FMI EL36LD User manual

For more information, visit www.fmiproducts.com
ELECTRIC FIREPLACE/INSERT
SAFETY INFORMATION AND INSTALLATION MANUAL
Patent No. 7,219,456 B1
MODEL EL36LD
PLEASE READ THIS MANUAL BEFORE INSTALLING
AND USING APPLIANCE.
WARNING: If the information in this manual is not fol-
lowed exactly, an electrical shock or re may result caus-
ing property damage, personal injury or loss of life.
FOR YOUR SAFETY
— Do not store or use gasoline or other ammable va-
pors and liquids in the vicinity of this or any other
appliance.
— Installation and service must be performed by a
qualied service agency.
This replace meets the construction and safety stan-
dards of H.U.D. for application in manufactured homes
when installed according to these instructions.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.

www.fmiproducts.com 122663-01E2
SAFETY
WARNING: Improper installa-
tion, adjustment, alteration, ser-
vice or maintenance can cause
injury or property damage. Refer
to this manual. For assistance or
additional information, consult
a qualied installer.
CAUTION: Do not expose the
heater to the elements (such as
rain, etc).
Do not place clothing or other
ammable material on or near
rebox. Never place any objects
on the replace.
Carefully supervise young chil-
dren when they are in the room
with replace.
Fireplace becomes very hot
when running. Keep children and
adults away from hot surfaces to
avoid burns or clothing ignition.
Fireplace will remain hot for a
time after shutdown. Allow sur-
faces to cool before touching.
Do not install replace directly
on carpet or similar surface
which may restrict air circulation
beneath unit.
When using electrical heaters, basic precau-
tions should always be followed to reduce
the risk of re, electric shock and injury to
persons, including the following:
1. Read all instructions before using this
heater.
2. Keep combustible materials, such as
furniture, pillows, bedding, papers, clothes
and curtains at least 3 feet (0.9 m) from
front of heater.
3. This heater is hot when in use. To avoid
burns, do not let bare skin touch hot surfac-
es. The grill directly in front of heater outlet
becomes hot during heater operation.
4. Extreme caution is necessary when any
heater is used by or near children and
whenever heater is left operating and
unattended.
5. Always unplug heater when not in use.
6. Do not operate any heater with a damaged
cord or plug or if heater malfunctions or
has been dropped or damaged in any way.
Return heater to authorized service facility
for examination, electrical or mechanical
adjustment or repair.
7. Do not use outdoors.
8. This heater is not intended for use in
bathrooms, laundry areas and similar
indoor locations. Never locate heater
where it may fall into a bathtub or other
water container.
9. Do not run cord under carpeting. Do not
cover cord with throw rugs, runners or the
like. Arrange cord away from trafc area
and where it will not be tripped over.
10. To disconnect heater, turn controls to the
OFF before removing plug from outlet
(turn off power to unit).
11. Do not insert or allow foreign objects to
enter any ventilation or exhaust opening
as this may cause an electric shock or re
or damage the heater.
12. To prevent possible re, do not block air
intakes in any manner. Do not use on soft
surfaces, like a bed, where openings may
become blocked.
13. Connect to properly grounded circuits only.
TABLE OF CONTENTS
Safety .................................................................. 2
Listing Approvals ................................................. 3
Product Dimensions ............................................ 3
Product Identication........................................... 4
Unpacking and Testing ........................................ 4
Locating Fireplace ............................................... 4
Installation ........................................................... 6
Operation............................................................. 7
Accessory Installation.......................................... 8
Cleaning .............................................................. 9
Servicing.............................................................. 9
Wiring Diagram.................................................. 14
Troubleshooting................................................. 15
Replacement Parts............................................ 16
Technical Service............................................... 16
Accessories ....................................................... 17
Parts .................................................................. 18
Warranty ..............................................Back Cover

