for Living 043-7334-2 User manual

Product No. 043-7334-2
45-PINT DEHUMIDIFIER
Assembly Instructions
Toll-free: 1-877-483-6759
Before operating this product, please read the instructions
carefully and save this manual for future use.

Imported for Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8

Safety Precautions
Control Panel
Parts Identification
Operation
Care and Maintenance
Troubleshooting
Limited Warranty
3
Table Of Contents
4
6
8
9
11
12
13

Product No. 043-7334-2
Safety Precautions
4
e or use an
wer cord.
To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect
operation due to ignoring of instructions may cause bodily harm or damage.
The seriousness is classified by the following indications.
This symbol indicates the possibility of death or serious injury.
Meanings of symbols used in this manual are as shown below.
Always do this.
Never do this.
CAUTION This symbol indicates the possibility of injury or damage to property.
WARNING
WARNING
CAUTION
Do not exceed the rating
of the power outlet or
connection device.
This can cause electric shock or
fire due to excess heat generation.
Do not operate or stop the
unit by switching main
power on or off.
It may cause electric shock
or fire due to heat generation.
Do not damage or use an
unspecified power cord.
It may cause electric shock or fire.
Do not modfiy power cord
length or plug other
appliances in the same outlet.
Do not insert or pull out
plug with wet hands.
Do not place the unit near
a heat source.
It may cause electric shock or fire
due to heat generation.
It may cause electric shock. Plastic parts may melt and cause
a fire.
Disconnect the power if
strange sounds, smell or
smoke comes from the unit.
It may cause fire and electric
shock.
You should never try to
take apart or repair the unit
by yourself.
Before cleaning, turn off the
power and unplug the unit.
It may cause machine failure or
electric shock.
This can cause electic shock or
injury.
Do not use the machine near
flammable gas or combustibles,
such as gasoline, benzene,
paint thinner, etc.
Do not drink or use the water
drained from the unit.
Do not take the water bucket
out during operation.
It may casue an explosion or fire. It contains contaminants and
could make you sick.
It may cause electric shock.
Do not use the unit in small
spaces.
Lack of ventilation can cause
overheating and fire.
Do not put in places where
water may splash onto the
unit.
Water may enter the unit and
degrate the insulation. It may
cause an electric shock or fire.
Place the unit on a level,
sturdy section of the floor.
If the unit falls over, it may cause
water to spill and damage
belongings, or it may cause electric
shock or fire.

Electrical lnformation
5
Safety Precautions
CAUTION
Do not cover the intake or exhaust
openings with clothes or towels.
A lack of airflow can lead to
overheating and fire.
Care should be taken when using
the unit in a room with the
following persons:
Infants, children, elderly people,
and people not senstive to
humidity.
Do not use in areas where
chemicals are handled.
This will cause the unit to
deteriorate due to
chemicals and solvents
present in the air.
Never insert your finger or
other foreign objects into grilles
or openings. Take special care
to warn children.
Do not climb up on or sit
on the unit.
It may cause electric shock
or failure of appliance.
There is danger of fire or electric
shock.
You may be injured if you
fall or if the unit falls over.
Always insert the filters securely.
Clean filter once every two
weeks.
If water enters the unit, turn the
unitoff and disconnectthe power;
contacta qualified service
technician.
Do notplace flower vases
or otherwater containers
on top of the unit.
Operation without filters may cause
failure.
It may cause failure of appliance
or accident.
Water may spill inside the
unit, causing insulation
failure and electrical
shock or fire.
Be sure the unit is properly grounded. To minimize shock and fire hazards, proper grounding is important. The power
cord is equipped with a three-prong grounding plug for protection against shock hazards.
The nameplate is located on the rear panel of the unitand contains electrical and othertechnical data specific to this unit.
Your unit must be used in a properly grounded wall receptacle. If the wall receptacle you intend to use is not adequately
grounded or protected by a time delay fuse or circuit breaker, have a qualified electrician install the proper receptacle.
To avoid the possibility of personal injury, always disconnect the power supply to the unit before installing and/or
servicing.
Do not use extension cords or an adaptor plug with this unit. However, if it is necessary to use an
extension cord, use an approved "Dehumidifier" extension cord only (available at most local hardware stores).
Make sure the receptacle is accessible after the unit has been installed.
Do not place heavy objects on the
power cord and take care so that
the cord is not compressed.

