Focal UNIVERSAL ISU130 User manual

Ø 156
4 X Ø5
48,40
55,50
Ø 165,60
Ø80
16,50
Ø 142,55
MECHANICAL DRAWING
UNIVERSAL
ISU165
Technical Sheet
Woofer
Nominal power 70W RMS
Maximum power 140W
Sensitivity (2,83V/1m) 93dB
Frequency response 60Hz-21kHz
Cone type Polyglass
Surround type Butyl
Nom. impedance 4Ω
VC diameter 25mm 1"
Net weight 750g 1.6lbs
PARAMETERS
Fs 90Hz
Vas
Qts 1
Qes 1.3
Qms 7
Re 2.9Ω
Sd 137cm2
Cms 0.23mm/N
Mms 14g
BI 4.3N/A
SPECIFICATIONS
FREQUENCY RESPONSE/IMPEDANCE
Frequency response 0° Frequency response -30° Impedance
• Polyglass cone
• Reduced height
0
5
10
15
20
25
30
35
40
50
55
60
65
70
75
80
85
90
95
100
105
110
10 100 1000 10000
dB/SPL Ohm
Integration
INSTANT GRATIFICATION
Focal America - Tel [phone] - www.Focal-America.com - @FocalAmerica

ADVANTAGES
• High sensitivity
• Shallow mounting depth (129/32
• Dynamics and neutrality
• 2 types of tweeter mounts
• Compact tweeter
Woofer: 61/2" (165mm)
Voice coil diameter: 1"(25mm)
Max. power: 140W
Nom. power: 70W RMS
Sensitivity (2.83V/1m): 93dB
Frequency response: 60Hz-21kHz
Al/Mg inverted dome tweeter
Accessories: delivered without grilles
Integrated crossover: 6dB/oct
UNIVERSAL
ISU165
Product Data Sheet
2-way component kit
TECHNICAL CHARACTERISTICS
Integration
INSTANT GRATIFICATION
Phase plug
Improved sound
dispersion
Connector with integrated
crossover (woofer + tweeter)
Easy to install
Butyl suspension
Excellent reliability
Polyglass cone
Natural sound
without coloration
Aluminum/Magnesium
inverted dome tweeter
Clear and detailed sound
Acoustic horn
Improves the position
of the soundstage
Tilted mounting frame:
Easy to install
Mounting options:
car and display
Detachable tweeter
