright © 2015 Flymo S.A. All rights reserved.
Flymo®and other product and feature names are registered or unregistered trademarks of Flymo S.A.
Great Britain
Husqvarna UK Ltd
Preston Road
Aycliffe Industrial Park
Newton Aycliffe
County Durham
DL5 6UP
Phone:[phone]
[email protected]
14
