DESCRIPTION
The SM-1621U model is a professional stereo mixer with 6 inputs, 3 channels and 2 outputs with independent
volume controls for DJ use. t has an MP3 player with LCD display that shows D3 information in MP3 files,
with USB port for USB drive connection and SD card reader.
Cueing is possible through the headphones and it has a replaceable crossfader with direct allocation of
channels 2 and 3, adjustable curve and a reverse function for the sliding controls. 3-band equalizer per
channel with up to -32 dB attenuation, LED level indicator and balance in the MASTER output.
t is a mixer that is suitable for use in nightclubs, discos, restaurants, commercial installations, etc., that
require several inputs, independent equalization per channel and MP3 file playback through the USB or SD port.
CONTROLS AND FUNCTIONS
FRONT PANEL
1.- MIC INPUT: balanced microphone input, combo connector (XLR and 6.3 mm stereo jack).
2.- GAIN: gain control for the corresponding channel input.
3.- HIGH-MID-LOW: tone controls. Equalizers that control the bass, mid and treble level in the
corresponding channel.
4.- MIC., LINE 1/PHONE 1: input selector that allows selection among M C NPUT, L NE 1 and PHONE 1
as the input source for channel 1.
PHONO 2/LINE 2/MP3: input selector that allows selection among PHONE 2, L NE 2 and the
USB/SD/MP3 player as the input source for channel 2.
PHONO 3/LINE 3: input selector that allows selection between PHONO 3 and L NE 3 as the input source
for channel 3.
-4-
EN
SM-1621U_MANUAL_PO_2146_(EN)_20171218_Maqu tación 1 18/12/17 8:43 Página 4

5.- Sliding volume control for the level of the corresponding channel.
6.- TALKOVER: button for activating/deactivating the talk over function in channel 1. This function weakens
the signal in the rest of the channels in the general mix. When activated the LED indicator lights up.
7.- REVERSE: allows the crossfader variation curve to be inverted.
8.- CURVE: allows the crossfader response curve to be selected.
9.- CROSSFADER: control which allows the balance to be made between 2 channels CH 2 and CH 3.
Note: this control is replaceable and can be unscrewed from the top.
10.- PHONES: headphone output, 6.3 mm stereo jack connector.
11.- CUE/MASTER: allows the monitored signal in the headphone output to be selected from between 2
positions:
CUE (turning the control to the left): allows the pre-fader mix from the CH1 to CH 3 input channels to
be monitored (with the cue button activated).
MASTER (turning the control to the right): allows the master output signal to be monitored. At mid-point
two signals are heard with the same intensity.
12.- CHANNEL SELECT: button to activate/deactivate the channel cue through the headphones on the
corresponding channel. When activated, the corresponding LED indicator lights up.
13.- CUE: headphone output volume control knob.
14.- BOOTH: BOOTH output volume control knob.
15.- BALANCE: control knob that allows adjustment of the stereo channel balance in the final mix in the
MASTER output.
16.- MASTER: MASTER output level control knob.
17.- LED level indicators: show the stereo channel level from the MASTER output.
18.- POWER: LED power indicator.
19.- USB/SD/MP3 player controls:
PLAY/PAUSE: start or pause playback.
STOP: stop current playback.
REPEAT: this button allows the different playback modeds to be varied: ONE/RANDOM/ALL, the default
repetition mode is ALL.
REVERSE: a short press returns to the start of the track currently being played. Press this button
repeatedly to select a previous track. A long press lowers the volume in USB/SD/MP3 mode.
FORWARD: a short press forwards to the start of the next track. Press this button repeatedly to select
one of the following tracks. A long press raises the volume in USB/SD/MP3 mode.
20.- USB: USB drive and USB hard disc connection port.
21.- SD: SD memory card connection port.
- 5-
EN
SM-1621U_MANUAL_PO_2146_(EN)_20171218_Maqu tación 1 18/12/17 8:43 Página 5

