for Living 052-2228-4 User manual

model no. 052-2228-4
Instruction Manual
IMPORTANT: Please read and understand this manual before any assembly. Before
beginning assembly of product, make sure all parts are present. Compare parts
with exploded view. If any part is missing, or if you have any questions,
contact customer service at 877-483-6759.
Toll-free: 1-877-483-6759
"
V. 4 2016

3
Table of Contents
IMPORTANT: RETAIN FOR FUTURE REFERENCE, AND READ CAREFULLY
Toll-free: 877-483-6759 • model no. 052-2228-4
Exploded view .............................................................................................................................................1
Important safety instructions................................................................................................................ 2
Rules for safe installation........................................................................................................................ 2
Tools required for assembly................................................................................................................... 3
Assembly....................................................................................................................................................... 3
Operation.......................................................................................................................................................6
Maintenance................................................................................................................................................. 7
Care and cleaning...................................................................................................................................... 7
Troubleshooting.......................................................................................................................................... 7
Environmental protection....................................................................................................................... 8
Warranty........................................................................................................................................................ 9

3
Exploded View
EXPLODED VIEW
No Description Qty
A
B
C
D
E
F
Mounting Plate
Motor
Blade Arm
Bulb (3X E12 X60 W)
Switching Housing
Light Shade
1
1
1
4
1
3
G3
J1
Blade
H4
1
Canopy
Remote
I 1
Control
Receiver
K1
Parts Pack

Toll-free: 877-483-6759 • model no. 052-2228-4
3
Instructions
IMPORTANT SAFETY INSTRUCTIONS
Please retain this manual for future reference.
Note
· A dry dust cloth is suitable for most cleanings.
· Should the ceiling fan become wet, have a qualified electrician inspect it before next use.
· In order to comply with safety regulations and to avoid safety hazards, ceiling fan repairs must be
carried out by qualified personnel.
· Pay attention to the ceiling fan blades when cleaning, painting or working nearby.
· Children do not recognize the dangers that may occur when operating ceiling fan. Keep children
away
from ceiling fans.
DO NOT: · Expose the ceiling fan to water or immerse it in water.
· Operate the ceiling fan if it shows any signs of damage or if it has been dropped.
· Attempt to remove any parts of the housing or insert any object while the ceiling
fan is operating.
· Position the ceiling fan on or near hot surfaces such as stove tops, or near open flames.
· Expose the ceiling fan to rain or moisture. Do not operate the ceiling fan outdoors
or with wet hands.
· Use the reverse switch while the fan blades are in motion. This cuold result in damage
to the ceiling Fan.
RULES FOR SAFE INSTALLATION
This ceiling fan is designed for household use only and not for commercial applications. No responsibility
is accepted for damage resulting from improper use or non compliance with the instructions.
CAUTION!
· To avoid possible electrical shock, be sure electricity at the fuse box or the circuit breaker is
· All wiring must be done in accordance with national and local wiring codes. Consult a qualified
electrician to ensure correct branch circuit conductor.
· Follow the recommended instructions for the proper method of wiring for the new ceiling fan.
The ceiling fan must be grounded as a precaution against possible electric shock.
electrician.
· The outlet box and joist must be securely mounted and capable of reliably supporting at least
15.9 kg (35 lbs).
· Mount the lowest moving parts at least 2.5 m above floor or ground level.
· Make sure all electrical connections are sealed with proper connector and electrical tape inside
the outlet box.
· Make sure the ceiling fan is securely fastened to the ceiling.
· All set screws must be checked and re-tightened where necessary before fan operation.
WARNING!
· Mount only to an outled box marked acceptable for fan support.
· To prevent injury, make sure the fan blades are not bent and that there are no
objects within the rotation area.
· The important precautions, safeguards and instructions appearing in this manual are not meant
to cover all possible situations. It must be understood that common sense and caution are
factors which cannot be built into the product.
· Not suitable for use with solid-state speed controls.
2

