FOR-A MV-1200 User manual

MV-12SDI
MV-12PCI
MV-12IF
MV-12SDO
MV-12PCO
MV-12PS
MV-1200 Series Options
1st Edition
INSTALLATION
GUIDE

2
Upon Receipt
MV-1200 Series optional card and AC adaptor units are fully inspected and adjusted prior to shipment.
Check your received items against the packing lists below. Check to ensure no damage has occurred
during shipment. If damage has occurred, or items are missing, inform your supplier immediately.
MV-12SDI
ITEM
QTY
REMARKS
MV-12SDI
1
SDI Composite card (4 inputs) for MV-1200 series
Screw (M3x6 PAN)
2
Screw (M3x6 SEMS)
2
Threaded washer screw
Installation guide
1
This guide
MV-12PCI
ITEM
QTY
REMARKS
MV-12PCI
1
HDMI and DVI card (4 inputs) for MV-1200 series
Screw (M3x6 PAN)
2
Screw (M3x6 SEMS)
2
Threaded washer screw
HDMI stopper
4
Set of stopper and fastener
Installation guide
1
This guide
MV-12IF
ITEM
QTY
REMARKS
MV-12IF
1
Interface card for MV-1200 series
Screw (M3x6 PAN)
2
Screw (M3x6 SEMS)
2
Threaded washer screw
Installation guide
1
This guide
MV-12SDO
ITEM
QTY
REMARKS
MV-12SDO
1
3G/HD-SDI card (4 outputs) for MV-1200 series
Screw (M3x6 PAN)
2
Screw (M3x6 SEMS)
2
Threaded washer screw
Screw (M3x35 FLAT HEAD)
2
Air duct
1
Cable tie
2
Fan
1
Fan mount bracket
1
Installation guide
1
This guide

3
MV-12PCO
ITEM
QTY
REMARKS
MV-12PCO
1
3G/HD-SDI card (4 outputs) for MV-1200 series
Screw (M3x6 PAN)
2
Screw (M3x6 SEMS)
2
Threaded washer screw
Screw (M3x35 FLAT HEAD)
2
Air duct
1
Cable tie
2
Fan
1
Fan mounting bracket
1
HDMI stopper
4
Set of stopper and fastener
Installation guide
1
This guide
MV-12PS
ITEM
QTY
REMARKS
MV-12PS
1
AC adaptor
Screw (M3x6 BINDING HEAD)
5
Code holder
1
Case Wiring
1
With connectors
Cable fixing bracket
1
Cable tie
7
D-sub plate nut
1
Label
1
Installation guide
1
This guide

4
Table of Contents
1. Prior to Starting..............................................................................................................................5
2. Installation of Optional Cards........................................................................................................7
2-1. MV-12SDI / 12PCI / 12IF .....................................................................................................7
2-2. MV-12SDO / 12PCO............................................................................................................9
2-3. Installation of Redundant Power Supply MV-12PS...........................................................12
3. Installation Verification ................................................................................................................15

5
1. Prior to Starting
MV-12SDI and MV-12PCI units are input cards for the MV-1200 Series.
The MV-12IF is an interface card for the MV-1200 Series.
MV-12SDO and MV-12PCO units are output cards for the MV-1200 Series.
Each optional card is installable in the following listed slots.
1 2 3 4
LAN
L/R
HDMI OUTPUTHDMI INPUT
4321
3G/HD-SDI
OUTPUT
AC100-240V 50/60Hz IN
ALARM OUTAUDIO OUT
3G/HD/SD-SDI,COMPOSITE INPUT
Slot
Installable Optional Item
INPUT SLOT A
MV-12SDI / 12PCI
INPUT SLOT B
IF SLOT
MV-12IF
OUTPUT SLOT
MV-12SDO / 12PCO
PS
MV-12PS
MV-12SDI (SDI/Analog Composite Card - 4 inputs)
3G/HD/SD-SDI, COMPOSITE INPUT
1 2 3 4
MV-12SDI
Name
Description
3G-SDI/HD-SDI/SD-SDI/
COMPOSITE INPUT 1-4
Inputs 3G-SDI, HD-SDI, SD-SDI, or analog composite signals.
MV-12PCI (HDMI/DVI Card - 4 inputs)
HDMI INPUT
1 2 3 4
MV-12PCI
Name
Description
HDMI/DVI INPUT
Inputs HDMI signals. (DVI-D shared + HDCP supported)
MV-12IF (Interface Card)
LTC REF
MV-12IF
GPIO
RS-232C/422/485
Name
Description
RS-232C/422/485
Used for remote control via a PC or other device.
GPIO
Used for tally input/output, layout switching, and alarm output.
LTC
Used for timecode input.
REF
Used for external reference input.
INPUT SLOTA
IF SLOT
INPUT SLOT B
OUTPUT SLOT
P
S