REAR PANEL
1.- POWER: device on/off switch.
2.- AC socket: for connection of the AC power supply cable.
3.- MASTER L/R: balanced output of the corresponding MASTER line level to the final mix, 2 x XLR
connectors.
4.- MASTER: unbalanced output of the corresponding MASTER line level to the final mix, 2 x RCA
connectors.
5.- BOOTH: BOOTH line level unbalanced output. t is a copy of the final mix for monitoring, 2 x RCA
connectors.
6.- TAPE: line level recording output, affected by the channel volume controls and the crossfader and is
independent from the MASTER and BOOTH volume controls, 2 x RCA connectors.
7.- LINE 3: line level stereo input for channel CH 3. Allows the connection of players with line level output,
2 x RCA connectors.
8.- PHONO 3: phono level stereo input for channel CH 3. Allows the connection of turntables with phono
level output, 2 x RCA connectors.
9.- LINE 2: line level stereo input for channel CH 2. Allows the connection of players with line level output,
2 x RCA connectors.
10.- PHONO 2: phono level stereo input for channel CH 2. Allows the connection of turntables with phono
level output, 2 x RCA connectors.
11.- INPUT 1: phono or selectable line level stereo input for channel CH 1. Allows the connection of players
with phono or line level output, 2 x RCA connectors.
12.- LINE 1/PHONO 1: NPUT 1 level selector.
13.- GND: mixer mass for connection to the turntable mass.
-6-
EN
SM-1621U_MANUAL_PO_2146_(EN)_20171218_Maqu tación 1 18/12/17 8:43 Página 6

CONNECTION
- Before making any connections, make sure that all the equipment has been switched off and
disconnected from the power supply.
- Check that all the sliding volume controls for each channel and that the MASTER output level controls
are at their minimum.
- Connect the players to the channel CH1 to CH3 inputs.
- Connect players with line level output (such as CD players) to the L NE inputs and place the input level
selector in the L NE position.
- Connect a turntable to the PHONO inputs on the rear panel and move the input level selector to the
PHONO position. f your turntable has an earth connection, connect it to the GND terminal on the rear
panel.
- Connect a microphone to the M C NPUT on the front panel using a 6.3 mm stereo jack connector or
XLR.
- Connect a USB device with FAT32 format or SD memory card with MP3 files to the corresponding port
on the MP3 player of CH2.
- Connect the balanced or unbalanced MASTER output to a line level input on the amplifier. f you wish,
the BOOTH output can be connected to monitored autoamplified speakers.
- Connect the equipment to the power supply.
- Switch the equipment on in this order: players, SM-1621U mixer and lastly the amplifier.
- Adjust the input level of each channel with the GA N control and mix using the volume controls for each
channel.
-7-
EN
SM-1621U_MANUAL_PO_2146_(EN)_20171218_Maqu tación 1 18/12/17 8:43 Página 7

BLOCK DIAGRAM
-8-
EN
SM-1621U_MANUAL_PO_2146_(EN)_20171218_Maqu tación 1 18/12/17 8:43 Página 8