www.fmiproducts.com
122663-01E 3
SAFETY
Continued
14. A heater has hot and arcing or sparking
parts inside. Do not use it in areas where
gasoline, paint or ammable liquids or
vapors are used or stored.
15. Use this heater only as described in this
manual. Any other use not recommended
by the manufacturer may cause re, elec-
tric shock or injury to persons.
16. Avoid the use of an extension cord be-
cause the extension cord may overheat
and cause a risk of re. However, if you
have to use an extension cord, the cord
should be No. 14 AWG minimum size and
rated not less than 1875 WATTS.
17. Always use ground fault protection where
required by electrical codes.
Description: 36" Fireplace
Voltage: 120 / 240
Watts: 1500 / 3000
Amps: 15 Amp / 20 Amp
Grounded Circuit
PRODUCT DIMENSIONS
Figure 1 - Heater Dimensions
Note: This heater must be electrically wired and
grounded in accordance with local codes or, in
the absence of local codes, with National Electric
Code ANSI/NFPA 70-latest edition or the Cana-
dian Electric Code, CSA C22.1 as appropriate.
18. Always disconnect power before perform-
ing any cleaning, maintenance or reloca-
tion of heater.
19. To prevent a possible re, do not burn
wood or other materials in this heater.
20. To prevent electric shock or re, always
use a certified electrician should new
circuits or outlets be required.
21. When transporting or storing heater, keep
in a dry place.
22. Control panel door gets hot during heater
operation. To open control panel door,
gently pull on left and right outer edges.
Do not open from center of control panel
door.
LISTING APPROVALS
This heater has been tested in accordance
with the CSA Standards for xed and location-
dedicated electric room heaters in the United
States. All components are UL or CSA safety
certied.
If you need assistance during installation,
please contact your local dealer or the FMI
PRODUCTS, LLC at 1-866-328-4537.
Please have the distributor’s model and serial
numbers when you call.
17 1/4"17 5/8"
24 1/4"
35"
8"
21"
37"
43"
42 1/8" To Nail Location
36 1/2"
31 7/8"
36 3/4" To Nail Location
41"
2 1/8"
5/8"
TOP
FRONT
LEFT SIDE RIGHT SIDE
361/8"
15 1/8"

www.fmiproducts.com 122663-01E4
UNPACKING AND TESTING
Carefully remove unit from box. Prior to per-
manently installing unit, test to make sure unit
operates properly. Unit does not come with a
power cord installed. Unit must be wired to
either a cord set (provided), 120/60 volt sup-
ply, or 240/60 volt supply.
CAUTION; The unit must
be connected to a properly
grounded and protected 120/240
volt circuits. Always use ground
fault protection where required
by the electrical code.
WARNING: Do not operate
the unit if it is damaged or has
malfunctioned. If you suspect
the unit is damaged, return the
unit to an authorized service
facility for examination, electri-
cal or mechanical adjustment
or repair.
Heater FlameEmber Backlight
Power
Figure 2 - Product Identication
PRODUCT IDENTIFICATION
Heat Vents
(Behind Door)
ON/OFF
Power
Button
Log Set
Front Glass
Heater
Control
Flame Control
Ember Control
Control
Panel
Door
LOCATING FIREPLACE
WARNING: Due to high tem-
peratures, this heater should
be located out of trafc. Keep
combustible materials such as
furniture, pillows, bedding, papers,
clothes and curtains at least 3 feet
(0.9 m) from the front of the heater.
WARNING: Never locate this
heater where it may fall into a
bathtub or other water container.
NOTICE: Minimumand maximum
clearances must be maintained at
all times. Illustrations throughout
these instructions reect typical
installations and are for design
purposes only. Actual installa-
tions may vary slightly due to
individual preferences.
WARNING: To prevent
contact with sagging or loose
insulation, the heater must not
be installed against vapor barrier
or exposed insulation. Localized
overheating could occur and a
re could result.
Backlight
Control
Remote Hide
Magnetic
Catch

www.fmiproducts.com
122663-01E 5
CAUTION: Do not expose the
heater to the elements (such as
rain, etc.)
CAUTION: Wear gloves and
safety glasses for protection
during installation and main-
tenance.
Plan where to locate and frame replace.
Before installation consider the following:
1. Fireplace location must allow for wall and
ceiling clearances (see Installation Clear-
ances).
2. Fireplace screen should not be exposed
to direct sunlight from windows or doors.
3. Unit can be wired for either 120/60 (15
amp circuit) or 240/60 (20 amp circuit).
A dedicated circuit should be provided
to avoid circuit breaker trips or blown
fuses.
Flush Installations are recommended where
living space is limited or at a premium. Since
space required to enclose replace would
be located beyond an outside wall, this in-
stallation would require additional planning
and construction. Check local codes for any
restrictions.
Projected Installations can extend any dis-
tance into room. A projection may be ideal for
a new addition on an existing, nished wall.
Corner Installations make use of space
that may not normally be used and provides
a wider and more efcient viewing angle and
heat distribution.
Internal Wall Installations provide a discrete
option for room separation and can also be an
ideal addition to an existing wall.
LOCATING FIREPLACE
Continued
Figure 3 - Possible Installation Locations
Internal Wall
Installation
Full Projection
Installation
Flush
Installation
Corner
Installation
Facing Material May
Be Noncombustible
Wall Treatments or
Combustible Wood
Combustible Wood
Mantels and Trims
May Extend Above
Profile Shown when
Maintained within
30° Parameter
Shown
Framed
Material
Top of Cabinet
Note: All Mantel Clearances
are Measured from Top of
Fireplace Opening
30°
23"
12" Ref.
21"
4 1/2"
1 1/2"
15" Min.
17"
10 1/2"
Figure 4 - Mantel Clearances
Top View of Fireplace
5"
3"
30° 1 3/4" Max.
Minimum 10"
from Perpendicular
Side Wall
Edge of
Firebox
Opening
Combustible
Material Must
Not Overlap
Front Face
Safe Zone
Figure 5 - Mantel Side Clearances
INSTALLATION
INSTALLATION CLEARANCES
Minimum clearances to combustible construc-
tion are:
Top, Back and Sides of Recessed Cabinet 0" Min.
Drywall to Sides of Front Face 0" Min.
Framing at Nailing Flanges 0" Min.
Ceiling to Opening 36" Min.
Floor 0" Min.
Front 36" Min.
Perpendicular Side Wall 10" Min.
M antel Clearances
For mantel clearances see Figures 4 and 5.

