Foremost Massa User manual

page 1/14
STEP-BY-STEP ILLUSTRATED
OPERATING MANUAL/INSTALLATION STEPS
Massa Intelligent Bidet Seat
FOREMOST GROUPS INC. (U.S.A.): 6241 Northwind Parkway, Hobart, IN, USA 46342 - 1-888-620-3667 www.foremostbath.com
OCTOBER 2020
• Prior to installation and use, please read this operating manual carefully.
• Please keep this manualafter installation for quick reference in future needs.
VIEW FROM RIGHT AND LEFT SIDE OF MASSA INTELLIGENT BIDET SEAT
PRODUCT DIAGRAM
Push Button Water Inlet
Seat water supply hose
T-valve
Power supply plug
Toilet water supply hose (not included)
Control panel
Caution label
Bidet cover
Warm air outlet
Nozzle
Heated seat ring
Right hand view Left hand view

page 2/14
STEP-BY-STEP ILLUSTRATED
OPERATING MANUAL/INSTALLATION STEPS
Massa Intelligent Bidet Seat
FOREMOST GROUPS INC. (U.S.A.): 6241 Northwind Parkway, Hobart, IN, USA 46342 - 1-888-620-3667 www.foremostbath.com
OCTOBER 2020
12
.
If not followed, may result in serious injury.
WARNING
This product must be grounded before use and plugged
into an (AC 110V, 60Hz) power outlet.
*Failing to do so can cause fire or electric shock.
Grounding
Do not plug or unplug the power plug with wet hands.
*Doing so may cause electric shock.
Wet hands
prohibited
Never disassemble, repair or alter the product.
*Doing so may cause fire, electric shock, heat or short
circuit.
Disassembling or
repair prohibited
Do not use a damaged power cord, plug or loose electric
outlet.
*Doing so may cause fire or electric shock.
Prohibited
Keep cigarettes and other open flames away from the
product.
*Doing so may cause fire, electric shock, heat or short
circuit.
Feu interdit
Children, elderly, patients and those who are physically
limited should be accompanied during use of toilet at all
times.
*Seated for long periods of time may cause low
temperature burn.
Prohibited
12
.
May result in electric shock, fire, injury, and property
damage.
CAUTION
Do not strike, pull, twist, excessively bend, damage, alter,
or heat the power cord.
Prohibited
Do not stand on the top of the seat cover, seat or main
body unit. This can damage or break the unit.
Prohibited
Prevent children from throwing substances or inserting
their hands into the dryer outler or into the nozzle.
Prohibited
Do not slam or close the seat cover forcefully.
Prohibited
When cleaning or not using the product over a long period
of time, be sure to unplug the unit.
Prohibited
Never submerge the product into water.
Prohibited

page 3/14
STEP-BY-STEP ILLUSTRATED
OPERATING MANUAL/INSTALLATION STEPS
Massa Intelligent Bidet Seat
FOREMOST GROUPS INC. (U.S.A.): 6241 Northwind Parkway, Hobart, IN, USA 46342 - 1-888-620-3667 www.foremostbath.com
OCTOBER 2020
IMPORTANT SAFEGUARDS
When using electrical products, especially when children are present, basic safety precautions should always be followed, including
the following:
READ ALL INSTRUCTIONS BEFORE USING
A. DANGER– To reduce the risk of electrocution:
1. Do not use while bathing.
2. Do not place or store product where it can fall or be pulled into a tub or sink.
3. Do not pour or spray water or other liquid onto the product.
5. Never operate this product if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or
dropped into water.
B. WARNING– To reduce the risk of burns, electrocution, fire, or injury to persons.
1. Close supervision is necessary when this product is used by children or people with physical disabilites.
2. Use this product only for its intended use as described in this manual. Do not use attachments not recommended by the
manufacturer.
3. Keep the power supply cord away from heated surfaces.
4. Never block the air openings of the product. Keep the air openings free of lint, and dust.
5. Never use while sleeping or drowsy.
6. Never drop or insert any object into any opening or hose.
7. Do not use outdoors.
8. Do not operate where aerosol (spray) products are being used or where oxygen is being administered.
9. Connect this product to a properly grounded outlet only.
- Return the product to place of purchase for examination and repair.
SAVE THESE INSTRUCTIONS