Humidity Set Control Buttons
Timer Set Control Buttons
The humidity level can be set within a range of
35% RH (Relative Humidity) to 85% RH (Relative
Humidity) in 5% increments.
For drier air, press the button and set to a
lower percent value (%).
For damper air, press the button and set to
a higher percent value (%).
The check filter feature is a reminder to clean the
air filter for more efficient operation. The clean
filter light will illuminate after 250 hours of
operation. To reset after cleaning the filter,
press the filter button and the light will go off.
The control panel of the unit you purchased may be slightly different depending on its
model .
Product No. 043-7334-2
6
Control Panel
Down/Up buttons
Filter button
Mode button
Press to select the desired operation mode:
Dehumidifying, Continuous Dehumidifying and
Comfort Dehumidifying.
In Comfort Dehumidifying mode, the unit will
automatically control room humidity to maintain a
comfortable range of 45 to 55% according to the
room temperature. The humidity setting function
will be invalid.
Timer Set Control Buttons
After the Auto Start or Auto Stop feature has
been initiated, press or to increase or
decrease time remaining.
Timer button
Press to initiate the Auto Start and Auto Stop feature,
in conjunction with the and buttons.
Fan button
Control the fan speed. Press to select either High or
Normal fan speed. Set the fan control to High for
maximum moisture removal. When the humidity has
been reduced and quiet operation is preferred, set the
fan control to Normal.
Power button
Press to turn the dehumidifier on and off.
Filter light
Bucket full light
Continuous dehumidifying light
Timer on light
Timer off light
High fan light
Comfort dehumidifying light
Auto defrost light
NOTE:
Fig.1
Filter
Filtre
Filter
Filtre
Mode
Fan
Ventilateur
Power
Alimentation
Timer
Minuterie
Comfort
Confort
Cont.
Continu
On Off
Marche Arrêt
Auto defrost
Auto-dégivrage
Full
Plein
Filter
Filtre
Mode
Fan
Ventilateur
Power
Alimentation
Turbo
On
Marche
Off
Arrêt
Comfort
Confort
Auto defrost
Auto-dégivrage
Full
Plein
Filter
Filtre
Cont.
Continu
Timer
Minuterie
Indicator lights

Control Panel
7
Other features
8
Display
When the unit is on, press the Timer
button and the Timer Off indicator light
will illuminate. It indicates the Auto Stop
program is initiated. Press Timer button again,
the Time On indicator light illuminates and
indicates the Auto Start program is initiated.
When the unit is off, first press the Timer
button and the Timer On indicator light
illuminates. It indicates the Auto Start
program is initiated. Press the button again,
the Time Off indicator light illuminates and
indicates the Auto Stop program is initiated.
Press or hold the UP or DOWN button to
change the Auto Start or Stop time in 0.5 hour
increments, up to 10 hours then in 1 hour
increments up to 24 hours. The control will
count down the time remaining until start or
stop.
The selected time will register in 5 seconds
and the system will automatically revert
back to display the previous humidity
setting.
When the Auto Start and Auto Stop times are
set, within the same program sequence,
Timer On/Off indicator lights illuminate
identifying both ON and OFF times are
now programmed.
Turning the unit ON or OFF at any time or
adjusting the timer setting to 0.0 will cancel
the Auto Start/Stop function.
When LED display window displays P2 code,
the Auto Start/Stop function will also be
cancelled.
Setting the Timer
Shows the set % humidity level from 35 to 85% or auto start/stop time (0 to 24 hours) while setting,
then shows the actual (± 5% accuracy) room % humidity level in a range of 30% RH (Relative
Humidity) to 90% RH (Relative Humidity).
Error Codes and Protection Codes
AS—Humidity sensor error: Unplug the unit and plug it back in. If error repeats, call for service.
ES—Temperature sensor error: Unplug the unit and plug it back in. If error repeats, call for service.
P2.—Bucket is full or bucket is not in correct position: Empty the bucket and replace it in the right
position.
EC—Unit malfunction: Please make sure that the ambient temperature is suitable for operation, as
stated in this manual. If not, please adjust the unit to operate within the stated temperature range.
If the ambient temperature is suitable for operation and the unit still malfunctions, please call for
service.
Bucket Full light
Glows when the bucket is ready to be
emptied, or when the bucket is removed
or not replaced in the proper position.
Auto Shut Off
The dehumidifier shuts off completely after 30
seconds when the bucket is full, or when the
bucket is removed or not replaced in the proper
position. When the set humidity is reached,
the unit will shut off automatically. For some
models, the fan motor will continue operating.
Auto Defrost
The Auto Defrost indicator light will illuminate
when frost builds up on the evaporator coils. The
compressor will cycle off and the fan will continue
to run until the frost disappears. The light will then
turn off.
Wait 3 minutes before resuming operation
After the unit has stopped, it cannot restart its
operation for 3 minutes. This feature protects
the unit. Operation will automatically start after
3 minutes.
Check Filter feature
The system starts to count the time once the fan
motor operates. The check filter feature will activate
when the accumulated operation time reaches 250
hours or more. The Clean Filter indicator light will
flash once per second. When finished cleaning the
air filter, press the Filter button and the Clean Filter
indicator light will go out.
Auto-Restart (on some models)
If the unit stops unexpectedly due to a loss of power,
it will restart automatically with its previous settings
when the power resumes.