www.fmiproducts.com 122663-01E6
WARNING - RISK OF FIRE!
Wiring to power source must not
be pinched or against a sharp
edge.
WARNING - RISK OF FIRE!
To prevent a possible re, do
not block air intake or exhaust
in any manner. Do not use on
soft surfaces where openings
may become blocked.
WARNING - RISK OF FIRE!
Do not blow or place insulation
against the rebox.
WARNING: If the informa-
tion in these instructions is
not followed exactly, a re or
explosion may result causing
property damage, personal in-
jury or death.
Do not store or use gasoline or
other ammable vapors in the vi-
cinity of this or any other heater.
A junction box is provided to wire to the cord
set provided or hard wire unit to either a 15
amp (120/60) or 20 amp (240/60), 120 Volt
60 Hz grounded circuit.
Tools and building supplies required for
installation:
• Saw • Square
• Pliers • Gloves
• Hammer • Level
• Phillips screwdriver • Surround
• Framing materials • Electric drill/bits
• Tape measure
• Wall-nishing materials
• Caulking material
CAUTION: Provide adequate
clearances around the air open-
ings and adequate accessibility
clearances for servicing and
proper operations.
WARNING: Control panel
door on this heater cannot, in
any way, be covered as it may
create a re hazard.
BUILT-IN INSTALLATION
Built-in installations require a framed enclo-
sure constructed of 2" x 4" or heavier lumber
and sized in accordance with Figure 6. This
allows unit to slide into opening and be nailed
to stud at sides and top nailing anges. These
anges accept 5/8" drywall or plywood board
to nish unit ush to face. Optional trim ac-
cessories are available that will extend 1/2"
over rough edge of wall opening (see Acces-
sories, page 17).
IMPORTANT: If installing a perimeter trim kit,
you must install shoulder screws before insert-
ing replace into opening. See instructions
included with trim kit. If installing a mantel,
you must follow clearance instructions (see
Installation Clearances, page 5).
41 1/4"
7 1/2"
36 1/2"
Platform/Subflooring
Figure 6 - Framing Dimensions
42 3/8"
29 3/8"
58 1/4"
11 5/8"
These Dimensions
Allow for 11 5/8" of
Clearance to Side
Wall of Fireplace
and 10' Clearance
to Perpendicular
Side Walls
Figure 7 - Corner Dimensions
INSTALLATION
Continued

www.fmiproducts.com
122663-01E 7
A hearth extension is suggested for a more
pleasing appearance. The replace may be
raised on a wood or non-combustible platform
supporting its entire width and depth and
extending in front of the replace as long as
louvers are not obstructed.
Note: When installing replace in cold cli-
mates against a non-insulated exterior wall,
wall must be fully insulated in accordance with
local building code.
ELECTRICAL INSTALLATION
WARNING: Any electrical re-
wiring of this appliance must be
done by a qualied electrician.
This wiring must be done in ac-
cordance with local codes and/or
in the U.S.A. with the current, Na-
tional Electrical CodeANSI/NFPA
No 70 and in Canada with CSA
C22.1 Canadian Electric code.
INSTALLATION
Continued
The controls (see Figure 8) are located behind
hinged control panel door. If using heater,
control panel door will be hot during and
immediately after operation. Open door by
pulling control panel door on left and right side.
1. Connect replace to power source. Turn
on lighted power switch (see Figure 8).
2. Adjust Flame/Ember/Backlight/Heater
to desired settings using the control pad
on replace (Figure 8) or remote control
(Figure 9). Figure 10, page 8, shows re-
place settings available. Default settings
are circled. Press control pad or remote
control buttons once and release to adjust
settings.
Note: When on, ember bed will lighten
and darken automatically to simulate real
embers.
Heater Flame EmberBacklight
Power
Figure 8 - Controls For Electric Fireplace
Lighted Power Switch
Ember
Control
Heater
Control Flame
Control
Backlight
Control
This replace should be con-
nected to a dedicated 15 amp
(120/60) or 20 amp (240/60),
circuit as other appliances may
cause the circuit breaker to trip
or fuse to blow when replace
is in operation.
A junction box is provided to hard wire unit to
either a 15 amp (120/60) or 20 amp (240/60),
120 Volt 60 Hz grounded circuit.
OPERATION
Figure 9 - Remote Control For Electric
Fireplace