page 4/14
STEP-BY-STEP ILLUSTRATED
OPERATING MANUAL/INSTALLATION STEPS
Massa Intelligent Bidet Seat
FOREMOST GROUPS INC. (U.S.A.): 6241 Northwind Parkway, Hobart, IN, USA 46342 - 1-888-620-3667 www.foremostbath.com
OCTOBER 2020
GROUNDING INSTRUCTIONS
Important: It is incumbent upon the installer/homeowner to consult local building and electrical codes to insure proper installation
of this toilet seat.
The Massa Intelligent Bidet Seat is manufactured with a Ground Fault Circuit Interrupter (GFCI) plug.
The GFCI provides a safety mechanism and a grounding wire to guard against an electrical shock.
Should this toilet seat come into contact with water or incur any surge in electrical current the GFCI plug would stop the electrical
Resetting
the plug . This will return the GFCI plug to its original operating setting.
Warning Note
Should this GFCI become damaged for any reason please consult a Licensed Electrician for
repair or replacement. DO NOT ATTEMPT THIS YOURSELF.
Check with a licensed electrician or serviceman if the grounding instructions are not completely understood. Or if there is any doubt
the product is properly grounded.
This product is for use on a nominal 110V circuit, and has a GFCI that looks like the electrical plug illustrated below.
This product has been certified by
GFCI Plug
Grounded Pin
Grounded Outlet
Grounded
Outlet Box
GROUNDING METHODS

page 5/14
STEP-BY-STEP ILLUSTRATED
OPERATING MANUAL/INSTALLATION STEPS
Massa Intelligent Bidet Seat
FOREMOST GROUPS INC. (U.S.A.): 6241 Northwind Parkway, Hobart, IN, USA 46342 - 1-888-620-3667 www.foremostbath.com
OCTOBER 2020
ABC
HARDWARES AND PARTS LIST
A Massa Intelligent Bidet Seat Cover x1
B Seat water supply hose & T-valve x1 Set
C Operating manuals and other printed material x1
D Mounting plate x1
E Seat boltskit x2
F Template x1
DEF• Please confirm that all articles in the package are complete. If any of parts
are missing, please contact our customer service department at 1-888-256-
7551 Canada or 1-888-620-3667 USA
QTY
T-valve
NOTES FOR INSTALLATION
Water Requirements
• The minimum dynamic water pressure required is 11.6 psi (0.8 kg / square cm).
• The maximum static water pressure required is 101.5 psi (7 kg / square cm).
Minimum Water Pressire Confirmation Essentials
This method can be used if you have no water measuring gauge:
Open the water supply angle valve
Measure whether the amount of water flowing out within 10 seconds reaches 3 litres/0.8
galllons, and if it reaches 3 liters/0.8 gallons, it indicates that the installation requirements are
met. Otherwise, the booster device needs to be installed for pressurization.

page 6/14
STEP-BY-STEP ILLUSTRATED
OPERATING MANUAL/INSTALLATION STEPS
Massa Intelligent Bidet Seat
FOREMOST GROUPS INC. (U.S.A.): 6241 Northwind Parkway, Hobart, IN, USA 46342 - 1-888-620-3667 www.foremostbath.com
OCTOBER 2020
INSTALLATION STEPS
REMOVE EXISTING SEAT (FIGURE 1)
INSERT THE RUBBER PLUG
Insert the rubber plug into each of the bowl holes (FIGURE 2).
Old toilet lid
FIGURE 1
FIGURE 2
Rubber Plug
Hole
PLACE TEMPLATE
Place the template horizontally on the ceramic surface. Fold the edgefold
vertically downward against the rear rim of bowl (FIGURE 3).
FIGURE 3
Edgefold
3
2
1
Template

page 7/14
STEP-BY-STEP ILLUSTRATED
OPERATING MANUAL/INSTALLATION STEPS
Massa Intelligent Bidet Seat
FOREMOST GROUPS INC. (U.S.A.): 6241 Northwind Parkway, Hobart, IN, USA 46342 - 1-888-620-3667 www.foremostbath.com
OCTOBER 2020
INSTALLATION STEPS
ATTACHING THE MOUNTING PLATE
Attaching the mounting plate. Place the mounting plate on
the blank space and use the screwdriver to tighten the bolt
with bolt guide from top (FIGURE 4).
FIGURE 4
arrow point towards the back of the toilet
Bolt
Bolt guide
Mounting plate
5ATTACH THE TOILET SEAT
Attach the toilet seat. Remove the template and press
the push button and slide the seat horizontally into the
mounting plate until the click sound is heard (FIGURE 5).
To detach seat: Press button and lift unit up and forward.
FIGURE 5
4
Push Button
Slide seat towards
Note: mark on the mounting plate shall point toward back
of toilet.
For full instructions please visit our website www.foremostcanada.com /
www.foremostbath.com OR Scan QR Code.