Product No. 043-7334-2
8
Parts Identification
Drain hose outlet
Band (Used only when
storing the unit.)
Rear
Air outlet grille
Castors
Fig. 2
Fig. 3
Air filter (behind the grille)
Control panel
Air intake grille
Water bucket
1
2
3
4
5
1
2
3
4
All pictures in the manual are for
explanation purposes only . The actual shape
of the unit you purchased may be slightly
different, but its operations and functions
are the same.
5
1
23
4
6
6Handle (both sides)
1
2
3
Front
Accessories:
NOTE:
Parts Identification
Power cord and plug
Drain hose (1 pc)Adaptor A (1 pc)Screw (2 pcs)

9
When using the unit
When first using the dehumidifier, operate the unit
This unit is designed to operate with a working
environment between 5ºC (41ºF) and 35ºC (95ºF).
If the unit has been switched off and needs to be
switched on again quickly, allow approximately
three minutes for the correct operation to resume.
Do not connect the dehumidifier to a multiple socket
outlet which is also being used for other electrical
appliances.
Select a suitable location, making sure you have easy
access to an electrical outlet.
Plug the unit into a electrical socket-outlet with ground
connection.
Make sure the water bucket is correctly fitted otherwise
the unit will not operate properly.
When water in the bucket reaches a certain
level, please be careful when moving the machine to
avoid spillage.
NOTE:
Prior to first use or after moving, the product must
remain in its upright position for at least 24 hours prior
to being turned on.
Castors can move freely.
Do not force castors to move over carpet,
nor move the unit with water in the bucket.
(The unit may tip over and spill water.)
Air outlet grille
Air intake
grille
more
Positioning the unit
Do not use outdoors.
This dehumidifier is intended for indoor residential
A dehumidifier operating in a basement will have little or no effect in drying an adjacent enclosed
storage area, such as a closet, unless there is adequate circulation of air in and out of the area.
applications only. This dehumidifier should not be used
for commercial or industrial applications.
enough to support the unit with a full bucket of water.
Place the dehumidifieron a smooth, level floorstrong
for good air circulation.
Place the unit in an area where the temperature will not
fall below 5ºC (41ºF). The coils can become covered with
frost at temperatures below 5ºC (41ºF), which may reduce
the performance.
Place the unit away from the clothes dryer, heater or radiator.
or valuables are stored.
Use the dehumidifier in a basement to help prevent
moisture damage.
The dehumidifier must be operated in an enclosed
area to be most effective.
Close all doors, windows and other outside openings
to the room.
Fig. 4
Allow at least 8" (20 cm) of air space on all sides of the unit
15" (40 cm) or
8" (20 cm) or more 8" (20 cm) or more
8" (20 cm) or more 8" (20 cm) or more
Castors (At four points on the bottom of unit)
Use the unit to prevent moisture damaging where books
continuously for 24 hours.
Operation