www.fmiproducts.com 122663-01E8
The heater is pre-set to the following
temperatures:
HIGH will shut off when room reaches
approximately 86° F (30° C).
MEDIUM will shut off when room reaches
approximately 79° F (26° C).
LOW will shut off when room reaches
approximately 72° F (22° C).
Note: Fan on heater will continue to run for 5-7
seconds after heater has been turned off.
3. When using remote control, aim remote
at sensor located in center of unit just
above log set. IMPORTANT: This remote
control must remain within 20 feet (6 m)
of replace to be effective.
4. When power switch is turned off, replace
settings go back to default (see Figure 10).
Figure 10 - Fireplace Settings (Default
Settings are Circled)
OPERATION
Continued
HEATER Off Low Medium High
FLAME Off Low Medium High
EMBER Off Low Medium High
BACKLIGHT Off Low High
BIFOLD GLASS DOOR INSTALLATION
Figure 11 - Installing/Removing Glass
Doors
Spring Clip
Press Spring Clip
to Release Pivot
Pin
Remove Pivot Pin
From Bottom Face
While Sliding Door
Out of Upper Track
Pivot Pin
Fold Bifold Door
After Releasing
Spring Clip to
Slide Door Out of
Upper Track
Figure 12 - Adjust Glass Door
Spring Clip
Partially
Opened
Door
Side Front
Face
Installing Bifold Glass Doors
Follow these steps to install left and right
operable panels:
1. With handle down, completely fold panel
on its hinges.
2. With handle facing center of rebox open-
ing insert lower pivot pin on door panel
into hole in bottom outer edge of rebox
opening (see Figure 11).
3. Keep folded door tilted and slide upper two
pins into guide track below upper facial
edge of rebox opening.
4. Tilt glass assembly fully vertical until outer
pivot pin snaps into mounting hole in up-
per spring clip.
5. Once top and bottom pins are secured,
unfold door into closed position.
6. Repeat steps 1 through 5 for opposite
door assembly.
7. To adjust doors, slide partially open. Using
a Phillips screwdriver, loosen hold-down
screws on spring clips (see Figure 12).
8. Close both doors until evenly joined at
middle and note gap as measured to outer
edges of front face.
9. Reopen each door one at a time and
retighten the hold-down screw while pre-
serving noted gap at each edge.
10. Repeat process until both doors are even-
ly joined, spaced and working freely.

www.fmiproducts.com
122663-01E 9
CLEANING
WARNING: Always discon-
nect power and allow the heater
to cool before performing any
cleaning, maintenance or reloca-
tion of this heater. Turn controls
to OFF and remove plug from
outlet or turn off circuit breaker
to heater.
CLEANING FIREBOX
1. Open bi-fold doors and screens.
2. Using a brush vacuum attachment, gently
clean compartment.
3. Close screens and doors.
Removing Bifold Glass Doors
Bifold doors may be removed for replacing
or cleaning.
1. Partially open each door and press up on
upper spring clip with a screw driver until
outer top pivot pin is free of the clip.
ACCESSORY INSTALLATION
Continued
2. Fully fold frame assembly and slide upper
edge towards center of rebox opening
until the guide pins are free of the frame
rail (see Figure 11, page 8).
CLEANING BACK SCREEN (GLASS)
1. The glass is cleaned in the factory during
assembly. During shipment, installation,
handling, etc. glass surface may collect
dust particles. These can be removed
by bufng lightly with a clean damp cloth
(water only). Glass should be completely
dried with a lint free cloth or paper towel.
2. To access glass to clean, follow steps
1 through 5 under Service Preparation,
page 10.
3. Using gloves, gently remove glass panel
by sliding it toward you. There is a rubber
bumper on each corner of glass.
4. Clean glass as instructed in step 1.
5. Follow steps 8 through 13 under Service
Preparation, page 10.
SERVICING
WARNING:Turnoff appliance
and let cool before servicing.
Only a qualied service person
should service and repair heater.
For questions regarding replacing parts, see
page 13.
Note: All service procedures are performed
through front face opening of replace.
REPLACING LOG
1. Turn off power to unit (circuit breaker).
2. Open upper control panel door. Turn
power switch off.
3. Open bi-fold doors (if equipped) and
screens.
4. Remove screws securing each side of log
to brackets (see Figure 13).
5. Carefully remove old log.
6. Install new log.
7. Reinstall screws into brackets to secure
new log.
8. Close screens and doors.
REPLACING SCREENS
Figure 13 - Removing Log and Ember LED
Log Ember LED Strip
with Standoffs
Screw