page 8/14
STEP-BY-STEP ILLUSTRATED
OPERATING MANUAL/INSTALLATION STEPS
Massa Intelligent Bidet Seat
FOREMOST GROUPS INC. (U.S.A.): 6241 Northwind Parkway, Hobart, IN, USA 46342 - 1-888-620-3667 www.foremostbath.com
OCTOBER 2020
INSTALLATION STEPS
FIGURE 6
7CONNECTING THE T-VALVE
Connect the T-valve to the toilet water tank (fill valve shank)
then connect the seat water supply hose to the T-valve and
to the filter inlet on the smart toilet seat (FIGURE 7).
Finally connect toilet water supply hose (not included) to
FIGURE 7
6
Toilet water
supply hose
WATER SUPPLY
water supply hose from the bottom of toilet tank (FIGURE 6).
Seat water supply hose
Toilet water suppy hose
8PLUG THE GFCI POWER PLUG
Plug the GFCI power plug to the wall grounded outlet and start to enjoy the Smart Toilet Seat.

page 9/14
STEP-BY-STEP ILLUSTRATED
OPERATING MANUAL/INSTALLATION STEPS
Massa Intelligent Bidet Seat
FOREMOST GROUPS INC. (U.S.A.): 6241 Northwind Parkway, Hobart, IN, USA 46342 - 1-888-620-3667 www.foremostbath.com
OCTOBER 2020
OPERATION & FUNCTIONS
The Smart toilet seat automatically turns on when it senses body weight being applied to the seat ring. The wash functions and warm
air function will not work unless the body sensor on the seat ring detects body weight.
• The water is sprayed from the nozzle to wash
the posterior area.
• Pressing the button again will change the
mode into oscillating cleaning and expand the
spray range.
• The water is sprayed from the nozzle to wash
the feminine area.
• Pressing the button again will change the
mode into oscillating cleaning and expand the
spray range.
• The UV sterilizing lamp cannot be
controlled.
• Automatically runs 20 seconds after the
when the cleaning function is used again.
• Stops all washing and drying
function currently running. • Adjusts water pressure.
• To Activate: Press “+” or “-” to increase or
decrease water pressure.
• *Nozzle position can move back and
forth by 5 gears.
+
DRY
WASH DRY
UV
STERILIZATION
FEMININE
POSTERIOR
SPRAY INTENSITY
NOZZLE POSITION
ON OFF
/
/
DRY
TEMP.
SEAT
TEMP.
WATER
TEMP.
LIGHTING MASSAGE
+
H L
STOP
POSTERIOR FEMININE UV STERILIZATION
ON/OFF STOP SPRAY INTENSITY NOZZLE POSITION

DRY
WASH DRY
UV
STERILIZATION
FEMININE
POSTERIOR
SPRAY INTENSITY
NOZZLE POSITION
ON OFF
/
/
DRY
TEMP.
SEAT
TEMP.
WATER
TEMP.
LIGHTING MASSAGE
+
H L
page 10/14
STEP-BY-STEP ILLUSTRATED
OPERATING MANUAL/INSTALLATION STEPS
Massa Intelligent Bidet Seat
FOREMOST GROUPS INC. (U.S.A.): 6241 Northwind Parkway, Hobart, IN, USA 46342 - 1-888-620-3667 www.foremostbath.com
OCTOBER 2020
OPERATION & FUNCTIONS
Dry
• Press to start the posterior wash for 90
seconds, then dry for 4 minutes.
• If pressed again during 90 seconds, it will skip
to drying function.
• While washing, press the button to start the
cycle of cold and warm water.
• Only available when the “POSTERIOR” or
“FEMININE” wasvh function has started.
• Press again to stop the massage.
• Press to dry the front and rear areas.
• Switch the display of [LOW], [MED], [HIGH], [OFF].
• Stops automatically after 4 minutes.
• Shows the current temperature when pressed
once.
• Press again to change the temperature.
• Default temperature is MEDIUM.
• Switch the display to [LOW], [MED], [HIGH],
[OFF].
To restore to factory settings:
• If there is a confusion (higher water temperature, lower seat temperature, weaker spray strength) while using,
please unplug the seat for 1 minute, then reconnect it. The water temperature, seat temperature, drying temp.
and spray strength, nozzle position will restore to middle level settings.
STOP
WATER
TEMP.
SEAT
TEMP.
• Shows the current temperature when pressed
once.
• Press again to change the temperature.
• Default temperature is MEDIUM.
• Switch the display to [LOW], [MED], [HIGH],
[OFF].
• Shows the current temperature when pressed
once.
• Press again to change the temperature.
• Default temperature is MEDIUM.
• Switch the display to [LOW], [MED], [HIGH],
[OFF].
DRY
TEMP.
WASH/DRY
MASSAGE
DRY
LIGHTING
WATER TEMP. SEAT TEMP. DRY TEMP.