6
MV-12SDO (3G/HD-SDI Card - 4 outputs)
MV-12SDO
S/No.
1 2 3 4
3G/HD-SDI OUTPUT
Name
Description
3G/HD-SDI OUTPUT
Outputs HD-SDI or 3G-SDI (Level-A) signals.
MV-12PCO (HDMI Card - 4 outputs)
HDMI OUTPUT S/No.
MV-12PCO
1 2 3 4
Name
Description
HDMI OUTPUT
Outputs HDMI video and audio.
MV-12PS (Redundant power supply)
Name
Description
DC12V IN
Connects AC adaptor to supply 12VDC.

7
2. Installation of Optional Cards
Save the MV-1200 Series settings before starting optional card installation. Refer to Layout Manager
Operation Manual Sec. 4-2. “Saving/Loading Setting Files.”
IMPORTANT
Note that optional cards and power supply installation should be performed by qualified technical
personnel familiar with FOR-A equipment. Do not touch any parts of the card with your hands to
prevent damage caused by static electricity. Power OFF all connected units / disconnect power cords
prior to accessing any part of the interior.
An MV-1200Series card may obstruct other card installation if installed in improper order.
Install multiple optional cards in the following order.
OUTPUT SLOT fans (MV-12SDO / 12PCO) -- MV-12PS -- MV12SDO / 12PCO -- MV-12SDI / 12PCI /
12IF.
Step-by-Step Guide
2-1. MV-12SDI / 12PCI / 12IF
Follow the procedure described below for MV-12SDI, MV-12PCI, and MV-12IF units.
Installable slots are INPUT SLOT A, INPUT SLOT B, or IF SLOT.
1. Turn the power off and confirm that the power cord is disconnected. Detach the top panel
following the procedure described as below.
a. Detach all top panel fastening screws. See the figure below.
6 pcs.
M3x6
Binding Head
4 pcs.
M4x8
Binding Head

8
b. Lift and pull the back of the top panel out slightly to detach.
2. Detach the blank slot panel to install the optional card.
a. Detatch 2 screws (M3x6 Pan head) fastening the panel.
The screw type is different from those fastening the top plate. Do not mix the screws.
1 2 3 4
LAN
L/R
HDMI OUTPUTHDMI INPUT
4321
3G/HD-SDI
OUTPUT
AC100-240V 50/60Hz IN
ALARM OUTAUDIO OUT
3G/HD/SD-SDI,COMPOSITE INPUT
3. Install the optional card.
a. Align connectors and insert the card from the top, ensuring that the plate of the card is placed
outside the chassis.
b. Secure the card using the M3x6 SEMS screws. Use M3x6 Pan screws to fasten the card to
the rear panel.
4. Optional card installation is complete. Put the top panel back on in reverse, referring to Step 1.
Go to Sec. 3. “Installation Confirmation.”
②
①

9
2-2. MV-12SDO / 12PCO
Follow the procedure described as below for MV-12SDO and MV-12PCO units.
The installable slot is OUTPUT SLOT.
1. Same procedure as that of Sec. 2-1. “MV-12SDI / 12PCI / 12IF” Step 1.
2. When optional card(s) is (are) installed into INPUT SLOT B and/or IF SLOT, they may
interfere with the installation of an optional card in OUTPUT SLOT, in which case the optional
card(s) should be uninstalled.
a. Detach the installed optional card or blank panel of INPUT SLOT B by removing the two
M3x6 Pan screws on the rear panel and the two M3x6 SEMS screws on the card and lift
the card up at a right angle, to not damage any connectors.
Type of the rear panel screw is different from the ones fastening the top plate, so do not
mix the screws.
b. When an MV-12IF is installed, un-install the unit following the above procedure.
When a blank panel is on the IF slot, it does not need to be detached.
3. Detach the OUTPUT SLOT blank panel.
a. Detach the 2 screws (M3x6 Pan head).
Type of the blank panel screw is different from the ones fastening the top plate, so do not
mix the screws.
1 2 3 4
LAN
L/R
HDMI OUTPUTHDMI INPUT
4321
3G/HD-SDI
OUTPUT
AC100-240V 50/60Hz IN
ALARM OUTAUDIO OUT
3G/HD/SD-SDI,COMPOSITE INPUT
4. Detach the blank panel of the fan slot for the OUTPUT SLOT.
a. Detach the 2 screws (M3x6 Pan head) to remove the blank panel.
a