www.fmiproducts.com 122663-01E10
1. Open upper control panel door. Turn
power switch off.
2. Open bi-fold doors (if equipped).
3. Remove 2 screws securing screen rods
(see Figure 14).
4. Tilt rod down and remove from bracket.
5. Remove old screen from rod and discard.
Install new screen onto rod.
6. Reinstall rod into bracket and replace
screws.
7. Close doors.
REPLACING EMBER STRIP
SERVICING
Continued
screens.
3. Remove screws securing each side of log
to brackets (see Figure 13, page 9).
4. Carefully remove log.
5. Remove screws from back corners and
front of top panel (see Figure 15). Remove
top panel and set aside.
Note: For LED drum and motor, only
remove back screws. Top panel does not
have to be completely removed. Care-
fully push top panel up to remove screen
glass.
6. Using gloves, gently remove glass panel
by sliding it toward you. There is a rubber
bumper on each corner of glass. Set aside
in a safe location.
7. Follow instructions on pages 11 thru 13 to
replace part.
8. Using gloves, install glass by gently slid-
ing, smooth side toward replace front,
into brackets on either side that hold glass
in place.
9. Reinstall top panel. Pull top panel down
so that screen glass seats into glass
retainer.
10. Reinstall screws from step 5.
11. Reinstall log.
12. Reinstall screws into brackets to secure
log.
13. Close screens and doors.
14. Turn on power to unit (circuit breaker).
SCREEN GLASS
Figure 14 - Removing Screen/Rod Assembly
Screen
Rod
Retaining
Screw
Mounting
Holes
1. Follow steps 1 and 4 under Replacing Log,
page 9.
2. Locate ember LED strip (see Figure 13,
page 9). Disconnect wire (right side).
3. Remove ember LED strip by squeezing
top of standoffs and discard.
4. Being careful not to break LED strip, press
new ember LED strip onto standoffs.
5. Reconnect wire to LED strip.
6. Follow steps 5 through 7 under Replacing
Log, page 9.
SERVICE PREPARATION
Perform steps 1 through 4 below, then locate
part that needs replacing in the instructions
that follow.
1. Open control panel door. Turn off power
to unit (circuit breaker).
2. Open bi-fold doors (if equipped) and
Figure 15 - Removing Screen Glass (all
parts not shown for clarity)
Screen Glass
Control
Panel
Door
Top Panel

www.fmiproducts.com
122663-01E 11
LED Drum
Assembly
Screws
White
Wire
Red
Wire
Figure 16 - Flame Generation LED Drum
Assembly
Motor
Clamps
SERVICING
Continued
Note: LED drum wires are polarity sensi-
tive and must be connected correctly.
White wire plugs onto left terminal and red
wire plugs onto right terminal. Motor wires
can be connected to either terminal.
8. Follow steps 8 through 13 under Service
Preparation, page 10.
MAIN CONTROL BOARD
1. Follow steps 1 through 6 under Service
Preparation, page 10.
2. Disconnect wires to main control board.
3. Squeeze top of standoffs to remove main
control board and discard.
4. Install new control board by gently pushing
onto standoffs.
5. Reconnect wires to main control board
(see Wiring Diagram, page 14).
6. Follow steps 8 through 13 under Service
Preparation, page 10.
TRANSFORMER
Figure 17 - Control Board
Main Control
Board
Standoffs
Transformer
1. In the event of glass breakage, vacuum all
remaining glass pieces with a shop vac. DO
NOT VACUUM WHILE PIECES ARE HOT.
Replace glass only with replacement part
specically for this heater. Never substitute
material. Only fully tempered soda lime
safety glass may be used on this heater.
2. Remove and replace glass, follow steps
1 through 13 (skip step 7) under Service
Preparation, page 10.
LED DRUM AND MOTOR (FLAME
GENERATION)
1. Follow steps 1 through 6 under Service
Preparation, page 10.
2. Disconnect wires from motor and LED
drum assembly.
3. Remove screws from bottom panel to
remove assembly (see Figure 16).
4. If motor on assembly fails, loosen clamps
(see Figure 16). Remove screws from
motor. Hold universal joint while removing
motor and discard.
5. Install new motor. Slide motor shaft into
universal joint and tighten clamps.
6. Hold LED drum assembly in place on
bottom panel and replace screws.
7. Reattach wires to motor and LED drum.