page 11/14
STEP-BY-STEP ILLUSTRATED
OPERATING MANUAL/INSTALLATION STEPS
Massa Intelligent Bidet Seat
FOREMOST GROUPS INC. (U.S.A.): 6241 Northwind Parkway, Hobart, IN, USA 46342 - 1-888-620-3667 www.foremostbath.com
OCTOBER 2020
MAINTENANCE
Daily cleaning precautions
Please do not spray water into the product.
When cleaning the toilet bowl keep the seat open after cleaning.
Clean it carefully, do not leave the cleaning agent in the gap between the cover and the ceramic.
CLEANING STEPS
Unplug the power (FIGURE 8).
FIGURE 8
1
CLEANING THE BODY
Cleaning the body: Regularly wipe the seat with a dry cloth or sponge, or wash with
a damp cloth and mild detergent (FIGURE 9).
Note: In order to protect the unit, ony use mild, non abrasive cleansers.
FIGURE 9
2
Test
Light
Reset button
110V

page 12/14
STEP-BY-STEP ILLUSTRATED
OPERATING MANUAL/INSTALLATION STEPS
Massa Intelligent Bidet Seat
FOREMOST GROUPS INC. (U.S.A.): 6241 Northwind Parkway, Hobart, IN, USA 46342 - 1-888-620-3667 www.foremostbath.com
OCTOBER 2020
MAINTENANCE OF THE STEEL MASH FILTER
Turn the coin counterclockwise to open the filter and clean with a brush
(FIGURE 10).
FIGURE 10
3
MAINTENANCE OF THE NOZZLE
In the non-working state, hold “water temperature” for 3 seconds to open the nozzle
cleaning mode, you can use a soft brush for cleaning.
Press the “stop” button to end this function.
Do not try to pull the nozzle out forcefully, or the nozzle may break (FIGURE 11).
FIGURE 11
4
toothbrush
filter
toothbrush
nozzle

page 13/14
Try these trouble shooting solutions if you run into issues, or please contact our Customer Service Department.
TROUBLESHOOTING
Type Problem Factors to check
Toilet is not working
Blackout or loose socket
Electric leakage
Check the power cord is plugged in
No water in the supply
Water hose is twisted
Water does no spray
Water pressure is weak
Water is not warm
Water is leaking
Wash function does not
activate
Dryer is not warm
Seat temp. not warm
Lid or seat closes fast
Functions cycles nonstop
Water level is set to LOW
Operational failure
Water temp. is set to LOW
Parts are loose or damaged
The body sensor can't detect your sitting down.
Body sensor is broken
Dryer temp. is set to OFF
Dryer is broken
Dryer will stop for every 4 minute
Seat temp. is set to OFF
Power-saving mode on
Damper is damaged
QA testing model activated
Unplug power cord, re-connect, then power on. If it is still not working,
please unplug again and contact us.
Wait for the water to restore to its normal level
Turn on the water supply valve
Stretch hose until it becomes untwisted
Turn up the water level to a higher setting
Unplug device and re-plug in after 1 minute.
Turn up the water level to higher setting
Contact us
Contact us
Contact us
Contact us
Adjust your sitting position so that the body sensor can be fully
activated.
Turn up the dryer temperature to a higher setting
Enable dryer again
Turn up the seat temperature to a higher setting
Unplug device and re-plug in after 1 minute to reset the functions
Dryer stops during use

page 14/14
FUNCTIONS OF PRODUCTS
Category Function BTS-1005E-W
Cleaning
Comfort
Convenience
Safety and environment
protection
Rear cleansing
Front cleaning
Mobile cleaning
One Touch cleaning (Wash/Dry)
Self-cleaning of nozzle
Warm and cold massage cleaning
Water temperature regulating
Water pressure regulating
Warm air drying
Seat heating
Slow close
Nozzle position adjustment
Variable frequency instant heating
Intelligent body sensor
Power saving function
Operating mode
Soft light at night
Self diagnosis
Antibacterial seat
Antibacterial nozzle
Eight-fold security protection
Medical ultraviolet sterilization
Prevent sewage from pouring back
Side control panel operation
Remarks: signifies that the product has this function.
FOREMOST GROUPS INC.
6241 Northwind Parkway, Hobart, IN, USA 46342 -
1-888-620-3667 www.foremostbath.com
Please read this product manual carefully before installation and use. Save these instructions.