10
5. Install an additional fan.
a. Fasten the fan with brackets and screws (M3x35 Flat head).
b. Connect the fan cable connector to CN25 on the main card.
c. Fasten the fan cable using the cable ties as shown in the picture below.
When an MV-12PS is already installed, fasten the cable on that side.
6. Install the optional card.
a. Put the card in the unit from the top vertically, until the OUTPUT SLOT height, and align
the card connectors with the connectors on the MV-1200 Series.
b. Secure the card using the M3x6 SEMS screws. Use M3x6 Pan screws to fasten the card
to the rear panel.
Additional Fan
a
c
b
c
c
c
a
b

11
7. Install the air duct.
a. Determine duct location by aligning the optional heat sink location with the duct then
insert the protruding duct part between the main card and optional card.
b. Bring the duct down to cover the heat sink, being careful not to let the duct interfere with
any card parts.
c. Insert the duct on both ends of the fan, being careful not to let the duct interfere with the
fan cabling.
8. Optional card installation is complete. Put the optional card and blank panel that were removed in
Step 2, back, then put the top panel back on in reverse, referring to Step 1.
Go to Sec. 3. “Installation Confirmation.”
a
a
b

12
2-3. Installation of Redundant Power Supply MV-12PS
Installing an MV-12PS unit is explained in this section.
1. Same procedure as that of MV-12SDI / 12PCI / 12IF.
2. Remove the center support.
a. The center support is fastened by two screws (M3x6 Flat Head) on both ends.
3. When an optional card is already installed in the OUTPUT SLOT, you need to uninstall the
duct.
a. Uninstall the optional cards in the INPUT SLOT B and the IF SLOT.
Detach the two pan screws on the rear panel and two SEMS screws on the card in the
unit, then pull up the card vertically, to not damage the connectors.
b. Pull up the fan side of the duct and take out the duct from the unit taking care not to
break the protruding part of the duct.
4. Install the cable fixing bracket.
a. Align the location and fix the bracket with 4 screws (M3x6 Binding)
Cable Fixing
Bracket
D-sub
plate nut

13
5. Install the internal wiring.
a. Fix the rear connector with the connector screws and the D-sub plate tie.
b. Connect the blue and white cables with the POWER2 switch on the front.
c. Fix the internal wirings to the cable fixing bracket with cable ties.
Detach the cable ties fixing the POWER1 cables, join the MV-12PS cables and fix them
altogether again with cable ties.
d. Connect the wiring to the main card connector (CN21) and fix the wirings with the cable
fixing bracket. Fix the bracket with screws (M3x6).
6. Paste the power rating label.
Apply the label to the bottom panel of the upper side of the main unit label.
7. The installation of a redundant power supply is complete. Put the duct, cards, and the center
support removed in Steps 2. and 3. back, then put the top panel back in reverse procedure 1.
Main Unit Label
MV-12PS Power
Rating Label
b
c
d
c
c
c
c

14
8. Software Installation
a. Start up the MV-1200 Series unit and connect to a PC using a LAN cable.
Use a cross cable to connect directly and a straight cable to connect via a HUB.
b. Access the “SoftwareOptionInstallation” window from the web browser.
The default setting is http://192.168.0.10/OptionInstall.html:192.168.0.10.
Input the main unit IP address as the destination.
c. Click “Select File” (Depends on the browser. Incase of Internet Explorer, “Reference…”)
to select the SOP file to install. (File name is “MV-12[Effective Option name]_[Serial
no.].sop)
If a wrong file is selected, the page needs to re-load. (If the SOP file does not agree with
the main unit serial number, an error dialog box will appear.)
d. When a correct file is selected, letters appears on top of the Apply button.
The letters look as garbled characters, but this is normal.
e. Click apply and import SOP files.
f. The MV-12PS set up procedure is complete. Reboot the power supply and go to
installation verification.
Select File