www.fmiproducts.com 122663-01E12
SERVICING
Continued
Figure 20 - Removing Blower/Blower
Assembly
1. Follow steps 1 through 6 under Service
Preparation, page 10.
2. Disconnect wires from heater.
3. Remove 4 screws from side of heater, see
(Figure 19).
4. Install new heater.
5. Connect wires to new heater (see Wiring
Diagram, page 14)
6. Follow steps 8 through 13 under Service
Preparation, page 10.
BLOWER ASSEMBLY
Figure 19 - Removing Heater from
Blower
Heater
Blower
1. Follow steps 1 through 6 under Service
Preparation, page 10.
2. Disconnect wires from heater/blower as-
sembly.
3. Remove 4 screws holding blower/heater
and brackets to replace top (see Figure
20).
4. Remove 4 screws securing heater to
blower (see Figure 19).
5. Install old heater onto new blower with
screws removed in step 4.
6. Install new blower/heater assembly to top
panel with screws removed in step 3.
7. Reconnect wires to blower/heater assem-
bly (see Wiring Diagram, page 14).
8. Follow steps 8 through 13 under Service
Preparation, page 10.
BACKLIGHT LED STRIP
Brackets
1. Follow steps 1 through 6 under Service
Preparation, page 10.
2. Disconnect transformer wires from control
board.
3. Remove 2 screws from rebox surround
to remove transformer (see Figure 18).
4. Remove and discard transformer.
5. Place new transformer against inside
of rebox surround and replace screws
removed in step 3.
6. Reconnect transformer wires to control
board (see Wiring Diagram, page 14).
6. Follow steps 8 through 13 under Service
Preparation, page 10.
HEATER
Transformer
Screws
Nuts
Figure 18 - Removing Transformer

www.fmiproducts.com
122663-01E 13
1. Follow steps 1 through 4 under Service
Preparation, page 10.
2. Disconnect wires from backlight LED
strip.
3. Squeeze top of standoffs to remove back-
light LED strip and discard.
4. Place new backlight LED strip onto stand-
offs and push gently.
5. Connect wires to backlight LED strip (see
Wiring Diagram, page 14).
6. Follow steps 11 through 13 under Service
Preparation, page 10.
REMOTE CONTROL SENSOR
1. Follow steps 1 through 6 under Service
Preparation, page 10.
2. Disconnect wire from remote control sen-
sor board.
3. Squeeze top of standoffs to remove
board.
4. Gently push new board onto standoffs.
5. Connect wires to remote sensor board.
6. Follow steps 8 through 13 under Service
Preparation, page 10.
SETTINGS CONTROL BOARD
1. Follow steps 1 through 6 under Service
Preparation, page 10.
2. Disconnect wire from settings control
board.
3. Remove screws from bracket to remove
settings control board (see Figure 23).
4. Place new settings control board into posi-
tion making sure each control is aligned
with slot in panel. Install using screws
from step 3. DO NOT overtighten. This
will damage control board.
5. Reconnect wire to settings control board
(see Wiring Diagram, page 14).
6. Follow steps 8 through 13 under Service
Preparation, page 10.
Figure 21 - Replacing Backlight LED
Strip
Backlight
LED Strip
Standoffs
SERVICING
Continued
Figure 23 - Replacing Settings Control
Board
Screw
Settings
Control
Board
Figure 22 - Replacing Remote Control
Sensor
Remote Control Sensor

www.fmiproducts.com 122663-01E14
WIRING DIAGRAM
Junction Box
Voltage 120V AC
32" and 36" BUILDER ELECTRIC FIREPLACE CONTROL DIAGRAM
PCB BOARD AND FUNCTION CONTROL ASSEMBLY
P/N F904-0036-9000 (Rev A)
DPST
Rocker Switch
Purple Yellow Brown Dark Green Gray Blue Red Black
Purple
Yellow
Brown
Dark Green
Gray
Blue
Red
Black
4
Note: YLW: Yellow CYA: Cyan BRW: Brown WHT: White BLK: Black ORG: Orange GRE: Dark Green
WHT
WHT
YLWYLWYLW BRW
ORGORG GRECYA
FANLESLBS LDA
+ +-
-
MTR RCS
SCB
TF1
THM
M
Gray
Heater Heater
Fuse
Heating Element
Assembly Blower
LED Ember Strip
LED Backlight Strip
Remote Control
Sensor (Infrared)
LED Drum/
Motor Assembly
Settings
Control
Board
1 99
1
Transformer
Thermostat
Blue
Cyan
White
Black
White
Black
Yellow
White
Red
Junction Box
Voltage 240V AC
WARNING
Cover all unused
wires with tape
and install wire
nuts. Unplug unit
before servicing.
Purple Yellow Brown Dark Green Gray Blue Red Black
White
Electrical
Outlet
Black Green
White
Black Green
1
2
5
M