12
Assembly
TOOLS REQUIRED FOR ASSEMBLY
This manual is designed to make it as easy as possible for you to assemble, install, operate and maintain
the ceiling fan.The following tools listed are required for assembly and installation:
1x star-head screwdriver
1x flat screwdriver
1x wrench
1x stepladder
1x wird stripper/pliers
1x electrical tape
After opening the package, you should find all the necessary parts for installing this ceiling fan.
The box should also contain:
Parts Pack Containing:
2 wood screws with flat washers
1 “J” hook
1 zip tie
ASSEMBLY
Preparing for installation
Getting ready
· Unpack and inspect carefully to make sure all parts are
included and not damaged (see Fig. 1). Lay all pieces out
on a working space.
possible electric shock (see Fig. 2).
Choosing a location for the ceiling fan
(81.3 cm) from adjacent walls or obstructions.
· Choose a location where there is a high enough ceiling clearance (at least 2.5 m above the floor
from the ceiling fan’s lowest moving part).
· Ensure that the outlet box in the room’s ceiling can support the weight of the fan.Typically, if the
outlet box is marked acceptable for fan support, it can hold the fan securely.
Installation
1.1 Mounting bracket
3
2 mounting screws with lock washers
Outlet box
screw
Lock washer
. Securely attach the mounting bracket to
an outlet box marked “Acceptable for Fan
Support”, using the supplied outlet box
screws with lock washers (Fig. 3a).
Mounting
bracket
Flat
washer
wood screw
3a
3b
Note: The mounting bracket depicted will vary
depending on the model .
. Remove the four sets of side screws from mounting
bracket and save for future use.
Normal masonry ceiling
Wooden ceiling
Drill two mounting holes in the ceiling joist.Securely
attach the mounting bracket to the ceiling or
wooden ceiling as indicated below (Fig. 3b).
.

Toll-free: 877-483-6759 • model no. 052-2228-4
Assembly
ASSEMBLY
until locks the blade
1.3 Hands-free wiring
2. Wiring instructions
IMPORTANT: If you are not sure if the electrical outlet box and fan are grounded, contact a licensed
electrician for advice.They must be grounded for safe operation.
WARNING
before wiring.
4
Raise canopy-motor assembly to mounting plate’s
hook and hang by the screw hole on the canopy
This will allow for hands-free wiring.
Bracket’s hook, follow wiring instructions.
m
4a4b
1.2 Attach blade to motor assembly
· Insert the blade to the blade bracket (see Fig. 4a).
· Pull the blade until it locks and you hear it click (see Fig. 4b).
· Repeat this step for all 4 blades.
Remote and Receiver Pairing
Codes are set by pushing the location of the dip switches located on the transmitter and receiver
up or down. It is important that the code used for both the remote and receiver are identical for
the two devices to be able to communicate; otherwise the remote will not be able to control
the fan.
If you plan to install more than one fan then each fan will require the remote and receive to
use a unique code, or else one remote will be able to control more than one fan.
Once the connection has been made, the receiver inserts into the drop rod hanging bracket.
The canopy comes up to cover the receiver and bracket .
Installing Receiver Assembly
!
!
!

“J”hook zip tie
Assembly
ASSEMBLY
· When wires are matched up,connect them by twisting frayed ends together (see Fig. 5a )
· Screw wire connectors (3 are provided) onto the tops of the twisted wires (see Fig. 5b).
· Fasten them with electrical tape (see Fig. 5c).
WARNING: Be sure no bare wire or wire strands are visible after making connection. Place
green and white connections on opposite side of box from the black and blue (if applicable)
connections.
3. Fan assembly
· Remove the side screws and washers on
the side of the mounting plate. Secure the
fan to the mounting plate with the side
screws and washers (see Fig. 6).
· Install three 60 W candelabra-base bulbs.
NOTE: Remove the paper card between the blade arms and
the switch cap before turning the power on.
5
6
Note: for added security, attach safety cable from fan unt to”J”hook in outlet box . Secure by
looping zip tie through safety cable and”J”HOOK. Tighten zip tie securely.
Between receiver and mains:
· Connect the black live wire marked “AC IN L” from the receiver to the live wire (typically
black) from the outlet box.
· Connect the white neutral wire marked “AC IN N” from the receiver to the neutral wire
(typically white) from the outlet box.
· Connect the green ground wires from the mounting bracket and nylon ball to the ground
wire (bare or green) from the outlet box.
Making Connections
5c
5b
5a
aluminium ball