Water can be automatically emptied into a floor drain
(I.D. 8 mm (5/16˝), not included) with a female threaded
end (I.D. 26 mm (1˝), not included)
Make sure the drain hose is connected to the adaptor
A (see Fig. 7, placed in the bucket).
Remove the plastic cover from the back drain outlet of
the unit and remove bucket, then insert the drain hose
through the drain outlet of the unit and securely press it
onto the connector on the front of the unit (see Fig. 9).
Tighten the adaptor A to the unit by using two screws
(placed in the bucket).
Install the female threaded end of the water hose
(not included) to adaptor A (see Fig. 10), then lead the
water hose to the floor drain or a suitable drainage opening.
Make sure the hose is secure so there are no leaks.
Direct the hose toward the drain, making sure that
there are no kinks that will stop the water flowing.
Place the end of the hose into the drain and make sure the
end of the hose is level or down to let the water flow
smoothly. Make sure it is not pointing upwards.
Place the bucket back in the unit and make sure
that it is located correctly.
Select the desired humidity setting and fan speed
on the unit for continuous draining to start.
NOTE: When the continuous drain feature
is not being used, remove the drain hose
from the outlet.
Removing the collected water 1. Pull out the bucket a little.
3. Pour the water out.
There are two ways to remove collected water.
1. Use the bucket
When the unit is off, if the bucket is full, the unit will
beep 8 times and the Full indicator light will flash. The
digital display shows P2.
When the unit is on, if the bucket is full, the compressor
turns off but the fan continues for 30 seconds to dry the
unit. Then the unit will beep 8 times and the Full indicator
light will flash. The digital display shows P2.
Slowly pull out the bucket. Grip the left and right
handles securely, and carefully pull out straight so
water does not spill. Do not put the bucket on the floor
because the bottom of the bucket is uneven—the bucket
will fall and cause the water to spill.
Pour out the water and reinstall the bucket. The bucket
must be in place and securely seated for the
dehumidifier to operate.
The machine will re-start when the bucket is restored
in its correct position
NOTES:
When you remove the bucket, do not touch any parts
inside of the unit. Doing so may damage the product.
Be sure to push the bucket gently all the way into the
unit. Banging the bucket against anything or failing to
push it in securely may cause the unit not to operate.
When you remove the bucket, if there is some water in
the unit it must be dried.
Fig. 5
Fig. 6
2. Continuous draining
Fig. 8
Plastic cover
Drain hose Adaptor A
Fig. 7
Drain hose
subassembly
Fig. 9
Connector
Drain hose
Fig. 10
Water hose
Female threaded end
d
2. Hold both sides of the bucket
with even strength, and pull it
out from the unit.
Product No. 043-7334-2
10
Operation

3. Clean the air filter
Remove the filter every two weeks based on normal
operating conditions.
Remove the filter from the top of the unit (see Fig. 11).
Wash the filter with clean water then dry.
Re-install the filter, and replace bucket.
DO NOT operate the dehumidifier without a filter
because dirt and lint will clog it and reduce the
performance.
CAUTION:
Fig. 11
4. When not using the unit for long time periods
Care and cleaning of the dehumidifier
Turn the dehumidifier off and remove the plug
from the wall outlet before cleaning.
1. Clean the grille and case
Use water and a mild detergent. Do not use bleach
or abrasives.
Do not splash water directly onto the main unit. Doing
so may cause an electrical shock, cause the insulation
to deteriorate, or cause the unit to rust.
The air intake and outlet grilles get soiled easily, so use
a vacuum attachment or brush to clean.
2. Clean the bucket
Every few weeks, clean the bucket to prevent growth of mold,
mildew and bacteria. Partially fill the bucket with clean water
and add a little mild detergent. Swish it around in the bucket,
empty and rinse.
Do not use a dishwasher to clean the bucket.
After cleaning, the bucket must be back in place and securely
seated for the dehumidifier to operate.
NOTE:
Fig. 12
11
Care And Maintenance
After turning off the unit, wait one day before emptying
the bucket.
Clean the main unit, water bucket and air filter.
Wrap the cord and bundle it with the band (Fig. 12).
Cover the unit with a plastic bag.
Store the unit upright in a dry, well-ventilated place.

Problem What to check
Unit does not start
Make sure the dehumidifer's plug is pushed completely into the
outlet.
Check the house fuse/circuit breaker box.
bucket is full.
Water bucket is not in the proper position.
Dehumidifier does not
dry the air as it should
Not enough time was allowed to remove the moisture.
Make sure there are no curtains, blinds or furniture blocking the
front or back of the dehumidifier.
The humidity control may not be set low enough.
Check that all doors, windows and other openings are securely
closed.
Room temperature is too low—below 5ºC (41ºF).
There is a kerosene heater or something giving off water
vapours in the room.
The unit makes a loud
noise when operating
The air filter is clogged.
The unit is tilted instead of upright as it should be.
The floor surface is not level.
Frost appears on the
coils
This is normal. The dehumidifier has an auto-defrost feature.
Water on floor Hose to connector or hose connection may be loose.
Drain hose and adaptor are not removed when using bucket
to collect water.
ES, AS , EC or P2
appear in the display
These are error codes and protection codes. See
section.
CONTROL
PANEL
Dehumidifier has reached its preset relative humidity level or
Before calling customer service, review the chart below first.
Product No. 043-7334-2
12
Troubleshooting

13
Limited Warranty
This For Living product carries a one (1) year warranty against defects in workmanship and materials. Trileaf
Distribution agrees to replace the defective product free of charge, within the stated warranty period, when
returned by the original purchaser with proof of purchase. This product is not guaranteed against wear or
breakage due to misuse and/or abuse.