www.fmiproducts.com
122663-01E 15
TROUBLESHOOTING
WARNING: Turn off appliance and let cool before servicing. Only
a qualied service person should service and repair heater.
POSSIBLE CAUSE REMEDY
OBSERVED PROBLEM
1. Fireplace has overheated
and safety device has
caused thermal switch to
disconnect or home circuit
breaker has opened
1. Loose wiring
2. Flame motor defective
1. Wiring is loose
1. Wiring is loose
1. Flame motor is defective
2. Flame generation contacts
dirty/obstructed
1. Low batteries
2. Not aiming control cor-
rectly
3. Defective remote control
and/or sensor
1. Control failure
2. Breaker tripped
1. Thermal switch has been
tripped
2. Circuit breaker has been
tripped
3. Wiring is loose
4. Heater is defective
5. Thermostat cycled off
Fireplace turns off and will
not turn on
Flame is not moving
Flame is not visible
Log set and/or ember is not
glowing
Flame sputters/ashes
Remote control does not
work
Fireplace will not come on
when switch is ipped to ON
Heater does not provide heat
when turned on
1. Reset switch by turning
main power switch off and
waiting 5 minutes then turn-
ing it back on or reset circuit
breaker
1. Inspect wiring for loose
connections
2. Call a qualied service techni-
cian to replace ame motor
1. Disconnect from power
source and inspect wiring for
loose connections and repair
or replace if necessary
1. Disconnect from power
source and inspect wiring for
loose connections and repair
or replace if necessary
1. Call a qualied service techni-
cian to replace ame motor
2. Disconnect power. Fol-
low steps to replace ame
generation LED. Clean
contacts with dry cloth.
1. Replace AAA batteries in
remote control
2. Aim control at sensor lo-
cated directly behind glass
screen in center of unit just
above logs
3. Replace remote control
and/or sensor
1. Call a qualied service tech-
nician to replace control
2. Reset breaker
1. Turn unit off. Turn off power
to unit for 5 minutes. Turn
power and unit on.
2. Turn off circuit breaker that
supplies electricity to unit.
Wait 5 minutes then flip
circuit breaker back on
3. Disconnect from power
source and inspect wiring for
loose connections and repair
or replace if necessary
4. Replace heater
5. Change to higher setting

www.fmiproducts.com 122663-01E16
REPLACEMENT PARTS
Note: Use only original replacement parts.
This will protect your warranty coverage for
parts replaced under warranty.
Contact authorized dealers of this product.
If they can’t supply original replacement
part(s), call FMI PRODUCTS, LLC at 1-866-
328-4537.
When calling, have ready:
• your name
• your address
• model and serial numbers of your heater
• how heater was malfunctioning
• purchase date
Usually, we will ask you to return the part to
the factory.
TECHNICAL SERVICE
You may have further questions about instal-
lation, operation, or troubleshooting. If so,
contact FMI PRODUCTS, LLC at 1-866-328-
4537. When calling please have your model
and serial numbers of your heater ready.
You can also visit our web site at
www.fmiproducts.com.
This information can be found on the
replace's rating plate located behind the
control panel door.

www.fmiproducts.com
122663-01E 17
ACCESSORIES
Purchase these accessories from your local
dealer. If they can not supply these acces-
sories, either contact your nearest Parts
Central or call FMI PRODUCTS, LLC at
1-866-328-4537 for information. You can
also write to the address listed on the back
page of this manual.
36" PERIMETER TRIM KITS
PT36 - Black
PT36B - Brushed Brass
PT36P - Platinum
36" WALL MANTELS WITH BASE
AND TRIM
W36TU - 36" Wall Mantel, Unnished,
Traditional
W36TO - 36" Wall Mantel, Oak Stain,
Traditional
36" CORNER MANTELS WITH BASE
AND TRIM
C36TU - 36" Corner Mantel, Unnished,
Traditional
C36TO - 36" Corner Mantel, Oak Stain,
Traditional

www.fmiproducts.com 122663-01E18
PARTS
MODEL EL36LD
23
6
28
15
29
19
19
14
24
5
7
22
16
17
18
4
8
21
32
30
2
27
25
26
3
13
10
11
20
12
1
9
31