TECHNICAL SPECIFICATIONS
SM-1621U
CHARACTERISTICS Professional mixer with 6 inputs, 3 channels and 2 outputs with independent
volume controls.
USB/SD/MP3 player.
PLAYER MP3 file player
USB port for USB drive connection
SD card reader
Accepts drives of up to 32 GB
D3 tag
INPUTS 1 balanced mic. combo (XLR and 6.3 mm jack), 600 Ω 1.5 mV
1 phono/line, 2 x RCA 56,000 Ω 3 mV and 47,000 Ω 300 mV
2 phono, 2 x RCA, 56,000 Ω 3 mV
2 lines, 2 x RCA, 47,000 Ω 150 mV
CONTROLS Mic.: gain, treble (-32, +12 dB, 10,000 Hz), mid (-32, +12 dB, 1,200 Hz),
bass (-32, +12 dB, 50 Hz), input selector, PFL, talkover and sliding volume
Phono/line: gain, treble (-32, +12 dB, 10,000 Hz), mid (-32, +12 dB, 1,200
Hz), bass (-32, +12 dB, 50 Hz), input selector, PFL and sliding volume
USB/SD player: play/pause, stop, repeat, track fast forward and rewind,
gain, treble (-32, +12 dB, 10,000 Hz), mid (-32, +12 dB, 1200 Hz), bass (-32,
+12 dB, 50 Hz), input selector, PFL and sliding volume
Master: balance, volume and LED output level indicator
Booth: volume
Cueing: volume and allocation control CUE/MASTER
Crossfader: sliding control, adjustable bend and reversible mode
FUNCTIONS Cueing through PFL headphones, assignable for each channel
Replaceable crossfader with adjustable curve and reversible mode
Sliding controls per channel
3-band equalizer per channel
Talkover in channel 1
LED level indicator for the master output
OUTPUTS Master (2 x XLR and 2 x RCA), booth (2 x RCA), recording (2 x RCA), stereo
headphones (6.3 mm jack)
RESPONSE 20-20,000 Hz
DISTORTION Harmonic: 0.05 %
S/N RATIO > 87 dB
POWER SUPPLY 230/115 V AC, 10 W maximum
DIMENSIONS 245 x 101 x 315 mm depth
- 9-
EN
SM-1621U_MANUAL_PO_2146_(EN)_20171218_Maqu tación 1 18/12/17 8:43 Página 9

- 10 -
ES
- 10 -
EN
WARRANTY
This product has been tested and has passed the corresponding quality control prior to being put on the market.
FONESTAR guarantees the suitability of the product for its specified use during a period of 2 years from the
delivery date and commits itself to repair or substitute the goods as expressed in the Spanish law ‘La Ley General
para la Defensa de los Consumidores y Usuarios, Real Decreto Legislativo 1/2007 16 Noviembre.
The lack of conformity in the first six months after purchase, due to a manufacturing defect, will be rectified with
no more than showing the proof of purchase. After six months FONESTAR reserves the right to demand proof of
the product being sold with that problem.
This warranty does not include damage produced by: inappropriate use or negligence, accidents, worn out parts
due to use, breakages, burns, spilt liquids or other substances, excessive humidity, battery deterioration and
internal manipulation of the device, the software or its components by unauthorized persons, and in general any
use that is unrelated to the nature and purpose of the product.
f any service is needed during the warranty period because of lack of conformity, please contact the business or
distributor where the product was purchased in no more than 2 months after being conscious of the problem. t
is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them to solve it.
To benefit from this warranty it is necessary to show the proof of purchase with the date clearly visible, with no
corrections or crossing out.
This document adds information, and never decreases the consumers’ rights, which in all cases are protected by
the Spanish law ‘La Ley General para la Defensa de los Consumidores y Usuarios, Real Decreto Legislativo 1/2007
16 Noviembre’.
FONESTAR is a member of ECOEMBALAJES ESPAÑA, S.A. “ECOEMBES”, with number 03497 and all our products
carry the symbol, backed by our membership and subscription to the above mentioned organization with the recycling
and subsequent management of our packaging.
FONESTAR, S.A. - N F: A28780443 - Polígono Trascueto - 39600 Revilla de Camargo, Cantabria (Spain) www.fonestar.com
SM-1621U_MANUAL_PO_2146_(EN)_20171218_Maqu tación 1 18/12/17 8:43 Página 10

EN
- 11 -
SM-1621U_MANUAL_PO_2146_(EN)_20171218_Maqu tación 1 18/12/17 8:43 Página 11

www.fonestar.com
SM-1621U_MANUAL_PO_2146_(EN)_20171218_Maqu tación 1 18/12/17 8:43 Página 12