Toll-free: 877-483-6759 • model no. 052-2228-4
Operation
OPERATION
· Restore power to ceiling fan and test for proper operation.
· Hand held controls the fan settings:
6
HI : Turn on the fan at high speed
MED : Turn on the fan at medium speed
LOW : Turn on the fan at low speed
LIGHT: ON/OFF : Press and release immediately to turn
DIMMER : Press and hold on to dim or brighten
lights to the desired level and release.
(Only for the tungsten bulb.)
LIGHT
ON/oFF
HI
MED
DIMMER
FAN OFF
LOW
Forward and reverse direction function
This ceiling fan is equipped with reverse switch for downward or upward air-flow.
NOTE: Do not change the direction of rotation while the fan blades are in motion.
before setting the switch to the desired rotation direction, either forward or
reverse.
Reverse
Forward Switch housing
Reverse switch
7
8
Forward function
· On this setting, the fan will turn counter-clockwise
warmer weather to circulate the hot air away from
your living space (see Fig. 7).
Reverse function
· On this setting, the fan will turn clockwise.Use this
function during cooler weather to re-circulate warm
air (see Fig. 8).
9V
Battery
Install the 9 V battery (included). To prevent damage to transmitter
remove the battery if not used for long periods .

Troubleshooting
MAINTENANCE
· Because of the fan’s natural movement, some connections may become loose. Check the support
connections, brackets and blade attachments twice a year. Make sure they are secure.
· There is no need to oil your fan. The motor has permanently lubricated bearings.
CARE AND CLEANING
· Dust your fan periodically with a soft, dry cloth. Do not use harsh cleaners or materials as they may
damage the unit.
· To prevent bending the blades during cleaning, support the blades so that no pressure is applied to
them.
Caution!
Do not allow water to come in contact with fan blades or the ceiling fan. Doing so will create
fire and/or shock hazards, damaging property.
TROUBLESHOOTING
If problems persist, seek help from a certified electrician.
Problem
Fan is noisy
during
operation
· Blade screws are loose.
· The mounting plate or canopy is loose.
· Screws securing decorative housing to
hanger are loose.
· Lamp shades or bulbs are loose.
· Screws securing downrod to hanger are
loose.
· Wire connectors are vibrating against the
inside of canopy.
· Light kit or light bulb is not firmly
attached.
· Canopy is rattling against ceiling.
· Motor housing screws have come loose.
Possible reason Solution
· Tighten screws on blades with a
screwdriver.
· Check and fasten the screws.
· Check and fasten the screws.
· Tighten by hand, as necessary.
· Check and fasten screws.
· Disconnect power at fuse box, loosen
canopy and re-position connectors.
· Remove and re-attach.
· Be sure canopy is not touching ceiling.
· Check and fasten the screws.
Fan does no
start
· Fuse or circuit breaker is blown.
· Loose or incorrect power line
connections to the fan or switch wires.
· Remote control
· Check main fuse and branch circuit
fuses or circuit breaker. Repair as
necessary.
· Check all the wire connections to
fan and housing wiring. Repair as
necessary.
· Check the setting and coding
· Check the battery
· Check the remote control
operation and installation instructions
Caution!Make sure the main
7