www.fmiproducts.com
122663-01E 19
PARTS
MODEL EL36LD
This list contains replaceable parts used in your replace. When ordering parts, follow the
instructions listed under Replacement Parts on page 16 of this manual.
KEY
NO. PART NO. DESCRIPTION QTY.
1 120929-01 Door Handles 2
2 120929-02 LED Ember Strip 1
3 120929-03 Log Set 1
4 120929-04 Rear Glass (Screen) 1
5 120929-05 Flame Effect Mirror 1
6 120928-46 Heater/Blower Bracket 2
7 120928-44 Flame Effect Mirror Bracket 2
8 120927-16 Back Light Strip 1
9 120929-09 Top 1
10 120929-10 Glass Door, Left 1
11 120929-11 Glass Door, Right 1
12 120929-12 Control Panel Door 1
13 120929-13 Front Panel 1
14 120929-14 Mesh Screens 2
15 120929-15 Screen Rods 2
16 120929-16 Back Panel, Left Side 1
17 120929-17 Back Panel, Center 1
18 120929-18 Back Panel, Right Side 1
19 120929-19 Magnetic Catch 2
20 120929-20 Bottom Panel 1
21 120928-40 Grate 1
22 120927-08 Handles 2
23 120928-42 Heater 1
24 120928-43 Blower 1
25 120928-27 Transformer 1
26 120928-26 Main Control Board and Standoffs 1
27 120927-21 Remote Control Sensor 1
28 120927-12 Settings Control Board 1
29 120927-24 ON/OFF Switch 1
30 120929-21 LED Drum Assembly 1
31 120927-14 Motor 1
32 120927-20 Remote Control 1
PARTS AVAILABLE - NOT SHOWN
120929-06 Wire (Flame Effect) 1
120929-07 Wire (Ember Bed) 1
120929-08 Wire (Backlight) 1
120927-23 Thermocouple 1
120927-22 Cord, Power 1

122663-01
Rev. F
11/11
WARRANTY
KEEP THIS WARRANTY
FMI PRODUCTS, LLC LIMITED WARRANTIES
New Products
Standard Warranty: FMI PRODUCTS, LLC warrants this new product and any parts thereof to be free from defects
in material and workmanship for a period of two (2) years from the date of rst purchase from an authorized dealer
provided the product has been installed, maintained and operated in accordance with FMI PRODUCTS, LLC’s
warnings and instructions.
For products purchased for commercial, industrial or rental usage, this warranty is limited to 90 days from the date
of rst purchase.
Factory Reconditioned Products
Limited Warranty: FMI PRODUCTS, LLC warrants factory reconditioned products and any parts thereof to be
free from defects in material and workmanship for 30 days from the date of rst purchase from an authorized dealer
provided the product has been installed, maintained and operated in accordance with FMI PRODUCTS, LLC’s
warnings and instructions.
Terms Common to All Warranties
The following terms apply to all of the above warranties:
Always specify model number and serial number when contacting the manufacturer. To make a claim under this
warranty the bill of sale or other proof of purchase must be presented.
This warranty is extended only to the original retail purchaser when purchased from an authorized dealer, and only
when installed by a qualied installer in accordance with all local codes and instructions furnished with this product.
This warranty covers the cost of part(s) required to restore this product to proper operating condition and an allow-
ance for labor when provided by a FMI PRODUCTS, LLC Authorized Service Center or a provider approved by
FMI PRODUCTS, LLC. Warranty parts must be obtained through authorized dealers of this product and/or FMI
PRODUCTS, LLC who will provide original factory replacement parts. Failure to use original factory replacement
parts voids this warranty.
Travel, handling, transportation, diagnostic, material, labor and incidental costs associated with warranty repairs,
unless expressly covered by this warranty, are not reimbursable under this warranty and are the responsibility of
the owner.
Excluded from this warranty are products or parts that fail or become damaged due to misuse, accidents, improper
installation, lack of proper maintenance, tampering, or alteration(s).
This is FMI PRODUCTS, LLC’s exclusive warranty, and to the full extent allowed by law; this express warranty
excludes any and all other warranties, express or implied, written or verbal and limits the duration of any and all
implied warranties, including warranties of merchantability and tness for a particular purpose to two (2) years on
new products and 30 days on factory reconditioned products from the date of rst purchase. FMI PRODUCTS, LLC
makes no other warranties regarding this product.
FMI PRODUCTS, LLC’s liability is limited to the purchase price of the product, and FMI PRODUCTS, LLC shall not
be liable for any other damages whatsoever under any circumstances including indirect, incidental, or consequential
damages.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental
or consequential damages, so the above limitation or exclusion may not apply to you.
This warranty gives you specic legal rights, and you may also have other rights which vary from state to state.
For information about this warranty contact:
Model ( located on product or identication tag )_____________________________
Serial No. ( located on product or identication tag )__________________________
Date Purchased __________________________
Keep receipt for warranty verication.
2701 S. Harbor Blvd.
Santa Ana, CA 92704
1-866-328-4537
www.fmiproducts.com