15
3. Installation Verification
Verify the optional boards/power supply are installed correctly.
1. Access the MV-1200 Web Index window using a web browser.
Default setting is http://192.168.0.10/: 192.168.0.10.
Input the main unit IP address as the destination.
2. Tap the Version & Option tab and confirm that the installed optional boards/ power supply units
are correctly identified in the Version Information and Option Information lists.
3. When an MV-12PS is installed, supply power via the installed DC12V IN connector and confirm
that the POWER 2 status LED on the front panel lights.
The optional component installation procedure is now complete.


Warning
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of FCC Rules. These limits are
designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference, in
which case the user will be required to correct the interference at his own
expense.

FOR-A COMPANY LIMITED
Head Office 3-8-1 Ebisu, Shibuya-ku, Tokyo 150-0013, Japan
Overseas Division Tel: +81(0)3-3446-3936 Fax: +81(0)3-3445-5116
Japan Branch Offices Osaka/Okinawa/Fukuoka/Hiroshima/Nagoya/Sendai/Sapporo
R&D/Production Sakura Center/Sapporo Center
FOR-A Co
r
poration of America Corporate Office/Service Cente
r
11155 Knott Ave., Suite G, H & I, Cypress, CA 90630, U.S.A.
Tel: +1 714-894-3311 Fax: +1 714-894-5399
FOR-A Corporation of America Northeast Office
1360 Clifton Ave., Clifton, NJ 07012, U.S.A.
Tel: +1 973-220-8471 Fax: +1 714-894-5399
FOR-A Corporation of America Southeast Office
Tel: +1-305-773-7608
FOR-A Corporation of America Support Cente
r
2400 N.E. Waldo Road, Gainesville, FL 32609, U.S.A.
Tel: +1 352-371-1505 Fax: +1 714-894-5399
FOR-A Latin America and the Caribbean Miami Office
Tel: +1 657-600-5759
FOR-A Latin America and the Caribbean Sao Paulo Office
Tel: +55 (0)11-99913-3751
FOR-A Europe S.r.l.
Via Volturno, 37, 20861 Brugherio MB, Italy
Tel: +39 039-916-4811 Fax: +39 039-878-140
FOR A UK Limited
Trident Court, 1 Oakcroft Road Chessington, KT9 1BD, U.K.
Tel: +44 (0)20-3044-2935 Fax: +44 (0)20-3044-2936
FOR-A Italia S.r.l.
Via Volturno, 37, 20861 Brugherio MB, Italy
Tel: +39 039-881-086/103 Fax: +39 039-878-140
FOR-A Corporation of Korea
1007, 57-5, Yangsan-ro, Yeongdeungpo-gu, Seoul 07271, Korea
Tel: +82 (0)2-2637-0761 Fax: +82 (0)2-2637-0760
FOR-A China Limited
1618 Huateng Building, No. 302, 3 District, Jinsong, Chaoyang, Beijing 100021, China
Tel: +86 (0)10-8721-6023 Fax: +86 (0)10-8721-6033
FOR-A Middle East Africa Office
Aurora Tower, Office 1407, Dubai Media City, P.O. Box 502688, Dubai, UAE
Tel: +971 (0)4 551 5830 Fax: +971 (0)4 551 5832
FOR-A India Private Limited. Mumbai Office
2nd Floor, Valecha Chambers, Link Road, Andheri (W), Mumbai 400053, India
Tel : +91-(0)22-2673-3623 Fax︓+91-(0)22-2639-3415
FOR-A India Private Limited. Delhi Office
8th floor, World Trade Tower, Sector-16, Noida, Uttar Pradesh 201301, India
Tel: +91-(0)12-0423-8674
FOR-A South East Asia Office
Studio 09, Rm. A1, 3/F., Phase 1, Hang Fung Ind. Bldg., 2G Hok Yuen St., Hung Hom, Hong Kong
Tel : +852 2110-1352
A
ugust 13, 2020 Printed in Japan
http://www.for-a.com/
Other manuals for MV-1200
1
This manual suits for next models
6
Table of contents