Toll-free: 877-483-6759 • model no. 052-2228-4
Troubleshooting
TROUBLESHOOTING
Problem
Lights does
not work
Possible reason
· Wires are not properly connected.
· Light bulbs are faulty.
Solution
· Ensure wire connector in switch
housing is connected.
· Unscrew light bulbs and discard
properly.
· Turn the power OFF and replace
the bulbs
Fan does
not seem to
move much
air
· Fan is in reverse (blades are moving in
clockwise direction).
· Fan is not properly located.
· Counter-clockwise (forward) is
recommended in warm weather.
rotation to stop. Use the eraser end
of a pencil to change the forward /
reverse slide switch.
· Place fan in the center of the room
so there is at least 12" (30 cm)
between the end of the blades and
walls or other obstructions.
Fan wobbles
or shakes
excessively
· Screws securing fan blade clips to motor
are loose.
· Fan blade and its blade clip are not
fastened securely.
· Canopy and mounting bracket are not
tightened securely.
· Make sure that screws which attach
fan blade clips to motor are fastened
and tightened.
· Tighten screws of fan blade to blade
clip securely.
· Ensure that canopy and mounting
bracket are tightened securely to
ceiling joist.
ENVIRONMENTAL PROTECTION
Discarded electrical appliances are recyclable and should not be discarded in your regular
domestic waste! Please actively support us in conserving resources and protecting the
environment by returning this appliance to a collection centre (if available).
Battery reclamation (please keep to comply with the local law.)
8

Warranty
WARRANTY
9
Impor
Subject to the conditions and limitations described below, this product, if returned to us with proof of
purchase within the stated warranty period and if covered under this warranty, will be repaired or
replaced (with the same model, or one of equal value or specification), at our option. We will bear the
cost of any repair or replacement and any costs of labor relating thereto.
These warranties are subject to the following conditions and limitations:
a) A bill of sale verifying the purchase and purchase date must beprovided;
b) This warranty will not apply to any product or part thereof which is worn or broken or which has
become inoperative due to abuse, misuse, accidental damage, neglect or lack of proper installation,
operation or maintenance (as outlined in the applicable owner’s manual or operating instructions)
or which is being used for industrial, professional, commercial or rental purposes;
c) This warranty will not apply to normal wear and tear or to expendable parts or accessories that
may be supplied with the product that are expected to become inoperative or unusable after a
seasonable period of use;
d) This warranty will not apply to routine maintenance and consumable items such as, but not limited
to, fuel, lubricants, vacuum bags, blades, belts, sandpaper, bits, fluids, tune-ups or adjustments;
e) This warranty will not apply where damage is caused by repairsmade or attempted by others
(i.e. persons not authorized by the manufacturer);
f) This warranty will not apply to any product that was sold to the original purchaser as a
reconditioned or refurbished product (unless otherwise specified in writing);
g) This warranty will not apply to any product or part thereof ifany part from another manufacturer
is installed therein or any repairs or alterations have been made or attempted by unauthorized
persons;
h) This warranty will not apply to normal deterioration of the exterior finish, such as, but not limited
to, scratches, dents, paint chips, or to any corrosion or discoloring by heat, abrasive and chemical
cleaners; and
i) This warranty will not apply to component parts sold by and identified as the product of another
company, which shall be covered under the product manufacturer’s warranty, if any.
Additional Limitations
This warranty applies only to the original purchaser and may not be transferred. Neither the retailer nor
the manufacturer shall be liable for any other expense, loss or damage, including, without limitation,
any indirect, incidental, consequential or exemplary damages arising in connection with the sale, use or
inability to use this product.
Notice to Consumer
This warranty gives you specific legal rights, and you may have other rights, which may vary from
province to province. The provisions contained in this warranty are not intended to limit, modify, take
away from, disclaim or exclude any statutory warranties set forth in any applicable provincial or
federal legislation
ted by/
Trileaf Distribution Trifeuil Toronto,Canada M4S 2B8
This For Living product carries a limited ten (10) year warranty against defects in the motor, and a one (1)
year warranty against defects in workmanship and materials. Trileaf Distribution agrees to replace the
defective product free of charge within the stated warranty period, when returned by the original
purchaser with proof of purchase. This product is not guaranteed against wear or breakage due to
misuse and/or abuse.
Table of contents
Other for Living Fan manuals

for Living
for Living 043-7330-0 User manual

for Living
for Living 043-5649-6 User manual

for Living
for Living Preston 52'' User manual

for Living
for Living 043-5218-2 User manual

for Living
for Living 052-2230-6 User manual

for Living
for Living 052-9715-2 User manual

for Living
for Living 043-7021-6 User manual

for Living
for Living 052-9706-4 User manual

for Living
for Living SFDRO-200BPT User manual

for Living
for Living 043-8603-6 User manual
